Data Warehousing and OLAP

CMPT 354: Database I -- Data Warehousing and OLAP 2

Decision Support Systems

• Decision-support systems are used to make

business decisions, often based on data collected by online transaction-processing systems

• Examples of business decisions:

– What items to stock? – What insurance premium to change? – To whom to send advertisements?

• Examples of data used for making decisions

– Retail sales transaction details – Customer profiles (income, age, gender, etc.)

CMPT 354: Database I -- Data Warehousing and OLAP 3

Data and Statistical Analysis

• Data analysis tasks are simplified by

specialized tools and SQL extensions

– Example tasks

• For each product category and each region, what

were the total sales in the last quarter and how do they compare with the same quarter last year

• As above, for each product category and each

customer category

• Statistical analysis packages (e.g., SAS)

can be interfaced with databases

CMPT 354: Database I -- Data Warehousing and OLAP 4

Data Analysis and OLAP

• Online Analytical Processing (OLAP)

– Interactive analysis of data, allowing data to be summarized and viewed in different ways in an online fashion (with negligible delay)

• Multidimensional data: data modeled as dimension

attributes and measure attributes

– Dimension attributes: define the dimensions on which measure attributes (or aggregates thereof) are viewed, e.g. the attributes item_name, color, and size of the sales relation – Measure attributes: can be aggregated upon, e.g., the attribute number of the sales relation

CMPT 354: Database I -- Data Warehousing and OLAP 5

Pivot Table

• Values for one of the dimension attributes form the row headers
• Values for another dimension attribute form the column headers
• Other dimension attributes are listed on top
• Values in individual cells are (aggregates of) the values of the

dimension attributes that specify the cell

CMPT 354: Database I -- Data Warehousing and OLAP 6

Relational Representation

• Cross-tabs can be

represented as relations

– The value all is used to represent aggregates – All represents a set – The SQL:1999 standard uses null values in place of all despite confusion with regular null values

CMPT 354: Database I -- Data Warehousing and OLAP 7

Data Cubes

• A data cube is a multidimensional

generalization of a cross-tab

• Can have n dimensions
• Cross-tabs can be used as views on a data

cube

CMPT 354: Database I -- Data Warehousing and OLAP 8

Online Analytical Processing

• Pivoting: changing the dimensions used in a

cross-tab is called

• Slicing: creating a cross-tab for fixed values only

– Sometimes called dicing, particularly when values for multiple dimensions are fixed

• Rollup: moving from finer-granularity data to a

coarser granularity

• Drill down: The opposite operation - that of

moving from coarser-granularity data to finer- granularity data

CMPT 354: Database I -- Data Warehousing and OLAP 9

Hierarchies on Dimensions

• Enable dimensions be viewed at different levels of

detail

– Dimension DateTime can be used to aggregate by hour

• f day, date, day of week, month, quarter or year

CMPT 354: Database I -- Data Warehousing and OLAP 10

Cross Tabulation With Hierarchy

CMPT 354: Database I -- Data Warehousing and OLAP 11

OLAP Implementation

• Multidimensional OLAP (MOLAP) systems

– Multidimensional arrays in memory to store data cubes

• Relational OLAP (ROLAP) systems

– Relational tables to store data cubes

• Hybrid OLAP (HOLAP) systems

– Store some summaries in memory and store the base data and other summaries in a relational database

CMPT 354: Database I -- Data Warehousing and OLAP 12

Extended Aggregation in SQL:1999

• The cube operation computes union of group by’s
• n every subset of the specified attributes

select item-name, color, size, sum(number) from sales group by cube(item-name, color, size)

• Compute the union of eight different groupings of

the sales relation: { (item-name, color, size), (item- name, color), (item-name, size), (color, size), (item-name), (color), (size), ( ) }

• For each grouping, the result contains the null

value for attributes not present in the grouping

CMPT 354: Database I -- Data Warehousing and OLAP 13

OLTP Versus OLAP

OLTP OLAP users clerk, IT professional knowledge worker function day to day operations decision support DB design application-oriented subject-oriented data current, up-to-date, detailed, flat relational Isolated historical, summarized, multidimensional integrated, consolidated usage repetitive ad-hoc access read/write, index/hash on prim. key lots of scans unit of work short, simple transaction complex query # records accessed tens millions #users thousands hundreds DB size 100MB-GB 100GB-TB metric transaction throughput query throughput, response

CMPT 354: Database I -- Data Warehousing and OLAP 14

What Is a Data Warehouse?

• “A data warehouse is a subject-oriented,

integrated, time-variant, and nonvolatile collection of data in support of management’s decision-making process.” – W. H. Inmon

• Data warehousing: the process of

constructing and using data warehouses

CMPT 354: Database I -- Data Warehousing and OLAP 15

Subject-Oriented

• Organized around major subjects, such as

customer, product, sales

• Focusing on the modeling and analysis of

data for decision makers, not on daily

• perations or transaction processing
• Providing a simple and concise view around

particular subject issues by excluding data that are not useful in the decision support process

CMPT 354: Database I -- Data Warehousing and OLAP 16

Integrated

• Integrating multiple, heterogeneous data sources

– Relational databases, flat files, on-line transaction records

• Data cleaning and data integration

– Ensure consistency in naming conventions, encoding structures, attribute measures, etc. among different data sources

• E.g., Hotel price: currency, tax, breakfast covered, etc.

– When data is moved to the warehouse, it is converted

CMPT 354: Database I -- Data Warehousing and OLAP 17

Time Variant

• The time horizon for the data warehouse is

significantly longer than that of operational systems

– Operational database: current value data – Data warehouse data: provide information from a historical perspective (e.g., past 5-10 years)

• Every key structure in the data warehouse

– Contains an element of time, explicitly or implicitly – But the key of operational data may or may not contain “time element”

CMPT 354: Database I -- Data Warehousing and OLAP 18

Nonvolatile

• A physically separate store of data

transformed from the operational environment

• Operational update of data does not occur in

the data warehouse environment

– Does not require transaction processing, recovery, and concurrency control mechanisms – Requires only two operations in data accessing:

• initial loading of data and access of data

CMPT 354: Database I -- Data Warehousing and OLAP 19

Data Warehousing

CMPT 354: Database I -- Data Warehousing and OLAP 20

Collecting Data

• Source driven architecture: data sources transmit

new information to a warehouse, either continuously or periodically (e.g. at night)

• Destination driven architecture: a warehouse

periodically requests new information from data sources

• Keeping warehouse exactly synchronized with

data sources (e.g. using two-phase commit) is too expensive

– Usually OK to have slightly out-of-date data at warehouse – Data/updates are periodically downloaded form online transaction processing (OLTP) systems

CMPT 354: Database I -- Data Warehousing and OLAP 21

Design Issues

• Data cleansing

– Correct mistakes in addresses (misspellings, zip code errors), and merge address lists from different sources and purge duplicates

• Update propagating

– Warehouse schema may be a (materialized) view of schema from data sources

• Summarizing data

– Raw data may be too large to store on-line – Aggregate values (totals/subtotals) often suffice – Queries on raw data can often be transformed by query

• ptimizer to use aggregate values

CMPT 354: Database I -- Data Warehousing and OLAP 22

Warehouse Schemas

• Dimension values are usually encoded

using small integers and mapped to full values via dimension tables

• Resultant schema is called a star schema

– More complicated schema structures

• Snowflake schema: multiple levels of dimension

tables

• Constellation: multiple fact tables

CMPT 354: Database I -- Data Warehousing and OLAP 23

Data Warehouse Schema

CMPT 354: Database I -- Data Warehousing and OLAP 24

Snowflake Schema

A star schema is a snowflake schema where each dimension has only

• ne single

dimension table

Picture from publib.boulder.ibm.com

CMPT 354: Database I -- Data Warehousing and OLAP 25

Why Data Mining?

• Evolution of database technology

– To collect a large amount of data primitive file processing – To store and query data efficiently DBMS

• New challenges: huge amount of data, how

to analyze and understand?

– Data mining

CMPT 354: Database I -- Data Warehousing and OLAP 26

What Is Data Mining?

• Mining data – mining knowledge
• Data mining is the non-trivial process of

identifying valid, novel, potentially useful, and ultimately understandable patterns in data

CMPT 354: Database I -- Data Warehousing and OLAP 27

The KDD Process

Data

Target data

Preprocessed data Transformed data

Patterns

Knowledge Selection Preprocessing Transformation Data mining Interpretation/ evaluation

CMPT 354: Database I -- Data Warehousing and OLAP 28

KDD Process Steps

• Preprocessing

– Data cleaning – Data integration

• Data selection
• Data transformation
• Data mining
• Pattern evaluation
• Knowledge presentation

CMPT 354: Database I -- Data Warehousing and OLAP 29

Summary

• OLAP
• Data warehousing

– Star schema – Snowflake schema

• Data mining and KDD process
