SLIDE 1
Database Systems Do Not Scale to 1000 CPU Cores
And Other Tales of the Macabre
@andy_pavlo
2
Three million children die per year due to poor nutrition.
Source: http://www.wfp.org/hunger/statsDatabase Systems Do Not Scale to 1000 CPU Cores And Other Tales of - - PowerPoint PPT Presentation
Database Systems Do Not Scale to 1000 CPU Cores And Other Tales of - - PowerPoint PPT Presentation
Database Systems Do Not Scale to 1000 CPU Cores And Other Tales of the Macabre @ andy_pavlo 2 Three million children die per year due to poor nutrition. Source: http://www.wfp.org/hunger/stats 3 Three days after you die, stomach enzymes
SLIDE 2
SLIDE 3
3
Three days after you die, stomach enzymes start to digest you.
Source: http://discovermagazine.com/2006/sep/10-20thingsdeath SLIDE 4
4
Everyone in this room will be dead in 65 years.
Source: http://discovermagazine.com/2006/sep/10-20thingsdeath SLIDE 5
5
Database systems cannot scale to 1000 CPU cores.
Source: http://www.vldb.org/pvldb/vol8/p209-yu.pdf SLIDE 6
YCSB //
6
DBx1000 on Graphite Simulator Write-Intensive Workload High Contention
SLIDE 7
Why This Matters
- The era of single-core CPU speed-up is over.
- Database applications are getting more
complex and larger.
- Existing DBMSs are unable to take advantage of
future “many-core” CPU architectures.
7
SLIDE 8
Today’s Talk
- Transaction Processing
- Experimental Platform
- Evaluation & Discussion
- The (Dire) Future
8
SLIDE 9
9
Transaction Processing
SLIDE 10
On-line Transaction Processing
- Fast operations that ingest new data and then
update state using ACID transactions.
- Transaction Example:
– Send $50 from user A to user B
10
SLIDE 11
Concurrency Control
- Allows transactions to access a database in a
multi-programmed fashion while preserving the illusion that each of them is executing alone on a dedicated system.
- Provides Atomicity + Isolation in ACID
11
SLIDE 12
Concurrency Control
- Two-Phase Locking (Pessimistic)
- Timestamp Ordering (Optimistic)
12
SLIDE 13
Two-Phase Locking (2PL)
13
Transaction #1
BEGIN COMMIT
LOCK(A) LOCK(B) UNLOCK(A) UNLOCK(B) READ(A) WRITE(B)
Shrinking Phase
LOCK(A) LOCK(B)
Growing Phase
SLIDE 14
Transaction #2
BEGIN COMMIT
LOCK(B) LOCK(A) WRITE(A) UNLOCK(A) UNLOCK(B) WRITE(B)
Two-Phase Locking (2PL)
14
Transaction #1
BEGIN COMMIT
LOCK(A) LOCK(B) UNLOCK(A) UNLOCK(B) READ(A) WRITE(B) LOCK(A) LOCK(B)
SLIDE 15
Transaction #2
BEGIN COMMIT
LOCK(B) LOCK(A) WRITE(A) UNLOCK(A) UNLOCK(B) WRITE(B)
Two-Phase Locking (2PL)
15
Transaction #1
BEGIN COMMIT
LOCK(A) LOCK(B) UNLOCK(A) UNLOCK(B) READ(A) WRITE(B) LOCK(A) LOCK(B)
SLIDE 16
Two-Phase Locking (2PL)
- Deadlock Detection (DEADLOCK)
- Non-waiting Deadlock Prevention (NO_WAIT)
- Wait-and-Die Deadlock Prevention (WAIT_DIE)
16
SLIDE 17
Record Read Timestamp Write Timestamp
A B 10000
Timestamp Ordering (T/O)
17
Transaction #1
BEGIN COMMIT
READ(A) WRITE(B) WRITE(A)
- • • •
10000 10000
- • •
10000
10001
SLIDE 18
Record Read Timestamp Write Timestamp
A B 10000
Timestamp Ordering (T/O)
18
Transaction #1
BEGIN COMMIT
READ(A) WRITE(B) WRITE(A)
- • • •
10001 10001
- • •
10000
10001
SLIDE 19
Record Read Timestamp Write Timestamp
A B 10000
Timestamp Ordering (T/O)
19
Transaction #1
BEGIN COMMIT
READ(A) WRITE(B) WRITE(A)
- • • •
10001 10001
- • •
10005
10001
SLIDE 20
Timestamp Ordering (T/O)
- Basic T/O (TIMESTAMP)
- Multi-Version Concurrency Control (MVCC)
- Optimistic Concurrency Control (OCC)
20
SLIDE 21
Concurrency Control Schemes
21
DL_DETECT NO_WAIT WAIT_DIE 2PL w/ Deadlock Detection 2PL w/ Non-waiting Prevention 2PL w/ Wait-and-Die Prevention TIMESTAMP MVCC OCC Basic T/O Algorithm Multi-Version T/O Optimistic Concurrency Control
SLIDE 22
22
Evaluation Testbed
SLIDE 23
23
No DBMS supports multiple CC schemes. No CPU supports 1000 cores.
SLIDE 24
Experimental Platform
24
DBx1000 Graphite Simulator Compute Cluster
Core L2 L1
Worker Threads
SLIDE 25
Target Workload
- Yahoo! Cloud Serving Benchmark (YCSB)
– 20 million tuples – Each tuple is 1KB (total database is ~20GB)
- Each transactions reads/modifies 16 tuples.
- Varying skew in transaction access patterns.
- Serializable isolation level.
25
SLIDE 26
26
Evaluation
SLIDE 27
YCSB //
27
DBx1000 on Graphite Simulator Read-Only Workload No Contention
SLIDE 28
YCSB //
28
DBx1000 on Graphite Simulator Write-Intensive Workload Medium Contention
SLIDE 29
YCSB //
29
DBx1000 on Graphite Simulator Write-Intensive Workload High Contention
SLIDE 30
YCSB //
Time % Breakdown (512 Cores)
30
DBx1000 on Graphite Simulator Write-Intensive Workload High Contention
SLIDE 31
Bottlenecks
- Lock Thrashing
– DL_DETECT, WAIT_DIE
- Timestamp Allocation
– All T/O algorithms + WAIT_DIE
- Memory Allocations
– OCC + MVCC
31
SLIDE 32
Bottlenecks
- Lock Thrashing
– DL_DETECT, WAIT_DIE
- Timestamp Allocation
– All T/O algorithms + WAIT_DIE
- Memory Allocations
– OCC + MVCC
32
SLIDE 33
Locking Thrashing
- Each transaction waits longer to acquire locks,
causing other transactions to wait a longer to acquire locks.
- The perfect workload is where transactions
acquire locks in primary key order.
33
SLIDE 34
YCSB //
34
DBx1000 with 2PL DL_DETECT Write-Intensive Workload No Deadlocks (Ordered Lock Acquisition)
SLIDE 35
YCSB //
35
DBx1000 with 2PL DL_DETECT Write-Intensive Workload No Deadlocks (Ordered Lock Acquisition)
SLIDE 36
36
Potential Solutions
SLIDE 37
Hardware/Software Co-Design
- Bottlenecks can only be overcome through
new hardware-level optimizations:
– Hardware-accelerated Lock Sharing – Asynchronous Memory Copying – Decentralized Memory Controller.
37
SLIDE 38
Next Steps
- Evaluating other main bottlenecks in DBMSs:
– Logging + Recovery – Indexes
- Extend DBx1000 to support distributed
concurrency control algorithms.
38
SLIDE 39
39
Andy Pavlo Mike Stonebraker Srini Devadas Xiangyao Yu
http://cmudb.io/1000cores
SLIDE 40
END
@andy_pavlo
