National Aeronautics and Space Administration

Comparison and Validation of Vortex Lattice Aerodynamic Analysis for the Learjet 24

Curtis Scholz & Andrew Hahn ASAB Systems Analysis and Concepts Directorate 08/06/2014

National Aeronautics and Space Administration

Caveats v This was done by a summer student over a few weeks. v Results are to be considered to be preliminary. v VSPaero is still in development and is at an Alpha state.

✧ Curtis’ work, along with 5 other students stress tested VSPaero, providing excellent feedback to the developer.

Validation of Vortex Lattice, CS 2

National Aeronautics and Space Administration

Motivation for Research

Validation of Vortex Lattice, CS 3

v Aerodynamic analysis performed by the Georgia Tech team competing in the AIAA Design, Build, Fly competition indicated widely varying accuracy of Vortex Lattice flow solvers.

National Aeronautics and Space Administration

Measure Drawings for Unknown Parameters (CANVAS or AutoCAD)

v Allow dimensioning of scaled 3-view drawings v Check Self Consistency v Measure:

✧ Lengths ✧ Areas ✧ Angles ✦ Sweep ✦ Bezier Tangent ✧ Not Tangent Strengths

Validation of Vortex Lattice, CS 4 Figure ¡C-­‑A13.2-­‑4 ¡from ¡Aircra5 ¡Dynamics ¡From ¡Modeling ¡to ¡Simula?on ¡by ¡Marcello ¡R. ¡Napolitano ¡

National Aeronautics and Space Administration

Good Information Is Hard To Come By

Validation of Vortex Lattice, CS 5 Figure ¡C-­‑A13.4 ¡from ¡Aircra5 ¡Dynamics ¡From ¡Modeling ¡to ¡Simula?on ¡by ¡Marcello ¡R. ¡Napolitano ¡

hEp%3A%2F%2Fwww.pprune.org%2Farchive%2Findex.php%2Ft-­‑486918.html&ei=5ZjrU6_BIYqNyATqg4DgDQ&bvm=bv. 72938740,d.aWw&psig=AFQjCNHpwk1uIvhPF1bO12hvn9wm-­‑a6Gag&ust=1408034742416898 ¡

National Aeronautics and Space Administration

Curtis Scholz’s OVSP Learjet 24 Model

Validation of Vortex Lattice, CS 6

National Aeronautics and Space Administration

VorView Analysis: Model Comparison – Learjet 24

Validation of Vortex Lattice, CS 7

National Aeronautics and Space Administration

Meta-geometry Comparison – Learjet 24

Validation of Vortex Lattice, CS 8

Background ¡(transparent) ¡= ¡Created ¡Model ¡ Front ¡(solid) ¡= ¡Provided ¡Model ¡ ¡

National Aeronautics and Space Administration

VorView Analysis: Curtis’ Learjet 24

Validation of Vortex Lattice, CS 9

v Aerodynamic Coefficients

✧ Surface Pressure Integration ✧ Trefftz Plane

Wake Integration

National Aeronautics and Space Administration

VorView and VSPaero Surface Pressure Integration Validation: Curtis’ Learjet 24

Validation of Vortex Lattice, CS 10

National Aeronautics and Space Administration

VorView and VSPaero Trefftz Plane Integration Validation: Curtis’ Learjet 24

Validation of Vortex Lattice, CS 11

National Aeronautics and Space Administration

VorView and VSPaero Comparison: Curtis’ Learjet 24 VorView VSPaero

Validation of Vortex Lattice, CS 12

National Aeronautics and Space Administration

Final Thoughts

Validation of Vortex Lattice, CS 13

v This exercise provided an excellent learning experience for 6 summer students (modeling and analyzing 9 aircraft total). v This exercise provided a base validation suite that we will eventually take through all of the computational aerodynamics tools that we can lay our hands on, through RANS. v This exercise provided a stress test for VSPaero that definitely helped to improve it. v I still need to review their work, cleaning up and correcting as necessary, but I want to put the end products up on the OpenVSP website to act as guides for the community. v My organization needs to understand the cost-benefit ratio of these tools and this exercise was a great start.
