University Of Paderborn Software Engineering Group Prof. Dr. W. Schfer An Architecture for An Architecture for Configurable Dependability of Configurable Dependability of Application Services Application Services Matthias Tichy

slide-1
SLIDE 1

University Of Paderborn Software Engineering Group

  • Prof. Dr. W. Schäfer

An Architecture for Configurable Dependability of Application Services An Architecture for Configurable Dependability of Application Services

Matthias Tichy mtt@uni-paderborn.de Software Engineering Group University Of Paderborn

slide-2
SLIDE 2

2

University Of Paderborn Software Engineering Group

  • Prof. Dr. W. Schäfer

Contents

  • Introduction
  • Architectural Principles for Dependability
  • Architecture
  • Improving Availability
  • Improving Reliability
  • Conclusion & Future Work
slide-3
SLIDE 3

3

University Of Paderborn Software Engineering Group

  • Prof. Dr. W. Schäfer

Introduction

  • Dependability

– Availability – Reliability – Safety – Security

<<deploy>>

Chart

MathInterface ChartInterface

Math

uther vivian

network <<deploy>>

slide-4
SLIDE 4

4

University Of Paderborn Software Engineering Group

  • Prof. Dr. W. Schäfer

Architectural Principles

  • Service Registry

Provides support for dynamic online binding and spontanous networking.

  • Leasing

The leasing principle extends the allocation of resources with time.The lease represents a period of time during which the resource is offered.

  • Proxy

A proxy is the placeholder for another object.

  • Smart Proxy

Smarter version of the proxy, may be a placeholder for more than one object.

  • Redundancy

Redundant services prevent a single-point-of-failure.

  • Replication

Replicating is the process of maintaining multiple copies of the same entity at different locations.

slide-5
SLIDE 5

5

University Of Paderborn Software Engineering Group

  • Prof. Dr. W. Schäfer

Architecture

  • Architecture provides means to achieve high availability for

application services

  • Reliability is highly

application specific

  • Every infrastructure

service is executed on every node – Redundancy of services – Replication of data – Service registry

Data access b: Check Register a.3: a.1: Start a.2: Create Responsibility : Monitor : Service Storage : Node : Application Service : Jini Lookup : Monitor Description Storage

slide-6
SLIDE 6

6

University Of Paderborn Software Engineering Group

  • Prof. Dr. W. Schäfer

Architecture – Monitor (Availability)

  • For each application service instance, one monitor supervises its

execution configurable degree of availability

  • Coordination by monitor responsibilities (registry + leasing)

responsibility lease t service lease

new resp. monitor node failure service restarted

  • s. lease
slide-7
SLIDE 7

7

University Of Paderborn Software Engineering Group

  • Prof. Dr. W. Schäfer

Reliability

  • Highly application specific
  • 3 types:

– Stateless session service

  • No problem, just use another service instance

– Stateful session service

  • Relevant history must be replayed on another

service instance – Entity service

  • Replicate data and use an appropriate consistency

model

slide-8
SLIDE 8

8

University Of Paderborn Software Engineering Group

  • Prof. Dr. W. Schäfer

Architecture – Responsibility Storage (Reliability)

  • Example for an entity service
  • Smart Proxy communicates via Multicast messages
  • Decentral majority voting
  • Redundancy, replication, smart proxy

Resp. „Mon2“

LAN

Resp. „Mon2“ Resp. „Mon5“

Messages:

Smart Proxy

Messages: Messages: Messages:

1: getData(„Chart“) 1: getData() 1: getData() 1: getData() 1: getData() 3: „Mon2“ 2: „Mon2“ 4: „Mon5“ 2: „Mon2“ 2: „Mon2“ 2: „Mon2“ 2: „Mon2“ 3: „Mon2“ 3: „Mon2“ 3: „Mon2“ 3: „Mon2“ 4: „Mon5“ 4: „Mon5“ 4: „Mon5“ 4: „Mon5“

Voting Voting Voting Voting

<<timeout>> <<timeout>> <<timeout>> <<timeout>>

„Mon2“ „Mon2“ „Mon2“ „Mon2“

Resp. „Mon2“

slide-9
SLIDE 9

9

University Of Paderborn Software Engineering Group

  • Prof. Dr. W. Schäfer

Conclusion & Future Work

  • Architectural principles for dependability
  • Architecture based on these principles
  • Provides means to achieve a configurable degree of

availability

  • Example for providing application specific reliability
  • Implementation based on Jini
  • Seamless UML support for service-based architectures
  • Runtime measurements to adapt architecture

parameters

  • Complex embedded and real-time systems
slide-10
SLIDE 10

University Of Paderborn Software Engineering Group

  • Prof. Dr. W. Schäfer

Thank you for your attention! Thank you for your attention! Questions? Questions?

slide-11
SLIDE 11

11

University Of Paderborn Software Engineering Group

  • Prof. Dr. W. Schäfer

Service Description Storage (Reliability)

  • Redundant and distributed storage of the

service descriptions

  • Strong consistency (sequentiell)
  • Probability: P(Read) >> P(Write)
  • Algorithm „Weighted Voting“
  • Implemented in a smart proxy
