Depot

Maciej Smolenski

19 January 2011

Introduction

2 / 36

Introduction

Depot

Introduction 3 / 36

Cloud storage system.

• Cloud storage: in the spirit of S3, Azure, Google

Storage.

• Depot clients do not have to trust that servers
• perate correctly.

Untrusted Storage Service Providers

Introduction 4 / 36

• Software bugs.
• Misconfigured servers or operator errors.
• Malicious insiders.
• Acts of God or Man (e.g. fires).

Providing trust guarantees will help both Clients and Storage Service Providers (SSPs).

Depot Consistency

Introduction 5 / 36

Depot ensures that the updates observed by correct nodes are consistently ordered under Fork-Join- Causal consistency (FJC). FJC is a slight weakening of causal consistency that can be both safe and live despite faulty nodes.

Depot Guarantees

Introduction 6 / 36

Depot implements protocols are based on FJC updates ordering. Depot provides guarentees for:

• Consistency
• Availability
• Durability
• Staleness
• Latency

Depot provides these guarantees with low overhead.

Consistency

7 / 36

Consistency

Consistency Types

Consistency 8 / 36

• Sequential Consistency
• Causal Consistency
• Fork Consistency
• Fork Join Consistency
• Fork Join Causal Consistency

Sequential Consistency

Consistency 9 / 36

updating (events): n1: ------------------------<n1_u1>-------- n2: ------------------------<n2_u1>-------- n3: ---<n3_u1>-----------------------------

• rdering:

n1,n2,n3: (n3_u1) (n2_u1) (n1_u1)

• r

n1,n2,n3: (n3_u1) (n1_u1) (n2_u1)

• Events are order linearly (totally).
• Conflicts resolution: no conflicts.

Causal Consistency

Consistency 10 / 36

updating (events): n1: ------------------------<n1_u1>-------- n2: ------------------------<n2_u1>-------- n3: ---<n3_u1>-----------------------------

• rdering:

n1: (n3_u1) (n1_u1) (n2_u1) n2: (n3_u1) (n2_u1) (n1_u1) n3: (n3_u1) (n1_u1) (n2_u1)

• r:

(n3_u1) (n2_u1) (n1_u1)

• Events are order causally.
• Conflicts resolution: merge (application-specific).

Fork Consistency

Consistency 11 / 36

Server orders events sequentially (correct server).

updating (events): c1: -<c1_u1>----------------------------------<c1_u2>----------------------------------- c2: ---------------------<c2_u1>--------------------------------------<c2_u2>-----------

• rdering:

s: (c1_u1) (c2_u1) (c1_u2) (c2_u2) c1: (c1_u1) (c2_u1) (c1_u2) (c2_u2) c2: (c1_u1) (c2_u1) (c1_u2) (c2_u2)

• Events are order totally
• Conflicts resolution: no conflicts.

Fork Consistency (Continued)

Consistency 12 / 36

Faulty server (can't modify data - just forks).

updating: c1: -<c1_u1>----------------------------------<c1_u2>----------------------------------- c2: --------------------<c2_u1>---------------------------------------<c2_u2>-----------

• rdering:

/--------(c1_u2)------------------------- version for c1 s: -(c1_u1)-------------(c2_u1)-----< \--------------------------------(c2_u2)- version for c2 c1:-(c1_u1)-------------(c2_u1)---------------(c1_u2)----------------------------------- c2:-(c1_u1)-------------(c2_u1)---------------------------------------(c2_u2)-----------

• Server may show different version to different

clients.

• Clients can be sure that they will be partitioned

forever after fork (server misbehaviour detection).

• Conflicts resultion: detection is enaugh.
• Untrasted server (fork is the only way to lie).

Fork Join Consistency

Consistency 13 / 36

Same as Fork Consistency when server is correct. Fork resolution (join) when servers misbehaviour detected.

updating: c1: -<c1_u1>----------------------------------<c1_u2>---------------------------------- c2: ---------------------<c2_u1>--------------------------------------<c2_u2>----------

• rdering:

/--------(c1_u2)---------------------------------- s: -(c1_u1)--------------(c2_u1)----< \--------------------------------(c2_u2)---------- fork seen as concurrent updates to different servers: s1:-(c1_u1)-------------(c2_u1)-------------------------(c1_u2)------------------------- s2:-(c1_u1)-------------(c2_u1)-------------------------(c2_u2)-------------------------

• Events after fork can be seen as concurrent (on

many servers).

• Conflicts resolution: merge (application-specific).

Fork Join Causal Consistency (FJC)

Consistency 14 / 36

• Fork Join Consistency with causal event ordering.
• Forks seen as concurrent operation (conflicts

resolution when needed).

• Conflicts resolution: merge (application-specific).

Weaker then "Sequential Consistency" but for many application still useful. Provides session guarantees for each client.

• Monotonic reads
• Monotonic writes
• Read-your-writes
• Writes-follow-reads

Because of weaker consistency more can be achived

• n the other fields:
• High availability.

Fork Join Causal Consistency (FJC) (Continued)

Consistency 15 / 36

• Untrasted servers.

Depot

16 / 36

Depot

Plan

Depot 17 / 36

Protocol to achive FJC. Extended protocol to create storage system with best guarantees (possible with FJC) for:

• Trust.
• Availability.
• Staleness.
• Durability.
• Integrity and authorization.
• Fault tolerance.
• Data recovery.

Depot - storage system.

Architecture

Depot 18 / 36

Nodes

• Clients.
• Servers.

All nodes run the same protocol. They are just configured differently. Servers can't issue valid updates (standard cryptography techniques). Key-Value store (GET/PUT interface).

Node

Depot 19 / 36

Each node maintains a Log and a Checkpoint:

• Log - current updates.
• Checkpoint - stable system state.

Updates Propagation

Depot 20 / 36

Gossiping (Log exchange)

• Server gossips with other servers regularly

(configuration parameter).

• Client gossips with its primary server regularly

(configuration parameter). Client switches to client- client mode when all servers unavailable.

Update Message

Depot 21 / 36

Extra data:

• Dependency Version Vector (causal ordering).
• History hash (causes that only possible server's

misbehaviour is a fork). Signature.

Conflicts Resolution

Depot 22 / 36

Concurrent updates: application-specific merge. Forks - handled the same way as concurrent updates.

• Application-specific merge.
• Proof Of Misbehaviour (POM).
• I-vouch-for-this certificates.

Replication

Depot 23 / 36

Storing values:

• Owner (client) keeps its value.
• Each value should be replicated on K servers.
• Receipt (prove that value is replicated on K

servers).

High Availability

Depot 24 / 36

Writes: always. Reads: when available.

• Owner's copy (client).
• Replicated on K servers.
• Client accepts updates only when associated with

receipt or value.

Staleness

Depot 25 / 36

Depot guarantees bounded staleness. Each client generates special update regularly (logicaltime). When client A sees this special update from client B then this client can be sure that it has seen all preceeding updates from client B (Fork Consistency). In FC (FJC also) staleness is separated from consistency (flexibility).

Eventual Consistency

Depot 26 / 36

Depot guarantees eventual consistency.

• Safety - successful reads of an object at correct

nodes that observe the same set of updates return the same values.

• Liveness - Any update issued or observed by

a correct node is eventually observeable by all correct nodes.

Evaluation

27 / 36

Evaluation

Method

Evaluation 28 / 36

• 8 Clients 4 Servers
• Server/Server gossiping every second
• Client/Primary Server gossiping every 5 seconds
• Key size: 32B
• Value size: 3B 10KB 1MB
• Read/Write: 0/100 10/90 50/50 90/10 100/0
• Non-overlapping key renges for clients (no

conflicts)

Method (Continued)

Evaluation 29 / 36

Compare versions (only Depot - different configurations)

• B(Baseline)
• B+H(Hash)
• B+H+S(Sign)
• B+H+S+St(Store)
• B+H+S+St(Store)+FJC=Depot

+FJC (fork handling):

• Extra data (history:

storing,checking,hashing,signing,verifying,transfering).

Latency

Evaluation 30 / 36

Overhead

• GET: no
• PUT: extra 40%

Cost

Evaluation 31 / 36

Factors:

• CPU
• Network
• Storage

Overhead

• GET: no
• PUT: extra 40%

Cost (Continued)

Evaluation 32 / 36

Fault: Cloud Disaster

Evaluation 33 / 36

300 seconds into the experiment all servers had been stopped. Clients swiched to client-client mode. Factors:

• Latency
• Staleness

Fault: Claud Disaster (Continued)

Evaluation 34 / 36

Latency Better then before (because client don't gossip with client in GET - as it does with server).

Fault: Claud Disaster (Continued)

Evaluation 35 / 36

Staleness Worse then before (because client don't gossip with client in GET - as it does with server).

Fault: Fork

Evaluation 36 / 36

Depot handles forks the same way as concurrency.

• No overhead in communication (just POMs and i-

vouch-for-this certificates).

• No overhead in cpu (all the time there is only

correct data in the system - no need to hurry).
