Delta UPS – Modulon Family

DPH, 25~800kW

PM EM EA December 2012

Version Number: V2

Delta Confidential

DPH Model Series

2

75kW 200kW

Delta Confidential 3

DPH 200 Configurations

DPH200 DPH200 UPS

(Top cable entry)

DPH 200kW Sys. Power Module 25kW (Option:1~8)

DPH200 UPS

(Bottom cable entry)

DPH 200kW Sys. Power Module 25kW (Option:1~8) Bottom Cable Entry Cabinet

DPH200

Power solution (Top/Bottom cable entry)

DPH 200kW Sys. Power Module 25kW (Option:1~8) Integrated Distribution Cabinet Subfeed breaker 75/ 100/ 150A

Delta Confidential

Modulon DPH Introduction

4

• Datacenter Demands
• Product Overview
• Target Customer
• Smart Modular Design
• Key Customer Benefits
• Various Configurations
• UPS Management
• Summary

25 ~ 800kW

Datacenter Demands

5

Delta Confidential 6

What are the challenges datacenters are facing now ?

Delta Confidential

Datacenter Challenges

7

Intense & growing applications driven by :

• Web sites
• Smart phones
• Big data

Increase of electricity bills!

• Energy expenditure is growing

in 15~20% every year.

• Cost of power is becoming the

new KPIs Loss caused by downtime per minute can be USD4,000~6,000

• r even more!

Mission Critical Data Booming Energy- Consuming Availability ↑

Customer Need #1

Scalability ↑

Customer Need #2

Power Performance & Efficiency ↑

Customer Need #3

Delta Confidential 8

 Designed with leading power performance and efficiency to lower down the operation cost

8

Modulon DPH

Ultimate availability without compromising power efficiency

Ideal UPS Solution for Medium Datacenters

Availability ↑

Customer Need #1

Scalability ↑

Customer Need #2

Power Performance & Efficiency ↑

Customer Need #3

 Designed for the ultimate availability to sustain continuity of the mission critical operations  With modular design to seamless scale up to meet rapid business expansion

Product Overview

9

Delta Confidential

Product Overview

10

Availability Scalability

Power Performance & Efficiency

Seamless scale up to meet rapid business expansion.

1.Vertical expansion:

Hot scalable in a rack up to 8 units

2.Horizontal expansion:

Parallel expansion up to 4 units. Leading power performance and efficiency to lower down operation cost.

1.AC-AC Efficiency:

96% at full load; 95% at 30% load

2.Fully-rated power factor: kVA=kW

(O/P pf = 1)

2.Low iTHD < 3%

Ultimate availability to sustain continuity of mission critical

• perations.

1.Fault tolerance design: Redundancy

for key components

2.Hot-swappable modular design:

Easy maintenance to reduce MTTR

Modulon DPH is a fully-modular designed UPS ideal for medium data center

Delta Confidential

Exterior Architecture

11

Dimensions

2000 mm

Front View with door open

Output Breaker Bypass Breaker Main Input Breaker STS Module Control Module Power Module

Rear View with door open

Manual Bypass Breaker

Split rear doors for space saving Same dimension as 19” standard rack

Target Customer

12

Delta Confidential

Target Customer

13

Regions

ESC TW ESI EMEA SA RC SEA

Vertical Market

Computing Services Financial Services Education Government Healthcare Infrastructure Manufacturing Transportation Retailers

Applications

Target customer of Modulon DPH is midsize datacenter across all vertical markets. Midsize Datacenter

*Number of racks : 26~100 *Area : 750~3000 ft2 (70~279 m2) *By Gartner definition

Delta Confidential

DPH Integration with Datacenters

 Easy layout planning

Width 600mm fits datacenter raised floor dimension (600 x 600 mm)

 High power density

Saves datacenter floor space with compact size and up to 200kW within a single UPS

14

The Modulon DPH is designed in modern IT aesthetics aligned with Delta InfraSuite datacenter solutions. By Gartner definition, number of racks for midsize datacenter is 26~100 DPH PDC Rack

19”

RowCool

29kW

Rack

19”

 IT style and dimensions

Exterior is aligned with IT style. 19” enclosure provides rack-based agility to datacenter space arrangement and infrastructure setup

 Well-integrated with Delta InfraSuite

Provides customers with single point of contact for total solution and service

Smart Modular Design

15

Delta Confidential

Characteristics of Modular Design

16

Standardization

Easy to understand Modular

Modularity is the foundation of standardization. Standardization can help:

Enhance human learning capability Predict problems Increase human & machine efficiency

Source: White paper from ESC – Power Supply Modular Design and Modular UPS

Delta Confidential

How Modularity increases the business value of datacenter?

17

Datacenter Business Value TCO Availability Adaptability

• Self redundancy
• Hot-swappable
• Reduced MTTR
• Flexibility
• Scalability
• Power performance
• Efficiency
• Scale optimization
• Easy & quick maintenance

Source: White paper from ESC – Power Supply Modular Design and Modular UPS

Key Customer Benefits

18

Delta Confidential

Modulon DPH

19

Availability Scalability Power Performance and Efficiency

Ultimate availability without compromising power efficiency

Delta Confidential

Dual auxiliary power ensures continuous power supply for UPS operation

Duality

Power Module

…

In the event of control module failure, full control logic at the power module level allows the system to self- synchronize for assured continuous operation.

Control module Power module Power module #1 Power module #8 Power module STS module

System fan x 2 Power module fan x 2 Self Redundancy Self Synchronization

Dual-fan architecture provides uninterruptible cooling and avoids over-heating N+X structure guarantees system availability

Control Mechanism Cooling Aux Power

Delta Confidential

Follower Follower

Self Synchronization

Modulon DPH is engineered to accommodate full logic control at power module level in the event of control module failure.

 This self-synchronization function brings high value to customers with assured continuous operation.  No risk from single point of failure to affect system operations!

STS Module MB/IO/bypass breaker Power Module (ID6) Power Module (ID7)

Load

Power Module (ID4) Power Module (ID3) Power Module (ID1) Power Module (ID8) Control Module

Leader

Power Module (ID2) Power Module (ID2)

Leader Follower

Power Module (ID1)

Leader Follower Follower Follower

Power Module (ID5)

Follower Follower Leader

Delta Confidential

Hot-Swappable Modules

Control Module Power Module STS Module Hot-swappable modules allow quick replacement and expansion; and it guarantees uninterruptible operations during maintenance.

22

Delta Confidential

When STS module is removed, Modulon DPH can still run under normal mode.

Normal Mode Operation without STS Module

23

Normal M ode

Delta Confidential

When the inverter encounters abnormal situations (over temperature,

• verload, short circuit, abnormal output voltage, low battery,…), STS

module can smoothly transfer to Bypass Mode to supply power to critical load without interruption.

Smooth Transfer to Bypass Mode

24

Delta Confidential

25

Easy Maintenance

Hot-swappable modules ensure mean time to repair (MTTR) close to ZERO without downtime risk

Quick replacement by standard operating procedures (SOPs) Standardized modules and procedures minimize human errors

Delta Confidential 26

AC/DC BYPASS INPUT M AIN INPUT OUTPUT DC/AC UPS

This design ensures system availability during service maintenance.

Maintenance

In-built Manual Bypass Switch

Switch to manual bypass source to avoid system downtime during service maintenance. Rear View with door open

Manual Bypass Breaker

Delta Confidential

Voltage Range and Stability

 Wide input voltage range* (-45% ~ +25%) and frequency (45Hz ~ 65Hz) Reduces battery discharging occurrence and prolongs battery lifetime  Narrow output voltage regulation < ± 1 % Provides stable power supply

27

Cope with harsh utility conditions and seamlessly provide stable power supply to the load. Inverter overload capacity for stable operation

 ≦ 125% : 10 minutes  ≦ 150% : 1 minute

• Pure sine wave
• Output voltage ± 1 %
• Over voltage
• Transient

* When input voltage is 140/242~176/305 Vac, the sustainable loading is from 60% to 100% of the UPS capacity.

Delta Confidential

Detection Mechanism

28

 Fan failure detection LED will be lighted up when failure is detected. A warning message is shown on LCD panel and recorded in the event log  Switch detection – Main input, Output, Bypass, Manual bypass If switch is off, a warning message will appear

• n LCD panel and is recorded in the event log

The design provides quick diagnosis of the problem caused by fan failure and switch faults to shorten repair time.

LED Indicator

Power Module

LED Indicator

STS Module

Delta Confidential

 Intelligent fan speed control

Adjusts fan speed based on the change of load percentage and also removes the heat efficiently

 Redundant system fans and power module fans

Ensures cooling availability

Intelligent Cooling Design

29

Intelligent fan speed control and optional redundant fan prevents UPS from

• verheating to increase system reliability.

Power Module STS Module

Delta Confidential

“Pay as You Go” modular design allows you to meet your consumption requirements without tying up valuable capital. No over-sizing is required !

Vertical & Horizontal Expansion

30

• On-site upgradable to 8 power modules within a rack
• Hot-scalable

VERTICAL MODULARITY

from 25 to 200kW

• Parallel expansion up to 4 units.
• Easy connection by parallel wire.

HORIZONTAL MODULARITY

up to 800kW

System 1 System 3 System 4 System 2

Delta Confidential

Fully-rated Power Factor

Fully rated power kVA=KW. Output power factor = 1

• No derating with any loads (leading or lagging). Permanent 100% kVA.
• No over-sized UPS for any loads. More output power than legacy UPS
• High inverter reliability to support full power to any loads.

Delta Confidential

High power efficiency across a wide load range results in marked energy cost savings.

Leading Power Efficiency

32

AC-AC Efficiency

• 95% at light load 30%
• 96% at 50% load or above

Delta Confidential

iTHD <3% can eliminate the need to oversize the generator to save

• n capital investment.
• Low iTHD (<3%) leads to better power quality and less heat
• Optimal generator size can be chosen
• Initial investment cost and installation cost can be reduced

Low iTHD

Lowest pollution (iTHD <3%) to upstream power Harmonic Distortion

• n mains

Load

Harmonic Distortion of load on UPS

Various Configurations

34

Delta Confidential

Single and Dual Input

35

Customer benefits:

 Maximize availability

Dual Loop Input

Delta Confidential

Common Battery

36

Customer benefits

 Save installation space  Reduce battery cost  Increase battery utilization  Prolong battery lifespan

Parallel Input

Delta Confidential

Load Bus Synchronization (LBS)

37

STS UPS 1 UPS 2

Inverter is synchronized

Load

UPS Management

38

Delta Confidential

Control Panel

39

User-friendly graphic LCD 3,000 event logs recorded for quick diagnosis Customize language setting

LCD Display LED Indicators EPO Button ON/OFF Buttons Function Keys

Delta Confidential

Communication Interfaces

40

SNMP IPv6 Card

Monitors UPS via SNMP protocol

ModBus Card

Provides ModBus compatibility

Relay I/O Card

Provides additional dry contacts for

• ther applications

Optional cards for additional functions :

Delta Confidential

• Adjustable charging voltage from 254V to 291V adapts to different types of batteries
• Battery temperature monitoring & compensation
• Battery remaining capacity displayed in percentage
• Over charge/discharge protection
• Boost/float stage charge
• Auto/manual battery test
• Up to 40A charging current even at full load conditions
• 38~42 battery units in one battery cabinet optimizes investment

Battery Management

41

Prevents battery from overcharge and deep discharge situations to sustain battery

• lifespan. Short recharging time keeps the capacity of battery up.

Summary

42

Delta Confidential

Modulon DPH : The Ideal UPS Solution for Medium Datacenters

43

Availability Scalability Power Performance and Efficiency

Ultimate availability without compromising power efficiency

Total Cost of Ownership Total Cost of Ownership SAVINGS SAVINGS

To learn more about Delta MCIS, please visit www.deltapowersolutions.com

Mission Critical Infrastructure Solutions (MCIS)

The power behind competitiveness
