Dependability Modelling and Assessment of Avionics Systems with Altarica. P. Bieber, Ch. Castel, G. Durrieu, Ch. Seguin, C. Pagetti, L. Sagaspe 1 General Problem Avionics are complex systems A380 (safety critical avionics): +100

slide-1
SLIDE 1

1

Dependability Modelling and Assessment

  • f Avionics Systems with Altarica.
  • P. Bieber, Ch. Castel, G. Durrieu, Ch. Seguin, C. Pagetti, L. Sagaspe
slide-2
SLIDE 2

2

General Problem

  • Avionics are complex systems

– A380 (safety critical avionics):

  • +100 computers connected to the main Aicraft network,
  • ~10 000 data flows transmitted over the network
  • Structured Design

– Modular design

  • Systems : Flight Control, Flight Management, Flight parameters, …

– Layered design

  • functional architecture/allocation/ hardware architecture
  • Complex Design Process

– Several actors:

  • System designers -> functional architecture
  • Platform designers -> hardware architecture
  • Integrator -> allocation
slide-3
SLIDE 3

3

General Goal

  • Support the safety assessment of avionics systems

– using Altarica models – and taking into account the current design process

  • Apply the approach on case-studies

– Dassault Mirage Terrain Following/Terrain Avoidance – Airbus systems (ADIRS, Fuel On Board,…) – Astrium ATV (Automatic Transfer Vehicle)

slide-4
SLIDE 4

4

Overview

  • Avionics Platform Design

– Functional and hardware description – Allocation

  • Safe Resource Allocation Process

– Failure Propagation Modelling – Safety Requirements Validation – Independence requirement derivation

  • Advanced Topics

– Allocation Generation by Constraint Solving – Installation related risks – Automatical production of Altarica models – Middleware Modelling

slide-5
SLIDE 5

5

Functional Architecture

  • Function and Data flows

– ADIRU: x3 – SEC: x6 – VL : x18

ADIRU SEC VL

slide-6
SLIDE 6

6

Hardware Architecture

Interconnected resources

– Bus, Switch, CPU, …

slide-7
SLIDE 7

7

Allocation

  • Described as tables

– well formalized at detailed design stages – but often missing at earlier design stages

VL_ADIRU1_SEC3A : ADIRU_Hard_1,AFDX_SW- 1,AFDX_SW-1,AFDX_SW- 9,SEC3A

slide-8
SLIDE 8

8

Overview

  • Avionics Platform Design

– Functional and hardware description – Allocation

  • Safe Resource Allocation Process

– Failure Propagation Modelling – Safety Requirements Validation – Independence requirement derivation

  • Advanced Topics

– Allocation Generation by Constraint Solving – Installation related risks – Automatical production of Altarica models – Middleware Modelling

slide-9
SLIDE 9

9

Functional Architecture Safety Model

  • Failure Propagation Model built using

predefined nodes in an Altarica Library

  • Qualitative Safety Requirement:

– « No double failure of dataflows between ADIRU and SEC shall cause the loss of all SEC functions » – « No double failure of dataflows between ADIRU and SEC shall cause the undetected erroneous behaviour of all SEC functions »

slide-10
SLIDE 10

10

Safety Requirement Assessment

  • Automatic Generation of the fault-tree from the model

– Generation of minimal cut sets – Computation of probabilities

3.0 e-24 2.0 e-24 Proba 9720 8000 Total 8 9 216 8 972 1944 7 8748 5832 6 5 4 3 2 1 Erroneous Loss Size

VL_ADIRU1_ADR_SEC1A.fail_erroneous, VL_ADIRU2_ADR_SEC1A.fail_erroneous VL_ADIRU1_ADR_SEC1B.fail_erroneous VL_ADIRU2_ADR_SEC1B.fail_erroneous VL_ADIRU1_ADR_SEC2A.fail_erroneous VL_ADIRU2_ADR_SEC2A.fail_erroneous

slide-11
SLIDE 11

11

Hardware + Allocation models

  • Hardware model

– very basic model

  • Allocation model

– Common cause failure – Use Broadcast to group failure event of the resource with failure events of all supported functions and data flows

F1 F2 F3 Res

slide-12
SLIDE 12

12

Impact of allocation on Safety requirements

  • Allocation of shared resources to functions and data-

flows creates Common Mode Failures.

  • Compare before/after allocation:
  • Decrease size of minimal cut sets,
  • increase probability of FC occurrence
  • Is this impact acceptable ?

VL_ADIRU1_ADR_SEC1A.fail_erroneous, VL_ADIRU2_ADR_SEC1A.fail_erroneous VL_ADIRU1_ADR_SEC1B.fail_erroneous VL_ADIRU2_ADR_SEC1B.fail_erroneous VL_ADIRU1_ADR_SEC2A.fail_erroneous VL_ADIRU2_ADR_SEC2A.fail_erroneous

Allocate

(SEC1A,1B connected to Switch1, SEC2A connected to Switch2) Switch1.fail_erroneous Switch2.fail_erroneous

slide-13
SLIDE 13

13

Derivation of Segregation Requirements

  • Extract segregation requirements from the safety assessment

results in order to avoid allocation common mode failures

Size Minimal Cut Sets Safety Objective 3 Data-flows shall be segregated 3 Data-flows out of 5 shall be segregated

slide-14
SLIDE 14

14

Overview

  • Avionics Platform Design

– Function and architecture description – Allocation

  • Safe Resource Allocation Process

– Failure Propagation Modelling – Safety Requirements Validation – Independence requirement derivation

  • Advanced Topics

– Allocation Generation by Constraint Solving – Installation related risks – Automatical production of Altarica models – Middleware Modelling

slide-15
SLIDE 15

15

Allocation Generation by Constraint Solving

  • Formalisation of allocation constraints

– {0,1} linear inequalities.

  • Variables :

– allotc(task,cpu) : {0,1} – allodb(data,bus) : {0,1} – connected(cpu,bus) or connected(bus,cpu) : {0,1}

  • Inequalities

– Any task has to be allocated to one and only cpu allotc(t,c1) +…+ allotc(t,cn) = 1 – Two segregated tasks should not be allocated to the same cpu

allotc(t1,c) + allotc(t2,c) + segregated(t1,t2) < 2

– A connection (C,B) is used if there exists a data flow D and its producing task T such D is allocated to B and T is allocated to C.

  • Criterion

– Minimise the number of used connections

slide-16
SLIDE 16

16

Tool Support for Constraint Solving

  • Generation of constraints
  • Call to solvers (ILOG solver, satzoo)
  • Visualisation of allocations

Goal= 8

slide-17
SLIDE 17

17

Installation Related Assessment

  • Assess the impact of

equipment installation on Safety Requirements

  • Link functional architecture

model with Digital Aircraft mockup (CATIA, IRIS)

– Similar to the modelling of allocation of functions on hardware

  • Study the effect of tyre or

engine burst on functions

3D model Altarica model

slide-18
SLIDE 18

18

ATV Case Study

  • Software dependability oriented model:

– More detailed functional Architecture, simpler hardware model – Add a model of middleware services « between » functional view and Hardware architecture view to study new kind of failure propagations in the temporal domain Functional hardware Middleware

slide-19
SLIDE 19

19

Automated Production of Altarica models

  • Generate dependability models

– Industrial need : decrease the modelling effort – AADL (Avionics Architecture Description Language) to Altarica model transformation – AADL models structured in layers

  • Hardware and allocation : similar to Altarica, easy to transform
  • Functional architecture : more expressive, not so easy to

transform…

– AADL Error Annex

  • AADL special notation for failure propagation models
  • Adapted for Software failure propagation modelling
  • Limited tool-support (by now)
slide-20
SLIDE 20

20

Conclusion – Further work

  • Requirement driven engineering

– Organize the design activities – Define what models should be built and what analysis should be performed

  • Models for software dependability

– Model more accurately software

  • Optimise avionics architecture with respect to several

viewpoints :

– real-time performances, operational reliability, installation, Electro-magnetic Interference, …
