SLIDE 1

CTSRD

CRASH-worthy Trustworthy Systems Research and Development

The CHERI CPU

RISC in the age of risk

David Chisnall University of Cambridge

Approved for public release; distribution is unlimited. This research is sponsored by the Defense Advanced Research Projects Agency (DARPA) and the Air Force Research Laboratory (AFRL), under contracts FA8750-10-C-0237 and FA8750-11-C-0249. The views,

pinions, and/or findings contained in this article/presentation are those of the author(s)/

presenter(s) and should not be interpreted as representing the official views or policies of the Department of Defense or the U.S. Government.

SLIDE 2

Memory: You’re doing it wrong!

2

~82% of exploited vulnerabilities in 2012

— Software Vulnerability Exploitation Trends, Microsoft

SLIDE 3

Low-level languages rule

3

Source: openhub.net C: 8,323,328,367 lines of code C++: 2,966,693,989 lines of code Java: 2,861,498,030 lines of code Scala:13,780,744 lines of code New code committed

SLIDE 4

Security is important again

4

Multi-user systems Disconnected single- user systems Single-user, multi-attacker systems

SLIDE 5

RISC is for compilers

Nothing that can be done fast in software should

be done in hardware.

Everything that can only be done well in hardware

should be in hardware.

5

SLIDE 6

The CHERI model

Memory protection as a first-class part of the ISA
A single abstraction for bounds checking and

sandboxing

Mechanism in the hardware, policy in software

6

SLIDE 7

Pointers should be capabilities

Smalltalk (Java, etc) pointers confer the rights to

access an object.

C pointers can (in practice) be constructed from

arbitrary integers.

Capabilities are unforgeable tokens of authority.

7

SLIDE 8

CHERI capabilities

32 capability registers

8

base ¡[64] length ¡[64] Permissions ¡[32] Type ¡[24]

Reserved ¡[8]

virtual ¡address ¡[64] ¡(exposed ¡as ¡offset)

Field Operation Permissions Bitwise and Base Increment (and decrease length) Length Decrease Offset Arbitrary manipulation

ISA Operations

SLIDE 9

Tags to Protect Capabilities in Memory

Capabilities on the stack and in data structures

DATA 256 bits 1 bit

CHERI

Capabilities

OS managed
Enables swapping
Centralised
Allows revocation
Compiler managed
Precise
Can be delegated
Many domains

Paged Memory+

Address validation Pointer safety

14

SLIDE 15

Memory safety in hardware

All memory accesses must be via a valid capability
Instructions only allow restricting range /

permissions of capabilities

Now all we need is software…

15

SLIDE 16

Building on open source

A full open source stack:
LLVM/Clang-based compiler.
Modified FreeBSD.
Extended BERI processor.
Real software from the FreeBSD ports collection.

16

SLIDE 17

Process start

$c0 and $pcc cover the entire address space.
Unmodified code is completely oblivious.
CHERI-aware code can derive restricted

capabilities from either.

Compartments can be created by discarding/

subsetting $c0 in some threads.

17

SLIDE 18

Don’t break the world!

Code that doesn’t contain memory safety errors

should work!

Even if it does slightly (or very) evil things with

pointers!

Ideally only code with memory safety errors should

break.

18

SLIDE 19

C is weird

Long standard describes allowed behaviour.
Lots of things are implementation defined or undefined.
All nontrivial programs depend on implementation-

defined behaviour.

Breaking this makes programmers cranky!
We discovered most of these things when we broke

them and tried to compile real programs (e.g. tcpdump)

19

SLIDE 20

Pointers and Integers

20 7.20.1.4 Integer types capable of holding object pointers 1 The following type designates a signed integer type with the property that any valid pointer to void can be converted to this type, then converted back to pointer to void, and the result will compare equal to the original pointer: intptr_t The following type designates an unsigned integer type with the property that any valid pointer to void can be converted to this type, then converted back to pointer to void, and the result will compare equal to the original pointer: uintptr_t These types are optional. 7.20.1.5 Greatest-width integer types void *a = something(); intptr_t b = (intptr_t)a; a = (void*)b; void *a = something(); long long b = (long long)a; a = (void*)b;

Implementation defined!

SLIDE 21

Simple Problem: memcpy()

21 struct foo { void *a; int b; }; struct foo new = old; memcpy(&new, &old, sizeof(struct foo);

The memcpy() function doesn’t know if it’s copying pointers or data!

SLIDE 22

Pointers as capabilities

22

C code used __capability qualifier to tag pointers to be represented as capabilities // 64-bit integer (address) void *foo; // 256-bit capability __capability int *bar; // Increment offset by sizeof(int) bar++; // Load 4 bytes at offset+sizeof(int) bar[1];

SLIDE 23

Enabling pointer abuse

23

// The low bit of a sensibly aligned pointer is // always 0, so we can hide a flag in it __capability int *set_flag(__capability int *b) { return (__capability int*)((__intcap_t)b | 1); }

SLIDE 24

Enabling pointer abuse

24

# Integer constant 1 daddiu $1, $zero, 1 # Derive a canonical null capability cfromptr $c1, $c0, $zero # Set intcap_t (tag not valid) to 1 csetoffset $c1, $c1, $1 # Get the integer values of both operands cgetoffset $1, $c1 cgetoffset $2, $c3 # Perform the arithmetic

r

$1, $1, $2 # Set the offset in the original capability csetoffset $c3, $c3, $1

SLIDE 25

Legacy interoperability

(is hard)

25

void *foo; __capability char *bar; // What does this do? bar = (__capability char *)foo; // Or this? foo = (void *)bar;

SLIDE 26

First cut at Casts

26

# Cast from pointer ($1) to capability ($c1) CIncBase $c1, $c0, $1 # Cast from capability ($c1) to pointer ($1) CGetBase $c1, $1

What happens if the pointer is null?
What happens if the capability is outside the $c0

range or $c0 has a non-zero offset?

SLIDE 27

NULL in C

27

§6.3.2.3.3: An integer constant expression with the value 0, or such an expression cast to type void *, is called a null pointer constant.66) If a null pointer constant is converted to a pointer type, the resulting pointer, called a null pointer, is guaranteed to compare unequal to a pointer to any object or function.

void *null = (void*)0; int a = 0; void *might_be_null = (void*)a;

No C programmer has ever paid attention to this!

SLIDE 28

Casts in CHERI

CFromPtr gives a null capability if the integer is 0
CToPtr gives a 0 integer if the capability is null or
utside of $c0

28

# Cast from pointer ($1) to capability ($c1) CFromPtr $c1, $c0, $1 # Cast from capability ($c1) to pointer ($1) CToPtr $1, $c0, $c1

SLIDE 29

Where do bounds come from?

An object in C is a single allocation.
OpenSSL’s Heartbleed vulnerability was caused

(partly) by splitting allocations.

Some programmer policy is essential!
Sizes of globals, stack allocations, malloc() calls

are not enough (but they’re a good start!)

29

SLIDE 30

Safer returning

30 MIPS CHERI Call jalr $t9, $ra cjalr $c12, $c17 Return jr $ra cjr $c17 Spill return address to stack sd $ra, 32($sp) csc $c17, $sp, 32($c11) Behaviour if spilled value is corrupted Jump somewhere (attacker’s choice) Trap

Capabilities are for code, not just for christmas data

SLIDE 31

Comparing pointers

C says it’s undefined behaviour to compare

pointers to different objects

C programmers do it all the time
CHERI adds pointer compare instructions

31

SLIDE 32

Some evil things people do to pointers

Store them in integer variables (works if they’re

[u]intcap_t)

Do arbitrary arithmetic on them
Let them go out of range in the middle of a

calculation

Compare pointers to different objects

32

All of these need to work!

SLIDE 33

A tale of 2 3 ABIs

Incremental deployment is vital for testing
Rewriting (or even recompiling) all code at once

isn’t feasible

33

More compatible More safe n64 Pure MIPS Pure-capability All pointers are capabilities n64 + CHERI Some pointers are capabilities

SLIDE 34

The pure-capability ABI

Code where all pointers are capabilities.
May have a null $c0.
Can only see a subset of all memory.
Incompatible with syscall ABI.

34

SLIDE 35

CHERI-friendly libraries

Always use typedefs for pointer types.
Don’t put struct definitions for opaque types in

headers.

Separate file-handling layers (that make syscalls)

from buffer-handling layers.

Write good code!

35

SLIDE 36

Memory Safety Overhead

36 Smaller is better Bisort MST Treeadd Perimeter 50 100 Time (seconds) MIPS CHERI Bigger is better M I P S C H E R I 10,000 20,000 30,000 Dhrystones (per-second) Smaller is better MIPS CHERI 50 100 Time (seconds)

Olden (pointer-chasing) benchmarks Dhrystone (CPU- intensive) benchmark tcpdump (real code!)

SLIDE 37

Building sandboxes

37

Shared Code Local Heap Shared Data Shared Data

$pcc $c0 $c1 $c2 ...

No access to any memory without valid capabilities

SLIDE 38

Process-based sandboxes?

More expensive to create (new kernel process,

virtual memory map)

More expensive to share (one TLB entry per page)
No fine-grained sharing (page granularity)
Better separation of kernel rights (so far!)

38

SLIDE 39

Library Sandboxing

Private heap per library instance (multiple isolated

copies of the same library allowed)

Shared code between all instances
Calls to the library delegate access to shared

buffers

Maintaining ABIs can be a bit tricky!

39

SLIDE 40

Lessons Learned

40

Only testing with real code can tell you how useful your ISA really is. Convincing a compiler it’s useful is a lot harder than convincing yourself. Software stack on GitHub now, hardware due new open- source release Real Soon Now™
