Motivations L-Store Evaluation Conclusions L-Store: A Real-time OLTP and OLAP System Mohammad Sadoghi Souvik Bhattacharjee , Bishwaranjan Bhattacharjee # , Mustafa Canim # Exploratory Systems Lab University of California, Davis

slide-1
SLIDE 1

Motivations L-Store Evaluation Conclusions

L-Store: A Real-time OLTP and OLAP System

Mohammad Sadoghi†

Souvik Bhattacharjee‡, Bishwaranjan Bhattacharjee#, Mustafa Canim#

†Exploratory Systems Lab † University of California, Davis

‡ University of Maryland, College Park # IBM T.J. Watson

EDBT’18 (March 27, 2018)

Mohammad Sadoghi (UC Davis) EDBT’18 1 / 16

slide-2
SLIDE 2

Motivations L-Store Evaluation Conclusions

Data Management at Macroscale: The Four V’s of Big Data

John Doe

Mohammad Sadoghi (UC Davis) EDBT’18 2 / 16

slide-3
SLIDE 3

Motivations L-Store Evaluation Conclusions

Data Management at Macroscale: The Four V’s of Big Data

John Doe

Mohammad Sadoghi (UC Davis) EDBT’18 2 / 16

slide-4
SLIDE 4

Motivations L-Store Evaluation Conclusions

Data Management at Microscale: Volume & Velocity

OLTP (Write-optimized) Data Velocity

Sales

Mohammad Sadoghi (UC Davis) EDBT’18 2 / 16

slide-5
SLIDE 5

Motivations L-Store Evaluation Conclusions

Data Management at Microscale: Volume & Velocity

OLAP (Read-optimized)

OLTP (Write-optimized)

Extract-Transform-Load (ETL)

Data Velocity

Sales Reports

Data Volume

Data is Stale

Mohammad Sadoghi (UC Davis) EDBT’18 2 / 16

slide-6
SLIDE 6

Motivations L-Store Evaluation Conclusions

Data Management at Microscale: Volume & Velocity

OLAP (Read-optimized)

OLTP (Write-optimized)

Extract-Transform-Load (ETL)

Data Volume

Data Velocity

Sales Reports

Mohammad Sadoghi (UC Davis) EDBT’18 2 / 16

slide-7
SLIDE 7

Motivations L-Store Evaluation Conclusions

One Size Does not Fit All As of 2012

Mohammad Sadoghi (UC Davis) EDBT’18 3 / 16

slide-8
SLIDE 8

Motivations L-Store Evaluation Conclusions

One Size Does not Fit All As of 2017

Mohammad Sadoghi (UC Davis) EDBT’18 3 / 16

slide-9
SLIDE 9

Motivations L-Store Evaluation Conclusions

Data Management at Microscale: Volume & Velocity

OLAP+OLTP (Read & Write-

  • ptimized)

Reports Sales

Mohammad Sadoghi (UC Davis) EDBT’18 4 / 16

slide-10
SLIDE 10

Motivations L-Store Evaluation Conclusions

Storage Layout Conflict

Read Optimized (compressed, read-only pages) Write Optimized (uncompressed in-place updates) Columnar Storage Row-based Storage

Write-optimized (i.e., uncompressed & row-based) vs. read-optimized (i.e., compressed & column-based) layouts

Mohammad Sadoghi (UC Davis) EDBT’18 5 / 16

slide-11
SLIDE 11

Motivations L-Store Evaluation Conclusions

Unifying OLTP and OLAP: Velocity & Volume Dimensions

Observed Trends In operational databases, there is a pressing need to close the gap between the write-optimized layout for OLTP (i.e., row-wise) and the read-optimized layout for OLAP (i.e., column-wise).

Mohammad Sadoghi (UC Davis) EDBT’18 6 / 16

slide-12
SLIDE 12

Motivations L-Store Evaluation Conclusions

Unifying OLTP and OLAP: Velocity & Volume Dimensions

Observed Trends In operational databases, there is a pressing need to close the gap between the write-optimized layout for OLTP (i.e., row-wise) and the read-optimized layout for OLAP (i.e., column-wise). Introducing a lineage-based storage architecture, a contention-free update mechanism over a native columnar storage in order to

Mohammad Sadoghi (UC Davis) EDBT’18 6 / 16

slide-13
SLIDE 13

Motivations L-Store Evaluation Conclusions

Unifying OLTP and OLAP: Velocity & Volume Dimensions

Observed Trends In operational databases, there is a pressing need to close the gap between the write-optimized layout for OLTP (i.e., row-wise) and the read-optimized layout for OLAP (i.e., column-wise). Introducing a lineage-based storage architecture, a contention-free update mechanism over a native columnar storage in order to lazily and independently stage stable data from a write-optimized layout (i.e., OLTP) into a read-optimized layout (i.e., OLAP)

Mohammad Sadoghi (UC Davis) EDBT’18 6 / 16

slide-14
SLIDE 14

Motivations L-Store Evaluation Conclusions

Lineage-based Storage Architecture (LSA): Intuition

Base Pages (Read-only) Tail Pages (Append-only) Index Lineage Mapping

(indirection layer, stable LID-to-RID mapping)

Base Version

( anchored RIDs)

Latest Version

(monotonically increasing RIDs)

In-page Lineage Tacking Points to Stable LIDs

(i.e., anchored RID) RIDi RIDi RIDk RIDj

Physical Update Independence: De-coupling data & its updates (reconstruction via in-page lineage tracking and lineage mapping)

Mohammad Sadoghi (UC Davis) EDBT’18 7 / 16

slide-15
SLIDE 15

Motivations L-Store Evaluation Conclusions

Lineage-based Storage Architecture (LSA): Intuition

Base Pages (Read-only) Tail Pages (Append-only) Index Lineage Mapping

(indirection layer, stable LID-to-RID mapping)

Base Version

( anchored RIDs)

Latest Version

(monotonically increasing RIDs)

Append-only Updates

(physical update independence)

In-page Lineage Tacking Points to Stable LIDs

(i.e., anchored RID)

Monotonically Increasing Lineage

(updates are assigned RIDs in an increasing order) RIDi RIDi RIDk RIDj

Physical Update Independence: De-coupling data & its updates (reconstruction via in-page lineage tracking and lineage mapping)

Mohammad Sadoghi (UC Davis) EDBT’18 7 / 16

slide-16
SLIDE 16

Motivations L-Store Evaluation Conclusions

Lineage-based Storage Architecture (LSA): Intuition

Base Pages (Read-only) Tail Pages (Append-only) Index Lineage Mapping

(indirection layer, stable LID-to-RID mapping)

Base Version

(stable anchored RIDs)

Latest Version

(monotonically increasing RIDs)

Append-only Updates

(physical update independence)

Lazy Update Consolidation

(snapshot reconstruction via lineage mapping & in-page tracking)

In-page Lineage Tacking In-page Lineage Tacking Data Block RIDs Remain Unchanged

(stable reference, anchored RIDs) Points to Stable LIDs (i.e., anchored RID)

Monotonically Increasing In-page Lineage Monotonically Increasing Lineage

(updates are assigned RIDs in an increasing order) RIDi

Consolidated Data (Read-only)

RIDi RIDk RIDj

Physical Update Independence: De-coupling data & its updates (reconstruction via in-page lineage tracking and lineage mapping)

Mohammad Sadoghi (UC Davis) EDBT’18 7 / 16

slide-17
SLIDE 17

Motivations L-Store Evaluation Conclusions

Lineage-based Storage Architecture (LSA): Overview

Columnar Storage Base Pages (read-only) Tail Pages (append-only) Range Partitioning Page Directory Record (spanning over a set of aligned columns)

Overview of the lineage-based storage architecture (base pages and tail pages are handled identically at the storage layer)

Mohammad Sadoghi (UC Davis) EDBT’18 8 / 16

slide-18
SLIDE 18

Motivations L-Store Evaluation Conclusions

L-Store: Detailed Design

Columnar Storage Range Partitioning Base Pages (read-only) Read Optimized (compressed, read-only pages)

Records are range-partitioned and compressed into a set of ready-only base pages (accelerating analytical queries)

Mohammad Sadoghi (UC Davis) EDBT’18 9 / 16

slide-19
SLIDE 19

Motivations L-Store Evaluation Conclusions

L-Store: Detailed Design

Write Optimized (uncompressed, append-only updates) Updated Columns Corresponding Columns Base Pages (read-only) Tail Pages (append-only) Read Optimized (compressed, read-only pages)

Recent updates for a range of records are clustered in their tails pages (transforming costly point updates into an amortized analytical-like query)

Mohammad Sadoghi (UC Davis) EDBT’18 9 / 16

slide-20
SLIDE 20

Motivations L-Store Evaluation Conclusions

L-Store: Detailed Design

Write Optimized (uncompressed, append-only updates) Updated Columns Base Pages (read-only) Tail Pages (append-only) Different Versions

  • f the Record

Base Record (older version) Tail Record (latest version) Read Optimized (compressed, read-only pages)

Recent updates for a range of records are clustered in their tails pages (transforming costly point updates into an amortized analytical-like query)

Mohammad Sadoghi (UC Davis) EDBT’18 9 / 16

slide-21
SLIDE 21

Motivations L-Store Evaluation Conclusions

L-Store: Detailed Design

Write Optimized (uncompressed, append-only updates) Pre-allocated Space (lazily) Base Pages (read-only) Tail Pages (append-only) Read Optimized (compressed, read-only pages)

Recent updates are strictly appended, uncompressed in the pre-allocated space (eliminating the read/write contention)

Mohammad Sadoghi (UC Davis) EDBT’18 9 / 16

slide-22
SLIDE 22

Motivations L-Store Evaluation Conclusions

L-Store: Detailed Design

Write Optimized (uncompressed, append-only updates) Indirection Column (uncompressed, in-place update) Forward Pointer to the Latest Version of the Record Indirection Column (back pointer to the previous version) Read Optimized (compressed, read-only pages)

Achieving (at most) 2-hop access to the latest version of any record (avoiding read performance deterioration for point queries)

Mohammad Sadoghi (UC Davis) EDBT’18 9 / 16

slide-23
SLIDE 23

Motivations L-Store Evaluation Conclusions

L-Store: Detailed Design

Write Optimized (uncompressed, append-only updates) Indirection Column (uncompressed, in-place update) Indirection Column (back pointer to the previous version) New Version Read Optimized (compressed, read-only pages)

Achieving (at most) 2-hop access to the latest version of any record (avoiding read performance deterioration for point queries)

Mohammad Sadoghi (UC Davis) EDBT’18 9 / 16

slide-24
SLIDE 24

Motivations L-Store Evaluation Conclusions

L-Store: Detailed Design

Write Optimized (uncompressed, append-only updates) Indirection Column (uncompressed, in-place update) Indirection Column (back pointer to the previous version) New Version Read Optimized (compressed, read-only pages) Backward Pointer

Achieving (at most) 2-hop access to the latest version of any record (avoiding read performance deterioration for point queries)

Mohammad Sadoghi (UC Davis) EDBT’18 9 / 16

slide-25
SLIDE 25

Motivations L-Store Evaluation Conclusions

L-Store: Contention-free Merge

Write Optimized (uncompressed, append-only updates) Merge Queue (tail pages to be merged) Consecutive Set of Committed Updates Indirection Column (uncompressed, in-place update) Read Optimized (compressed, read-only pages)

Contention-free merging of only stable data: read-only and committed data (no need to block on-going and new transactions)

Mohammad Sadoghi (UC Davis) EDBT’18 9 / 16

slide-26
SLIDE 26

Motivations L-Store Evaluation Conclusions

L-Store: Contention-free Merge

Read Optimized (compressed, read-only pages) Write Optimized (uncompressed, append-only updates)

⋈ =

Asynchronous Lazy Merge (committed, consecutives updates) Indirection Column (uncompressed, in-place update) Merge Queue (tail pages to be merged)

Lazy independent merging of base pages with their corresponding tail pages (resembling a local left outer-join of the base and tail pages)

Mohammad Sadoghi (UC Davis) EDBT’18 9 / 16

slide-27
SLIDE 27

Motivations L-Store Evaluation Conclusions

L-Store: Contention-free Merge

Write Optimized (uncompressed, append-only updates) In-page, Independent Lineage Tracking Asynchronous Lazy Merge (committed, consecutives updates)

⋈ =

Indirection Column (uncompressed, in-place update) Read Optimized (compressed, read-only pages)

Independently tracking the lineage information within every page (no need to coordinate merges among different columns of the same records)

Mohammad Sadoghi (UC Davis) EDBT’18 9 / 16

slide-28
SLIDE 28

Motivations L-Store Evaluation Conclusions

L-Store: Epoch-based Contention-free De-allocation

Epoch-based De-allocation (longest running query) Page Directory Indirection Column (uncompressed, in-place update) Write Optimized (uncompressed, append-only updates) Read Optimized (compressed, read-only pages) Asynchronous Lazy Merge

⋈ =

Contention-free page de-allocation using an epoch-based approach (no need to drain the ongoing transactions)

Mohammad Sadoghi (UC Davis) EDBT’18 9 / 16

slide-29
SLIDE 29

Motivations L-Store Evaluation Conclusions

L-Store: Epoch-based Contention-free De-allocation

In-page, Independent Lineage Tracking Page Directory Indirection Column (uncompressed, in-place update) Write Optimized (uncompressed, append-only updates) Epoch-based De-allocation (longest running query) Read Optimized (compressed, read-only pages)

Contention-free page de-allocation using an epoch-based approach (no need to drain the ongoing transactions)

Mohammad Sadoghi (UC Davis) EDBT’18 9 / 16

slide-30
SLIDE 30

Motivations L-Store Evaluation Conclusions

L-Store: Epoch-based Contention-free De-allocation

Page Directory Indirection Column (uncompressed, in-place update) Write Optimized (uncompressed, append-only updates) Epoch-based De-allocation (longest running query) Asynchronous Lazy Merge

⋈ =

Read Optimized (compressed, read-only pages)

Contention-free page de-allocation using an epoch-based approach (no need to drain the ongoing transactions)

Mohammad Sadoghi (UC Davis) EDBT’18 9 / 16

slide-31
SLIDE 31

Motivations L-Store Evaluation Conclusions

L-Store: Epoch-based Contention-free De-allocation

Page Directory Indirection Column (uncompressed, in-place update) Write Optimized (uncompressed, append-only updates) Epoch-based De-allocation (longest running query) Asynchronous Lazy Merge

⋈ =

Read Optimized (compressed, read-only pages)

Contention-free page de-allocation using an epoch-based approach (no need to drain the ongoing transactions)

Mohammad Sadoghi (UC Davis) EDBT’18 9 / 16

slide-32
SLIDE 32

Motivations L-Store Evaluation Conclusions

L-Store: Epoch-based Contention-free De-allocation

Epoch-based De-allocation (longest running query) In-page, Independent Lineage Tracking Write Optimized (uncompressed, append-only updates) Page Directory Indirection Column (uncompressed, in-place update) Asynchronous Lazy Merge

⋈ =

Read Optimized (compressed, read-only pages)

Contention-free page de-allocation using an epoch-based approach (no need to drain the ongoing transactions)

Mohammad Sadoghi (UC Davis) EDBT’18 9 / 16

slide-33
SLIDE 33

Motivations L-Store Evaluation Conclusions

Experimental Analysis

Mohammad Sadoghi (UC Davis) EDBT’18 10 / 16

slide-34
SLIDE 34

Motivations L-Store Evaluation Conclusions

Experimental Settings

Hardware:

2 × 6-core Intel(R) Xeon(R) CPU E5-2430 @ 2.20GHz, 64GB, 15 MB L3 cache

Workload: Extended Microsoft Hekaton Benchmark

Comparison with In-place Update + History and Delta + Blocking Merge Effect of varying contention levels Effect of varying the read/write ratio of short update transactions Effect of merge frequency on scan Effect of varying the number of short update vs. long read-only transactions Effect of varying L-Store data layouts (row vs. columnar) Effect of varying the percentage of columns read in point queries Comparison with log-structured storage architecture (LevelDB)

Mohammad Sadoghi (UC Davis) EDBT’18 11 / 16

slide-35
SLIDE 35

Motivations L-Store Evaluation Conclusions

Effect of Varying Contention Levels

0.2 0.4 0.6 0.8 1 5 10 15 20 25

Throughput (M txns/s)

Number of Parallel Short Update Transactions

L-Store In-place Update + History Delta + Blocking Merge

0.5 1 1.5 2 5 10 15 20 25

Throughput (M txns/s)

Number of Parallel Short Update Transactions

L-Store In-place Update + History Delta + Blocking Merge

Achieving up to 40× as increasing the update contention

Mohammad Sadoghi (UC Davis) EDBT’18 12 / 16

slide-36
SLIDE 36

Motivations L-Store Evaluation Conclusions

Effect of Merge Frequency on Scan Performance

0.5 1 1.5 2 2.5 4K 8K 16K 32K 64K

Scan Execution Time (in seconds) Number of Tail Records Processed per Merge

Mixed OLTP + OLAP Workload; Low Contention (1 Scan + 1 Merge Threads, Page Size = 32 KB)

Scan Performance (4 Update Threads) Scan Performance (14 Update Threads)

Merge process is essential in maintaining efficient scan performance

Mohammad Sadoghi (UC Davis) EDBT’18 13 / 16

slide-37
SLIDE 37

Motivations L-Store Evaluation Conclusions

Effect of Mixed Workloads: Update Performance

0.2 0.4 0.6 0.8 1 1 4 8 12 16 Update Throughput (million of txn/s)

Number of Parallel Update Transactions

Mixed OLTP + OLAP Workload; Medium Contention (Total of 17 Threads + 1 Merge Thread, Page Size = 32 KB)

Lineage-based Data Store (L-Store) In-place Update + History Delta + Blocking Merge

Eliminating latching & locking results in a substantial performance improvement

Mohammad Sadoghi (UC Davis) EDBT’18 14 / 16

slide-38
SLIDE 38

Motivations L-Store Evaluation Conclusions

Effect of Mixed Workloads: Read Performance

200 400 600 800 1 5 9 13 16

Read Throughput (txn/s) Number of Parallel Read-only Transactions

Mixed OLTP + OLAP Workload; Medium Contention (Total of 17 Threads + 1 Merge Thread, Page Size = 32 KB)

Lineage-based Data Store (L-Store) In-place Update + History Delta + Blocking Merge

Coping with tens of update threads with a single merge thread

Mohammad Sadoghi (UC Davis) EDBT’18 14 / 16

slide-39
SLIDE 39

Motivations L-Store Evaluation Conclusions

L-Store Key Contributions

Unifying OLAP & OLTP by introducing lineage-based storage architecture (LSA) LSA is a native multi-version, columnar storage model that lazily & independently stages data from a write-optimized layout into a read-optimized one Contention-free merging of only stable data without blocking ongoing

  • r incoming transactions

Contention-free page de-allocation without draining ongoing transactions L-Store outperforms in-place update & delta approaches by factor of up to 8× on mixed OLTP/OLAP workloads and up to 40× on update-intensive workloads

Mohammad Sadoghi (UC Davis) EDBT’18 15 / 16

slide-40
SLIDE 40

Motivations L-Store Evaluation Conclusions

Questions? Thank you!

Exploratory Systems Lab (ExpoLab) Website: https://msadoghi.github.io/

Mohammad Sadoghi (UC Davis) EDBT’18 16 / 16
