COMPANY PROFILE BioKube is headquarter is Tappernoje, Denmark - - PowerPoint PPT Presentation

“Solutions to get you moving” WASTE TE WATE TER TREATMENT

1

BIOKUBE PRODUCTS

PRESENTATION FOR RESORT INDUSTRY

UN - ESCAP

26 August 2016

“Solution to get you moving” WASTE TE WATE TER TREATMENT

2

COMPANY PROFILE

• BioKube is headquarter is Tappernoje, Denmark
• BioKube was established to support EU in implementing the water directives
• f 1999.
• BioKube has offices in Denmark, and Singapore.
• BioKube has over 15 years experience in the treatment of waste water.
• BioKube develops, manufactures and sells biological operated waste water

treatment systems world-wide through a large distributor and agent network.

• BioKube has production facilities in Czech, Malaysia and India.
• BioKube has sold products in over 20 countries and more than 5,000 systems.
• BioKube produced under ISO 9000.
• BioKube has a patented technology.
• BioKube products comply to the most stringent regulations in the world.

“Solution to get you moving” WASTE TE WATE TER TREATMENT

3

Three different reasons for treating wastewater

100.000.000 people in category

Environment Keep water blue, leisure Health Untreated water make People ill Characteristics:

• Rich countries with strong or

some environmental agenda – Treated water safely discharged to nature

• Driven by legislation which is

enforced by authorities

• Water in big cities (80%)

already treated, open country (20%) being implemented

• Owners will buy cheapest

available systems – only functional systems approved

• Decentralized solutions winning

market due to low cost of

• wnership

Characteristics:

• Areas with no well-functional

separation between wastewater and clean water

• Increasing implications from

failure of water treatment as population grow

• Some level of wealth required

to prioritize water treatment but increasing issue until resolved

• Wastewater cleaning is first
• rder priority as national

wealth increases and massive funds from aid available Water scarcity Reuse of wastewater Characteristics:

• Global water scarcity can only

be met reusing wastewater

• Water scarcity also a challenge

in rich country who have available funds

Time horizon Time horizon Time horizon Rich Poor Remaining China 5 year plan

“Solution to get you moving” WASTE TE WATE TER TREATMENT

4

HOW DOES A BIOKUBE SYTEM WORK

A B

Clarifier after bio zone for settling biological sludge

• Submerged aerated filters (SAF) is the heart of the biological treatment
• Clarifier ensures low SS by settling biological sludge
• Bio-sludge continuously removed to the septic tank

A C C

Pre-treatment Biological treatment

B

“Solution to get you moving” WASTE TE WATE TER TREATMENT

5

Small Systems Single houses – small resorts Jupiter Small cities & resorts BioReactor Larger villages Orion Large villages/cities Saturn Large villages/cities BioContainer For temporary use

PRODUCT PORTFOLIO

“Solution to get you moving” WASTE TE WATE TER TREATMENT

6

PRODUCT TYPES Single Household Systems

(Fixed)

Volume 1 – 5 m3 / day

PE 5 to 100

Containerized Systems

(Transportable)

Volume 50 – 2,000 m3 / day

PE 50 to 2,500

Medium & Large Systems

(Fixed)

Volume 10 – 10,000 m3 / day

PE 100 to 10,000

“Solution to get you moving” SING SINGLE HO HOUSEHOLD SYSTE TEMS

7

MARS 3000/4000/5000 VENUS 2200 VENUS 1850 PLUTO

“Solution to get you moving” SING SINGLE HO HOUSEHOLD SYSTE TEMS

8

• BioKube’s small to medium size systems will treat domestic sewage water ranging from 5 to

50 people.

• These systems are offered as standard solutions for a People Equivalent (PE) of 5 PE, 10 PE,

20 PE or 50 PE.

• Systems can be equipped with special Phosphorous Removal Kits (PRK) and/or Ultra Violet

Lighting (UVL).

• Systems are compacts with a small foot print.
• Systems are light weight.
• The size of the system is determined by the amount of aeration needed for the BioBlocks to

effectively grow the good bacteria and break down the organic material (waste).

• The BioKube products portfolio fulfil any requirements for treatment of waste water (BOD

goes from <30 mg/Liter to BOD <10 mg/Liter)

• Low maintenance for sludge removal

“Solution to get you moving” SING SINGLE HO HOUSEHOLD SYSTE TEMS

9

Higher inflow volume = installation in parallel Higher cleaning demand = installation in series

Modular design of standardized element fits any situation

One technology for all cleaning demands

All BioKube systems are based on the same technology allowing for modular build up and applications for any cleaning demands, volumes and requirements.

• From small systems for single

houses to STP plants for entire villages above 10.000 m³.

• From the strictest Scandinavian

Cleaning Requirements to less strict cleaning demands.

• Cleaner = more in series

Larger = more in parallel

“Solution to get you moving” MEDIU IUM & LAR LARGE SYSTEMS

10

Above ground support beams

“Solution to get you moving” MEDIU IUM & LAR LARGE SYSTEMS

11

Bio-Reactor: Yemen Saturn: Netherlands Saturn: Poland Jupiter: Ghana

Complete Packaged System The 3D image depicts a complete Medium/Large system package.

“Solution to get you moving” CONTAINERIZED S SYSTEMS

12

“Solution to get you moving” WASTE TE WATE TER TREATMENT

13

THAILAND HOTELS & RESORTS INDUSTRY

• Big Sewage Crisis on

Thailand’ Islands

• How are we sizing the waste

water treatment systems?

• PE – 150 Ltr per day (UK-UN)
• PE – 300 Ltr per day (Hotels)
• PE – 1,200 Ltr per day (All)

“Solution to get you moving” WASTE TE WATE TER TREATMENT

14

HOTEL & RESORT INDUSTRY

• BIOKUBE’ products are well fitted for remote sites or de-centralized systems
• Reusing treated waste water is more and more of a demand and generate savings in areas of:
• Irrigation
• Floor & Car Washing
• Toilet Flushing
• Cooling Towers
• BIOKUBE installation of its products in the hotel/resort industry to name few:
• English Point Marina Hotel – Kenya – 260 m3/d
• Glebozek Vine Resort & Spa – Poland – 100 m3/d
• Krotiri Beach Resort – Greece – 80 m3/d
• Ramada Resort – Tanzania – 100 m3/d
• BIOKUBE Biological products advantages:
• Compactness – can fit in basement
• Easy installation
• No Noise / No Smell

“Solution to get you moving” WASTE TE WATE TER TREATMENT

15

“Solution to get you moving” WASTE TE WATE TER TREATMENT

16

CONTACTS

REGIONAL BIOKUBE OFFICE BioKube Asia Pacific Pte Ltd.

Address: 350 Orchard Road Shaw House # 15-08/10 Phone: (65) 6697 5900 Mob: (65) 9737 9071 Fax: (65) 6735 3580 Email: Sebastian.giebel@biokube.com Website: www.biokube.com

“Solution to get you moving” WASTE TE WATE TER TREATMENT

17

THANK YOU

Happy to help saving water for the Hotel & Resort Industry
