SLIDE 1

Collusion-resilient credit-based reputation for peer-to-peer content distribution

Nguyen Tran, Jinyang Li, Lakshminarayanan Subramanian New York University NetEcon’10

1

SLIDE 2

Incentive in P2P CDNs

A solved problem?

Yes

– BitTorrent tit-for-tat provides incentives for nodes to upload during download nodes to upload during download

No

– No incentives for nodes to act as seeders (seeder promotion problem)

2

SLIDE 3

Incentive in P2P CDNs

A solved problem?

Yes

– BitTorrent tit-for-tat provides incentives for nodes to upload during download nodes to upload during download

No

– No incentives for nodes to act as seeders (seeder promotion problem)

3

SLIDE 4

Private vs public BitTorrent communities

CDF

PirateBay TorrentLeech

4

Average download speed [Kbps]

More seeders better performance

SLIDE 5

Robust reputations seeder promotion

Private BitTorrent

– Nodes report their contribution vulnerable

Graph-based reputation (Page-rank, max-flow)
Graph-based reputation (Page-rank, max-flow)

– not capture node contribution – vulnerable to collusion

5

SLIDE 6

Credo: a credit-based reputation mechanism

capture node contribution correctly
resilient to attacks (Sybil attack and collusion)

6

SLIDE 7

Credo’s system architecture

7

central server

SLIDE 8

Credo’s system architecture

Sybil-resilient node admission

using social network (SybilLimit

[S&P’08], SumUp [NSDI’09], GateKeeper [PODC’10])

each adversary can bring in few Sybils

8

central server

SLIDE 9

Credo’s system architecture

Sybil-resilient node admission

using social network (SybilLimit

[S&P’08], SumUp [NSDI’09], GateKeeper [PODC’10])

each adversary can bring in few Sybils

9

central server

A

SLIDE 10

Credo’s system architecture

Sybil-resilient node admission

using social network (SybilLimit

[S&P’08], SumUp [NSDI’09], GateKeeper [PODC’10])

each adversary can bring in few Sybils

10

central server

A seeder

SLIDE 11

Credo’s system architecture

Sybil-resilient node admission

using social network (SybilLimit

[S&P’08], SumUp [NSDI’09], GateKeeper [PODC’10])

each adversary can bring in few Sybils

upload 11

central server

upload upload upload

A seeder

SLIDE 12

Credo’s system architecture

Sybil-resilient node admission

using social network (SybilLimit

[S&P’08], SumUp [NSDI’09], GateKeeper [PODC’10])

each adversary can bring in few Sybils

upload 12

central server

upload upload upload

A seeder

SLIDE 13

Credo’s system architecture

Sybil-resilient node admission

using social network (SybilLimit

[S&P’08], SumUp [NSDI’09], GateKeeper [PODC’10])

each adversary can bring in few Sybils

13

central server

A

download download

leecher

SLIDE 14

Credo’s system architecture

Sybil-resilient node admission

using social network (SybilLimit

[S&P’08], SumUp [NSDI’09], GateKeeper [PODC’10])

each adversary can bring in few Sybils

14

central server

A

download download

leecher

SLIDE 15

Credo’s system architecture

Sybil-resilient node admission

using social network (SybilLimit

[S&P’08], SumUp [NSDI’09], GateKeeper [PODC’10])

each adversary can bring in few Sybils

15

Rep (# uploads) (# ) downloads = −

central server

A

download download

leecher

SLIDE 16

Credo’s system architecture

Sybil-resilient node admission

using social network (SybilLimit

[S&P’08], SumUp [NSDI’09], GateKeeper [PODC’10])

each adversary can bring in few Sybils

16

Rep (# uploads) (# ) downloads = −

central server

A

download download

leecher

Seeders choose the highest reputation leecher to serve

SLIDE 17

Seeders collect credits in exchange for uploads

A C D E

17

credit pool credit pool

signed token

B B

SLIDE 18

Nodes issue their own credits

A B C D E

18

credit pool credit pool B

18

SLIDE 19

Nodes issue their own credits

A B C D E

19

credit pool credit pool B

19

Rep (# ) (# ) credit earned issued credit = −

SLIDE 20

Nodes issue their own credits

A B C D E

20

credit pool credit pool B

20

Rep (# ) 2 (# ) credit earned issued credit = −

SLIDE 21

Nodes issue their own credits

A B C D E

21

credit pool credit pool B

21

Rep (# ) 2 (# ) credit earned issued credit = −

To encourage nodes to use credits in credit pools before issuing new credits

SLIDE 22

Sybil attack

A C D E

22 X X2

Rep (# ) 2 (# ) credit earned issued credit = −

X1

B credit pool

X1 X1 X1 X2 X2 X2

SLIDE 23

Idea 1: Credit diversity

A C D E

23 X X2 X1

B credit pool

X1 X1 X1 X2 X2 X2

Rep (# different issuers) 2 (# ) issued credit = −

SLIDE 24

Credit diversity is not enough

A C D E

Y Y1 24 X X2 X1

B

Rep (# different issuers) 2 (# ) issued credit = −

Y2

SLIDE 25

Credit diversity is not enough

A C D E

Y Y1

colluders

25 X X2 X1

B

Rep (# different issuers) 2 (# ) issued credit = −

Y2

SLIDE 26

Credit diversity is not enough

A C D E

Y Y1

colluders

X X Y Y 26 X X2 X1

B

Rep (# different issuers) 2 (# ) issued credit = −

Y2 X1 X1 X1 X2 X2 X2 Y1 Y1 Y1 Y2 Y2 Y2 X1 X1 X1 X2 X2 X2 Y1 Y1 Y1 Y2 Y2 Y2

SLIDE 27

Credit pool of attackers vs honest nodes

A C D E

Y Y1 X X Y Y 27 X X2 X1

B

Y2 X1 X1 X1 X2 X2 X2 Y1 Y1 Y1 Y2 Y2 Y2 X1 X1 X1 X2 X2 X2 Y1 Y1 Y1 Y2 Y2 Y2

Volume(c) : # of credits issued by the issuer of c

Volume = 6

SLIDE 28

Credit pool of attackers vs honest nodes

A C D E

Y Y1 X X Y Y 28 X X2 X1

B

Y2 X1 X1 X1 X2 X2 X2 Y1 Y1 Y1 Y2 Y2 Y2 X1 X1 X1 X2 X2 X2 Y1 Y1 Y1 Y2 Y2 Y2

Volume(c) : # of credits issued by the issuer of c

SLIDE 29

Credit pool of attackers vs honest nodes

A C D E

Y Y1 X X Y Y 29 X X2 X1

B

Y2 X1 X1 X1 X2 X2 X2 Y1 Y1 Y1 Y2 Y2 Y2 X1 X1 X1 X2 X2 X2 Y1 Y1 Y1 Y2 Y2 Y2

Volume(c) : # of credits issued by the issuer of c

6 6 6 6

SLIDE 30

Credit pool of attackers vs honest nodes

A C D E

Y Y1 X X Y Y 30 X X2 X1

B

Y2 X1 X1 X1 X2 X2 X2 Y1 Y1 Y1 Y2 Y2 Y2 X1 X1 X1 X2 X2 X2 Y1 Y1 Y1 Y2 Y2 Y2

Volume(c) : # of credits issued by the issuer of c

all are high volume credits

6 6 6 6

SLIDE 31

Credit pool of attackers vs honest nodes

A C D E

Y Y1 X X Y Y

3 3

31 X X2 X1

B

Y2 X1 X1 X1 X2 X2 X2 Y1 Y1 Y1 Y2 Y2 Y2 X1 X1 X1 X2 X2 X2 Y1 Y1 Y1 Y2 Y2 Y2

Volume(c) : # of credits issued by the issuer of c

all are high volume credits

6 6 6 6 6 3

SLIDE 32

Credit pool of attackers vs honest nodes

A C D E

Y Y1 X X Y Y C D B E

3 3

32 X X2 X1

B

Y2 X1 X1 X1 X2 X2 X2 Y1 Y1 Y1 Y2 Y2 Y2 X1 X1 X1 X2 X2 X2 Y1 Y1 Y1 Y2 Y2 Y2

Volume(c) : # of credits issued by the issuer of c

all are high volume credits B

6 6 6 6 6 3

SLIDE 33

Credit pool of attackers vs honest nodes

A C D E

Y Y1 X X Y Y C D B E

low volume

3 3

33 X X2 X1

B

Y2 X1 X1 X1 X2 X2 X2 Y1 Y1 Y1 Y2 Y2 Y2 X1 X1 X1 X2 X2 X2 Y1 Y1 Y1 Y2 Y2 Y2

Volume(c) : # of credits issued by the issuer of c

all are high volume credits B

high volume

6 6 6 6 6 3

SLIDE 34

Distribution of credits’ volume

bability density

3 1013

1

34

Volume Prob

3 6

313

Expected volume distribution in a normal credit pool Volume distribution in an adversary’s credit pool

SLIDE 35

Idea 2: Modeling good behavior

bability density

3 1013

35

Volume Prob

3 6

313

Expected volume distribution in a normal credit pool

SLIDE 36

Idea 2: Modeling good behavior

bability density

3 1013

Central server samples a subset of peers and ask for # of issued credits

36

Volume Prob

3 6

313

Expected volume distribution in a normal credit pool

SLIDE 37

Idea 2: Modeling good behavior

bability density

3 1013

37

Volume Prob

3 6

313

Expected volume distribution in a normal credit pool

SLIDE 38

Idea 2: Modeling good behavior

bability density

3 1013

38

Volume Prob

3 6

313

Expected volume distribution in a normal credit pool Volume distribution in a credit pool

SLIDE 39

Idea 2: Modeling good behavior

bability density

3 1013

filter credits 39

Volume Prob

3 6

313

Expected volume distribution in a normal credit pool Volume distribution in a credit pool

SLIDE 40

Idea 2: Modeling good behavior

bability density

3 1013

filter credits 40

Volume Prob

3 6

313

Expected volume distribution in a normal credit pool Volume distribution in a credit pool

Rep (diversity of filtered pool) 2 (# ) issued credit = −

SLIDE 41

Effect on attackers

A C D E

Y Y1 X X Y Y C D B E

low volume

3 3

41 X X2 X1

B

Y2 X1 X1 X1 X2 X2 X2 Y1 Y1 Y1 Y2 Y2 Y2 X1 X1 X1 X2 X2 X2 Y1 Y1 Y1 Y2 Y2 Y2 B

high volume

Sybils issue similar amount of credits as honest nodes

6 3 6 6 6 6 3 6 3 3

SLIDE 42

Credo’s security properties

Suppose there are adversaries, each

brings in Sybils. They form a collusion size of , and do not contribute. s C k =

k

s

42

SLIDE 43

Credo’s security properties

Suppose there are adversaries, each

brings in Sybils. They form a collusion size of , and do not contribute.

– The reputation of each adversary is bounded

s C k =

k

s

– The reputation of each adversary is bounded by the collusion size

43

C

SLIDE 44

Credo’s security properties

Suppose there are adversaries, each

brings in Sybils. They form a collusion size of , and do not contribute.

– The reputation of each adversary is bounded

s C k =

k

s

– The reputation of each adversary is bounded by the collusion size – Reputation of adversary decrease after download

44

(s ) x γ

C

SLIDE 45

Credo’s security properties

Suppose there are adversaries, each

brings in Sybils. They form a collusion size of , and do not contribute.

– The reputation of each adversary is bounded

s C k =

k

s

– The reputation of each adversary is bounded by the collusion size – Reputation of adversary decrease after download

45

Average number of self- issued credits of an issuer A small constant

(s ) x γ

C

SLIDE 46

Auditing to catch misbehavior

Nodes can lie

– Double spend credits – Falsely report number of issued credits – Many others … – Many others …

Audit to catch liars with provable evidence

(PeerReview) disincentivize nodes to lie

46

SLIDE 47

Credo reputation reflects node contribution

eputation

47

Node contribution Re

Simulate 1 year of 3000 nodes network
Continuously inject 100MB file and choose 300 nodes to download
Use Maze data (2005) to model nodes’ demand
Use BitTorrent data (2007) to model nodes’ upload capacity

# uploaded chunks - # downloaded chunks

SLIDE 48

Higher reputation faster download

ad time [sec]

48

Node contribution Downloa

SLIDE 49

Higher reputation faster download

ad time [sec] Limited by upload capacity

f the initial seeder

49

Node contribution Downloa

SLIDE 50

Higher reputation faster download

ad time [sec] Limited by upload capacity

f the initial seeder

Limited by queuing time

50

Node contribution Downloa

SLIDE 51

Credo is robust against collusion

nload time [sec]

honest nodes colluders

51

Node contribution Downlo

30 adversaries, each brings in 3 Sybil nodes
Colluders do not upload
Vary demand of colluders at each run of the simulation

SLIDE 52

More seeders better performance

CDF

52

Experiment on 210 PlanetLab nodes
Inject 25MB file at the beginning
Nodes arrives every 15 second

Credo, nodes stay online BT, nodes go offline

Complete time [sec]

SLIDE 53

Related work

Graph-based reputation

– Page-rank style: EigentTrust [WWW’03], multi-level tit-for-tat [IPTPS’06] – Max-flow style: SybilProof [P2PEcon’05], Feldman [EC’04] – Other: Onehop [NSDI’09] – Other: Onehop [NSDI’09]

Currency

– Dandelion [Usenix’07], Pace [Conext’08], Ppay [CCS’03]

53

SLIDE 54

Conclusion

Credo addresses seeder promotion

problem

– Higher reputation faster download

Credo is a credit-based reputation system

– Reflect nodes’ net contribution correctly – Resilient to Sybil and collusion attacks

54
