DC Green & Energy Codes Update 30 July 2018 | 6:30-8:00 p.m. 1.5 HSW|LUs Agenda Codes & Policy Context Lessons Learned from Current Green & Energy Codes Proposed Green & Energy Code Updates DC Incentives &

slide-1
SLIDE 1

DC Green & Energy Codes Update

30 July 2018 | 6:30-8:00 p.m. 1.5 HSW|LUs

slide-2
SLIDE 2

Agenda

  • Codes & Policy Context
  • Lessons Learned from Current Green & Energy Codes
  • Proposed Green & Energy Code Updates
  • DC Incentives & Resources
  • Global Policy & Codes Context
  • Advocacy & Engagement
slide-3
SLIDE 3

Gre e n Building Ac t Cle an Affordable E ne rgy Ac t E ne rgy E ffic ie nc y F inanc ing Ac t Sustainable DC Plan Community Re ne wable s Ac t Gre e n Are a Ratio Stormwate r Re gulations Gre e n Code s Wildlife Ac tion Plan RPS Update Climate Re ady DC Gre e n Bank & Cle an E ne rgy DC

2006 2010 2013 2014 2016 Created DC PACE Created the Green Building Fund Set minimum green building standards Launched DC SEU & benchmarking and disclosure program Adopted 2012 International Green Construction Code

@DOE E _DC

2008 Enabled community solar Creation of Solar for All Provided plan to transition to a new storm water management requirements Created a storm water credits trading platform Implemented environmental sustainable zoning 2012 2015 Developed a long- term plan for sustainability in the built environment Protects endangered species habitat

POL ICY T

I ME L I NE

2018 Identified Climate Resilience Strategies for Buildings & Development Coming Soon

slide-4
SLIDE 4

NET ZERO RETROFITS CUT ENERGY USE 50% CUT GHG EMISSIONS 50% ADAPT TO CLIMATE CHANGE CLIMATE READY BUILDINGS NET ZERO NEW BUILDINGS 50% RENEWABLE ENERGY

GOAL S: 2032 2050: Mayor

Bowse r Commitme nt to ZE RO Car bon

slide-5
SLIDE 5

@DOEE_DC

ENERGY USE AND EMISSIONS IN DC

MODE L E D PROPORT ION OF GHG E MISSIONS BY SE CT OR PROPORT ION OF GHG E MISSIONS BY SOURCE

slide-6
SLIDE 6

@DOEE_DC

  • 2,510
  • 390
  • 500
  • 856
  • 147
  • 599
  • 32
  • 473
  • 522
  • 32

10,540 +519 4998 2000 4000 6000 8000 10000 12000

GHG E missions (thousa nd tons CO2e )

50% re duc tio n b y 2032

CLEAN ENERGY DC: DC’s Climate & Energy Plan

slide-7
SLIDE 7

@DOEE_DC

NET-ZERO ENERGY CONSTRUCTION

American Geophysical Union

DC’s 1st NZE Building

  • Re side ntia l ne w c o nstruc tio n – 2020
  • Co mme rc ia l re q uire me nts – 2026
  • Pro po se d DC 2018 E

ne rg y Co de inc lude s Appe ndix Z: Ne t-Ze ro Pa thwa y

  • DC e a sing the pa th fo r a do ptio n
  • So la r + Sto rmwa te r
  • Zo ning re g ula tio ns
  • Pe rmitting
  • Distric t E

ne rg y & Mic ro g rids

slide-8
SLIDE 8

@DOEE_DC

CONSTRUCTION CODE UPDATES

  • Cle a n E

ne rg y DC Ac tio n - Pa th to 2032

  • Pro po se d c o de s pa sse d b y the CCCB a nd c urre ntly

b e ing re vie we d b y E OM

  • Pub lic Co mme nt Pe rio d (1 o r 2) b e fo re pro po sa l to

Co unc il

  • 2018 E

ne rg y Co nse rva tio n Co de

  • 15% impro ve me nt in e ffic ie nc y o ve r c urre nt

c o de

  • Sig nific a nt e ffic ie nc y c ha ng e s fo r re side ntia l

c o nstruc tio n

  • Ame ndme nts inc o rpo ra te I

E CC 2015 a lo ng with ASHRAE 90.1-2013 & 2016, 189.1 e ne rg y se c tio ns.

CO CODES ES A ARE E OUT UTDATED AS AS SO SOON ON A AS T S THEY ARE PA PASSED.

slide-9
SLIDE 9

@DOEE_DC

PNNL Study

  • 54% o f ne w c o nstruc tio n is multifa mily
  • 14% o f ne w c o nstruc tio n is o ffic e b uilding s
  • Ove ra ll, ne w c o de is inte nde d to sa ve 11% site

e ne rg y a nd 10% so urc e e ne rg y o ve r c urre nt c o de .

  • E

ne rg y c o st sa ving s a re e stima te d a t 10% Offic e b uilding s a nd 17.6% fo r Midrise Multifa mily

  • Big g e st impa c ts: pre sc riptive ma nda to ry e xte rio r

sha ding , so la r po we r, re duc e d inte rio r lig hting po we r de nsity

slide-10
SLIDE 10

@DOEE_DC

What’s Changed Since 2013?

  • 2013 DC Gre e n Co nstruc tio n Co de a nd E

ne rg y Co nse rva tio n Co de a do pte d Ma rc h 28, 2014

  • DCRA Gre e n Building Divisio n e sta b lishe d 2013
  • We ’ ve g ro wn to a te a m o f 12 pe o ple . We

ha ndle de sig n c o a c hing , pla n re vie w, inspe c tio ns, a nd c e rtific a te o f o c c upa nc y re vie ws.

  • We a lso e duc a te , tra in, a dvo c a te , de ve lo p

po lic y, & re g ula te ne w te c hno lo g y

  • F

Y16 & F Y17 = 7,392 uniq ue b uilding pe rmits

  • 480 Gre e n Co de & 190 GBA
  • 3,000 so la r pe rmits fo r 50 me g a wa tts o f so la r
slide-11
SLIDE 11

@DOEE_DC

Updates: How Are We Doing?

  • Pro je c t te a ms ha ve impro ve d c o mplia nc e ! E

spe c ia lly te na nt la yo uts

  • Co o rdina te e ne rg y mo de l with dra wing s prio r to se nding pe rmit
  • Use pe rfo rma nc e re q uire me nts fo r c o mplia nc e
  • T

he GE CS a nd E VS a re to o ls to he lp yo u c o mply. I f yo u do no t use the m o r use the m inc o rre c tly, the n yo u a re mo re like ly to se e HF C.

  • Mo st sig nific a nt Gre e n Co de issue s: E

NE RGY ST AR kitc he n e q uipme nt, pipe line le ng th, lig hting Co ntro ls - da ylig hting , sc he dule inspe c tio ns! (re vie w pe rmit/ c o ve rshe e t fo r GCC no te )

  • Mo st sig nific a nt E

ne rg y Co de issue s: sla b e dg e insula tio n, lo a d sizing , a nd lig hting c o ntro l de ta ils

What ar e you se e ing?

slide-12
SLIDE 12

@DOEE_DC

Updates: Where Are We Headed?

  • RE

CAP: Ne t-ze ro e ne rg y Co nstruc tio n

  • Re side ntia l ne w c o nstruc tio n – 2020
  • Co mme rc ia l re q uire me nts – 2026
  • We a re b uilding o ut vo lunta ry ne t-ze ro pro g ra ms

fo r re side ntia l a nd c o mme rc ia l b uilding s tha t pulls the industry fo rwa rd

  • T

he b a se c o de pushe s fro m b e hind

  • Re g io na l Ne t-Ze ro E

ne rg y Building s Co a litio n

  • L
  • o king fo r b uilding pro fe ssio na ls a c ro ss the

b o a rd who a re inte re ste d in pa rtic ipa ting

  • Gre e n Se mina r Se rie s 8/ 29 – E

ne rg y Mo de ling

  • Gre e n Building & Ne t-Ze ro E

xpo

There’s mountains beyond mountains. The devil’s in the details.

The more you know, the more you know you don’t know

slide-13
SLIDE 13

DC Energy & Green Code Update

slide-14
SLIDE 14

Timeline DC Green & Energy Code Updates

Feb 2016 Green/Energy TAG starts code updates Feb 2017 Green/Energy TAG completes code updates Code updates clear CCCB and legal review March 2018 Codes submitted to EOM Q? 2018 Public Comments? 2018 / 2019 Adoption?

slide-15
SLIDE 15

DC Green & Energy Codes are approved by CCCB:

  • Draft out for Public Comments Q? 2018.
  • Adoption in Q? 2018.
  • Any projects without permit or design contract will be kicked into

new codes. DC Green and Energy Code TAG:

  • HOK, GHT, WDG, Akridge, Paladino, JLL, WRL Design
  • DCRA, DOEE, AOBA, DC SEU, IMT

Code Update

slide-16
SLIDE 16

Added

  • Preferred parking req’ts for LE/FE, HOV vehicles
  • WaterSense pre-rinse spray valves
  • Condensate drainage recovery (New Construction & Level III Alterations)
  • Ventilation req’ts for interior fitouts
  • IAQ testing ACP for low emitting materials (moved from Appendix A)

More stringent

  • Light pollution req’ts for athletic fields and industrial areas
  • Water efficiency private kitchen faucets, public & remote WCs

Replaced / Removed

  • Section 505 IgCC with Section 505 ASHRAE 189.1 (more robust, can’t count

materials multiple times)

  • Chapter 6 (Energy) & 9 (Commissioning) -> see energy code

Green Code Update

slide-17
SLIDE 17

Appendix A

  • Includes Level II Alterations (50,000 sf+)
  • Includes first time fitouts (10,000 sf+)
  • Increasing req’d number of electives by 2
  • Bird-safe building design guidelines
  • Larger green roof coverage
  • Electric vehicle charging stations
  • Deconstruction
  • More electives for energy conservation, green power
  • More electives for LPD reduction and ADR for lighting
  • Increased insulation & higher performing windows
  • Permanent shading devices
  • Reduced air leakage
  • Waste water heat recovery
  • Recirculating hot water
  • Very high efficiency equipment
  • Condensate drainage recovery (when not req’d)
  • Wet hood exhaust scrubber systems
  • Views
  • Pre-occ AQ testing or flush out (in addition to low emitting materials)

Green Code Update

slide-18
SLIDE 18

DC will adopt:

  • ASHRAE 90.1 (2013) merged with Chapter 7 of ASHRAE 189.1 (2014) = energy

code DC will not adopt:

  • IECC 2015

New:

  • Cleaned up, streamlined language
  • More stringent req’ts for additions (>5%), alterations, core & shells

improvements

  • e.g. bldg. insulation must be brought up to code when roof is replaced
  • Measured Performance Pathway (replaces energy cost budget method with

Appendix G)

  • Stretch goals for Net Zero, Passive House, LBC (tie to incentives)

Energy Code Update

slide-19
SLIDE 19
  • More stringent envelope req’ts:
  • c.i., r-values, u-values
  • SHGC
  • Prescriptive path requires permanent

shade devices

  • Continuous Thermal Barrier
  • Best practices dehumidification &

ventilation

Energy Code Update

slide-20
SLIDE 20
  • More stringent HVAC req’ts:
  • If compressor, use heat pump instead of electric resistance
  • High occupancy areas must use CO2 sensors
  • Improve efficiency of hotel/motel HVAC
  • Automatic HVAC controls in hotels/motels
  • Fan power limitation 10% lower
  • Fan efficiency increased from 15% to 10% of maximum total efficiency
  • Exhaust air energy recovery efficiency increased from 50% to 60%
  • Supermarkets over 25,000 sf included in heat recovery req’ts
  • Restaurants and kitchens compliance threshold down from 5000 cfm to 2000 cfm
  • Spa pool insulation req’d
  • ADR equipment (not participation)
  • Higher efficiency lighting in dwellings
  • Exceptions for replacement lighting, lighting load 50%
  • Automatic controls parking lighting

Energy Code Update

slide-21
SLIDE 21
  • More stringent Lighting req’ts:
  • Higher efficiency lighting in dwellings
  • Exceptions for alterations replacement lighting, lighting load 50%
  • Automatic controls parking lighting
  • Prescriptive req’ts occupancy sensors or auto controls
  • Lower LPD cap space-by-space or building area method. ex: office 0.77 W/sf
  • Additional 20% total LPD reduction in lieu of daylight harvesting controls.
  • Daylight zone simplification (15’ from window, 3’ on either side).
  • Specialty/Decorative lighting capped at 5% of overall lighting allowance.
  • Sign lighting requirements

Energy Code Update

slide-22
SLIDE 22
  • Renewables:
  • Renewable energy space & pathways requirement (25% gross roof area).
  • Prescriptive path requires 20% roof area renewables installation (higher req’ts for

core and shell)

  • Alternate Renewables/Equipment Efficiency (higher Energy Star req’ts) 15%
  • Renewables to include biogas

Energy Code Update

slide-23
SLIDE 23
  • All Commissioning is in Energy Code – applies to all projects (IgCC or LEED

pathway)

  • Envelope Cx - new requirement
  • All bldgs. 50,000+ sf
  • 2 pathways:
  • Document peer review and assembly testing OR
  • Whole building air tightness testing
  • Req’d for projects replacing or altering 25%+ of exterior façade, glazing, or

fenestration in buildings 50,000+ sf

  • MEP Cx – lower threshold
  • All bldgs. or fit-outs 25,000+ sf
  • Req’d for any Mechanical System(s) install/replacement rated at 600,000

BTUs

Energy Code Update

slide-24
SLIDE 24
  • Alternative compliance paths:
  • Net Zero certified by ILFI
  • LBC certified (including energy petal) by ILFI
  • Passive House+

Energy Code Update

slide-25
SLIDE 25

New in the Residential Energy Code:

  • Enhanced envelope insulation and air leakage requirements
  • Energy Efficiency Options Packages (pick one mandatory)
  • Addresses alterations in a more robust way
  • Simplifies performance pathway
  • Simplifies as strips out unnecessary, non-applicable language
  • Alternative compliance paths:
  • Net Zero certified by ILFI
  • LBC certified (including energy petal) by ILFI
  • Passive House

Code Update

slide-26
SLIDE 26

DC GREEN BUILDING INCENTIVES

@DOE E _DC @DOE E _DC

CASH-FLOW POSITIVE SPECIAL TAX ASSESSMENT COMMUNITY SOLAR REBATES LMI BENEFITS PAY FOR PERFORMANCE

slide-27
SLIDE 27

T he DC Gre e n Ba nk wo uld utilize a n initia l inve stme nt o f pub lic funds a nd le ve ra g e priva te c a pita l to :

  • Cre a te jo b s a nd spur e c o no mic g ro wth;
  • Me e t the c ity’ s susta ina b ility g o a ls; a nd
  • Po sitio n DC a s a na tio na l le a de r in me e ting

the c o mmitme nts o f the Pa ris Ag re e me nt.

T his le gislation to make the Distr ic t of Columbia the fir st c ity in the Unite d State s to e stablish a Gr e e n Bank.

PROPOSED

CREDIT ENHANCEMENTS LOANS AND INVESTMENTS INFRASTRUCTURE

slide-28
SLIDE 28
slide-29
SLIDE 29

Codes and Policy Driving to Net Zero

ASHRAE DRIVING TOWARDS NET ZERO ARCHITECTURE 2030 ZERO CODE

slide-30
SLIDE 30

Mandatory Net Zero Energy/Carbon Policies

2017 2018 2020 2022 2023 2026 2030 2040

SANTA MONICA, CA

SF/low-rise Net Zero

CA Single

Family Net Zero

VANCOUVER

, Carbon Neutral

EU –

Nearly Zero, Public Bldgs

CA – 50%

New Gov Bldgs

JAPAN, All

Public Buildings Net Zero

EU, All Bldgs

Nearly Zero

OR, New Gov

Buildings Carbon Neutral

OR, New

Residential Net Zero Ready

CLEAN ENERGY DC, New SF

Net Zero

CA, All New Gov

Bldgs, and 50% Existing Bldgs

CLEAN ENERGY DC, All New

Buildings Net Zero

OR, All Gov

Bldgs Net Zero

US, All Federal

Buildings Net Zero

OR, All

Commercial Net Zero

CA, All

Commercial Net Zero, All Gov Net Zero

AIA 2030 JAPAN, All

Commercial Net Zero CAMBRIDGE, MA, All Buildings

slide-31
SLIDE 31

Feb 2016 Green/Energy TAG starts code updates Feb 2017 Green/Energy TAG completes code updates Code updates clear CCCB and legal review March 2018 Codes submitted to EOM Q? 2018 Public Comments? 2018 / 2019 Adoption?

Timeline DC Green & Energy Code Updates

slide-32
SLIDE 32

Advocacy: Contact the Mayor

@MayorBowser or eom@dc.gov Or: Mayor Bowser John A. Wilson Building 1350 Pennsylvania Avenue, NW, Washington, DC 20004 Or: Phone: (202) 727-2643

slide-33
SLIDE 33

Contact the Council: http://dccouncil.us/council

  • Chairman Phil Mendelson pmendelson@dccouncil.us or (202) 724-8032
  • Councilmember at-large Anita Bonds abonds@dccouncil.us or (202) 724-8064
  • Councilmember at-large David Grosso dgrosso@dccouncil.us or (202) 724-8105
  • Councilmember at-large Elissa Silverman esilverman@dccouncil.us or (202)-724-7772
  • Councilmember at-large Robert White rwhite@dccouncil.us or (202) 724-8174
  • Councilmember Ward 1 Brianne Nadeau bnadeau@dccouncil.us or (202) 724-8181
  • Councilmember Ward 2 Jack Evans* jevans@dccouncil.us or (202) 724-8058
  • Councilmember Ward 3 Mary Cheh** mcheh@dccouncil.us or (202) 724-8062
  • Councilmember Ward 4 Brandon Todd* btodd@dccouncil.us or (202) 724-8052
  • Councilmember Ward 5 Kenyan McDuffie* kmcduffie@dccouncil.us or (202) 724-8028
  • Councilmember Ward 6 Charles Allen* callen@dccouncil.us or (202)-724-8072
  • Councilmember Ward 7 Vincent Gray vgray@dccouncil.us or (202) 724-8068
  • Councilmember Ward 8 Trayon White twhite@dccouncil.us or (202) 724-8045

*Member Transportation & Environment Committee, **Chair Transportation & Environment Committee
