DeepCache: Principled Cache for Mobile Deep Vision

Mengwei Xu1, Mengze Zhu1, Yunxin Liu2 Felix Xiaozhu Lin3, Xuanzhe Liu1

1Peking University, 2Microsoft Research, 3Purdue University

Background: Mobile Vision

• Your mobile device sees what you see, and does what you cannot do
• Core: computer vision algorithm

Augmented Reality Recognition & Detection Game Face Beauty

Background: CNN-based Vision

• Convolutional Neural Network (CNN) is the state-of-the-art vision algorithm.
• CNN is accurate, but also resource-hungry.

CNN model: a graph of computation nodes (convolution, pooling, activation, etc) convolution operation (input feature map * kernel = out feature map)

Background: Optimizing CNN Workloads

• Our approach: leveraging the temporal locality of mobile video stream
• Similar but not identical
• Object movement/appearance
• Camera movement
• Light variation
• etc…

Algorithm-level Compression

• quantization
• pruning
• factorization
• distilling

Hardware-level Acceleration

• CPU
• GPU
• DSP
• AI-specific chips

previous frame Current frame

Caching Mobile Vision – a naïve approach

• Just cache/reuse the final results based on input image

Inference Engine Class: elephant Pos: (-1.5, 7.9)

input

• uput

ith frame

Caching Mobile Vision – a naïve approach

• Just cache/reuse the final results based on input image

Inference Engine Class: elephant Pos: (-1.5, 7.9)

input Similar? ith frame (i+1)th frame

• uput

Caching Mobile Vision – a naïve approach

• Just cache/reuse the final results based on input image

Inference Engine Class: elephant Pos: (-1.5, 7.9) Class: elephant Pos: (-1.5, 7.9)

input Similar? YES: Let’s Reuse ith frame (i+1)th frame

• uput

Caching Mobile Vision – a naïve approach

• Just cache/reuse the final results based on input image

Inference Engine Class: elephant Pos: (-1.5, 7.9) Inference Engine Class: elephant Pos: (-1.1, 9.3)

input Similar? YES: Let’s Reuse NO: Do Computation ith frame (i+1)th frame

• uput

Caching Mobile Vision – a naïve approach

• Just cache/reuse the final results based on input image
• Why it’s not enough?
• Coarse-grained: whole image as comparison unit
• Cannot handle position-sensitive tasks

Two images are similar

• Similar background
• Similar animals

But the elephant position is different!

Caching Mobile Vision – De

DeepCa Cache

• Treat image as a collection of blocks, and cache/reuse them at a fine granularity.

previous frame current frame

Reuse the CNN computations of similar regions

cache & reuse

KEY IDEA

Caching Mobile Vision – De

DeepCa Cache

• Treat image as a collection of blocks, and cache/reuse them at a fine granularity.

Inference Engine Class: elephant Pos: (-1.5, 7.9) Inference Engine (revised) Class: elephant Pos: (-1.1, 9.3)

input

matching reusable regions

ith frame (i+1)th frame

• uput

layer-level cache/reuse

Challenges of DeepCache

• Scene variation – the overall background may be moved between frames
• Moving camera, autonomous driving, drone, etc
• ffset

previous frame current frame

Challenges of DeepCache

• Cache erosion – reusability tends to diminish at its deeper layers

Reusable region (5x5)

• n input feature map

Reusable region (3x3)

• n output feature map

3x3 Convolution Eroded

Re-computation Required

Challenges of DeepCache

• Cache erosion – reusability tends to diminish at its deeper layers

current frame

(a) The “best” match, with highest matching score

B1 B2 B1 B2 B1 B2 previous frame previous frame

(b) The “proper” match, with a high matching score

• 1. Merge smaller ones
• 2. Good news: early layers contribute most of the computation cost and

also suffer less cache erosion.

DeepCache Design: Overview

• Design Principles
• No cloud offloading
• No efforts from developers
• No modification to models

conv pool conv fc conv pool conv fc Image match previous frame current frame Cache and reuse Cache-aware CNN inference engine Reusable regions Processors (CPU, GPU, etc.) Camera Deep learning engine w/ DeepCache Raw image Pre-processing (resizing etc.) Input Output

Vision Applications

Storage Operating System Cache storage

• Two modules
• Image matcher
• Cache-aware inference engine

DeepCache Design: Image Matching

• Principles: high similarity, low overhead, and merged to big ones.
• Input: two raw images
• Output: a set of matched rectangles
• (x1, y1, w, h) in current frame -> (x2, y2, w, h) in previous frame

DeepCache Design: Image Matching

• Step 1: dividing the current frame into an NxN grid.
• N is a configurable parameter (default: 10 x 10).

Current Frame Previous Frame

DeepCache Design: Image Matching

• Step 2: find the most-matched block in previous frame for each divided block
• Motion estimation: diamond search

(x1, y1) Current Frame Previous Frame

(x2, y2)

DeepCache Design: Image Matching

• Step 3: calculate the average block movement (offset): (Mx, My).
• Filter those outliers

(x1, y1) Current Frame Previous Frame

(x2, y2)

DeepCache Design: Image Matching

• Step 4: calculate the similarity between block (x1, y1) in current frame and the

block (x1+Mx, y2 + My) with average movement in previous frame

• Metrics: Peak Signal to Noise Ratio (PSNR)

(x1, y1) Current Frame Previous Frame

(x1+Mx, y2 + My)

PSRN: 24 (reusable) PSRN: 21 (reusable)

DeepCache Design: Image Matching

• Step 5: merge blocks into larger ones if possible

(x1, y1) Current Frame Previous Frame

(x1+Mx, y2 + My)

(x1, y1)

DeepCache Design: Image Matching

• Optimization 1: skip block matching in Step 2 (k-skip)
• Optimization 2: in Step 4, reuse the matching scores computed in Step 2
• Not always applicable: depends on the average movement

2-skip 8/16 blocks computed 3-skip 6/16 blocks computed

DeepCache Design: Cache-aware CNN Inference

• Propagation: the reusable regions passed from image matching is not

unchangeable during execution among CNN layers. reusable

reusable

Convolution

Kernel=11x11 Stride=2 Padding=5

(100, 100, 100, 40) ⇒ (120, 120, 100, 40)

(53, 53, 45, 15) ⇒ (63, 63, 45, 15) reusable

ReLu

reusable

Pooling

Kernel=3x3 Stride=2 Padding=1

(27, 27, 21, 7) ⇒ (32, 32, 21, 7)

(53, 53, 45, 15) ⇒ (63, 63, 45, 15)

Because of cache erosion! But what affects cache erosion?

DeepCache Design: Cache-aware CNN Inference

• Propagation: the reusable regions passed from image matching is not

unchangeable during execution among CNN layers. partial erosion full erosion no erosion

DeepCache Design: Cache-aware CNN Inference

• Why Propagation? Why not match the input of each layer?
• Low return: feature maps are high dimensional data, difficult to interpret.
• High cost: matching feature map requires a lot of computations (40× compared to

propagation for ResNet).

1.00 1.00 1.00 1.00 1.00 1.84 21.24 35.77 26.67 3.44 2.25 28.63 43.67 34.31 3.57 2.30 30.98 48.59 37.82 3.67

10 20 30 40 50 60 AlexNet GoogLeNet ResNet-50 YOLO Dave-orig

Normalized Latency

DeepCache MIL-50% MIL-75% MIL-100%

• DeepCache: match input images once,

and using propagation later

• MIL: matching inter-layer

DeepCache Design: Cache-aware CNN Inference

• Cache/Reuse: reuse the computation results at the output of convolutions.
• Mind the data locality during reuse!
• Depends on the convolution implementation: img2col + gemm, unrolled, etc.

29.2 0.4 5.7 0.2 21.0 0.0 2.9 13.0 0.0 9.5 0.0 6.5 0.0 5.9 0.0 4.4 0.0 0.8 0.4

0.0 5.0 10.0 15.0 20.0 25.0 30.0 35.0

conv1 relu1 lrn1 pool1 conv2 relu2 lrn2 conv3 relu3 conv4 relu4 conv5 relu5 fc6 relu6 fc7 relu7 fc8 prob

Normalized Latency (%) Convolutional Fully-connected Others

Convolution is often the dominant layer (> 80% overall computations)

DeepCache Implementation

• Image matching is implemented based on RenderScript
• A programming framework on Android for intensive computations
• GPU-support, generic, high data-parallel
• Cache-awareness is built upon ncnn
• Popular deep learning inference framework for mobile devices
• High speed, lightweight, no dependency

Evaluation – Setup

• Popular CNN models and datasets
• Platform: Nexus 6, Android 6.0
• Alternative
• ncnn without cache
• Coarse-grained cache used in [1]DeepMon

[1] Huynh Nguyen Loc, Youngki Lee, and Rajesh Krishna Balan. 2017. DeepMon: Mobile GPU-based Deep Learning Framework for Continuous Vision Applications. In Proceedings of the 15th Annual International Conference on Mobile Systems, Applications, and Services (MobiSys’17)

Evaluation – Execution Speedup

• DeepCache saves 15% ~ 28% model execution time (2X DeepMon)
• The speedup depends on model architecture
• Deeper layers, less savings

1 1 1 1 1 0.870 0.898 0.927 0.929 0.932 0.720 0.803 0.849 0.858 0.862

0.0 0.2 0.4 0.6 0.8 1.0 1.2

REC_1 REC_2 REC_3 DET DRV

Normalized Processing Latency no-cache DeepMon DeepCache

10 20 30 40 50 60 70 80 Conv_1 Conv_10 Conv_20 Conv_30 Conv_40 Conv_50

Conv-layer Latency (ms)

no-cache DeepCache

165

deeper layers

Evaluation – Energy Saving

• DeepCache can save around 20% energy consumption of processing same

number of images.

• The energy saved by using DeepCache to process 10 images (ResNet) is equal to 40 seconds
• f playing video on mobile devices.

1.83 6.86 11.85 35.63 39.90 1.67 6.01 11.11 33.26 37.27 1.49 4.90 9.71 28.97 34.47

10 20 30 40 50

DRV REC_1 REC_2 REC_3 DET

Energy (J)

no-cache DeepMon DeepCache

Evaluation – Accuracy

• DeepCache is able to keep the accuracy
• 2% on average, similar to DeepMon

0.000 0.002 0.004 0.006 0.008

DeepMon COMO

AlexNet Euclidean Distance

0.000 0.002 0.004 0.006

DeepMon COMO

YOLO

2.43 1.14 2.98 0.91 2.29 1.43 2.62 1.06

1 2 3 4 5 REC_3-top1 REC_3-top3 REC_2-top1 REC_2-top3

Accuracy drop (%) DeepMon DeepCache

Evaluation – Memory Overhead

• The overhead of cache is acceptable
• 2MB ~ 44MB, while nowadays mobile devices usually have more than 1G memory
• Note we only cache the results of convolutional layers, and only for one frame

252.2 81.4 342.8 407.7 18.5 36.2 135.3 100.9 254.7 94.0 386.6 422.1 21.7 47.0 144.5 121.7

100 200 300 400 500 REC_1 REC_2 REC_3 DET DRV SqueezeNet DeepFace MobileNet

Memory Usage (MB) no-cache DeepCache

Conclusion

• DeepCache: cache design for mobile deep vision
• Image matching on raw images
• Cache/reuse in inference engine
• Evaluation
• ~20% execution speedup and energy savings
• Little accuracy loss

Thank you for attention!

Evaluation – Execution Speedup

• DeepCache saves 15% ~ 28% model execution time (> DeepMon)
• Performance depends on scenarios

100 200 300 400 500 600 700

T1 T2 T3 T4 T5 T6 T7 T8 T9 T10 Processing Latency (ms)

no-cache DeepMon DeepCache

200 400 600 800 1000

T1 T2 T3 T4 T5 T6 T7 T8 T9 T10 Processing Latency (ms)

no-cache DeepMon DeepCache

500 1000 1500 2000 2500 3000 3500

T1 T2 T3 T4 T5 T6 T7 T8 T9 T10 Processing Latency (ms)

no-cache DeepMon DeepCache

500 1000 1500 2000 2500 3000 3500

T1 T2 T3 T4 T5 T6 T7 T8 T9 T10 Processing Latency (ms)

no-cache DeepMon DeepCache

T1: Basketball T2: ApplyEyeMakeup T3: CleanAndJerk T4: Billiards T5: BandMarching T6: ApplyLipstick T7: CliffDiving T8: BrushingTeeth T9: BlowDryHair T10: BalanceBeam

Evaluation – Configuration

• Some configuration can be tailored to make better trade-off among accuracy,

latency, and energy for different scenarios and applications.

• Matching threshold, block size

4 8 12 16 700 750 800 850 900

5 10 15 20 25 30

Accuracy Drop (%) Processing Latency (ms)

Block Size processing latency accuracy drop

5 10 15 20 25 400 500 600 700 800 900

10 15 20 25 30

Accuracy Drop (%) Processing Latency (ms)

Matching Threshold processing latency accuracy drop
