Design Patterns for modular services, drivers and user land Bernd Onasch dieCobol.de GmbH 2016-02-01 MINIXCON 2016 Amsterdam Abstract While porting MINIX to specific hardware the requirement of highly modular services and drivers became

slide-1
SLIDE 1

Design Patterns for modular services, drivers and user land

Bernd Onasch dieCobol.de GmbH 2016-02-01 MINIXCON 2016 Amsterdam

slide-2
SLIDE 2

2016-02-01 MINIXCON 2016 - Bernd Onasch – dieCobol.de GmbH 2

Abstract

While porting MINIX to specific hardware the requirement of highly modular services and drivers became apparent. We need standardized MINIX micro- kernel compliant interfaces on service and driver level to be able to add new hardware components like network cards or complete new platforms. A generalized approach of "starting MINIX up" which is as independent as possible from hardware and boot device will additionally help making new hardware supportable. Using a highly modular approach will allow MINIX to reach out to many platforms so far unsupported.

slide-3
SLIDE 3

2016-02-01 MINIXCON 2016 - Bernd Onasch – dieCobol.de GmbH 3

Boot Process

➢MINIX boot process (1) … (3) ➢Modularized booting? (4) ➢Dynamic booting? (5)

slide-4
SLIDE 4

2016-02-01 MINIXCON 2016 - Bernd Onasch – dieCobol.de GmbH 4

MINIX boot process (1)

Hardware

BIOS Devices Boot Device Boot Loader KERNEL module SERVICE modules RAMDISK module INIT module rc Scripts

Login Shell System Bus Additional Services System Devices System Processes

Current status of booting MINIX

slide-5
SLIDE 5

2016-02-01 MINIXCON 2016 - Bernd Onasch – dieCobol.de GmbH 5

Boot process (2)

We are aiming for a generalized booting process

(1)Hardware and BIOS

  • BIOS provides hardware support, e.g. USB
  • BIOS initiates boot loader (block device or network)

(2)BIOS and boot loader interaction

  • Modern BIOS and boot loader share functionality
  • Boot loader is parametrized to know target OS specifics

(3)Boot loader and kernel interaction

  • Stage the loaded kernel for 32/64 bit mode and graphics

mode

What does the KERNEL really need to start? How much more does the Developer want to have?

slide-6
SLIDE 6

2016-02-01 MINIXCON 2016 - Bernd Onasch – dieCobol.de GmbH 6

MINIX boot process (3)

Starting MINIX kernel and core services

  • Micro-kernel initializing
  • Hand-over from boot loader (multiboot data record)
  • Core service startup (modules loaded by boot loader)

– Virtual memory, ProcessMgr, Scheduler, Reincarnation, …

  • RAMdisk available to INIT process
  • Initial system bus (PCI) validation
  • Initialisation based on pre-defined RAMdisk scripts

„Hen-and-egg”-Problem

  • Mass storage and file system are present after INIT
  • Requirement for core services, buses and drivers before
slide-7
SLIDE 7

2016-02-01 MINIXCON 2016 - Bernd Onasch – dieCobol.de GmbH 7

Modularized booting?

Ideas

  • Any boot loader loads MINIX, core services, initial ramdisk
  • Current status: Multiboot v1 compliant boot loader
  • Thin separation of MINIX kernel and boot headers
  • Current status: Multiboot data handled by kernel
  • Idea: Separate „boot data handling” and kernel
  • Join core services into one module to simplify loading
  • Current status: Many separate modules, issue for e.g. iPXE/PXE
  • Idea: Use one module with offset table
  • RAMdisk provides drivers to mount mass storage
  • Current status: PCI and pre-selected drivers
  • Idea: Dynamic bus/device loading incl. PCI and USB
  • Idea: Identical scripts in INIT ramdisk and later mounted disk

Suggested changes

slide-8
SLIDE 8

2016-02-01 MINIXCON 2016 - Bernd Onasch – dieCobol.de GmbH 8

Container Container

Dynamic booting?

Hardware

BIOS Devices Boot Device Boot Loader KERNEL module CORE SERVICES RAMDISK INIT module rc Scripts

Web Server System Bus System Processes Devices & Buses Device Broker Service SSH Demon Login Shell

Dynamic Detection

Suggested way of booting MINIX

Container module Container module

slide-9
SLIDE 9

2016-02-01 MINIXCON 2016 - Bernd Onasch – dieCobol.de GmbH 9

Privilege Modes

➢Monolithic system design (1) ➢Modular system design (2)

slide-10
SLIDE 10

2016-02-01 MINIXCON 2016 - Bernd Onasch – dieCobol.de GmbH 10

Privilege Modes (1)

Supervisor Mode

  • Unrestricted hardware access
  • Free physical memory access
  • Any CPU instruction

User Mode

  • No direct access to hardware
  • No direct access to physical

memory

  • Virtual memory isolation
  • System API restricts hardware

access

  • System API controls phyiscal

memory access kernel services (e.g. Scheduler) System processes Device drivers User processes user mode supervisor mode Monolithic kernel Virtual device drivers

slide-11
SLIDE 11

2016-02-01 MINIXCON 2016 - Bernd Onasch – dieCobol.de GmbH 11

Privilege Modes (2)

Micro-kernel design

  • Very small supervisor mode
  • Additional protection layers

MINIX service design

  • Core services with kernel

communication

  • Virtual Memory Service
  • Scheduler and Process Mgr.
  • Reincarnation Service
  • Support services with messages
  • System TTY console
  • Device Manager
  • Device drivers with messages
  • PCI, SATA, etc.
  • User processes with system API

MINIX micro-kernel MINIX core services Support services System processes Device/Bus drivers User processes supervisor mode restricted mode user mode kernel access mode message access mode

slide-12
SLIDE 12

2016-02-01 MINIXCON 2016 - Bernd Onasch – dieCobol.de GmbH 12

Bus/Device Concept

➢Generic view on devices (1) … (3) ➢Separation of concerns (4)

slide-13
SLIDE 13

2016-02-01 MINIXCON 2016 - Bernd Onasch – dieCobol.de GmbH 13

Generic view on devices (1)

Ideas

  • Separation of components
  • Hardware handshake (classic driver)
  • Required communication protocol and functionality
  • Keep layered devices separated
  • Bus as interface and middle layer
  • Bus provides enumeration of devices
  • Layered device communicate via the bus interface
  • Device management „broker”
  • Devices and Buses register themselves
  • Usage is requested via the broker

Suggested changes

slide-14
SLIDE 14

2016-02-01 MINIXCON 2016 - Bernd Onasch – dieCobol.de GmbH 14

Generic view on devices (2)

Example

  • Device Broker as

managing service

  • Initial System Bus, e.g.

PCI

  • Drivers providing

hardware handshake

  • Buses providing protocol

and functionality layer

  • Every Bus or Driver

instance registers at the Device Broker

Device Broker PCI

System Bus

xHCI

USB HC

USB

Generic Bus

Keyboad

USB Driver

Mouse

USB Driver

SATA

Controller

SATA

Protocol Bus

HDD

Device Driver

BlockDev

Virtual Bus

MinixFS

Virtual Driver

EXT2

Virtual Driver

Suggested changes

slide-15
SLIDE 15

2016-02-01 MINIXCON 2016 - Bernd Onasch – dieCobol.de GmbH 15

Generic view on devices (3)

Benefits

  • New hardware relies upon existing interfaces
  • e.g. Keyboard/Mouse on USB share common code

with system bus equivalent

  • e.g. any disk on USB or SATA or Network share

same code via „block device bus”

  • Smaller implementation risks on adding new devices
  • Existing and tested functionality code will be used
  • Less effort on introducting new bus systems
  • Providing a shared interface allows plugin of

existing devices Suggested changes

slide-16
SLIDE 16

2016-02-01 MINIXCON 2016 - Bernd Onasch – dieCobol.de GmbH 16

Separation of concerns

Expected modular (service oriented) design

  • New drivers provide clear and common interfaces
  • Bus systems provide common interfaces
  • Interfaces are generic for device types
  • e.g. all block devices provide the same interface
  • Device driver does not care for later use of I/O data
  • i.e. implements hardware handshake only
  • Virtual driver does not access hardware directly
  • i.e. implements protocol and/or functionality
slide-17
SLIDE 17

2016-02-01 MINIXCON 2016 - Bernd Onasch – dieCobol.de GmbH 17

Thank you for listening.

Contact: Bernd Onasch dieCobol.de GmbH Karlsruhe, Germany bernd.onasch@diecobol.de

slide-18
SLIDE 18

2016-02-01 MINIXCON 2016 - Bernd Onasch – dieCobol.de GmbH 18

Additional Slides

➢Glossary ➢References

slide-19
SLIDE 19

2016-02-01 MINIXCON 2016 - Bernd Onasch – dieCobol.de GmbH 19

Glossary

KERNEL

  • Exclusively the MINIX kernel module

SYSTEM CORE

  • MINIX kernel module and core services

CORE SERVICE

  • Mandatory service on system boot
  • Service required to have the system running

SERVICE

  • Privileged process providing a service to the userland
  • Service process can be „reincarnated”

DEVICE

  • Privileged process interfacing a hardware component

BUS

  • Privileged process communicating with device(s) and providing a bus structure
slide-20
SLIDE 20

2016-02-01 MINIXCON 2016 - Bernd Onasch – dieCobol.de GmbH 20

References

Boot Process http://wiki.minix3.org/doku.php?id=developersguide:frompowerontologinprompt ftp://download.intel.com/design/archives/wfm/downloads/pxespec.pdf http://ipxe.org/docs Privilege Modes https://en.wikipedia.org/wiki/Protection_ring http://www.linfo.org/kernel_mode.html Bus/Device Concept http://git.minix3.org/index.cgi?p=minix.git;a=summary (Status from 2016-01-12) http://www.intel.com/content/dam/www/public/us/en/documents/technical-specification s/extensible-host-controler-interface-usb-xhci.pdf etc.
