Configuration and Interoperability Presented by : Jack van der - - PowerPoint PPT Presentation

Malaysia End-User Seminar 11 November 2009

Configuration and Interoperability

Presented by : Jack van der Horst Technology Manager ABB Singapore Pte Ltd

Malaysia End-User Seminar 11 November 2009

Configuration and Interoperability

• Configuration
• Benefits
• Fieldbus is easy to configure
• Concerns
• Offline Configuration Steps
• ONLINE Configuration
• Configuration Example
• Interoperability
• Concept
• ITK
• HIST
• DD and EDDL
• Avoid Surprises
• Interoperability Demonstration

Malaysia End-User Seminar 11 November 2009

Configuration

• Benefits

Foundation Fieldbus Profibus PA 4 ‐ 20 + HART Media Shielded Twisted Pair Shielded Twisted Pair Shielded Twisted Pair Intrinsic Safety FISCO FISCO Entity Diagnostics HOST/Asset Management HOST/Asset Management with Handheld/Multiplexer Calibration HOST/Asset Management Need to connect to DP/PA Coupler with Handheld/Multiplexer Configuration HOST/Asset Management Need to connect to DP/PA Coupler with Handheld/Multiplexer Logic from DCS use 4.20mA Automatic Detection Yes No No Self‐addressing Yes No No Function block Yes, with configuration blocks also inside transmitters Yes, no configuration blocks

• n transmitters

No

Malaysia End-User Seminar 11 November 2009

Configuration

• Easy to configure
• Use of function blocks will make the

configuration look like the P&ID

• Use of templates
• Self Addressing
• Addressing is not necessary

Malaysia End-User Seminar 11 November 2009

Configuration

• Easy to configure
• Use of function blocks will make the

configuration looks like the P&ID

OUT IN OUT IN OUT OUT TRD_IN_D CAS_IN BKCAL_IN BKCAL_OUT CAS_IN BKCAL_IN BKCAL_OUT

FLOW AI FLOW PID FLOW AO TEMP AI TEMP PID

Malaysia End-User Seminar 11 November 2009

Configuration

• Easy to configure
• Use of templates

Malaysia End-User Seminar 11 November 2009

Configuration

• Easy to configure
• Self Addressing
• Auto Detection

Malaysia End-User Seminar 11 November 2009

Configuration

• Concerns
• Too many parameters!!!! – No need to configure all of them
• Cross reference on Tags and address for OPC database

– Not necessary! FF refers to tag only and follow a standard for tags Servername/Tag_name.parameter.Value, status

• FAT – Need all devices for FAT!!! Not necessary,

simulation and typical loops test are enough.

Malaysia End-User Seminar 11 November 2009

Configuration

• ONLINE Configuration
• Detect devices Automatically
• Address defined automatically
• Macrocycle calculated automatically
• Possibility to import templates
• Instantiate the function blocks according to your need
• Download will not interrupt other loops, even in the same

bus segment

Malaysia End-User Seminar 11 November 2009

Configuration

Step by step configuration

Malaysia End-User Seminar 11 November 2009

Interoperability

• Concept

The ability to operate multiple devices from multiple manufacturers, in the same system, without loss of functionality.

• Different hosts and field devices interacting, exchanging

data and executing control, seamless interfaced.

• ITK – Interoperability Test Kit
• HIST – Host Interoperability Support Test

Malaysia End-User Seminar 11 November 2009

Interoperability

Malaysia End-User Seminar 11 November 2009

Interoperability

• ITK - Interoperability Test Kit
• Interoperability Test Kit

Malaysia End-User Seminar 11 November 2009

Interoperability

• HIST – Host Interoperability Support Test
• Profiles defined by Fieldbus Foundation
• Tests execute Mandatory, Optional and Prohibited

features

• Four Profile Classes:
• Class 61 – Integrated Host
• Class 62 – Visitor Host
• Class 63 – Bench Host (non-commissioned device)
• Class 64 – Bench Host (commissioned device)

Malaysia End-User Seminar 11 November 2009

Interoperability

• DD and EDDL

Device Descriptions

The DD file set is compounded by three files: Capability Files ( *.cff extension ) and Device Description Files ( *.sym, *.ffo extensions )

Malaysia End-User Seminar 11 November 2009

Interoperability

• Avoid Surprises uses tested devices

Malaysia End-User Seminar 11 November 2009

Interoperability

Demonstration

Malaysia End-User Seminar 11 November 2009

www.fieldbus.org
