Creating an API Centric Enterprise

Solutions Engineer Lakmal Kodithuwakku

2

3

• API Management Vision
• Solution Architecture
• Product Features and Capabilities
• API Store / Developer Portal
• Publishing Application
• API gateway, including security
• Monitoring And Analytics

Presentation Agenda

4

“API Economy”

• Foster Internal Reuse and Share
• Realize the value of SOA with APIs, adding monitoring, access control, and importantly
• monetization. SOA and APIs are complementary approaches.
• Unleash external developers Innovation
• Let external developers innovate around your APIs and other APIs on the market
• Accelerate Mobile applications development
• Driven by the need to consume internal data from mobile applications
• Build new Channels and Ecosystems
• Build new distribution channels to selected partners and customers
• Open APIs provides a platform on which they can build.
• Create new Business Models
• The APIs are the main source of revenue for the enterprise

5

When APIs meet SOA

“APIs are the missing link for SOA success”

6

Managing APIs

• An API is a business capability delivered over the

Internet to internal or external consumers

• Network accessible function
• Available using standard web protocols
• With well-defined interfaces
• Designed for access by third-parties

• A Managed API is:
• Actively advertised and subscribe-able
• Available with SLAs
• Secured, authenticated, authorized and protected
• Monitored and monetized with analytics

7

WSO2 API Manager

• The only complete, 100% open source API Management solution
• A cleanly integrated system which supports API publishing,

lifecycle management, developer portal, access control and analytics

• Backed by High performance gateway
• A single node supports more than 100 million requests/day
• eBay handles 6 billions/day, a number which nearly doubles at peak season time.
• Includes Social enablement such as ratings and comments
• Supports single-sign on with Facebook, GoogleApps, etc.
• Named a Strong Performer in this space by Forrester in 2014
• Best API Design across all vendors
• Best Solution Cost for on-premise solution
• Extremely Satisfied customers
• Available on-premise, as managed deployment and as SaaS

application (beta)

8

API Centric Capabilities

• Expose APIs for public

consumption

• Extend your business through APIs.
• API Branding
• Expose APIs for internal

consumption

• Manage the APIs used in internal applications
• Detect Usage Patterns
• Internal Monetization
• Control Access to Cloud Services
• Manage and Secure access from internal

applications to cloud services (SalesForce, Google Apps, etc.)

9

WSO2 API Management Platform

API Management Vision

• Create APIs
• WSO2 Application Server, Data Services Server and ESB
• Find and subscribe/buy APIs
• API Store and Governance
• Manage, secure and protect APIs
• API Management and Gateway
• Monitor and Monetize APIs
• API Monitoring and Analytics
• Develop, host and run API-based

applications in a Platform-as-a- Service

• WSO2 Private PaaS and Cloud Development Platform
• API Cloud

10

API Management Platform

11

API Ecosystem Model

From SOA lessons learned, best practices roles


• API Creator
• Designs, Implements, manages and versions API
• Understand business and technical requirements
• Cares about usage and scaling
• Seeks feedback, ratings, usage
• API Publisher
• Publishes, Promotes and encourages consumers to adopt APIs
• Determines usage patterns and how to best monetize asset
• Monitors and secures
• API Consumer
• Understands the interface definition
• Subscribes and connects application to API
• Monitors own usage and cost basis
• Provides feedback and ratings

12

API Manager Components

13

API Gateway Processing Flow

14

Multi-Tenancy

• Creation of multiple domains (tenants)
• Each domain can have their own store or publish APIs to a central store
• This is transparent to the consumers.
• Typical Use Cases:
• Segmenting the publishers by business unit or partner and restricting editing rights by domain
• Create an API marketplace : one-stop store for domain APIs.
• API Cloud heavily leverages this functionality

15

API Store: Customization

16

Scalable Deployment Architecture

17

API Facade Pattern: Recommended Deployment

• API Gateway acts as simple reverse proxy, enforcing policies and

collecting monitoring information

• Specific security checks/protection at edge of the network
• Invalid requests are stopped at the edge of the network
• Clear separation of concern between layers
• The mediation and API management layers scale independently
• You can combine the Façade and Mediation layers (if required) and

run as a single architecture layer.

18

Demo

Contact us !

Join us at :
