Creating and Deploying Visualize Innovate a Digital Strategy Transform Improve the way you Trisotech brings Strategies, Design and T echnology do business together to provide business guidance and insight in the digital enterprise age.

slide-1
SLIDE 1

Creating and Deploying a Digital Strategy

Visualize Innovate Transform Improve the way you do business

Where strategies come to life!

Trisotech brings Strategies, Design and T echnology together to provide business guidance and insight in the digital enterprise age.

slide-2
SLIDE 2

Trisotech Digital Enterprise Suite

Where strategies come to life!

Business ss Model Business ss Model Golde n n Circl cle Golde n n Circl cle SWOT Value Propos

  • sition
  • n

Value Propos

  • sition
  • n

Custome

  • mer

Journey Map Custome

  • mer

Journey Map Empathy Map Empathy Map CMM MMN CMM MMN DMN MN DMN MN BPMN MN BPMN MN HW5 Value Map Value Map Capab abilities Model Capab abilities Model SIPOC SIPOC Balan ance ced Scoreca card Balan ance ced Scoreca card RACI RACI

Outside tside In Inside side Out

Str trateg egic Ope peration ional

Canva anvases ses Brai ainsto nstorm Mode dels ls Analysis alysis

What ever the path you decide to follow for your Digital Transformation, Trisotech Digital Enterprise Suite offers the collection of software tools that together will ensure your Digital Transformation success.

Business ss Motivatio ation

slide-3
SLIDE 3

Trisotech Digital Enterprise Suite

Cloud-based software to Visualize, Innovate, Transform, and Improve your organization

Where strategies come to life!

Companies are facing serious problems:

Trisotech with its Digital Enterprise Suite is in a unique position to help

  • rganizations to transform their business, not only to be more efficient

and effective, but also more agile in delivering and improving customer experience.

slide-4
SLIDE 4
slide-5
SLIDE 5

Trisotech is a global leader in digital enterprise solutions, offering innovative and easy-to-use software tools that allow customers to discover, model, analyze and find insights into their digital enterprise.

BASIC ELEMENTS

Pool

Event Activity Gateway FLOW

20161007

BPMN Quick Guide A simple, basic, yet complete, BPMN reference accessible to everyone. www.BPMNQuickGuide.com

Start Event Service Task Decision Task Data Object End Event End Event Intermediate Message Event

BPMN is a universal graphical notation for documenting business processes and driving process improvement initiatives. It enables a disciplined process approach that allows organizations to become more efficient.

www.Trisotech.com

Download Free BPMN, CMMN and DMN templates at www.Trisotech.com/Visio Sequence Flow Message Flow Data Association

Subprocess Case Task

T r i g g e r s a n e w p r

  • c

e s s i n s t a n c e E x t e r n a l P a r t i c i p a n t t

  • t

h e p r

  • c

e s s W h a t i s d

  • n

e n e x t T a s k t

  • b

e c

  • m

p l e t e d R

  • u

t i n g I n f

  • r

m a t i

  • n

r e q u i r e d a s i n p u t E n d s t a t e

  • f

t h e p r

  • c

e s s E x t e r n a l c

  • m

m u n i c a t i

  • n

Current Status BPMN 2.0 Released 2010

slide-6
SLIDE 6

Benefits of using Standard Notations and Execution

 Unambiguous format for modeling processes, cases and decisions  Can be interchanged between different vendors’ products  Provide common and readily-transferable skills that are learned by business and IT professionals

slide-7
SLIDE 7

“Giving back control to business”

RDBMS DMS BRMS BPMS

slide-8
SLIDE 8

Citizen Developers are key to business agility

A citizen developer is a user who creates new business applications for consumption by others using development and runtime environments sanctioned by corporate IT. Gartner

slide-9
SLIDE 9

Informed decision-making comes from a long tradition of guessing and then blaming others for inadequate results. Scott Adams

Decision Making

slide-10
SLIDE 10
  • Strategic Decisions
  • Tactical Decisions
  • Operational Decisions

Operational decisions are made every day!

Decision Making

slide-11
SLIDE 11

Decision Input Data

Decision 1 Decision 2 Input Data 3 Input Data 1 Input Data 2 Knowledge Source

www.Trisotech.com

BASIC ELEMENTS

REQUIREMENT

Business Knowledge Model

20161007

Download Free BPMN, CMMN and DMN templates at www.Trisotech.com/Visio

Trisotech is a global leader in digital enterprise solutions, offering innovative and easy-to-use software tools that allow customers to discover, model, analyze and find insights into their digital enterprise.

DMN provides a modeling notation to capture business decision requirements and decision logic. It increases an organization’s agility and adaptability by capturing the business decisions independently from where they are used.

Decision logic using a Decision Table

Decision Requirement Diagram (DRD)

Each row is a rule Conditions Result Defined decision logic Re- usable decision logic Input required for the decision Authority source

  • f this data

Information Knowledge Authority

Current Status DMN 1.1 Released 2016

slide-12
SLIDE 12

DMN

What is DMN

  • What is DMN?
  • Decision Model and Notation
  • DMN is a standard published by the Object Management Group (OMG).
  • Why DMN matters?
  • A common meta-model and notation for describing and modeling

repeatable Business Decisions

  • Enables various groups to effectively collaborate in defining a Decision

Model

  • Provides a standard notation for Decision Tables
  • DMN increases an organization’s agility and adaptability by defining both

the requirements of the business decision and the structured design logic

  • Current Status
  • DMN 1.1 Released 2016
slide-13
SLIDE 13

DMN is by design a complement to BPMN and CMMN

slide-14
SLIDE 14

Discovery Specification Execution Business “harvest” rules Business translate rules into business requirements IT translate rules an executable rule language

Decision Making using Rules

Lost in translation

slide-15
SLIDE 15

Different Perspectives

BDMS ≠ BRMS ≠ BVMS Just like a BRMS features cannot be evaluated against BVMS features A BDMS features cannot be evaluated against a BRMS or BVMS features Some of the same goals are achieved differently

BVMS

Business Vocabulary Management System

BDMS

Business Decision Management System

BRMS

Business Rule Management System

BVMS

Business Vocabulary Management System Decisions Rules Terms Rules, Terms Decisions, Terms Rules, Decisions

First Class Citizen Second Class Citizens

slide-16
SLIDE 16

Decision Making

Using Rules

  • Text based and not verifiable
  • Misinterpretation during translation
  • Rule are continuously changing
  • Proprietary rule languages
  • Verifiable
  • No translation. Model driven.
  • Decisions are tangible and more stable
  • It is a standard. The same in every tool

Using DMN Decisions

What you model is what you execute! Decisions as first class citizen

slide-17
SLIDE 17

Decision Modeled Graphically

Executable logic from diagrams and tables

Input Data Decision Business Knowledge Model Hit policy Rule number Inputs Output

slide-18
SLIDE 18

Decision Task Inputs of Decision Branching based on Decision

BPMN: Process Modeled Graphically

slide-19
SLIDE 19

Inputs of Decision Decision

DMN: Decision Modeled Graphically

Captures the Decision’s Requirements via the Decision Requirement Diagram (DRD) Captures the Decision’s Logic via Decision Tables or Boxed Expressions

slide-20
SLIDE 20

BPM N DMN

slide-21
SLIDE 21
slide-22
SLIDE 22

Name of Decision Hit policy Rule number Conditions Result

DMN: Decision Table

Inputs

slide-23
SLIDE 23
slide-24
SLIDE 24
slide-25
SLIDE 25
slide-26
SLIDE 26

FEEL Expressions Invocation Parameters Context entries (“Local variables”) Result Name of Decision

DMN: Boxed Expression

slide-27
SLIDE 27
  • Modeling
  • Authoring
  • Methodology
  • Training
  • Runtime
  • Validation

Decision Model and Notation (DMN)

Only End-to-End DMN Solution

slide-28
SLIDE 28

Only Conformance Level 3 solution

The spec defines 3 incremental conformance levels for implementations:

Conformance Level 1:

  • Requires support for authoring of Decision Requirements Diagram, Decision Logic and Decision Tables
  • This conformance level is basically “documentation only”, no execution required

Conformance Level 2:

  • Everything from conformance level 1, plus support for the S-FEEL (simplified FEEL) expression

language

  • Requires execution, and requires the logic modeled in CL1 to be expressed in S-FEEL

Conformance Level 3:

  • Everything from conformance level 2, plus support for the full FEEL language
  • This includes additional modeling elements like “boxed expressions”
slide-29
SLIDE 29

Business-Friendly Interface

  • Prepopulate decision tables

with input(s) structure(s)

  • Create types automatically
slide-30
SLIDE 30

DMN Model Validation

slide-31
SLIDE 31

Method & Style DT Analysis

  • Gaps
  • Overlaps
  • Normal Forms
slide-32
SLIDE 32

Method & Style eLearning

slide-33
SLIDE 33

All FEEL Functions and Operators

slide-34
SLIDE 34

Trisotech FEEL Editor

  • Code completion
  • Code coloring
  • Content assist

(Text, Dates,etc)

slide-35
SLIDE 35

Full Boxed Expression Support

slide-36
SLIDE 36

Logic Reuse via BKMs

slide-37
SLIDE 37

Export to DMN XML

slide-38
SLIDE 38

The Model is the Documentation

slide-39
SLIDE 39

Test the Model Logic

Execution… not “Requirements”

slide-40
SLIDE 40

The Model is Executable

DMN Native

  • Deploy as a cloud

service

  • Deploy in Red Hat on

Premise

  • Deploy in Red Hat

Openshift

Translation

  • Deploy in Idiom
  • Deploy in OpenRules

Execution… not “Requirements”

slide-41
SLIDE 41

https://dmn-tck.github.io/tck/ https://www.amazon.com/Bruce-Silver/e/B0062AXUFY/ref=dp_byline_cont_book_1 Red Hat JBoss BPM Suite: https://developers.redhat.com/products/bpmsuite/overview/ https://Trisotech.com/DMNQuickStart
