Daniel Morrell Limited The Carbon Advisory Service Daniel Morrell Limited The Carbon Advisory Service Cities cover less than 1% of the earths surface, but are responsible for 80% of the worlds CO2 output In our cities, only 1% of the

slide-1
SLIDE 1

Daniel Morrell Limited The Carbon Advisory Service

slide-2
SLIDE 2

Cities cover less than 1% of the earth’s surface, but are responsible for 80% of the world’s CO2 output In our cities, only 1% of the building stock is new

We need a solution for the other 99% .....

Daniel Morrell Limited The Carbon Advisory Service

slide-3
SLIDE 3

A responsible, sustainable refurbishment programme is the only solution….

We need a solution for the other 99% .....

Daniel Morrell Limited The Carbon Advisory Service

slide-4
SLIDE 4

So what must we do?

We need a solution for the other 99% .....

Daniel Morrell Limited The Carbon Advisory Service

slide-5
SLIDE 5

The building

  • 1970’s construction
  • 3 stories
  • basement parking
  • concrete frame
  • concrete clad
  • double glazed - solar tinted
  • four-pipe fan coil air

conditioning

  • conventional sanitary

installation

  • conventional lighting installation

Daniel Morrell Limited The Carbon Advisory Service

slide-6
SLIDE 6
  • structure

retain existing concrete frame

  • cladding

remove existing cladding

  • replace glazed elements with

responsive cladding solution

  • basement usage

reduce car parking to minimum re-locate plant in basement introduce social amenities The opportunities

Daniel Morrell Limited The Carbon Advisory Service

slide-7
SLIDE 7
  • footprint

extend ground and first floors to maximum footprint add lightweight pavilion to roof re-locate core and building entrance

  • site

reduce car parking introduce shuttle drop off create reed beds and pond The opportunities

Daniel Morrell Limited The Carbon Advisory Service

slide-8
SLIDE 8
  • services

replace conventional fan coil solution with mixed mode ventilation system replace lighting with low energy solution and stringent controls replace sanitary installation with low water/no water solution introduce on-site power generation The opportunities

Daniel Morrell Limited The Carbon Advisory Service

slide-9
SLIDE 9
  • space usage

flexible working zones variable usage patterns community engagement 24/7 capability sectional operating capability multi-function spaces flexible working patterns The opportunities

Daniel Morrell Limited The Carbon Advisory Service

slide-10
SLIDE 10

Existing Site Plan

Daniel Morrell Limited The Carbon Advisory Service

slide-11
SLIDE 11

Proposed Site Plan

Daniel Morrell Limited The Carbon Advisory Service

slide-12
SLIDE 12

Existing Section

  • inverted ziggurat
  • 3 stories with basement

parking and roof plant

  • increased floorplate
  • central green core/atrium
  • basement plant and social

amenities

  • third floor pavilion

Proposed Section

Daniel Morrell Limited The Carbon Advisory Service

slide-13
SLIDE 13

Space Gain

floor existing building refurbished building G 582 1389 1 723 1168 2 1020 1295 3

  • 930

total NIA sq m 2325 4782

Daniel Morrell Limited The Carbon Advisory Service

slide-14
SLIDE 14

Core Design

  • re-locate core to central

position

  • create vertical green shaft

within central atrium

  • introduce daylight tubes
  • create open verandah floors
  • allow for natural ventilation

Daniel Morrell Limited The Carbon Advisory Service

slide-15
SLIDE 15
  • staggered floorplate
  • small side entrance
  • off-centre core

Existing Plan Proposed Plan

  • consistent floorplate
  • relocated/enhanced entrance
  • central atrium and green core

Daniel Morrell Limited The Carbon Advisory Service

slide-16
SLIDE 16

Third Floor Pavilion Plan

  • fluid form
  • lightweight structure
  • green terrace zones
  • central green shaft

Daniel Morrell Limited The Carbon Advisory Service

slide-17
SLIDE 17

New Roof Plan

  • green roof
  • energy generation

capabilities

  • daylight tubes
  • central green core

Daniel Morrell Limited The Carbon Advisory Service

slide-18
SLIDE 18

Community spaces

  • multi-purpose shared space
  • technology for remote

working

  • concierge IT/FM

management

  • café for catch up sessions
  • meeting spaces to support

dispersed teams

  • local community usage
  • utside core hours
  • 24/7 workspace

Daniel Morrell Limited The Carbon Advisory Service

slide-19
SLIDE 19

Flexible project spaces

  • flexible, short term project

spaces

  • support areas for

collaborative working

  • communication tools for

remote working

  • managed space to ‘turn off’

areas when not in use

Daniel Morrell Limited The Carbon Advisory Service

slide-20
SLIDE 20
  • team bases for office

based core

  • shared / bookable space

for flexible workers

  • space management

software to maximise space utilisation

  • recycling hubs
  • document scanning and

electronic data

  • managed space to ‘turn
  • ff’ when not in use

Flexible project spaces

Daniel Morrell Limited The Carbon Advisory Service

slide-21
SLIDE 21

Core Design

Daniel Morrell Limited The Carbon Advisory Service

slide-22
SLIDE 22

Cladding

The cladding design must integrate the building requirements and consider: Insulation and u-values Acoustics Wind loading and structure Glazing specification Weather resistance Maintenance Cost Appearance Natural light

Daniel Morrell Limited The Carbon Advisory Service

slide-23
SLIDE 23

Cladding

The cladding design must integrate the following building requirements: Ventilation Solar heating Photovoltaics Solar shading Security

Daniel Morrell Limited The Carbon Advisory Service

slide-24
SLIDE 24

…..but it starts with simple floor to floor slabs… …which, if exposed, are a major part of the building’s thermal mass and can be used to stabilise the internal environment.

Cladding

Daniel Morrell Limited The Carbon Advisory Service

slide-25
SLIDE 25

A 1500mm grid is the most flexible for commercial use

Cladding

Daniel Morrell Limited The Carbon Advisory Service

slide-26
SLIDE 26

A 1500mm grid is the most flexible for commercial use Insulation panels are introduced to desk height

Cladding

Daniel Morrell Limited The Carbon Advisory Service

slide-27
SLIDE 27

A 1500mm grid is the most flexible for commercial use Insulation panels are introduced to desk height A horizontal glazing zone above desk height maximises daylight

Cladding

Daniel Morrell Limited The Carbon Advisory Service

slide-28
SLIDE 28

A 1500mm grid is the most flexible for commercial use Insulation panels are introduced to desk height A horizontal glazing zone above desk height maximises daylight Upper areas of glazing are treated to avoid glare

Cladding

Daniel Morrell Limited The Carbon Advisory Service

slide-29
SLIDE 29

A 1500mm grid is the most flexible for commercial use Insulation panels are introduced to desk height A horizontal glazing zone above desk height maximises daylight Upper areas of glazing are treated to avoid glare…. ….and to project natural light deep into the office

Cladding

Daniel Morrell Limited The Carbon Advisory Service

slide-30
SLIDE 30

Coatings on the glass filter the sun’s energy allowing maximum transmission of the visible spectrum…but exclude energy that only transmits heat Coatings also keep in heat, improving u-values High performance solar coatings are used on a building’s south side… low-e only on the north

Cladding

Daniel Morrell Limited The Carbon Advisory Service

slide-31
SLIDE 31

Glass weathers well, lasts and is easy to maintain…self cleaning glass will reduce water use

Cladding

Daniel Morrell Limited The Carbon Advisory Service

slide-32
SLIDE 32

A typical office ‘manufactures’ cool air in chillers and pumps it around the building….. ….using substantial amounts

  • f fossil fuel.

Cladding

Daniel Morrell Limited The Carbon Advisory Service

slide-33
SLIDE 33

But if we allow the air outside the window into the building…. air need not be pumped far…. fans can be very low power…. …..and the electrical load is greatly reduced. Openings allow the building skin to breathe.

Cladding

Daniel Morrell Limited The Carbon Advisory Service

slide-34
SLIDE 34

Air enters the floor or ceiling void….. to local fresh air units with variable speed low energy fans …providing local heat recovery, and evaporative cooling…. and allow night-cooling of the building's thermal mass

Cladding

Daniel Morrell Limited The Carbon Advisory Service

slide-35
SLIDE 35

Openable windows allow natural ventilation…. and give occupants additional local control and an increased feeling of comfort.

Cladding

Daniel Morrell Limited The Carbon Advisory Service

slide-36
SLIDE 36

But openings in the cladding raise security issues in commercial properties. Brise-soleil can supplement the performance of glass coatings and counter security issues These security-cum-solar shading features contain photovoltaics, providing energy for the building.

Cladding

Daniel Morrell Limited The Carbon Advisory Service

slide-37
SLIDE 37

Nano-technology will allow energy collection to become cheaper… we now can print photovoltaics onto our cladding components

Cladding

Daniel Morrell Limited The Carbon Advisory Service

slide-38
SLIDE 38

At lower and upper levels restaurants and cafes, require hot water….. Solar pipes pre-heat water for washing dishes whilst you eat and for showers in the basement gym…..

Cladding

Daniel Morrell Limited The Carbon Advisory Service

slide-39
SLIDE 39

…. put all together the components of our cladding help us reduce our dependence on fossil fuel… by allowing us a closer connection to the light and air around us.

Cladding

Daniel Morrell Limited The Carbon Advisory Service

slide-40
SLIDE 40

Cost Comparison

All costs inclusive of Preliminaries, OH&P’s and Contingency.

Standard refurbishment No structural alterations and no extensions including Cat B fit-out £1,200 per sq metre New build BREAMM Excellent rated fit-out to Cat B £2,650 per sq metre

Proposed refurbishment Including extensions to floor plates, pavilion floor, new façade and Cat B Fit-out £2,500 per sq metre

Daniel Morrell Limited The Carbon Advisory Service

slide-41
SLIDE 41

3D Animation

Daniel Morrell Limited The Carbon Advisory Service

slide-42
SLIDE 42

“Creating spaces for people that work.”
