Convolutional Neural Networks Rachel Hu and Zhi Zhang Amazon AI d2l.ai Outline GPUs Convolutions Pooling, Padding and Stride Convolutional Neural Networks (LeNet) Deep ConvNets (AlexNet) Networks using Blocks (VGG)

slide-1
SLIDE 1

d2l.ai

Convolutional Neural Networks

Rachel Hu and Zhi Zhang Amazon AI

slide-2
SLIDE 2

d2l.ai

Outline

  • GPUs
  • Convolutions
  • Pooling, Padding and Stride
  • Convolutional Neural Networks (LeNet)
  • Deep ConvNets (AlexNet)
  • Networks using Blocks (VGG)
  • Residual Neural Networks (ResNet)
slide-3
SLIDE 3

d2l.ai

GPUs

NVIDIA Turing TU102

slide-4
SLIDE 4

d2l.ai

Intel i7-6700K

  • 4 Physical cores
  • Per core
  • 64KB L1 cache
  • 256KB L2 cache
  • Shared 8MB L3 cache
  • 30 GB/s to RAM
slide-5
SLIDE 5

d2l.ai

GPU performance

slide-6
SLIDE 6

d2l.ai

Highend Gaming / DeepLearning PC

DDR4 32 GB Nvidia Titan RTX 12 TFLOPS (130TF for FP16 TensorCores) 24 GB Intel i7 0.15 TFLOPS

slide-7
SLIDE 7

d2l.ai

Highend Gaming / DeepLearning PC

DDR4 32 GB Nvidia Titan RTX 12 TFLOPS (130TF for FP16 TensorCores) 24 GB Intel i7 0.15 TFLOPS

ctx = npx.cpu() ctx = npx.gpu(0) x.copyto(ctx)

slide-8
SLIDE 8

d2l.ai

GPU Notebook

slide-9
SLIDE 9

d2l.ai

From fully connected to convolutions

slide-10
SLIDE 10

d2l.ai

Classifying Dogs and Cats in Images

  • Use a good camera
  • RGB image has 36M elements
  • The model size of a single hidden

layer MLP with a 100 hidden size is 3.6 Billion parameters

  • Exceeds the population of dogs

and cats on earth
 (900M dogs + 600M cats)

slide-11
SLIDE 11

d2l.ai

Flashback - Network with one hidden layer

36M features 100 neurons

h = σ (Wx + b)

3.6B parameters = 14GB

slide-12
SLIDE 12

d2l.ai

Where is Waldo?

slide-13
SLIDE 13

d2l.ai

  • Translation

Invariance

  • Locality

Two Principles

slide-14
SLIDE 14

d2l.ai

Rethinking Dense Layers

  • Reshape inputs and output into matrix (width, height)
  • Reshape weights into 4-D tensors (h,w) to (h’,w’)

V is re-indexes W such as that

hi,j = ∑

k,l

wi,j,k,lxk,l = ∑

a,b

vi,j,a,bxi+a,j+b

vi,j,a,b = wi,j,i+a,j+b

slide-15
SLIDE 15

d2l.ai

Idea #1 - Translation Invariance

  • A shift in x also leads to a shift in h
  • v should not depend on (i,j). Fix via vi,j,a,b = va,b

hi,j = ∑

a,b

va,bxi+a,j+b hi,j = ∑

a,b

vi,j,a,bxi+a,j+b

That’s a 2-D convolution cross-correlation

slide-16
SLIDE 16

d2l.ai

Idea #2 - Locality

  • We shouldn’t look very far from x(i,j) in order to assess

what’s going on at h(i,j)

  • Outside range parameters vanish

hi,j = ∑

a,b

va,bxi+a,j+b

|a|, |b| > Δ va,b = 0

hi,j =

Δ

∑

a=−Δ Δ

∑

b=−Δ

va,bxi+a,j+b

slide-17
SLIDE 17

d2l.ai

Convolution

slide-18
SLIDE 18

d2l.ai

2-D Cross Correlation

(vdumoulin@ Github)

0 × 0 + 1 × 1 + 3 × 2 + 4 × 3 = 19, 1 × 0 + 2 × 1 + 4 × 2 + 5 × 3 = 25, 3 × 0 + 4 × 1 + 6 × 2 + 7 × 3 = 37, 4 × 0 + 5 × 1 + 7 × 2 + 8 × 3 = 43.

slide-19
SLIDE 19

d2l.ai

2-D Convolution Layer

  • input matrix
  • kernel matrix
  • b: scalar bias
  • output matrix





  • W and b are learnable parameters

Y = X ⋆ W + b

X : nh × nw W : kh × kw Y : (nh − kh + 1) × (nw − kw + 1)

slide-20
SLIDE 20

d2l.ai

Examples

Edge Detection Sharpen Gaussian Blur

(wikipedia)

slide-21
SLIDE 21

d2l.ai

Examples

(Rob Fergus)

slide-22
SLIDE 22

d2l.ai

Convolutions Notebook

slide-23
SLIDE 23

d2l.ai

Padding and Stride

slide-24
SLIDE 24

d2l.ai

Padding

  • Given a 32 x 32 input image
  • Apply convolutional layer with 5 x 5 kernel
  • 28 x 28 output with 1 layer
  • 4 x 4 output with 7 layers
  • Shape decreases faster with larger kernels
  • Shape reduces from to

nh × nw (nh − kh + 1) × (nw − kw + 1)

slide-25
SLIDE 25

d2l.ai

Padding

Padding adds rows/columns around input

0 × 0 + 0 × 1 + 0 × 2 + 0 × 3 = 0

slide-26
SLIDE 26

d2l.ai

Padding

  • Padding rows and columns, output shape will be
  • A common choice is and
  • Odd : pad on both sides
  • Even : pad on top, on bottom

(nh − kh + ph + 1) × (nw − kw + pw + 1)

ph pw ph = kh − 1 pw = kw − 1 kh ph/2 kh

⌈ph/2⌉ ⌊ph/2⌋

slide-27
SLIDE 27

d2l.ai

Stride

  • Padding reduces shape linearly with #layers
  • Given a 224 x 224 input with a 5 x 5 kernel, needs 44

layers to reduce the shape to 4 x 4

  • Requires a large amount of computation
slide-28
SLIDE 28

d2l.ai

Stride

  • Stride is the #rows/#columns per slide

Strides of 3 and 2 for height and width 0 × 0 + 0 × 1 + 1 × 2 + 2 × 3 = 8 0 × 0 + 6 × 1 + 0 × 2 + 0 × 3 = 6

slide-29
SLIDE 29

d2l.ai

Stride

  • Given stride for the height and stride for the width,


the output shape is

  • With and
  • If input height/width are divisible by strides

sh sw

⌊(nh − kh + ph + sh)/sh⌋ × ⌊(nw − kw + pw + sw)/sw⌋

ph = kh − 1 pw = kw − 1

⌊(nh + sh − 1)/sh⌋ × ⌊(nw + sw − 1)/sw⌋ (nh/sh) × (nw/sw)

slide-30
SLIDE 30

d2l.ai

M u l t i p l e I n p u t a n d O u t p u t C h a n n e l s

slide-31
SLIDE 31

d2l.ai

Multiple Input Channels

  • Color image may have three RGB channels
  • Converting to grayscale loses information
slide-32
SLIDE 32

d2l.ai

Multiple Input Channels

  • Color image may have three RGB channels
  • Converting to grayscale loses information
slide-33
SLIDE 33

d2l.ai

Multiple Input Channels

  • Have a kernel for each channel, and then sum results
  • ver channels

(1 × 1 + 2 × 2 + 4 × 3 + 5 × 4) +(0 × 0 + 1 × 1 + 3 × 2 + 4 × 3) = 56

slide-34
SLIDE 34

d2l.ai

Multiple Input Channels

  • input
  • kernel
  • output

X : ci × nh × nw W : ci × kh × kw Y : mh × mw

Y =

ci

∑

i=0

Xi,:,: ⋆ Wi,:,:

slide-35
SLIDE 35

d2l.ai

Multiple Output Channels

  • No matter how many inputs channels, so far we always

get single output channel

  • We can have multiple 3-D kernels, each one generates a
  • utput channel
  • Input
  • Kernel
  • Output

X : ci × nh × nw W : co × ci × kh × kw Y : co × mh × mw

Yi,:,: = X ⋆ Wi,:,:,: for i = 1,…, co

slide-36
SLIDE 36

d2l.ai

Multiple Input/Output Channels

  • Each output channel may recognize a particular pattern
  • Input channels kernels recognize and combines patterns

in inputs

slide-37
SLIDE 37

d2l.ai

1 x 1 Convolutional Layer

is a popular choice. It doesn’t recognize spatial patterns, but fuse channels.
 Equal to a dense layer with input and
 weight. kh = kw = 1 nhnw × ci co × ci

slide-38
SLIDE 38

d2l.ai

2-D Convolution Layer Summary

  • Input
  • Kernel
  • Bias
  • Output
  • Complexity (number of floating point operations FLOP)
  • 10 layers, 1M examples: 10PF


(CPU: 0.15 TF = 18h, GPU: 12 TF = 14min) X : ci × nh × nw W : co × ci × kh × kw Y : co × mh × mw

Y = X ⋆ W + B

B : co × ci

O(cicokhkwmhmw)

ci = co = 100 kh = hw = 5 mh = mw = 64 1GFLOP

slide-39
SLIDE 39

d2l.ai

P

  • l

i n g L a y e r

slide-40
SLIDE 40

d2l.ai

Pooling

  • Convolution is sensitive to position
  • Detect vertical edges
  • We need some degree of invariance to translation
  • Lighting, object positions, scales, appearance vary

among images

X Y 0 output with 1 pixel shift

slide-41
SLIDE 41

d2l.ai

2-D Max Pooling

  • Returns the maximal value in the

sliding window

max(0,1,3,4) = 4

slide-42
SLIDE 42

d2l.ai

2-D Max Pooling

  • Returns the maximal value in the sliding window

Conv output 2 x 2 max pooling Vertical edge detection Tolerant to 1 pixel shift

slide-43
SLIDE 43

d2l.ai

Padding, Stride, and Multiple Channels

  • Pooling layers have similar padding

and stride as convolutional layers

  • No learnable parameters
  • Apply pooling for each input channel to
  • btain the corresponding output

channel

 #output channels = #input channels

slide-44
SLIDE 44

d2l.ai

Average Pooling

  • Max pooling: the strongest pattern signal in a window
  • Average pooling: replace max with mean in max pooling
  • The average signal strength in a window

Max pooling Average pooling

slide-45
SLIDE 45

d2l.ai

Pooling Notebook

slide-46
SLIDE 46

d2l.ai

LeNet

slide-47
SLIDE 47

d2l.ai

Handwritten Digit Recognition

slide-48
SLIDE 48

d2l.ai

MNIST

  • Centered and scaled
  • 50,000 training data
  • 10,000 test data
  • 28 x 28 images
  • 10 classes
slide-49
SLIDE 49

d2l.ai

  • Y. LeCun, L.

Bottou, Y. Bengio,

  • P. Haffner, 1998

Gradient-based learning applied to document recognition

slide-50
SLIDE 50

d2l.ai

Expensive if we have many

  • utputs
slide-51
SLIDE 51

d2l.ai

LeNet Notebook

slide-52
SLIDE 52

d2l.ai

AlexNet

slide-53
SLIDE 53

d2l.ai

AlexNet

  • AlexNet won ImageNet

competition in 2012

  • Deeper and bigger LeNet
  • Key modifications
  • Dropout (regularization)
  • ReLu (training)
  • MaxPooling
  • Paradigm shift for computer

vision

Manually engineered features SVM Features learned by a CNN Softmax regression

slide-54
SLIDE 54

d2l.ai

AlexNet Architecture

LeNet AlexNet

Larger kernel size, stride because of the increased image size, and more

  • utput channels.

Larger pool size, change to max pooling

slide-55
SLIDE 55

d2l.ai

AlexNet Architecture

LeNet AlexNet

More output channels. 3 additional
 convolutional layers

slide-56
SLIDE 56

d2l.ai

AlexNet Architecture

LeNet AlexNet

Increase hidden size
 from 120 to 4096 1000 classes output

slide-57
SLIDE 57

d2l.ai

More Tricks

  • Change activation function from sigmoid to ReLu


(no more vanishing gradient)

  • Add a dropout layer after two hidden dense layers


(better robustness / regularization)

  • Data augmentation
slide-58
SLIDE 58

d2l.ai

Complexity

#parameters FLOP AlexNet LeNet AlexNet LeNet Conv1 35K 150 101M 1.2M Conv2 614K 2.4K 415M 2.4M Conv3-5 3M 445M Dense1 26M 0.48M 26M 0.48M Dense2 16M 0.1M 16M 0.1M Total 46M 0.6M 1G 4M Increase 11x 1x 250x 1x

slide-59
SLIDE 59

d2l.ai

AlexNet Notebook

slide-60
SLIDE 60

d2l.ai

Inception

slide-61
SLIDE 61

d2l.ai

Picking the best convolution …

LeNet AlexNet VGG NiN 1x1 3x3 5x5 Max pooling Multiple 1x1

slide-62
SLIDE 62

d2l.ai

Why choose? Just pick them all.

slide-63
SLIDE 63

d2l.ai

  • Inception Blocks

4 paths extract information from different aspects, then concatenate along the output channel

Extract with different spatial size convolutions Extract spatial info with pooling Same width/ height as input

slide-64
SLIDE 64

d2l.ai

Inception Blocks

  • Allocate various

capacities to each channel Reduce channel size to lower model capacity

The first inception block with channel sizes specified

slide-65
SLIDE 65

d2l.ai

Inception Blocks

  • #parameters FLOPS

Inception 0.16 M 128 M 3x3 Conv 0.44 M 346 M 5x5 Conv 1.22 M 963 M

Inception blocks have fewer parameters and less computation complexity than a single 3x3 or 5x5 convolutional layer

  • Mix of different functions (powerful function class)
  • Memory and compute efficiency (good generalization)
slide-66
SLIDE 66

d2l.ai

GoogLeNet

  • 5 stages with 9

inceptions blocks

Stage 1 Stage 2 Stage 3 Stage 4 Stage 5 Output

  • 2x

5x 2x

slide-67
SLIDE 67

d2l.ai

The many flavors of Inception Networks

  • Inception-BN (v2) - Add batch normalization
  • Inception-V3 - Modified the inception block
  • Replace 5x5 by multiple 3x3 convolutions
  • Replace 5x5 by 1x7 and 7x1 convolutions
  • Replace 3x3 by 1x3 and 3x1 convolutions
  • Generally deeper stack
  • Inception-V4 - Add residual connections (more later)
slide-68
SLIDE 68

d2l.ai

GluonCV Model Zoo https://gluon- cv.mxnet.io/model_zoo/ classification.html Inception V3

slide-69
SLIDE 69

d2l.ai

Batch Normalization

NORM

slide-70
SLIDE 70

Batch Normalization

  • Loss occurs at last layer
  • Last layers learn quickly
  • Data is inserted at bottom layer
  • Bottom layers change - everything changes
  • Last layers need to relearn many times
  • Slow convergence
  • This is like covariate shift


Can we avoid changing last layers while
 learning first layers? loss data

slide-71
SLIDE 71

Batch Normalization

  • Can we avoid changing last layers while


learning first layers?

  • Fix mean and variance





 and adjust it separately loss data µB = 1 |B| X

i∈B

xi and 2

B =

1 |B| X

i∈B

(xi − µB)2 + ✏ xi+1 = γ xi − µB σB + β mean variance

slide-72
SLIDE 72

d2l.ai

This was the original motivation …

slide-73
SLIDE 73

d2l.ai

What Batch Norms really do

  • Doesn’t really reduce covariate shift (Lipton et al., 2018)
  • Regularization by noise injection
  • Random shift per minibatch
  • Random scale per minibatch
  • No need to mix with dropout (both are capacity control)
  • Ideal minibatch size of 64 to 256

xi+1 = γ xi − ̂ μB ̂ σB + β

Empirical mean Empirical variance Random

  • ffset

Random scale

slide-74
SLIDE 74

d2l.ai

Residual Networks

slide-75
SLIDE 75

d2l.ai

Does adding layers improve accuracy?

? ✔

slide-76
SLIDE 76

d2l.ai

Residual Networks

  • Adding a layer

changes function
 class

  • We want to add to

the function class

  • ‘Taylor expansion'


style parametrization f(x) = x + g(x)

He et al., 2015

slide-77
SLIDE 77

d2l.ai

ResNet Block in detail

slide-78
SLIDE 78

d2l.ai

In code

def forward(self, X): Y = npx.relu(self.bn1(self.conv1(X))) Y = self.bn2(self.conv2(Y)) if self.conv3: X = self.conv3(X) return npx.relu(Y + X)

slide-79
SLIDE 79

d2l.ai

The many flavors of ResNet blocks

Try every permutation Try every permutation Try every permutation

slide-80
SLIDE 80

d2l.ai

ResNet Module

  • Downsample per module

(stride=2)

  • Enforce some nontrivial

nonlinearity per module (via 1x1 convolution)

  • Stack up in blocks

Stride 2 Stride 2 Multiple Repetitions

blk = nn.Sequential() for i in range(num_residuals): if i == 0 and not first_block: blk.add(Residual(num_channels, use_1x1conv=True, strides=2)) else: blk.add(Residual(num_channels))

slide-81
SLIDE 81

d2l.ai

Putting it all together

  • Same block structure as e.g. VGG or

GoogleNet

  • Residual connection to add to

expressiveness

  • Pooling/stride for dimensionality reduction
  • Batch Normalization for capacity control

… train it at scale …

slide-82
SLIDE 82

d2l.ai

GluonCV Model Zoo https://gluon- cv.mxnet.io/model_zoo/ classification.html ResNet 152

slide-83
SLIDE 83

d2l.ai

Jupyter Notebook

slide-84
SLIDE 84

d2l.ai

More Ideas

slide-85
SLIDE 85

d2l.ai

DenseNet (Huang et al., 2016)

  • ResNet combines x and f(x)
  • DenseNet uses higher order


‘Taylor series’ expansion

  • Occasionally need to reduce resolution (transition layer)

xi+1 = [xi, fi(xi)] x1 = x x2 = [x, f1(x)] x2 = [x, f1(x), f2([x, f1(x)])]

slide-86
SLIDE 86

d2l.ai

Squeeze-Excite Net (Hu et al., 2017)

  • Learn global weighting function per channel
  • Allows for fast information transfer between pixels in

different locations of the image

slide-87
SLIDE 87

d2l.ai

Separable Convolutions - all channels separate

  • Parameters
  • Computation
  • Break up channels to the extreme


No mixing between channels kh ⋅ kw ⋅ ci ⋅ co mh ⋅ mw ⋅ kh ⋅ kw ⋅ ci ⋅ co mh ⋅ mw ⋅ kh ⋅ kw ⋅ c

slide-88
SLIDE 88

d2l.ai

ShuffleNet (Zhang et al., 2018)

  • ResNext breaks convolution into channels
  • ShuffleNet mixes by grouping (very efficient for mobile)
slide-89
SLIDE 89

d2l.ai

Outline

  • GPUs
  • Convolutions
  • Pooling, Padding and Stride
  • Convolutional Neural Networks (LeNet)
  • Deep ConvNets (AlexNet)
  • Networks using Blocks (VGG)
  • Residual Neural Networks (ResNet)
