SLIDE 1
When you know better you do better
Maya Angelou
CRITICALITY When you know better you do better Maya Angelou - - PowerPoint PPT Presentation
CRITICALITY When you know better you do better Maya Angelou - - PowerPoint PPT Presentation
CRITICALITY When you know better you do better Maya Angelou CRITICALITY OF ASSETS Eric Saylor, Cincinnati, OH Wha hat i t is the the l likelihood tha that a an n asset et w will fa ill fail? il? Wha hat i t is the the c cons
SLIDE 2
SLIDE 3
Wha hat i t is the the l likelihood tha that a an n asset et w will fa ill fail? il? Wha hat i t is the the c cons
- nsequence i
if the the asse asset d does f s fai ail?
SLIDE 4
ASSET RISK
PROBABILITY OF FAILURE
CONSEQUENCE OF FAILURE
SLIDE 5
FAILURE MODES
MORTALITY LEVEL OF SERVICE CAPACITY FINANCIAL INEFFICIENCY
SLIDE 6
FAILURE MODES
MORTALITY
SLIDE 7
FAILURE MODES
LEVEL OF SERVICE
SLIDE 8
FAILURE MODES
CAPACITY
SLIDE 9
FAILURE MODES
FINANCIAL INEFFICIENCY
More to fix than to replace
SLIDE 10
ASESSING CONSEQUENCES?
CONSIDER THE TRIPLE BOTTOM LINE
SLIDE 11
CALCULATING CRITICALITY
COF= CONSEQUENCE OF FAILURE Criticality = POF X COF
SLIDE 12
WAYS TO REDUCE RISK
Routine & Preventative Maintenance Redundancy Spare Parts Specialized Training Replace Assets Early Monitoring
SLIDE 13
CALCULATING CRITICALITY INCLUDING REDUNDANCY
COF= COST OF FAILURE Redundancy Factor = RF Criticality = POF X COF X RF
SLIDE 14
ASSESSING CRITICALITY: A SIMPLE EXAMPLE
SLIDE 15
FACTORS TO CONSIDER FOR
Age of Well Condition of Well Clogging of Well Aesthetic Water Concerns Depth of Well
PROBABILITY OF FAILURE
SLIDE 16
Well Name POF Factor Westside Well 4 Eastside Well 2 Northside Well 4 Southside Well 1 Central Well 4
Scores for PoF
SLIDE 17
FACTORS TO CONSIDER FOR
Cost of Repair Number of Customers Served Number of Critical Customers Time of Repair Redundancy
CONSEQUENCE OF FAILURE
SLIDE 18
Well Name COF Factor Westside Well 4 Eastside Well 4 Northside Well 3 Southside Well 2 Central Well 5
Scores for CoF
SLIDE 19
Well Name POF COF TOTAL RISK SCORE Westside Well 4 4 16 Eastside Well 2 4 8 Northside Well 4 3 12 Southside Well 1 2 2 Central Well 4 5 20
Risk Scores for Wells
SLIDE 20
Westside Well
PROBABILITY OF FAILURE
CONSEQUENCE OF FAILURE
VISUAL DISPLAY OF EXAMPLE DATA
SLIDE 21
DOES IT MAKE SENSE? DO YOU CARRY TOO MUCH RISK, NOT ENOUGH OR JUST RIGHT?
What does the data say?
SLIDE 22
Westside Well
PROBABILITY OF FAILURE
CONSEQUENCE OF FAILURE
WHAT IF IT LOOKED LIKE THIS?
SLIDE 23
Westside Well
PROBABILITY OF FAILURE
CONSEQUENCE OF FAILURE
Or this?
SLIDE 24
CRITICALITY IS NOT STATIC EACH DAY CRITICALITY CHANGES SLIGHTLY NEED TO REASSESS CRITICALITY AT LEAST EVERY YEAR IF NOT SOONER REASSESS WHEN MAJOR CHANGES ARE MADE (UPGRADES, REPLACEMENTS, MAJOR CONSTRUCTION, REHABILITATION, REDUNDANCY ADDED)
CRITICALITY CHANGES
SLIDE 25
CRITICALITY IN ACTION
Frank Roth, ABCWUA, Albuquerque, NM
SLIDE 26
Tools Available
Criticality of Assets
Allows you to calculate risk for assets
http://southwestefc.unm.edu/asset-management/
SLIDE 27
Tools Available
http://southwestefc.unm.edu/asset-management/ Reference Guide for Asset Management Inventory and Risk Analysis
Provides you with lists of characteristics to take into consideration when determining Probability and Consequence of Failure
