AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED AMERICAN LIGHTING ASSOCIATION SEMINAR 09/25/18 AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED AVOIDING LIGHTING MISTAKES BEFORE THEY ARE INSTALLED AMERICAN LIGHTING ASSOCIATION CLC

slide-1
SLIDE 1

AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION SEMINAR 09/25/18

slide-2
SLIDE 2

AVOIDING LIGHTING MISTAKES BEFORE THEY ARE INSTALLED

AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-3
SLIDE 3
  • Managing client expectations
  • Communicating the our designs/specs in an

efficient and professional manner

TWO MAIN ISSUES…

AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION SEMINAR 09/25/18

slide-4
SLIDE 4

ISSUE #1: MISSING THE BASICS

AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-5
SLIDE 5
  • COLOR
  • DISTRIBUTION
  • DIMMING
  • GLARE CONTROL

THE BIG FOUR...

AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-6
SLIDE 6

2700 K

INCANDESCENT 3000K FLUORESCENT LOW VOLT. HALOGEN

WARM

2900 K 3000 K 3500 K 4100 K 4200 K 6000 K

3500K FLUORESCENT 4100K FLUORESCENT 4200K FLUORESCENT

COOL

NOON DAYLIGHT

NEUTRAL

AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-7
SLIDE 7

Color Rendering & R9 Values

AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-8
SLIDE 8

Spectral Power Distribution

AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

slide-9
SLIDE 9

ISSUE #2: RECESSED FIXTURE PLACEMENT & SELECTION

AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-10
SLIDE 10

AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-11
SLIDE 11

AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-12
SLIDE 12

Start with the perimeter of the room and then work your way inward. (and don’t worry about a symmetric RCP!!!)

WHERE TO START

AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-13
SLIDE 13

Do I need the fixtures to be soft and wide (distribution) or tight and directional?

Question #1: AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-14
SLIDE 14

Do I need the fixtures to be adjustable, or is a non-adjustable downlight more appropriate?

Question #2: AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-15
SLIDE 15

Does size really matter???

Question #3: AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-16
SLIDE 16

Is there anything “special” that I need the fixture to be able to do?

Question #4: AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-17
SLIDE 17

AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-18
SLIDE 18

AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-19
SLIDE 19

AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-20
SLIDE 20

AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-21
SLIDE 21

AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-22
SLIDE 22

AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-23
SLIDE 23

AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-24
SLIDE 24

AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-25
SLIDE 25

AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-26
SLIDE 26

AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-27
SLIDE 27

WALL WASHING vs. ADJUSTABLE ACCENTS

  • Wall Washers
  • Wall washing is a very effective way of making a room feel open and

bright due to the reflected (indirect) lighting it provides into a space.

  • Are you really trying to “wall wash” or are you trying to highlight

artwork?

  • Spacing criteria is very easy…essentially a 1:1 ratio of distance out from a

wall and distance apart…can be stretched to 1.5:1 if needed.

  • However, it requires (what looks like) more fixtures to do it correctly.
  • Based on “normal” framing, this means fixtures would be placed 32”

apart from each other…every other ceiling joist bay

AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-28
SLIDE 28
  • Wall Washers
  • 24” out from a wall…fixtures can be placed anywhere from 24” to 32”

apart from each other.

  • 36” out from a wall…fixtures can be placed anywhere from 36” to 45”

apart from each other.

  • Any farther from the walls than 36”, wall washers are not recommended

because the light level drops off precipitously.

WALL WASHING vs. ADJUSTABLE ACCENTS

AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-29
SLIDE 29

Wall Washing AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-30
SLIDE 30
  • Adjustable Accents
  • Adjustable accents are the most versatile fixture type…
  • Can be used as downlights, “wall washers” or to specifically highlight

artwork/objects.

  • Using adjustable accents in most locations can be very helpful to deal

with changes in use of room or unexpected ceiling conditions.

  • Does the adjustability happen inside the fixture or does it stop the fixture

from really being a recessed light?

  • Internal adjustment vs. gimbal ring

WALL WASHING vs. ADJUSTABLE ACCENTS

AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-31
SLIDE 31

Specific Highlighting AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-32
SLIDE 32

Specific Highlighting AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-33
SLIDE 33

Combination – Using Adjustables for Wall Washing AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-34
SLIDE 34

Combination – Using Adjustables for Wall Washing AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-35
SLIDE 35

ISSUE #3: DIMMING LED FIXTURES AND LAMPS

AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-36
SLIDE 36
  • Explain the differences to Clients…LEDs are NOT incandescent

and will not “act” exactly the same as what they are used to…

  • Benefits of staying with a constant CCT as opposed to “warm

dim”

  • How low is low?
  • How to deal with flickering light sources
  • Is 5% actually 5% or is it 5% of “perceived brightness”
  • 5% OF 650 lumens is a lot different than 5% of 1100 lumens

DIMMING LED FIXTURES AND LAMPS AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-37
SLIDE 37

DIMMING LED FIXTURES AND LAMPS

  • ALL LED fixtures and light sources dim differently…some good, some

bad

  • Different “languages”…ELV, MLV, Forward Phase, Reverse Phase, 0-10V
  • Dimmer style MUST match what is required by the LED manufacturer
  • Will it flicker? Will it hum?
  • If it’s not tested or listed, can you use it?
  • When in doubt, read the dimming performance listed by the fixture or

LED manufacturer.

AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-38
SLIDE 38

ISSUE #4: COVE LIGHTING

AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-39
SLIDE 39

COVE LIGHTING

AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-40
SLIDE 40
  • Cove lighting is only successful if minimum distances are

provided in the architectural details…

  • Most critical distance is the shortest distance from the cove light

to the first surface it hits (wall or ceiling)

  • The greater the distance, the better the spread and the better

the effect.

  • Smaller distances (6” or less) will never provide a soft, even

effect

  • Determine whether the lighting is meant to be a soft, low level

accent or a “performance” cove.

COVE LIGHTING

AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-41
SLIDE 41
  • Performance coves are typically going to…
  • be larger rooms with higher ceilings
  • have greater distance between fixture and ceiling
  • require higher lumen outputs (600 lumens per foot)
  • be line voltage cove lights with integral drivers

COVE LIGHTING

AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-42
SLIDE 42
  • Accent (only) coves are typically going to…
  • be smaller rooms or areas with lower ceilings
  • have minimal distance between fixture and ceiling
  • require lower lumen outputs (200-300 lumens per foot)
  • be low voltage cove lights with remote drivers

COVE LIGHTING

AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-43
SLIDE 43
  • Always consider a 1:1 ratio…
  • Distance from fixture to back wall of cove must be equal to or

greater than the spacing between lamps (or ends of fixtures).

  • Think about how possible is to install the fixtures or access

them

  • Just because something is LED doesn’t mean it does not have

to be accessed at some point

COVE LIGHTING

AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-44
SLIDE 44

COVE LIGHTING

AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-45
SLIDE 45

COVE LIGHTING

AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-46
SLIDE 46

COVE LIGHTING

AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-47
SLIDE 47

COVE LIGHTING

AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-48
SLIDE 48

COVE LIGHTING

AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-49
SLIDE 49

COVE LIGHTING

AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-50
SLIDE 50

COVE LIGHTING

AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-51
SLIDE 51

COVE LIGHTING

AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-52
SLIDE 52

COVE LIGHTING

AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-53
SLIDE 53

COVE LIGHTING

AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-54
SLIDE 54

ISSUE #5: LIGHTING CABINET INTERIORS

AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-55
SLIDE 55
  • What is being displayed?
  • Are they glass shelves or just glass doors?
  • Are the doors transparent or translucent?
  • What is the back wall surface?
  • How high (off the floor) are the cabinets?
  • Are they worth lighting???
  • What is the finish of the painted surface?
  • Above eye level vs. below eye level

LIGHTING CABINET INTERIORS

AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-56
SLIDE 56

LIGHTING CABINET INTERIORS

AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-57
SLIDE 57

LIGHTING CABINET INTERIORS

AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-58
SLIDE 58
  • What is being displayed?
  • Books, decorative objects, etc.
  • How are they being displayed?
  • Are the shelves fixed or adjustable?
  • What is the finish? Is it high gloss, matte, satin, etc?
  • Are there lights (recessed) outside of it as well?
  • What about decorative wall mounted bookcase lights?
  • What are the finishes in the room?
  • Above eye level vs. below eye level

LIGHTING BOOKCASE INTERIORS

AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-59
SLIDE 59

LIGHTING BOOKCASE INTERIORS

AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-60
SLIDE 60

LIGHTING BOOKCASE INTERIORS

Shelf #7 Shelf #6 Shelf #5 Shelf #4 Shelf #3 Shelf #2 Shelf #1

AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18

slide-61
SLIDE 61

LIGHTING BOOKCASE INTERIORS

AVOIDING LIGHTING PROBLEMS BEFORE THEY ARE INSTALLED

AMERICAN LIGHTING ASSOCIATION CLC SEMINAR 09/24/18
