Design & Construction Considerations When Lining CMP Pipe-Arches Hugh B. Mickel, P.E. www.ContechES.com Design Methods for Lining and Sliplining Round Pipes are Usually Straightforward www.ContechES.com Construction Methods for Lining and
SLIDE 2
SLIDE 3
www.ContechES.com
Construction Methods for Lining and Sliplining Round Pipes are Usually Straightforward
SLIDE 4
www.ContechES.com
What About Pipe-Arches?
SLIDE 5
www.ContechES.com
- Design
Challenges
- Construction
Challenges
- Pipe-Arch
Case Studies
Today’s Focus Areas:
SLIDE 6
www.ContechES.com
Fit/Geometry is the 1st Major Hurdle
6
SLIDE 7
www.ContechES.com
7
Pipe-Arch Dimensions: it’s much more than just span & rise
SLIDE 8
www.ContechES.com
…Pipe-Arch History…
8
From 1958 Handbook:
SLIDE 9
www.ContechES.com
- Early dimensions and tolerances varied by manufacturer.
- AASHTO M-36 and present day equipment provides
greater consistencies among manufacturers.
For More Pipe-Arch History:
SLIDE 10
www.ContechES.com
1
Structural Plate Pipe-Arches are in 2 Size Groupings:
- 18” Corner Radius
(shown)
- 31” Corner Radius
SLIDE 11
www.ContechES.com
1
SLIDE 12
www.ContechES.com
1
What size is this structural plate pipe-arch? Count the spaces around the perimeter
SLIDE 13
www.ContechES.com
The best method for determining available space: 3D Laser Scanning
SLIDE 14
www.ContechES.com
1
Structural Design of Pipe-Arches is Different Compared to Round Pipe
SLIDE 15
www.ContechES.com
Soil Arching
How do you know it’s present? Where is it occurring? What can make it shift? What can negate it?
SLIDE 16
www.ContechES.com
How do you know it’s present? Where is it occurring? What can make it shift? What can negate it?
Soil Arching
SLIDE 17
www.ContechES.com
When Can a Reduced Load Be Used?
- For Rigid Pipes
- Possibly when installation records show an induced, zero projecting
- r negative projecting trench installation
- For Flexible Pipes
- Only if original soil arch is in place (recent movements negate it)
- Installation records are detailed, including deflection at the time of
acceptance
- Current and full soils investigation shows backfill and prism properties
are favorable, and there are no inconsistent areas indicating future consolidation or movements might occur
- Groundwater migration isn’t possible
SLIDE 18
www.ContechES.com
1
(See this paper for more information)
SLIDE 19
www.ContechES.com
- Designing Outside the Limits of AASHTO & ASTM Standards is Risky
- Examine the strength of freezing water left behind in the corrugations.
SLIDE 20
www.ContechES.com
2
2017 ODOT Project in Brown County
SLIDE 21
www.ContechES.com
2
2017 ODOT Project in Brown County
SLIDE 22
www.ContechES.com
2
2017 ODOT Project in Brown County
Type equation here.
Color Key: Built / Attempted / Existing
SLIDE 23
www.ContechES.com
2
126 pi MPPA 135pi didn’t fit
Layover of Original & Attempted, Drawn to Design Shapes :
SLIDE 24
www.ContechES.com
2
123 pi into 135 pi
Resubmitted a 123 pi MPPA with an improved hydraulic inlet
SLIDE 25
www.ContechES.com
2
New Structure with Improved Inlet and Paved Invert
SLIDE 26
www.ContechES.com
Lessons Learned
- 1. Get a 3D Laser Profile if possible, or
- 2. Provide detailed field measurements in plans
- 3. Assess possibility of movements between Scoping
and Construction
- 4. Engage us early (we have lots of knowledge)
2
SLIDE 27
www.ContechES.com
2
2017 ODOT Project in Highland County
SLIDE 28
www.ContechES.com
2
Tunnel Liner Plate with Paved Invert
SLIDE 29
www.ContechES.com
Under I-91 in Connecticut
- ADT: 57,000 vehicles per day
- Abrasion Level 3 site
- 22’ of fill
- Active movement
1964 MPPA – 8’-10” Span x 6’-1” Rise
SLIDE 30
www.ContechES.com
Corrosion and Invert Wall Buckling
SLIDE 31
www.ContechES.com
3D Laser Survey
SLIDE 32
www.ContechES.com
Laser scan sections
SLIDE 33
www.ContechES.com
Controlled Invert Removal Limits
SLIDE 34
www.ContechES.com
Bracing the Host Structure
SLIDE 35
www.ContechES.com
Aluminum Tunnel Liner Plate
- builds safe working environment as you go
- allows for partial & full tunneling with assembly done from the inside
SLIDE 36
www.ContechES.com
Construction
SLIDE 37
www.ContechES.com
Don’t Forget the Hydraulics
- Inlet Control vs. Outlet
Control - the governing mode is the one that produces the highest Headwater Depth (inlet end)
- HY8 v 7.50 software by
FHWA
It’s a free download at: http://www.fhwa.dot.gov/engineering /hydraulics/software/hy8/
