Deep Dive on RNNs

Charles Martin

What is an Artificial Neurone?

Source - Wikimedia Commons

Feed-Forward Network

For each unit: y = tanh

Wx + b

Recurrent Network

For each unit: yt = tanh

Uxt + Vht−1 + b

Sequence Learning Tasks

Recurrent Network

• simplifying. . .

Recurrent Network

simplifying and rotating. . .

“State” in Recurrent Networks

◮ Recurrent Networks are all about

storing a “state” in between computations.

◮ A “lossy summary of. . . past

sequences”

◮ h is the “hidden state” of our RNN ◮ What influences h?

Defining the RNN State

We can define a simplified RNN represented by this diagram as follows: ht = tanh

Uxt + Vht−1 + b

• ˆ

yt = softmax(c + Wht)

Unfolding an RNN in Time

Figure 1: Unfolding an RNN in Time

◮ By unfolding the RNN we can compute ˆ

y for a given length of sequence.

◮ Note that the weight matrices U, V , W are the same for each timestep; this is the

big advantage of RNNs!

Forward Propagation

We can now use the following equations to compute ˆ y3, by computing h for the previous steps: ht = tanh

Uxt + Vht−1 + b

• ˆ

yt = softmax(c + Wht)

Y-hat is Softmax’d

ˆ y is a probability distribution! A finite number of weights that add to 1: σ(z)j = ezj

K

k=1 ezk for j = 1, . . . , K

Calculating Loss: Categorical Cross Entropy

We use the categorical cross-entropy function for loss: ht = tanh

b + Vht−1 + Uxt

• ˆ

yt = softmax(c + Wht) Lt = −yt · log(ˆ yt) Loss =

• t

Lt

Backpropagation Through Time (BPTT)

Propagates error correction backwards through the network graph, adjusting all parameters (U, V, W) to minimise loss.

Example: Character-level text model

◮ Training data: a collection of text. ◮ Input (X): snippets of 30 characters from the collection. ◮ Target output (y): 1 character, the next one after the 30 in each X.

Training the Character-level Model

◮ Target: A probability distribution

with P(n) = 1

◮ Output: A probability distribution

• ver all next letters.

◮ E.g.: “My cat is named Simon”

would lead to X: “My cat is named Simo” and y: “n”

Using the trained model to generate text

◮ S: Sampling function, sample a letter

using the output probability distribution.

◮ The generated letter is reinserted at

as the next input.

◮ We don’t want to always draw the

most likely character. The would give frequent repetition and “copying” from the training text. Need a sampling strategy.

Char-RNN

◮ RNN as a sequence generator ◮ Input is current symbol, output is

next predicted symbol.

◮ Connect output to input and

continue!

◮ CharRNN simply applies this to a

(subset) of ASCII characters.

◮ Train and generate on any text

corpus: Fun! See: Karpathy, A. (2015). The unreasonable effectiveness of recurrent neural networks.

Char-RNN Examples

Shakespeare (Karpathy, 2015): Second Senator: They are away this miseries, produced upon my soul, Breaking and strongly should be buried, when I perish The earth and thoughts of many states. DUKE VINCENTIO: Well, your wit is in the care of side and that. Latex Algebraic Geometry: N.B. “Proof. Omitted.” Lol.

RNN Architectures and LSTM

Bidirectional RNNs

◮ Useful for tasks where the whole

sequence is available.

◮ Each output unit (ˆ

y) depends on both past and future - but most sensitive to closer times.

◮ Popular in speech recognition,

translation etc.

Encoder-Decoder (seq-to-seq)

◮ Learns to generate output sequence

(y) from an input sequence (x).

◮ Final hidden state of encoder is used

to compute a context variable C.

◮ For example, translation.

Deep RNNs

◮ Does adding deeper layers to an RNN

make it work better?

◮ Several options for architecture. ◮ Simply stacking RNN layers is very

popular; shown to work better by Graves et al. (2013)

◮ Intuitively: layers might learn some

hierarchical knowledge automatically.

◮ Typical setup: up to three recurrent

layers.

Long-Term Dependencies

◮ Learning long dependencies is a

mathematical challenge.

◮ Basically: gradients propagated

through the same weights tend to vanish (mostly) or explode (rarely)

◮ E.g., consider a simplified RNN with

no nonlinear activation function or input.

◮ Each time step multiplies h(0) by W. ◮ This corresponds to raising power of

eigenvalues in Λ.

◮ Eventually, components of h(0) not

aligned with the largest eigenvector will be discarded. ht = Wht−1 ht = (W t)h0 (supposing W admits eigendecomposition with orthogonal matrix Q) W = QΛQ⊤ ht = QΛtQh0

Vanishing and Exploding Gradients

◮ “in order to store memories in a way

that is robust to small perturbations, the RNN must enter a region of parameter space where gradients vanish”

◮ “whenever the model is able to

represent long term dependencies, the gradient of a long term interaction has exponentially smaller magnitude than the gradient of a short term interaction.”

◮ Note that this problem is only

relevant for recurrent networks since the weights W affecting the hidden state are the same at each time step.

◮ Goodfellow and Benigo (2016): “the

problem of learning long-term dependencies remains one of the main challenges in deep learning”

◮ WildML (2015). Backpropagation

Through Time and Vanishing Gradients

◮ ML for artists

Gated RNNs

◮ Possible solution! ◮ Provide a gate that can change the

hidden state a little bit at each step.

◮ The gates are controlled by

learnable weights as well!

◮ Hidden state weights that may

change at each time step.

◮ Create paths through time with

derivatives that do not vanish/explode.

◮ Gates choose information to

accumulate or forget at each time step.

◮ Most effective sequence models

used in practice!

Long Short-Term Memory

◮ Self-loop containing an internal state

(c).

◮ Three extra gating units:

◮ Forget gate: controls how much

memory is preserved.

◮ Input gate: control how much of

current input is stored.

◮ Output gate: control how much

• f state is shown to output.

◮ Each gate has own weights and

biases, so this uses lots more parameters.

◮ Some variants on this design, e.g.,

use c as additional input to three gate units.

Long Short-Term Memory

◮ Forget gate: f ◮ Internal state: s ◮ Input gate: g ◮ Output gate: q ◮ Output: h

Other Gating Units

Source: (Olah, C. 2015.)

◮ Are three gates necessary? ◮ Other gating units are simpler, e.g.,

Gated Recurrent Unit (GRU)

◮ For the moment, LSTMs are winning

in practical use.

◮ Maybe someone wants to explore

alternatives in a project?

Visualising LSTM activations

Sometimes, the LSTM cell state corresponds with features of the sequential data: Source: (Karpathy, 2015)

CharRNN Applications: FolkRNN

Some kinds of music can be represented in a text-like manner. Source: Sturm et al. 2015. Folk Music Style Modelling by Recurrent Neural Networks with Long Short Term Memory Units

Other CharRNN Applications

Teaching Recurrent Neural Networks about Monet

Google Magenta Performance RNN

◮ State-of-the-art in music generating RNNs. ◮ Encode MIDI musical sequences as categorical data. ◮ Now supports polyphony (multiple notes), dynamics (volume), expressive timing

Neural iPad Band, another CharRNN

◮ iPad music transcribed as sequence

• f numbers for each performer.

◮ Trick: encode multiple ints as one

(preserving ordering).

◮ Video

Books and Learning References

◮ Ian Goodfellow, Yoshua Bengio, and Aaron Courville. 2016. Deep Learning. MIT

Press.

◮ François Chollet. 2018. Manning. ◮ Chris Olah. 2015. Understanding LSTMs ◮ RNNs in Tensorflow ◮ Maybe RNN/LSTM is dead? CNNs can work similarly to BLSTMs ◮ Karpathy. 2015. The Unreasonable Effectiveness of RNNs

Summary

◮ Recurrent Neural Networks let us capture and model the structure of sequential

data.

◮ Sampling from trained RNNs allow us to generate new, creative sequences. ◮ The internal state of RNNs make them interesting for interactive applications, since

it lets them capture and continue from the current context or “style”.

◮ LSTM units are able to overcome the vanishing gradient problem to some extent.
