 Motivation  Part I: Basic Retargeting Operations

• Scaling and cropping
• Regions of interest
• Automatic crop & scale
• Sports video adaptation

 Part II: Seam Carving

• Seam carving for images
• Preservation of straight lines
• Fast seam carving for videos

 Summary

15.02.2011 Stephan Kopf 2

 Mobile phones are multimedia devices that allow to

• browse the Web
• display images and videos
• support novel input technologies (multi-touch)

15.02.2011 Stephan Kopf 3

 But they still have limitations:

• Small screen size
• Wireless connection (bandwidth)
• Computational power (CPU, memory)
• Battery

 Typical resolutions of images and videos

• Digital camera: 10 megapixels (3.600 x 2.700 pixels)
• Camcorder: high definition (1.920 x 1.080 pixels)
• Mobile phone (240 x 320 pixels)

15.02.2011 Stephan Kopf 4

HD video mobile phone

 Bitrate: 24 Mbit/s  Distortions caused by scaling (aspect ratio)

Goal als of media dia retar arget getin ing

 Shrink photos and videos for the presentation on a mobile

phone (this automatically limits the bitrate)

 Keep aspect ratio  Preserve the most important visual content

 Algorithms for image and video retargeting

15.02.2011 Stephan Kopf 5

6

 Shrink image (merge pixels) by a fixed scale factor (uniform

scaling)

 Different scale factors for each axis change the aspect ratio

(non-uniform scaling)

 Relevance of image content is ignored  „Letterboxing“ is used to preserve aspect ratio  Example:

15.02.2011 Stephan Kopf 7

 Crop image borders until aspect ratios of image and display

match

 Relevance of image content is ignored: important content

may be lost

 Typically use scaling to convert to target size  Example:

15.02.2011 Stephan Kopf 8

Idea ea

 Identify most relevant image regions (regions of interest)  Crop borders but preserve regions of interest  Use automatic algorithms to identify regions of interest:

• Saliency maps
• Faces
• Text regions

15.02.2011 Stephan Kopf 9

 Assumption: image regions that are relevant for an observer

have a high contrast

 Step 1: Contrast map of an image of size n × m :

color of a pixel: pi ,j pixel in local neighborhood of pi ,j : distance function: d (.)

 Step 2: Quantize contrast map  Step 3: Find connected regions  Step 4: Mark region of interest

15.02.2011 Stephan Kopf 10 *Source: Ma and Zhang HJ: Contrast-based image attention analysis by using fuzzy growing, ACM Intl. Conf. on Multimedia, 2003

contrast map quantized contrast map region of interest bounding box

15.02.2011 Stephan Kopf 11

 Use automatic face detection algorithms to localize face

regions

 Frontal face detection algorithms work very robust

(in contrast to face recognition)

15.02.2011 Stephan Kopf 12

 Characteristic features of text:

• horizontal alignment
• significant luminance difference between text and background
• the character size is within a certain range
• single-colored
• text is visible in consecutive frames (video)
• horizontal or vertical motion is possible (video)

 Calculate a horizontal projection profile to detect the

boundaries of text lines

15.02.2011 Stephan Kopf 13

 Calculate importance value V for each region of size H:

minimum perceptible size: Hmin maximum reasonable size: Hmax

 Find optimal target region W based on regions of interest Si:

15.02.2011 Stephan Kopf 14

Selection of one feature Combination of two features … three features Full image

15.02.2011 Stephan Kopf 15

scaling cropping crop & scale

15.02.2011 Stephan Kopf 16

Automatically detect:

 Court lines  Players  Ball

scaled video modify video content

15.02.2011 Stephan Kopf 17 *Source: Kopf, Guthier, Farin, Han: Analysis and Retargeting of Ball Sports Video, IEEE Workshop on Applications

• f Computer Vision, 2011

 Step 1: Mark bright pixels (line pixels)  Step 2: Algorithm to detect straight lines (based on RANSAC)

• 1. Randomly select two line pixels and calculate line parameters
• 2. Count number of white pixels N located on line
• 3. If (N

N > threshold) stop

• 4. Goto 1.

 Step 3: Remove line pixels and detect next line (Step 2)

15.02.2011 Stephan Kopf 18 RANSAC: Fischler, Bolles: Random sample concensus: a paradigm for model fitting with applications to image analysis and automated cartography, Communications ACM, vol 24(6), 1981.

 Problem: Position of lines change from frame to frame  Solution: use a reference court model to estimate camera

motion

• Step 1: Calculate intersection points of two lines
• Step 2: Transform lines to court model

 How many intersection points do we need

for the transformation?

15.02.2011 Stephan Kopf 19

 Translation (horizontal/vertical shift)

 1 intersection point

15.02.2011 Stephan Kopf 20

 Translation and scaling

 2 intersection points

 Affine transform (translation, scaling, rotation)

 3 intersection points

 Perspective transform

 4 intersection points

cropping scaling crop & scale (zoom on largest player) modify lines & ball

15.02.2011 Stephan Kopf 21

22

 If important content is located near image borders:

 crop & scale is not applicable Idea ea of f seam am carvin ving* g*

 Systematic removal of less important pixels  Use energy function as measurement of „importance“ of

single pixels

*Source: Shai Avidan and Ariel Shamir: Seam Carving for Content-Aware Image Resizing. ACM SIGGRAPH, 2007 15.02.2011 Stephan Kopf 23

Image width should be reduced by 40 percent

• riginal image energy map

15.02.2011 Stephan Kopf 24

 Remove N pixels with the lowest energy from each line

15.02.2011 Stephan Kopf 25

remove N=200 pixels from each line based on energy values source image

 Summarize energy in each column of the image and

remove N columns with lowest energy

remove 200 columns based on energy values

• f columns
• riginal image

15.02.2011 Stephan Kopf 26

 A vertical seam is an 8-connected path

• f pixels from top to bottom that contains
• ne and only one pixel in each row.

 Formal definition:  Horizontal seams are defined in a analog way.

15.02.2011 Stephan Kopf 27

1 | 1)

• x(i
• x(i)

| : i subject to , i)} {(x(i), = } {s = s

n 1 i n 1 i x i x

 

 

 Advantage of seams compared to columns or rows:

• Pixels of low energy are removed
• Relevant objects are preserved

15.02.2011 Stephan Kopf 28

 Remove the vertical seam with the lowest energy  Repeat this step N times

15.02.2011 Stephan Kopf 29

remove N=200 seams based on lowest energy source image

 Seam carving uses an energy function that characterizes the

relevance of each pixel (similar to saliency maps).

 The optimal seam minimizes the cumulated pixel energy of

all seam pixels.

 Method to find optimal seam: dynamic programming

15.02.2011 Stephan Kopf 30

 M ( i, j ) specifies the cost of the optimal (vertical) seam from

the upper image border to pixel position (i, j )

 Calculate M( i, j ) recursively:

            ) 1 , 1 ( ) , 1 ( ) 1 , 1 ( min ) , ( ) , ( j i M j i M j i M j i e j i M

15.02.2011 Stephan Kopf 31

1

 Example how to calculate the optimal seam:

1 3 6 7 3 6 7 2 5 1 4 1 2 3 4 1 2 3 3 5 4 4 1             ) 1 , 1 ( ) , 1 ( ) 1 , 1 ( min ) , ( ) , ( j i M j i M j i M j i e j i M 2 5 4 3 4 5 4 5 7 9 8 9

15.02.2011 Stephan Kopf 32

energy map cumulated energy map M( i, j )

 Image gradient: simple energy function that calculates the

luminance difference to adjacent pixels:

 Assumption: Luminance values do not differ much in image

regions of low relevance

 This simple energy function gives good results in many cases

) , ( ) , ( )) , ( ( y x I y y x I x y x I e      

15.02.2011 Stephan Kopf 33

 Problem: The light house is an important region, but the pixel

values are very similar

• riginal image
• ptimal seams

result

15.02.2011 Stephan Kopf 34

 Combine energy function with saliency map

)) , ( ( ) , ( )) , ( ( y x I e y x saliency w y x I e

s sal

  

saliency map

• ptimal seams result

(esal is used as energy function)

Source: Hwang and Chien. Content-Aware Image Resizing using Perceptual Seam Carving with Human Attention Model. IEEE Conference on Multimedia and Expo, 2008. 15.02.2011 Stephan Kopf 35

 Use results from face detection as additional saliency:

)) , ( ( ) , ( ) , ( )) , ( ( y x I e y x face w y x saliency w y x I e

f s face sal

    



saliency map face map seams based on esal+face as energy function result

15.02.2011 Stephan Kopf 36

 The quality of seam carving drops significantly in case of

straight lines

• riginal image

seam carving (width reduced by 40%)

Source: Kiess, Kopf, Guthier and Effelsberg: Seam Carving with Improved Edge Preservation.

• Proc. of IS&T/SPIE Electronic Imaging, 2010.

15.02.2011 Stephan Kopf 37

 Problem: lines become distorted when seams are removed

image section visualizing a straight line seams intersect a straight line result after removal of seams

15.02.2011 Stephan Kopf 38

 This is especially critical when several seams intersect a line

in adjacent pixel positions

 Idea: Distribute intersection points of seams and lines

along the line

seams intersect a line in adjacent pixel positions result: errors are clearly visible equal distribution

• f intersection

points result: errors are much less obvious

15.02.2011 Stephan Kopf 39

 Implementation: modify energy function before the next

• ptimal seam is calculated

 Intersection point of seam and line: increase energy values in

a certain radius

 The following seams will avoid these pixels

seam intersects a straight line Modify energy function next to the intersection point detect next seams and modify energy function for each intersection

15.02.2011 Stephan Kopf 40

• riginal image seam carving

seam Carving with line preservation

15.02.2011 Stephan Kopf 41

 1. Idea: Use seam carving on each frame separately

 video becomes blurred and shaky

• riginal

adapted

Impr provem

• vements

ts

 Video defines a 3D space-time volume (3D cube)  Remove 2D seam manifolds (seam surface areas) where each

seam pixel is connected in 3D

 Use graph cuts (max-flow min-cut) to detect optimal seam

manifold

Source: Rubinstein, Shamir, Avidan: Improved seam carving for video retargeting. ACM Trans. Graph. 27, 3, 2008.

time

source node sink node frame N frame 1 edges: energy between pixels

 Computational effort?

Idea ea

 Create one image that aggregates the pixel values / energy

values of all frames

 Detect 1D seam in aggregated image  Map this seam back to all frames

Source: Kopf, Kiess, Lemelson, Effelsberg: FSCAV - Fast Seam Carving for Size Adaptation of Videos, ACM Intl. Conf. on Multimedia, 2009. 15.02.2011 Stephan Kopf 44

Proble lem: camera motion, zoom, panning

 Use image registration techniques to calculate the parameters

• f the camera model (use perspective camera model)

 Align frames and create a background image  Detect optimal seam in background image  Use inverse camera motion to transform optimal seam back

to all original frames

15.02.2011 Stephan Kopf 45

 Example: construct background image from a camera pan

15.02.2011 Stephan Kopf 46

15.02.2011 Stephan Kopf 47

scaling seam carving

15.02.2011 Stephan Kopf 48

scaling fast seam carving

 The quality of adapted images or videos depends on the

visual content. The results of crop & scale might be much better than seam carving or vice versa.

 Crop & scale typically works well if the relevant content is

located in a small region.

 In case of large background areas, many seams with low

energy are detected and the results based on seam carving are very good.

15.02.2011 Stephan Kopf 49

 No technique works well if most of the content is highly

relevant.

 Would it be possible to find better energy functions for

seams?

 Would it be possible to preserve other geometric objects

similar to straight lines?

 Would it be possible to automatically evaluate the quality of

adapted images or videos?

15.02.2011 Stephan Kopf 50
