SLIDE 1
When you know better you do better
Maya Angelou
CRITICALITY When you know better you do better Maya Angelou - - PowerPoint PPT Presentation
CRITICALITY When you know better you do better Maya Angelou - - PowerPoint PPT Presentation
CRITICALITY When you know better you do better Maya Angelou CRITICALITY OF ASSETS Eric Saylor, Cincinnati, OH What is the e likelih ihood ood that t an asset t will fail? What is the e conseq sequen uence e if the asset t does es
SLIDE 2
SLIDE 3
What is the e likelih ihood
- od that
t an asset t will fail? What is the e conseq sequen uence e if the asset t does es fail?
SLIDE 4
ASSET RISK
PROBABILITY OF FAILURE
CONSEQUENCE OF FAILURE
SLIDE 5
FAILURE MODES
MORTALITY LEVEL OF SERVICE CAPACITY FINANCIAL INEFFICIENCY
SLIDE 6
FAILURE MODES
MORTALITY
SLIDE 7
FAILURE MODES
LEVEL OF SERVICE
SLIDE 8
FAILURE MODES
CAPACITY
SLIDE 9
FAILURE MODES
FINANCIAL INEFFICIENCY
More to fix than to replace
SLIDE 10
ASESSING CONSEQUENCES?
CONSIDER THE TRIPLE BOTTOM LINE
SLIDE 11
CALCULATING CRITICALITY
COF= COST OF FAILURE Redundancy Factor = RF Criticality = POF X COF X RF
SLIDE 12
WAYS TO REDUCE RISK
Routine & Preventative Maintenance Redundancy Spare Parts Specialized Training Replace Assets Early Monitoring
SLIDE 13
ASSESSING CRITICALITY: A SIMPLE EXAMPLE
SLIDE 14
FACTORS TO CONSIDER FOR
Age of Well Condition of Well Clogging of Well Aesthetic Water Concerns Depth of Well
PROBABILITY OF FAILURE
SLIDE 15
Well Name POF Factor Westside Well 4 Eastside Well 2 Northside Well 4 Southside Well 1 Central Well 4
Scores for PoF
SLIDE 16
FACTORS TO CONSIDER FOR
Cost of Repair Number of Customers Served Number of Critical Customers Time of Repair Redundancy
CONSEQUENCE OF FAILURE
SLIDE 17
Well Name COF Factor Westside Well 4 Eastside Well 4 Northside Well 3 Southside Well 2 Central Well 5
Scores for CoF
SLIDE 18
Well Name POF COF TOTAL RISK SCORE Westside Well 4 4 16 Eastside Well 2 4 8 Northside Well 4 3 12 Southside Well 1 2 2 Central Well 4 5 20
Risk Scores for Wells
SLIDE 19
Westside Well
PROBABILITY OF FAILURE
CONSEQUENCE OF FAILURE
VISUAL DISPLAY OF EXAMPLE DATA
SLIDE 20
DOES IT MAKE SENSE? DO YOU CARRY TOO MUCH RISK, NOT ENOUGH OR JUST RIGHT?
What does the data say?
SLIDE 21
Westside Well
PROBABILITY OF FAILURE
CONSEQUENCE OF FAILURE
WHAT IF IT LOOKED LIKE THIS?
SLIDE 22
Westside Well
PROBABILITY OF FAILURE
CONSEQUENCE OF FAILURE
Or this?
SLIDE 23
CRITICALITY IS NOT STATIC EACH DAY CRITICALITY CHANGES SLIGHTLY NEED TO REASSESS CRITICALITY AT LEAST EVERY YEAR IF NOT SOONER REASSESS WHEN MAJOR CHANGES ARE MADE (UPGRADES, REPLACEMENTS, MAJOR CONSTRUCTION, REHABILITATION, REDUNDANCY ADDED)
CRITICALITY CHANGES
SLIDE 24
CRITICALITY IN ACTION
Frank Roth, ABCWUA, Albuquerque, NM
