Composite Insulated Instrument Transformers for AC & DC Applications ERIK SPERLING COMPOSITE INSULATED INSTRUMENT TRANSFORMERS FOR AC & DC APPLICATIONS by Erik Sperling Presenta?on
by ¡Erik ¡Sperling ¡
COMPOSITE ¡INSULATED ¡ INSTRUMENT ¡TRANSFORMERS ¡ FOR ¡AC ¡& ¡DC ¡APPLICATIONS ¡
PFIFFNER Technology Ltd. / Page 2 / 8/25/15
Presenta?on ¡overview ¡
- Introduc?on ¡
- Basic ¡design ¡criteria ¡for ¡instrument ¡transformer ¡applica?on ¡
- Mechanical ¡discussion ¡
- Electrical ¡field ¡distribu?on ¡
- Heavy ¡rain ¡test ¡performance ¡
- AC ¡applica?on ¡
- DC ¡applica?on ¡– ¡new ¡development ¡of ¡combined ¡unit ¡RJGF400DC ¡
- Conclusion ¡
PFIFFNER Technology Ltd. / Page 3 / 8/25/15
Introduc?on ¡ ¡ • AC ¡system ¡voltage ¡market ¡with ¡composite ¡insulator ¡solu?on ¡
72.5kV ¡ 123kV ¡ 145kV ¡ 170kV ¡ 245kV ¡ 300kV ¡ 362kV ¡ 420kV ¡ 550kV ¡
- DC ¡system ¡voltage ¡market ¡with ¡composite ¡insulator ¡solu?on ¡
±10kV ¡ ±100kV ¡ ±250kV ¡ ±320kV ¡ ±400kV ¡ ±500kV ¡ ±800kV ¡ with ¡HV ¡oil/paper ¡insula?on ¡/ ¡SF6-‑gas ¡(or ¡gas ¡mixtures) ¡insula?on ¡ with ¡HV ¡SF6-‑gas ¡(or ¡gas ¡mixtures) ¡insula?on ¡
PFIFFNER Technology Ltd. / Page 4 / 8/25/15
Basic ¡design ¡criteria ¡ ¡ ¡
- arcing ¡distance, ¡depending ¡on ¡voltage ¡levels ¡(test ¡voltage, ¡lightning-‑ ¡
and ¡switching ¡voltage, ¡tests ¡under ¡wet ¡or ¡dry ¡condi?ons) ¡
- voltage ¡distribu?on ¡along ¡the ¡arcing ¡distance ¡of ¡insulator ¡
- creepage ¡distance, ¡depending ¡on ¡pollu?on ¡level ¡
- installa?on ¡at ¡an ¡al?tude ¡higher ¡than ¡1000 ¡m ¡
- mechanical ¡stresses ¡like ¡bending ¡load, ¡vibra?ons ¡and ¡earthquake ¡
load ¡ requirements ¡to ¡instrument ¡transformer ¡insulators ¡ ¡
PFIFFNER Technology Ltd. / Page 5 / 8/25/15
Basic ¡design ¡criteria ¡– ¡Mechanical ¡discussion ¡
¡
¡ ¡ ¡
1*: ¡sum ¡of ¡all ¡mechanical ¡load ¡during ¡service ¡ 2*: ¡sta?c ¡test ¡bending ¡load ¡ 3*: ¡dynamic ¡bending ¡load ¡ 4*: ¡guaranteed ¡mean ¡value ¡of ¡the ¡breaking ¡strength ¡
- Acc. ¡DIN ¡48113 ¡& ¡IEC ¡61869-‑1 ¡
1.0 ¡× ¡MML: ¡Maximum ¡mechanical ¡load ¡(MML) ¡which ¡ is ¡the ¡design ¡load ¡ 1.5 ¡× ¡MML: ¡Damage ¡limit ¡ 2.5 ¡× ¡MML: ¡Type ¡test ¡SML ¡bending ¡load ¡
- Acc. ¡IEC ¡61462 ¡& ¡IEC ¡61869-‑1 ¡
PFIFFNER Technology Ltd. / Page 6 / 8/25/15
Basic ¡design ¡criteria ¡– ¡Mechanical ¡discussion ¡
¡
¡ ¡ ¡
Mechanical ¡type ¡test ¡on ¡ a ¡3.43m ¡composite ¡ insulator ¡(Di=150mm) ¡ with ¡11kN ¡ d ¡ Deflec?on ¡
- p?miza?on ¡ ¡
da ¡= ¡172 ¡mm ¡ l ¡= ¡2000 ¡mm ¡ F ¡= ¡5 ¡kN ¡
PFIFFNER Technology Ltd. / Page 7 / 8/25/15
Basic ¡design ¡criteria ¡– ¡Electrical ¡field ¡distribu?on ¡
¡
¡ ¡ ¡
4.5 ¡kV/cm ¡
low-‑grade ¡/ ¡ ¡ non-‑grade ¡ fine-‑grade ¡ linear-‑grade ¡
PFIFFNER Technology Ltd. / Page 8 / 8/25/15
Basic ¡design ¡criteria ¡– ¡Heavy ¡rain ¡test ¡performance ¡ ¡ ¡
porcelain ¡insulator ¡for ¡145 ¡kV ¡ composite ¡insulator ¡for ¡123 ¡kV ¡ ¡
- water ¡conduc?vity ¡ ¡ ¡than ¡IEC ¡
- rainfall ¡density ¡ ¡ ¡than ¡IEC ¡
- No ¡internal ¡grading ¡
- Voltage ¡raise ¡up ¡to ¡discharge ¡
Switching ¡impulse ¡test ¡ at ¡1050kVpeak ¡under ¡ wet ¡condi?ons ¡
PFIFFNER Technology Ltd. / Page 9 / 8/25/15
AC ¡applica?on ¡– ¡voltage ¡measurement ¡transformers ¡
¡
¡ ¡ ¡
PFIFFNER Technology Ltd. / Page 10 / 8/25/15
AC ¡applica?on ¡– ¡current ¡measurement ¡transformers ¡
¡
¡ ¡ ¡
PFIFFNER Technology Ltd. / Page 11 / 8/25/15
AC ¡applica?on ¡– ¡combined ¡measuring ¡units ¡
¡
¡ ¡ ¡
PFIFFNER Technology Ltd. / Page 12 / 8/25/15
DC ¡applica?on ¡– ¡electrical ¡requirements ¡
¡
¡ ¡ ¡
PFIFFNER Technology Ltd. / Page 13 / 8/25/15
DC ¡applica?on ¡– ¡basics ¡
¡
¡ ¡ ¡
¡ Voltage section ¡ UN ¡ ±400 kV DC ¡ UM ¡ ±415 kV DC ¡ U2 ¡ ±5 V DC ¡ IN ¡ ±1 mA ¡
- Acc. up to 1.1 p.u. UN ¡
≤ ±0.2 % ¡
- Acc. up to 1.5 p.u. UN ¡
≤ ±0.5 % ¡
- Acc. up to 3 kHz ¡
±2 % ¡ UBIL ¡ 1175 kV peak ¡ USIL ¡ 950 kV peak ¡ UTest dry / wet ¡ ±625 kV DC ¡ PD at: (≤ 2pC) ¡ 440 kV rms ¡ UTest AC ¡ 510 kV rms ¡ RIV level: ¡ ≤ 2500 µV ¡ Creepage distance factor (cdf) ¡ 50 mm/kVDC ¡ ¡ Current section Ipr ¡ ±2000 A DC ¡ Isc (transient) ¡ ±10000 A DC ¡
- Acc. class: ¡
±0.02 % ¡
Voltage ¡measurement: ¡RC-‑divider ¡technology ¡ Current ¡measurement: ¡Shunt ¡technology ¡
𝑉 ↓2 /𝑉 ↓1 =𝑆↓2 /𝑆↓2 +𝑆↓1 ∙(1+𝑘𝜕𝐷↓2 𝑆↓2 )/ (1+𝑘𝜕𝐷↓1 𝑆↓1 ) ¡ ¡ ¡ ¡ ¡ ¡ ¡ ¡= ¡ ¡ ¡ ¡ ¡𝑆↓2 /𝑆↓2 +𝑆↓1 ¡ 𝒈→𝟏 ¡
¡
𝑉=𝑆↓𝑡ℎ𝑣𝑜𝑢 ∙𝐽
PFIFFNER Technology Ltd. / Page 14 / 8/25/15
DC ¡applica?on ¡– ¡design ¡of ¡composite ¡insulator ¡
¡
¡ ¡ ¡
Test ¡ Value ¡
- Min. arcing
distance lAD ¡
- 1. UTest_DC ¡
±625 kV DC ¡ 2300 mm ¡
- 2. UTest_AC ¡
510 kV rms ¡ 2200 mm ¡
- 3. UBIL ¡
±1175 kV peak ¡ 2400 mm ¡
- 4. USIL ¡
+950 kV peak ¡ 3200 mm ¡
- 5. cdf ¡
50 mm/kVDC ¡ 4800 mm ¡
𝑚↓𝐵𝐸 =𝑉↓𝑁 ∙(50𝑛𝑛/𝑙𝑊)∙𝑙↓𝑇𝑄 ∕ 𝑙↓𝑀𝑏𝑞𝑞
- maximum ¡system ¡voltage ¡UM ¡
- kSP ¡= ¡0.8 ¡-‑ ¡reduc?on ¡of ¡equivalent ¡porcelain ¡ ¡
creepage ¡distance ¡
- kLapp ¡= ¡3.5 ¡-‑ ¡rela?on ¡of ¡shed ¡profile ¡CD/AD ¡
Nominal ¡creepage ¡distance ¡length: ¡20750 ¡mm ¡ ¡ UM ¡= ¡±415 ¡kVDC ¡ Cdf ¡= ¡50 ¡mm/kVDC ¡ mean ¡outer ¡diameter ¡
PFIFFNER Technology Ltd. / Page 15 / 8/25/15
DC ¡applica?on ¡– ¡external ¡field ¡grading ¡
¡
¡ ¡ ¡
Current ¡measuring ¡system ¡with ¡shunt ¡technology ¡ E-‑field ¡simula?on ¡result ¡ with ¡lightning ¡impulse ¡
PFIFFNER Technology Ltd. / Page 16 / 8/25/15
DC ¡applica?on ¡– ¡design ¡of ¡DC ¡combined ¡unit ¡
¡
¡ ¡ ¡
Voltage ¡measuring ¡system ¡with ¡RC-‑divider ¡ technology ¡
RC-‑divider ¡unit ¡ ¡
PFIFFNER Technology Ltd. / Page 17 / 8/25/15
Conclusions ¡
¡
¡ ¡ ¡
AC ¡applica?on ¡
- Solu?ons ¡are ¡on ¡the ¡market ¡for ¡the ¡complete ¡voltage ¡range ¡
- Mechanical ¡forces ¡and ¡their ¡effect ¡to ¡the ¡deflec?on ¡have ¡to ¡be ¡taken ¡into ¡account ¡
- Voltage ¡grading ¡has ¡a ¡very ¡important ¡impact ¡to ¡the ¡design ¡of ¡an ¡composite ¡insulator ¡ ¡
DC ¡applica?on ¡
- Solu?ons ¡with ¡composite ¡insulators ¡are ¡on ¡the ¡market ¡for ¡all ¡used ¡voltage ¡levels ¡ ¡
- Voltage ¡and ¡current ¡measurement ¡is ¡available ¡with ¡very ¡high ¡precision ¡
- Pollu?on ¡/ ¡leakage ¡current ¡effects ¡are ¡s?ll ¡in ¡study ¡status ¡
