Commercial Storage Residential Storage With years of experience in - - PowerPoint PPT Presentation
Commercial Storage Residential Storage With years of experience in both the clean energy and battery industries, the Provident team helps families and businesses reduce their electricity costs and achieve energy independence through their own
Commercial Storage
With years of experience in both the clean energy and battery industries, the Provident team helps families and businesses reduce their electricity costs and achieve energy independence through their own power generation, storage, and
Provident's products have spread to more than 20 countries through our partners, benefitting thousands of customers.
Residential Storage
100+ Patents 3 Tripled growth annually 6000+ Installed units 9 Nationalities 50% R&D experts 10000m2 Plant
City Building Commercial Energy Storage System
A B C D E
A B C D E
Vision Of Future
Large Scale Industrial Energy Storage System Smart Homes Residential Energy Storage System Solar Power Station Electric Vehicle
CGN
China General Nuclear Power Group
EVE(300014)
Lithium Battery Maker Listed in 2009
CAIF
China Aviation Industrial Fund
Provident's Products
Provident covers full spectrum of products and services in the industry. It ranges from 3kW to 10kW residential applications to 500kW or 1MW commercial solutions.
SMILE5-INV 1 Battery 5kW/5.7 kWh 2 Batteries 5kW/11.5 kWh 5 Batteries 5kW/28.7 kWh
SMILE5 System
Residential Energy Storage System Output Input Option Cycle Life Chemistry Function Communication IP Certification
5kW 2 MPPT 5.7~34.4kWh ≥6000 LiFePO4 UPS RS 485 IP65 VDE, SAA, TÜV, CE
SMILE5 Multi-Applications
DC Coupling AC Coupling Hybrid Coupling
Solar inverter Solar inverter
DC/AC DC/AC
SMILE B3 System
Residential Energy Storage System AIO AC-coupling Energy Storage System Easy installation and low maintenance 24/7 Monitoring with local interface Flexible capacity
3kW Output AC-Coupling ≥ 6000 Cycle Life
2.9-14.4kWh Capacity Expansion (1-5 M4856-P in parallel) 56A (1C) IP65 Protection UPS Backup
SMILE T10 System
Residential Energy Storage System On/off micro-grid compatible IP65 Outdoor Rated 24/7 Monitoring Modular battery High efficiency
10kW Output 2.9~23.0kWh Option ≥ 6000 Cycle Life 8 Max. Modules in Parallel 56A (1C) IP65 Protection UPS Backup
Storion-OF5
Off-Grid Energy Storage System
Hybrid Inverter Super Cable Box Battery (M4860 or M48112-P)
5kW Output 2 MPPT Input 5.4~32.4kWh Option ≥ 6000 Cycle Life Max 1000V Input Max 10kW Input
M4860 3 kWh 90% 2.7 kWh ≥8000 LiFePO4 40kg CAN 6 M48112-P 5.4 kWh 90% 4.8 kWh ≥6000 LiFePO4 62kg CAN 6 SMILE5-BAT 5.7 kWh 90% 5.2 kWh ≥6000 LiFePO4 65kg CAN 6 Model Energy Capacity DOD Usable Capacity Cycle Life Chemistry Weight Communication Max units in Parallel
Lithium Iron Phosphate Battery——Low Voltage 48V
M4856-P 2.9 kWh 90% 2.6 kWh ≥6000 LiFePO4 35kg CAN 4
Storion-T30
AIO Commercial Solution Battery Inverter High Voltage Box (BMU) Battery (M48112-S) EMS
30kW Output AC-Coupling 23~69 kWh Option ≥ 6000 Cycle 97.1% Efficiency 50/60Hz Option 400V/480V Option On/Off-Grid System
Storion-T50/T100
Commercial Solution without Container
50/100kW Output DC/AC-Coupling 29~1031 kWh Option ≥ 6000 Cycle Life 96.1% Efficiency Include Transformer without Container On/Off-Grid System
T50/T100 50/100kW with 29 ~ 1031kWh capacity without container
Storion-T50/T100
Commercial Solution with Container
50/100kW Output DC/AC-Coupling 29~1031 kWh Option ≥ 6000 Cycle Life 96.1% Efficiency Include Transformer with Container On/Off-Grid System
T50/T100 50/100kW with 29 ~1031 kWh capacity with container（10/20/40FT）
CS
Big Commercial Solution with Container PCS: 250kW, 500kW, 1000kW STORAGE: 20FT /40FT container --- 2MWh Customizable, supports parallel connection of multiple containers On/Off grid integrated design Self consumption , demand shift Accessible to cloud platform monitoring system to detect management data in real time
M48112-S 5.7 kWh 90% 5.2 kWh ≥6000 LiFePO4 65kg CAN 15 M15020-S 3 kWh 90% 2.7 kWh ≥8000 LiFePO4 62kg CAN 6 M4856-S 2.9 kWh 90% 2.6 kWh ≥6000 LiFePO4 35kg CAN 8 Model Energy Capacity DOD Usable Capacity Cycle Life Chemistry Weight Communication Max units in Series
Lithium Iron Phosphate Battery——High Voltage
HV-Cluster 4-15 M48112-S in series
Cloud Cloud Fiv ive M Maj ajor r Fu Func nctio ions ns： Detailed and accurate visual monitoring data
Secure and reliable data encryption transmission Intelligent operation and maintenance process management to guaranty the after-sales Powerful remote fault diagnosis, remote upgrade and remote scheduling function Real time big data analysis capability, combined with power generation forecasting and load forecasting data, provides energy storage intelligent charging / discharging solutions.
Cloud
Remote monitoring
Remotely control systems with Web & APP Remotely upgrade EMS & BMS through USB or internet Remotely change parameter settings through Web's management account Combine with smart home and access to energy Internet
Cloud
Info on electricity charge, discharge, power, capacity, area, self-consumption and self-sufficiency of Provident's energy storage system in the whole world
Data Analysis
Solutions Reliability
We are passionate about what we do and we put safety, credibility and reliability as our first priority. Through the cell we adapt to the BMS and EMS we independently developed, making sure our clients are in the best hands.
LiFePO4 (LFP) LiCOO2 (LCO) NMC Whilst Alpha’s batteries are slightly larger per physical capacity versus other types of Li-Ion used in electronics and EVs, they are easily banked in parallel close together because they don’t suffer heat issues and thermal runaway. We have chosen LiFePO4 for their superior life, safety and environmental performance.
CHEMISTRY Provident only goes with LFP for safest operation and longest cycle-life
Calendar Life: 5 years Cost: Low Small Cylindrical Calendar Life: 3 years Cost: Medium Big Polymer Pouch Calendar Life: 5 years Cost: Medium Calendar Life: 20 years Cost: High Metal Can Plastic Cell
CELL TYPE
Provident only goes with Metal-Can cell for its longest calendar Life
PREMIUM CELLS SUPPLIER
Provident never compromise on LFP cell quality
LGC Panasonic Lishen CATL BYD EVE Samsung SDI SONY
Chemistry Cell Type LFP LCO & NMC Small Cylindrical Sony Samsung SDI LGC Panasonic Big Polymer Pouch Plastic Cells Metal CAN Cells CATL Lishen BYD EVE
Provident strategic partner - LISHEN - one of the world’s top 5 LFP cell producers Provident shareholder & partner - EVE - one of the tier-1 lithium battery producers in China
BMS
Provident’s BMS is the brain behind battery packs. It manages the ultimate function of the battery and also provides critical safeguards to protect and prolong the batteries. Real-time volt. / temp./ current monitoring on cell level Multiple-level protections based on the data monitored Communication to EMS (Energy management System) Reliable battery cell balancing management Intelligent SOC% (State of Charge) algorithm
BMS Cell Cell Block
EMS
Provident’s independently developed EMS ensures the overall reliability and efficiency use of the electricity. It provides functions such as monitoring and control, generation control, load forecasting, load balancing and the economic factors in generation and transmission of electricity. Safe and Reliable Third level data monitoring and logical control and protection. Adaptability Compatible with RS485， CAN ,Ethernet and other interfaces. Functionality Integrated with functions
stop, grid scheduling, UPS functional logic.
Inverter
Safer Charging and discharging
within isolated circuits. Faster response time Reponses to sudden load change within 9 seconds. Seamless switch Switching between charging and discharging without a glitch. Better quality The battery has no ripple under high current. More accurate The power of SMILE5 at low load can be 30W.
5 Years Product Warranty 10 Years Battery Perf. Warranty Without Cycle-life Limitation 20 Years Design Life Time
Certification
IEC 62109-1/2 VDE 0126 VDE 4105 IEC 61000 AS 4777 CEI 0-21 G59/3 EN 50438 UL1741 CE LVD UL 1741SA UL 9540 IEC 62619 UL 1642 The First & Only storage Brand with insurance covered in Germany 3rd Party Certified
Project References
Our collection of featured projects highlights
are implemented in real scenarios.
Project Detail: Photovoltaic Capacity: 4 kWp System Specification: Storion-SMILE5 Battery Specification: SMILE5-BAT 11.5 kWh System Application: Self-consumption
Residential Solution / SMILE5
Australia
Project Detail: Photovoltaic Capacity: 7 kWp System Specification: Storion-OF5 Battery Specification: 21.5 kWh (4 x of M48112-P)
Residential Solution / Storion OF5
Australia-Queensland
Provident together with our Philippines partner customized solutions for 8 islands across the Philippines with different storage solutions from 5- kWh to 350kWh. System configuration
Commercial Solution
Philippines-APO ISLAND
Indonesian state-owned oil and natural gas corporation PETRAMINA installed PV systems with Provident storage batteries for 5 of their petrol stations in Jakarta. Total storage capacity is 306kWh.
System configuration of each site:
Commercial
Indonesia-Bogor/Su bang/Pamanukan
PV with storage system to reduce monthly electricity bill
The factory has offered about 360kWh battery storage in total for this client in Africa in 2017.
System configuration:
South Sudan Commercial Commercial Solution
South Sudan-Juba
Big Industrial Energy Storage System
Cambodia Project Detail: Project Location: Cambodia Configuration: 500kW / 1MWh System Application: Max. self consumption, backup This is a factory project in Cambodia. Due to the constant blackout situation, this storage system can work as backup power supply source. It can also maximize self generation for profit maximization.
