DATTA HYDRO CHEM (P) LTD. I S O 9 0 0 1 : 2 0 1 5 QUALITY - - PowerPoint PPT Presentation

May 27, 2023 479 likes •711 views

DATTA HYDRO CHEM (P) LTD. I S O 9 0 0 1 : 2 0 1 5 QUALITY MANAGEMENT SYSTEMS D H C P L INTRODUCTION COMPANY PROFILE MAVDIKAR GROUP of company. Extensive experience of THREE decades in the trading & transportation of

slide-1
SLIDE 1

DATTA HYDRO CHEM (P) LTD.

I S O 9 0 0 1 : 2 0 1 5

QUALITY MANAGEMENT SYSTEMS

slide-2
SLIDE 2

INTRODUCTION

COMPANY PROFILE

  • MAVDIKAR GROUP of company.
  • Extensive experience of THREE decades in the trading &

transportation of Petro-Chemicals.

  • Manufactures Specialty Petro-Chemicals solvents like PENTANE &

HEXANE since July 2002.

T H E FA C T O R Y I S S I T U AT E D I N A F U L LY D E V E L O P E D C H E M I C A L Z O N E AT K U R K U M B H M I D C , D I S T. P U N E , M A H A R A S H T R A , I N D I A .

I S O 9 0 0 1 : 2 0 1 5 D H C P L

slide-3
SLIDE 3

MANUFACTURING PROCESS

  • The plant designed for fractionating (Distilling) various types & grades of Hydrocarbon solvents into various

types & grades of Specialty petroleum Solvents (Industrial Grade) which are used in various types of chemical Industries such as Paints, Textile, Printing Inks, etc. operate on batch wise basis. The details of the plant operation are described in the following paragraphs.

  • The plant contains distillation column special type of packing material for better mass transfer & separation.
  • The manufacturing process involves following stages:
  • Charging Hydrocarbon Solvents / Chemicals from storage tank to distillation kettle.
  • Heating of Hydrocarbon Solvents / Chemicals by hot thermic fluid slowly.
  • Vapors are then passed through the Distillation column.
  • Vapor formed during the process is collected in Cooling water Condenser, where the vapor are condensed

and then passed through the Product Cooler & Bottoms Condenser and a part of it through the Vent Condenser.

  • Collection of different fractions of Hydrocarbon Solvents from distillation column in bulk storage tanks.

Different fractions are collected at different temperature range as per customer’s requirement.

  • As per the requirements from customers the specific fraction is blended to formulate to the required

specialty petroleum solvents

******************************************************************************

I S O 9 0 0 1 : 2 0 1 5 D H C P L

slide-4
SLIDE 4

OPERATIONS

  • Raw pentane is tested in unloaded in storage tanks after measurements.
  • Raw Pentane is charged into Kettle as per required batch size.
  • Thermic fluid & Cooling water circulation is started for process.
  • Top temperature of distillation column is maintained at specific temperature where pentane is separated and

satisfies specification of end user mainly this product is name under D Sol Pentane.

  • Further after recovery of pentane, N- hexane fraction is separated by maintaining specific temperature in

process where N Hexane reach fraction is separated and satisfies specification of end user mainly this product is name under D Sol N Hexane.

  • At different stage of process during the production of D Sol Pentane & D Sol N Hexane , a intermediate

fraction is collected which is mainly a mixture of impure Pentane and Hexane majorly and blended to satisfies end user requirement in paint and thinner industry to get cheaper hydrocarbon solvent, this product is name under D Sol 50.

  • As and when specific requirement of Petroleum Ether is received and alternate or equivalent mixture of

above pentane and hexane stream is so formulated to give boiling point result of required specification of 40 60 and vice versa with 50 70, the indicator 40 60 and 50 70 , is nothing but define the range of boiling point of blend of pentane and hexane stream with some addition of specific fraction from pentane and hexane production process, and satisfies specification of end user mainly this product is name under D Sol Petroleum Ether 40 60 and D Sol Petroleum Ether 50 70.

  • Similarly other product DSOL Pentane CP-IP-95 & DSOL Pentane CP-IP-75 is produce by distillation of crude

Cyclopentane and formulated with D Sol Pentane to required specification to satisfy end user requirement in appliance industry.

I S O 9 0 0 1 : 2 0 1 5 D H C P L

slide-5
SLIDE 5

2 3

1)CYCLOPENTANE 2)PENTANE 3)PENTANE PLUS SOURCE CONDENSATE FROM LPG REFINERY RAW MATERIAL SUPPLIER GAIL , HPL & IMPORT MANUFACTURING PROCESS FRACTIONAL DISTILLATION

PENTANE

ISO PENTANE

N PENTANE COMMERCIAL PENTANE

1

HEXANE

COMMERCIAL / FOOD GRADE HEXANE SPECIAL BOILING POINT SOLVENTS

PETROLEUM ETHER

40:60, 60:80, 40:80 & 55/115

I S O 9 0 0 1 : 2 0 1 5 D H C P L

FLOW CHART

slide-6
SLIDE 6

TO PRODUCT INDIGNEOUS QUALITY PRODUCTS

  • Dsol Pentane
  • Dsol N Hexane
  • Dsol Pentane CPIP 95
  • Dsol Pentane CPIP 75
  • Dsol Petroleum Ether 40 60
  • Dsol Petroleum Ether 50 70

I S O 9 0 0 1 : 2 0 1 5 D H C P L

slide-7
SLIDE 7

PROCESS:- Distillation Column(C-101 & C-201), Kettle Reboiler(E-101 & TH-201), Reflex Drum, Condenser, Product cooler, Bottom Cooler, Receivers, Process Intermediate tanks, Final Finished Product and Raw Material Storage tanks. CONTROL SYSTEM:- DCS Control System FM series. UTILITY :- Thermo Pack, Thermic Fluid Heater – (Thermax Pune) Cyclotherm - VTCY Series Boiler (Thermax Pune ) Cooling Tower ( M Square Engineer) Air Compressor (Ingersoll Rand) Nitrogen Blanketing Vacuum Pump (Toshniwal) DG set Eco Friendly (Kirloskar) Fire Fighting Equipment's.(Entire System)

EQUIPMENT I S O 9 0 0 1 : 2 0 1 5 D H C P L

slide-8
SLIDE 8

QC/QA

  • Quality Assurance LABORATORY in House.
  • Controlled input Raw Materials, Intermediates & Finished

Products.

  • Required tests are based on ASTM, UOP& BIS standards.
  • Analysis carried out in PPM level accuracy.
  • Modern Equipment :-

Ø Ultra Fast Trace Gas Chromatograph Make by Thermo Fisher. Ø UV 3000+ Double beam Ø Metrohm KF Coulometer (Swiss made) Ø Distillation unit, Hydrometer... etc. Ø Electrometric Autotitrator ( Bromine index) Ø Karl Fischer Autotitrator (Moisture) Ø Sulphur content analysis unit. Ø Nitrogen content analysis unit.

I S O 9 0 0 1 : 2 0 1 5

D H C P L

slide-9
SLIDE 9

ØLatest Gas Chromatograph Analyzer To Analyze

  • CO (Carbon Monoxide)
  • CO2 (Carbon di Oxide)
  • O2 (Oxygen)
  • Low Oxygenate viz :-
  • 1. Diethyl ether 2.Isovaleraldehyde 3.Valeraldehyde
  • 4. Acetaldehyde 5.Methyle pert. Butyl ether

6.Disoprpylether 7.Butyraldehyde 8.Propylether 9.Methnol 10. Acetone 11.Propanol 12. Tert.amyl methyl ether

  • 13. 2-Butanone 14. Ethanol. 15.Propylether

16.Propanol 17. Tert. Butanol 18.Ethanol 19.1- Butanol

QC/QA

D H C P L I S O 9 0 0 1 : 2 0 1 5

slide-10
SLIDE 10

ØElectrometric Auto Titrator ( Bromine index) ØKarl Fischer Auto Titrator Moisture) ØSulphur content analysis unit. ØSpectrophotometer. ( LAB INDIA) Ø Shaw Meter for Due Point. ØMetrohm KF Coulometer (Swiss Made) ØDistillation unit, Hydrometer.. etc.

QC/QA

I S O 9 0 0 1 : 2 0 1 5 D H C P L

slide-11
SLIDE 11

QUALITY

MANAGEMENT

SYSTEM

  • ISO 9001:2015 by World wide

recognized Accredited certification Body DNV.

  • DEVELOPMENT

MANUFACTURE AND SUPPLY OF SPECIALTY HYDROCARBON SOLVENTS LIKE ALKANE

I S O 9 0 0 1 : 2 0 1 5 D H C P L

ISO 9001:2015

QUALITY MANAGEMENT SYSTEMS

slide-12
SLIDE 12

C A P I T A L I N V E S T M E N T I N I N R : - 4 2 C R

I S O 9 0 0 1 : 2 0 1 5

  • 5.00

10.00 15.00 20.00 25.00 30.00 35.00 40.00 45.00

sales

slide-13
SLIDE 13

VISION

  • To establish as a “World Class Company” in the field of Pentane Products.
  • To achieve continuous profitable business growth
  • Stake holder satisfaction & pride
  • Fulfillment of social obligations

ACHIEVEMENT

  • Established an in-house R&D, which lead to the development of an OWN TECHNOLOGY

for producing Pentane and Hexane quality Products.

  • Fulfillment of QUALITY PRODUCTS as per customer requirement.
  • Certification awarded by world renowned certification authority DNV as ISO 9001:2015

QMS certified company, being first in India among Pentane manufacturers.

  • First DCS CONTROL fully automatic plant.

I S O 9 0 0 1 : 2 0 1 5 D H C P L

VISION AND ACHIEVMENT

slide-14
SLIDE 14

A D D I T I O N A L F A C I L I T I E S

u COMPANY OWN DEDICATED ROAD TANKER. SPECIALLY DESIGNED AND APPROVED BY PESO FOR ONLY PENTANE LOGISTIC. u IN HOUSE DIGITAL 60 MT WEIGH BRIDGE TO ENSURE TRUE AND CORRECT MEASURMENT OF PRODUCT. TO AVOID ANY CONTAMINATIONS IN PRODUCT u ECOFREINDLY EQUIPMENT USED TO AVOID FOSSIEL FUEL IN PRODUCTION. u DG SET AND ONLINE UPS INSTALLED TO ENSURE SMOOTH OPERATION. TO ENSURE RIGHT & ACCURATE WEIGHT CYCLOTHERM- VTCY SERIES FOR ECOFREINDLY FUEL UNINTERRUPTED POWER DEDICATED ROAD PENTANE TANKER

D H C P L

slide-15
SLIDE 15

– U s u a l l y i n a H yd ro ca r b o n h a n d l i n g a n d p ro c e s s i n g In d u st r y A c c i d e nt s ta ke p l a c e d u e to G a s L e a ka ge & E l e c t r i ca l Fa u l t s i n t h e O P E R AT I O N A L A R EA S . – A s o n to d ay t h e co nve nt i o n a l p ra c t i c e to f i n d o u t l e a ka ge i s N OT S U F F I C E N T TO P I N P O I N T T H E E X AC T FAU LTS . – Re p o r t o f te st i n g s e r v i c e s ta ke s m o re t i m e a n d i s a l ways w i t h t h e l i m i tat i o n to t h e s at u rat i o n o f G A S VO LU M E . – Re p o r t p ro d u c e d by s e r v i c e p rov i d e r a re m o st o f t h e t i m e i n CO N F U S I O N w i t h t h e a c t u a l f i e l d o p e rato rs , S afe ty

  • f f i c e rs , S e n i o r M a n a ge m e nt a n d th e M o st I m p o r ta nt

P r in c ip le M a n u fa c tu re r / S u p p lie r o f th at p a r tic u la r Pa r t o r Eq u ip m e nt .

I S O 9 0 0 1 : 2 0 1 5 D H C P L

I N D U S T R I A L S A F E T Y

slide-16
SLIDE 16

– U s u a l l y E l e c t r i ca l In sta l l at i o n fa u l t s a re n o t n o t i c e d

  • r e a r l y d e te c te d .

– M a ny t i m e s i n a e l e c t r i ca l f i tt i n g s e r ro rs a re o bs e r ve d u r i n g co n n e c t i o n s w h i c h re s u l t s to t h e ca u s e o f e m e rge n c y b re a k d ow n . – T h i s E l e c tr i ca l Fa u l ts i n tu r n l e a d s to th e s o u rc e o f E n e rg y to th e s u r ro u n d in g G a s le a ka ge a n d th e co m b in atio n re s u lts to u ltim ate F I R E in c id e nts . – F IR E i n c i d e nt a re u s u a l l y co u nt l e s s a n d ve r y p a i nf u l to t h e O rga n i zat i o n . – M o re t i m e i s re q u i re d to re g u l a r i ze a n d n o r m a l i ze t h e A c c i d e nt S i t u at i o n .

I S O 9 0 0 1 : 2 0 1 5 D H C P L

I N D U S T R I A L S A F E T Y

slide-17
SLIDE 17
  • D H C P L O B J E C T I V E T O I N D U S T R Y T O W A R D S

G L O B A L S A F E T Y .

  • I N T I A T I V E S T E P T O W A R D S

S A V I N G O F N A T I O N A L P R O P E R T Y .

  • A S T E P T O W A R D S P R O T E C T I N G

G L O B A L W A R M I N G .

  • D H C P L O B J E C T I V E T O E N H A N C I N G I T S C L I E N T S

P R O F I T A B I L I T Y A N D R E D U C E I T S O P E R A T I N G L O S S E S .

I S O 9 0 0 1 : 2 0 1 5 D H C P L

I N D U S T R I A L S A F E T Y

slide-18
SLIDE 18
  • To extend Unique and Guaranteed Solution to the Pin Pointing of Exact

Hydrocarbon Gas Leak spots. (PENTANE VAPOUR)

  • Similarly other refrigerant's like R600 & R600 a , Gas Leakage exact spots can also

be detected.

  • To extend Unique and Guaranteed Solution to the Pin Pointing of Exact Electrical

faults in Hydrocarbon solvent Storage area.

  • DHCPL will report real time …… REPORT of the exact fault for 100% assurance to

the Management and Safety officers at their desktop.

  • If fault is located 100% assurance to satisfy its prime principle supplier.

I S O 9 0 0 1 : 2 0 1 5 D H C P L

slide-19
SLIDE 19
  • 100% Guaranteed NO CONFUSION

in f i e l d o p e ra t o r, S a f e t y

  • f f i c e r s , S e n i o r M a n a g e m e n t a n d t h e M o s t I m p o r t a n t

P r i n c i p a l M a n u f a c t u r e r / S u p p l i e r o f t h a t p a r t i c u l a r P a r t o r E q u i p m e n t .

  • Extremely SPEEDY service

to initialize immediate PROMPT ACTION by Safety Officer without any doubts.

  • Most important facility in this service is availability of revalidation and 100%

assurance of complaisance done by respective agencies.

  • A complimentary Service Free Of Charge will be extended for One Man Day.
  • The above service is itself is unique and not at all available with any other

service provider in INDIA.

I S O 9 0 0 1 : 2 0 1 5 D H C P L

slide-20
SLIDE 20

REGISTERED OFFICE:

204, Vinayak House,

  • Opp. Bank of Saurashtra,

Sector 19 , Vashi, Navi Mumbai. : 400 703 Email : sales@dhcpl.com

FACTORY:

Plot No. A-56/57/48, MIDC Kurkumbh Tal.: Daund Dist.: Pune Pin Code: 413 105 Email: sarkar@dhcpl.com

Website: www.dhcpl.com E M A I L : a t u l @ d h c p l . c o m & s a l e s @ d h c p l . c o m

ADMINISTRATIVE OFFICE:

S.NO. 418 A /1067/A, 1St floor, Flat no. 3, Mandke Abhusan Near Om Super Market, Gokhale Road, Model Colony, PUNE-411016 Tel / Fax : + 91 20 4120 8937 Mobile No.: +91 99220 88700 Email : dhcpl.pune@gmail.com

DATTA HYDRO CHEM PVT . LTD.

I S O 9 1 : 2 1 5 CIN NO: U24110MH1999PTC120629

slide-21
SLIDE 21

We look forward to develop an everlasting relationship with you.
