SLIDE 1

Florida Institute for Cybersecurity (FICS) Research

CS 8803 - Cellular and Mobile Network Security:

Data Air Interface

Professor Patrick Traynor 10/23/18

SLIDE 2

Florida Institute for Cybersecurity (FICS) Research

Packet-Switched Mobile Data

2

SLIDE 3

Florida Institute for Cybersecurity (FICS) Research

GSM/UMTS Data

Overview of System Architecture
Compare and Contrast
Protocol Stacks
GSM Overview
UMTS Overview
Mobility Management

3

SLIDE 4

Florida Institute for Cybersecurity (FICS) Research

General Packet Radio Service (GPRS)

GSM
verlay network on basic GSM infrastructure
new mobile “routers” introduced
supports both “GPRS” (2.5G) and “EDGE” (2.75G) wireless protocols
UMTS
re-uses GPRS network from GSM
new air interface

4

SLIDE 5

Florida Institute for Cybersecurity (FICS) Research

GGSN

Internet

HLR

SS7 Network IP Network

GSM Data Network Architecture

SGSN - Serving GPRS Support Node
Serves mobile user based on location
GGSN - Gateway GPRS Support Node
Serves mobile user based on address
BTS/BSC - new call processing and channels for data
HLR - extended user profiles

5

BTS BTS BTS

SGSN

BSC BSC

SLIDE 6

Florida Institute for Cybersecurity (FICS) Research

Network Attachment

Previous lectures covered the process of attaching to the network (i.e.,

authentication to the CS portion of the network).

This is known as “IMSI Attach”
Mobile devices can/must also attach themselves to the data services provided

by the network.

This is known as “GPRS Attach”
The processes are largely the same, except that the MS interacts with the

MSC for an IMSI Attach and the SGSN for the GPRS Attach.

Most networks allow for a

“Combined GPRS/IMSI Attach”.

6

SLIDE 7

Florida Institute for Cybersecurity (FICS) Research

Combined Attach

The advantage to performing a combined attach is that both CS and PS

signaling can be dealt with at the SGSN.

The MSC/VLR really just provides look-up facilities.
The absence of this combined attach means that the network provider

must dedicate two sets of air interface resources to CS and PS signaling.

Pros? Cons?
Reality: SGSNs and MSCs are often a single box.

7

SLIDE 8

Florida Institute for Cybersecurity (FICS) Research

Attach

8

New SGSN Old SGSN HLR GGSN Attach Request ID Request

(TMSI, IMSI)

ID Request Auth Info Auth & Cipher Update Location Cancel Location Insert Subscriber Data Location Update Accepted Attach Accept

SLIDE 9

Florida Institute for Cybersecurity (FICS) Research

Detach

9

SGSN HLR GGSN Detach Request Delete PDP Context Detach Accept Purge MS

SLIDE 10

Florida Institute for Cybersecurity (FICS) Research

PDP Context

Once attached to the network, mobile devices need a means of communicating with
ther data-enabled entities.
A Packet Data Protocol (PDP) Context is a virtual channel between a device and

a GGSN.

PDP Contexts serve two main functions in GPRS/UMTS:
Assign the phone an IPv4/IPv6 address, making it reachable.
Associate a quality of service (QoS) profile with the device.
The second point, while specified in the standards, is not currently implemented/used.
Accordingly, let’s view PDP Context establishment as a

high-level dual to DHCP - interaction with a DHCP   server is actually one of the parts of this operation.

10

SLIDE 11

Florida Institute for Cybersecurity (FICS) Research

Multiple Contexts

This architecture allows for a single device to establish and maintain multiple

PDP Contexts.

Known as Primary and Secondary PDP Contexts
Secondary PDP contexts are always associated with a Primary context.
Multiple primaries are also possible, generally connected to multiple PDNs.
Secondary PDP contexts share an IP address with the Primary, but allow

different QoS terms to be enforced.

A device may specify to the network that its SIP flows are more important

than those delivering traffic to its mobile browser.

11

SLIDE 12

Florida Institute for Cybersecurity (FICS) Research

PDP Context Activation

12

SGSN GGSN Activate PDP Context Activate PDP Context Accept Create PDP Context

SLIDE 13

Florida Institute for Cybersecurity (FICS) Research

Call vs Data Path

13

HLR

BTS

SGSN

SS7 Network

BTS BSC BSC BTS

IP Network

GGSN

Internet

SLIDE 14

Florida Institute for Cybersecurity (FICS) Research

GTP and RAB

GPRS Tunneling Protocol (GTP) allows the mobility of a device to be

hidden to the outside world.

The IP address is fixed by the GGSN, and a “tunnel” to that device’s

current SGSN is stored so that packets can be correctly forwarded.

Each tunnel is differentiated by its Tunnel Endpoint Identifier (TEI).
This allows the SGSN to allocate an arbitrary local address for a device

(and change that address) without telling the GGSN.

The SGSN then forwards packets through the Radio Access Bearer (RAB)

service, which connects the core network to the wireless device.

14

SLIDE 15

Florida Institute for Cybersecurity (FICS) Research

RAB GTP Tunnel

Tunnels, etc

Each PDP Context allows a set of flows to request a QoS from the RAB.

These include Conversational (voice), Streaming (YouTube), Interactive (web surfing) and Background (FTP).

RAB ends at a lower layer of the MS protocol stack.

15

SGSN GGSN

Internet

BS

PDP Context

MS

SLIDE 16

Florida Institute for Cybersecurity (FICS) Research

GSM/GPRS Protocol Stacks

16

Internet

SGSN GGSN

BS

Server

GTP TCP/UDP IP LAPD L1 SNDCP LLC BSSGP LAPD L1 GTP TCP/UDP IP LAPD L1 IP/X25 L1 LAPD BSSGP RLC/ MAC GSM IP/X25 App TCP/UDP GSM RLC/MAC LLC SNDCP App TCP/UDP IP Lower Layers

SLIDE 17

Florida Institute for Cybersecurity (FICS) Research

UMTS Architecture

Re-used from GSM/GPRS Core Network
SGSN - signaling interface and some access protocols change
GGSN - re-used (PDP contexts remain)
HLR - some extensions
Main differences
Much higher data rates, soft handoffs

17

HLR

Node B

SGSN

SS7 Network

RNC

BSC BTS

IP Network

GGSN

Internet

UE

SLIDE 18

Florida Institute for Cybersecurity (FICS) Research

UMTS/GPRS Protocol Stacks

18

Internet

SGSN GGSN

BS

Server

GTP-U TCP/UDP IP L2 L1 GTP-U TCP/UDP IP L2 L1 IP/PPP IP/PPP App TCP/UDP UMTS RLC/MAC PDCP App TCP/UDP IP Lower Layers AAL5 ATM IP GTP-U TCP/UDP ATM AAL5 IP

TCP/UDP

GTP-U

RLC/ MAC UMTS PDCP

SLIDE 19

Florida Institute for Cybersecurity (FICS) Research

Inter-SGSN Move

19

New SGSN Old SGSN HLR GGSN RA Update SGSN Context ID Request Auth Info Auth & Cipher Update Location Cancel Location Location Update Accepted Attach Accept

SGSN Context Ack

FWD Packets Update PDP Context Insert Subscriber Data

SLIDE 20

Florida Institute for Cybersecurity (FICS) Research

Inter-SGSN Move: Data

20

New SGSN Old SGSN HLR GGSN RA Update SGSN Context ID Request Auth Info Auth & Cipher Update Location Cancel Location Location Update Accepted Attach Accept

SGSN Context Ack

FWD Packets Update PDP Context Insert Subscriber Data Packets Flowing to Old SGSN New Tunnel

SLIDE 21

Florida Institute for Cybersecurity (FICS) Research

Data Network Functionality Redux

21
