SLIDE 1
1
Dark Sky Lighting and Energy Savings
Gary Schroeder RMUE September 26, 2019
2003 Northeast Blackout
2
Dark Sky Lighting and Energy Savings Gary Schroeder RMUE - - PowerPoint PPT Presentation
Dark Sky Lighting and Energy Savings Gary Schroeder RMUE - - PowerPoint PPT Presentation
Dark Sky Lighting and Energy Savings Gary Schroeder RMUE September 26, 2019 1 2003 Northeast Blackout 2 The Energy Cost of Light Pollution 30% of all outdoor lighting is wasted, ending up in the night sky International Dark-Sky
SLIDE 2
SLIDE 3
The Energy Cost of Light Pollution
- 30% of all outdoor lighting is wasted, ending up in the night sky
International Dark-Sky Association (www.darksky.org)
- Unshielded outdoor lights waste $2 billion (17 terawatt-hours) of
energy in the U.S. each year
- Equivalent of 8.2 million tons of coal burned annually to light up the
night sky
https://www.scientificamerican.com/article/outdoor-light-pollution/ http://adsabs.harvard.edu/full/1991ASPC...17...89H
3
SLIDE 4
4
Skyglow Brightening of the night sky over inhabited areas
SLIDE 5
Light Tresspass
5
Light falling where it is not intended, wanted or needed
SLIDE 6
Glare
6
Excessive brightness that causes visual discomfort or disability
SLIDE 7
Light Clutter
7
Bright, confusing and excessive groupings of light sources
SLIDE 8
Safety and Security
8
SLIDE 9
Lighting Best Practices
9
SLIDE 10
Saddlebrook Townhomes
- 102 Townhomes
- 172 Porch/deck lights
- 65 Post-top lights
- City Neighborhood Innovation Grants
- 2017 – Porch Lights
- 2018 – Post-top Lights
10
SLIDE 11
Saddlebrook Townhomes Porch Lights
11
Old New
SLIDE 12
Saddlebrook – Out with the old
12
Sample of original bulbs Original fixtures
SLIDE 13
Porch Lights
13
Before After
SLIDE 14
Unshielded vs Shielded Porch Light
14
Max Luminance: 7,732 cd/m2 Ground Luminance: 0.66 cd/m2 Max Luminance: 170 cd/m2 Ground Luminance: 1.66 cd/m2
Unshielded: 46x brighter (Glare) Shielded: 2.5x more light on porch Old New
SLIDE 15
Post-top Fixtures
15
Before After
SLIDE 16
Post-top fixture retrofit
16
SLIDE 17
Post-top light metrics
17
Max Luminance: 10,000 cd/m2 Ground Luminance: 0.1 cd/m2 Max Luminance: 56 cd/m2 Ground Luminance: 0.6 cd/m2
Unshielded: 180x brighter (Glare)! Shielded: 6x more light on ground Old New
SLIDE 18
Saddlebrook Night Sky Event 7/9/2019
18
SLIDE 19
Energy Savings
Porch lights
- Baseline = 60 Watts average, New fixtures = 9 Watts
- 172 Fixtures
11,526 kWh/yr Savings Post-top lights
- Baseline = 6.3 Watts (previous 60 Watts), New fixtures = 10
Watts
- 65 Fixtures
- 1,053 kWh/yr Savings
Net Savings = 10,672 kWh/yr ≈ $1,000/year
(possibly some take-back from more people leaving their porch lights on)
19
SLIDE 20
Lighting Value / Distribution Efficiency
Porch lights
- 60 Watts → 9 Watts (85% savings)
- 800 lumens → 750 lumens
- 13.3 lumens/W → 83.3 lumens/W (↑525%)
- Luminance Efficacy: 0.011 Cd/W → 0.184 Cd/W (↑1,577%)
20
SLIDE 21
Lighting Value / Distribution Efficiency
Post-top Lights
- 6.3 Watts → 10 Watts (↓59% savings)
- 450 lumens → 450 lumens
- 71.4 lumens/watt → 45.0 lumens/watt (↓37%)
- Luminance Efficacy: 0.016 Cd/W → 0.060 Cd/W (↑278%)
21
SLIDE 22
Other Benefits
- Measure persistence – integral LEDs
- Uniform look in neighborhood
- Better light distribution
- Safety/security
- Quality of life – “I now enjoy sitting out on my patio at night without
being bombarded by glaring lights” (resident referring to old post- tops)
22
SLIDE 23
Typical Box Store Offering
23
SLIDE 24
Fort Collins Utilities / Efficiency Works Rebates
24
https://efficiencyworksrebates.com/
- Integral LED
- Fully shielded
- 3000K or less
$25 RaaS
SLIDE 25
Suggested Path Forward for Outdoor Lighting
- Provide rebates only for lighting fixtures that are night-sky friendly
- Disqualify “glare bombs”
- Implement color temperature requirements (e.g., 3000K or less)
- Create channel for homeowners and businesses to purchase quality
fixtures.
25
SLIDE 26
www.fcgov.com/nightsky
26
Thank you!
Gary Schroeder
- Sr. Energy Services Engineer
