Designed to do more

EPIQ Elite premium ultrasound for Ob/Gyn

EPIQ Elite for obstetrics and gynecology

2

A new class of EPIQ Elite premium ultrasound has arrived

3

EPIQ Elite for Ob/Gyn meets the needs of today's most demanding practices through:

• Powerful image processing
• Efficient workflow
• System intelligence

Diagnostic confidence, earlier and easier

Be certain and decisive with Philips premium-quality imaging.

4

Made for you

With optimized workflow, you can spend more time caring for your patients.

Your partner today and tomorrow

High-impact diagnoses require a trusted partner that brings you closer to your patients.

Designed for life

Our solutions are designed to give your patients peace of mind by giving you more information earlier in pregnancy and making it easier to make a confident diagnosis.

5

Amazing processing power

Our most powerful architecture

nSIGHT Imaging far surpasses conventional ultrasound performance to reach new levels of definition and clarity. Incorporating a custom multi-stage precision beamformer along with massive parallel processing, this proprietary architecture captures an enormous amount of acoustic data from each transmit operation and performs digital beam reconstruction along with mathematically optimized focal processing. This creates extraordinary real-time images with exceptional frame rate, uniformity and penetration.

EPIQ Elite processing power

Equivalent to processing 10 DVDs/sec

Processing power of other beam former architectures

Equivalent to processing 2 DVDs/sec

6

nSIGHT Imaging changes the paradigm

Next-generation image processing designed for Ob/Gyn imaging elevates tissue definition

• Superb

conspicuity

• f tissue

textures, interfaces and borders

• Elevated

diagnostic confidence

• n virtually

all patients

• Reduction
• f artifacts

with excellent delineation

• f structural

anatomy

7 Exceptional detail with the V9-2. First-trimester imaging with the V9-2 with FlexVue feature. An expanded view of the fetal spine using the V9-2 and TrueVue.

Philips XRES Pro

MicroFlow Imaging

8

Remarkable sensitivity and detail in assessing blood flow

Fetal bowel with MFI compare Fetal kidney with MFI Fetal bowel with MFI compare Fetal kidney with MFI

Advanced artifact reduction to reveal small vessel anatomy Enhanced image displays such as 2D subtraction Excellent temporal resolution and 2D image quality

MicroFlow Imaging for Ob/Gyn

Detects flow with low volume and low velocity in fetal, placental, uterine and ovarian vasculature

9

• Small vessel perfusion of the lips and nose
• Pericolosal artery
• Perfusion of the fetal liver
• Fetal cardiac and pulmonary vein flow

10

Expand your HD work environment

Superb off-angle viewing for visualization of clinical images throughout the scanning room.

HD MAX uses high-contrast dynamic range and enhanced black levels for subtle delineation of grayscale values.

• 24-inch immersive display
• Meets ACR display standard for

diagnostic imaging brightness levels

• Exceptional fit for the Philips MaxVue

imaging mode

• Supported by a new ergonomic arm

Philips HD MAX display is 40 brighter than OLED technology

%

11

A par

param amount de develo lopment

in transducer technology for Philips. Elevated performance for Doppler

85 85% more

efficient than conventional PZT material Superb penetration and image quality

Conventional (x800) PureWave (x800)

PureWave transducers

Exceptional imaging even on technically difficult patients

PureWave crystals have virtually perfect uniformity for greater bandwidth and twice the efficiency of conventional ceramic

• materials. The result is excellent detail

resolution, superb Doppler sensitivity and exceptional shear wave elastography performance

New generation of PureWave

• C5-1
• C9-2
• V9-2
• C10-3v
• eL18-4
• X6-1

12

PureWave transducers built for Ob/Gyn

Next-generation PureWave

• V9-2 color flow umbilical cord

13

• eL18-4 14 week fetal profile
• eL18-4 spine with Myelomeningocele
• C9-2 early fetal profile
• eL18-4 fetal liver
• C5-1 Lung, heart, liver, bowel and bladder

14

New V9-2 PureWave transducer

Supports additional

Pairing the new V9-2 PureWave transducer with the EPIQ Elite premium ultrasound system

• ffers next-level Ob/Gyn imaging
• First PureWave mechanical volume transducer
• Lightest in its class
• Exceptional ergonomic design
• First, second and third trimester applications

technology

PureWave technology Ergonomic design 3D mechanism re-design

• Broad bandwidth

for clinical versatility

• Superb detail and

contrast resolution with penetration

• Lightest-weight 3D

mechanical transducer among major competitors

• Advanced handle design
• ptimized for all-day use
• Cable optimized

to reduce fatigue

• 2-stage gearbox

for reduced size and weight

• Low vibration

and audible noise

V9-2 PureWave transducer

15

V9-2 PureWave transducer images

• V9-2 early Ob with TrueVue

16

• V9-2 heart and arch of the aorta
• V9-2 fetal kidney
• V9-2 fetal face and hand with TrueVue
• V9-2- fetal lung, heart, liver and bowel
• V9-2 fetal face with TrueVue and flexible light source

17

Discover ultra-diagnostic confidence with the eL18-4 transducer

Ultra broadband technology brings the image quality to a premium level. The Philips eL18-4 ultra broadband transducer provides superb 2D detail resolution, along with the penetration needed to provide diagnostic confidence, especially in those critical first and second trimester OB exams.

The eL18-4 fine-elevation focused linear transducer generates ultra-broadband frequencies from 2 to 22 MHz.

18

Delivers thin-slice elevation focusing capability

The combination of superb detail resolution and penetration is made possible by advanced PureWave crystal technology with fine-elevation focusing capability.

• Multi-row array configuration for full

electronic focusing of the elevation plane

• Elevation focusing works in conjunction

with azimuthal focusing to provide thin-slice imaging Azimuthal focusing Elevation focusing Generates frequencies from 2 to 22 MHz

2 MHz 22 MHz

eL18-4 imaging (2D)

• Myelomeningocele demonstrated

using the eL18-4.

• Fetal profile shown using the eL18-4.
• Imaging with eL18-4 reveals the

fetal spinal cord. 19

• The eL18-4 demonstrates the

fetal patella.

• Fetal brain as shown by the eL18-4.
• Fetal kidney detail demonstrated

using the eL18-4.

20

Overcome imaging challenges

xMATRIX* is our most leading-edge and versatile ultrasound transducer technology. No other premium ultrasound system can run the complete suite of Philips most innovative ultrasound transducers. With the touch of a button, xMATRIX offers all modes in a single transducer: 2D, 3D/4D, Live xPlane, Live MPR, MPR, pulsed wave Doppler, color Doppler and CPA.

* xMATRIX is available on EPIQ Elite advanced and as an upgrade path on EPIQ Elite.

21

The Philips OB solution for earlier diagnosis

Image quality

Philips eL18-4 transducer with MicroFlow Imaging and V9-2 transducer offer outstanding imaging quality for evaluating fetal anatomy. Leading-edge image quality and ergonomics speed confident fetal health assessments.

Lifelike imaging

TrueVue, with its internal light source, provides innovative 3D/4D imaging that outperforms traditional rendering algorithms, allowing for highly detailed images of the fetus.

Efficient workflow

aBiometry AssistA.I. combined with SmartExam uses Anatomical Intelligence to automate fetal

• measurements. TouchVue and MPR Touch provides an easier, more intuitive method of 3D

workflow using simple finger gestures to control 3D volumes and MPR parameters. FlexVue is a highly versatile tool that allows visualization of technically difficult anatomical views from 3D volumes that are essential for diagnosis.

Optimize 3D/4D workflow with TrueVue

22

Bring clinicians closer to their Ob/Gyn patients with “lifelike” TrueVue 3D imaging display with the intuitive TouchVue 3D volume workflow. The combination of TrueVue and TouchVue are features designed to assist in both the maternal-fetal bonding and doctor-patient communication process. Real life, illuminated

Philips TrueVue virtual light source can be placed anywhere within the acquired 3D volume, allowing manipulation of light and shadow on anatomical structures to enhance clinical confidence and promote maternal-fetal bonding.

Light source, umbilical cord Light source, upper right Light source, lower left Light source, lower right

TrueVue and GlassVue

23

Optimize 3D/4D workflow

24

• TouchVue and MPR Touch are

easier, more intuitive methods

• f 3D workflow
• Simple finger gestures on touch

panel allow you to control 3D volume rotation in all axes

• Control size and position of

MPR parameters in all views

• Position internal light source

in all axes

MPR Touch finger gestures

25

• ROI box panning
• ROI box resizing
• Active view selection
• Crosshair movement
• ROI box trimming

Visualize the challenging with ease

26

FlexVue

You need the ability to quickly visualize orthogonal planes within 3D volumes. FlexVue is a highly versatile tool that allows easy visualization of technically difficult anatomical views from the 3D volumes that are essential for diagnosis of Ob/Gyn pathology.

• Curved MPR allows curved anatomy on an MPR to be “displayed flat” in a projected view

Easily evaluate even curved anatomy

27

FlexVue displays structures in their entirely in a projected view.

• Easily evaluate even curved anatomy in a wide variety of orthogonal planes of section

FlexVue feature demonstrating curved MPR reconstruction of fetal spine anatomy. Uterus with IUD

Anatomical Intelligence Ultrasound for Ob/Gyn

28

Anatomical Intelligence for Ultrasound (AIUS) is designed to elevate the ultrasound system with advanced organ modeling, image slicing and proven quantification. Exams are easier to perform, more reproducible and deliver new levels of clinical information.

Before aRevealA.I. After aRevealA.I. applied

aRevealA.I.

29

aRevealA.I. is an advanced feature of Philips Anatomical Intelligence for Ultrasound (AIUS) that removes extraneous information to quickly and easily reveal the fetal face.

aBiometry AssistA.I

30

• Virtually all obstetrical ultrasound examinations

include standardized measurements of fetal biometry to assess fetal age and growth trends

• Philips aBiometry AssistA.I. utilizes anatomical

intelligence technology to assist measurements

• f the most commonly used fetal biometry

parameters BPD, OFD, HC, AC, and FL

• aBiometry AssistA.I. allows for a reduction

in measurement steps and time -savings over conventional manual measurement methods

• Measurements generated by aBiometry AssistA.I.

are editable and automatically transfer to

• bstetrical reports

aBiometry AssistA.I. default

EPIQ has completely reinvented the premium ultrasound user experience. Ease of use, workflow, ergonomics, portability – we’ve revolutionized how you interact with an ultrasound system from every standpoint.

Streamlined workflow

The EPIQ tablet-like interface results in 40% to 80% less reach and 15% fewer steps.1 SmartExam decreases exam time by 30-50%, keystrokes by as many as 300 per exam.2 Auto Doppler takes 10 steps to 3 steps and reduces the number

• f button pushes by

an average of 68%.3

31

• 1. 2013 engineering study comparing EPIQ with Philips iU22 ultrasound system.
• 2. University of Colorado, Protocols Study, April 2007.
• 3. Auto Doppler clinical study, December 2011.

32

Powerful system security protects sensitive patient data

Protect your patients

Philips defense-in-depth strategy

33

Source: Gallagher L. Presentation. 2012 Boston Privacy and Security Forum.

Always there,

always on

• Remote service capabilities
• Proactive monitoring

solutions to maximize uptime

• Immediate support request

at your fingertips

• On-cart transducer tests

Sharing risk,

increasing the return on your investment

Business optimization tools such as OmniSphere harness the power of data and connectivity to generate actionable insights and enhance productivity

Understanding your needs,

• Flexible RightFit service agreements
• Technology Maximizer Program keeps

your system performing at its peak

• Xtend Service Coverage to more easily

calculate your total cost of ownership

designed for you
