CO COMPANY MPANY PRE RESENTATIO SENTATION AB ABOUT OUT Schaefer Technologies is a Romanian company established in collaboration with abroad based tool manufacturing companies. The main task is to give professional service to the Romanian

SLIDE 1

CO COMPANY MPANY PRE RESENTATIO SENTATION

SLIDE 2

AB ABOUT OUT

Schaefer Technologies is a Romanian company established in collaboration with abroad based tool manufacturing companies. The main task is to give professional service to the Romanian customers with quality tools that fit to the application for which it were designed. The industry areas covered and the variety of tailor made tools, the quality and the professional design are the main strengths of Schaefer Technologies with which we approach the customers.

SLIDE 3

PRODUCT ODUCTIO ION N AREAS AS COVERED VERED

SMT THT COATING DEPANELING INDUCTIVE SOLDERING

SLIDE 4

SM SMT

TOOLING For all printer types: DEK, EKRA, MPM, etc With or without vacuum Used material: AL 5083 Finishing: Hard Anodizing SMT carrier Pick and Place trays For Flexboard 0.4mm thickness With magnets and Nickel fixing sheet For placing odd form components with the P&P macine

SLIDE 5

CONFOR NFORMAL MAL COATING ATING

COATING PALLETS Manufactured from composite material or from Aluminum

SLIDE 6

Wa Wave e an and S d Sel elec ective tive S Sol

derin ring

WAVE SOLDERING CARRIERS ESD high temperature resistant top and bottom plate material Available base materials:

CDM 68.610
CDM 68.940
Contaval 2576GP
POM-C (ESD)
Titanium Grade2

SLIDE 7

Wa Wave ve and d Se Selective lective S Soldering ldering

WAVE SOLDERING CARRIERS Professional top-hat with dedicated pushers Aluminum stiffeners applied even for the top-hats Colored pillars for a smarter poka-yoke solution available upon request

SLIDE 8

Wa Wave e an and S d Sel elec ective tive S Sol

derin ring

WAVE SOLDERING CARRIERS Titanium inserts Down to 0,4mm Pocket Walls Titanium coated screws – the flux doesn´t stick to them

SLIDE 9

Wa Wave e an and S d Sel elec ective tive S Sol

derin ring

WAVE SOLDERING CARRIERS Teflon coating available upon request Benefits:

The flux will not stick to it so easily
Gives a longer lifetime for the carrier by protecting the

base plate material

SLIDE 10

DEP EPAN ANELING ELING

Depaneling Fixtures Available for Asys, Schunk, etc Smart dedicated solutions for each type of product and machine

SLIDE 11

IN INDUCTIVE DUCTIVE S SOLDERING OLDERING

Trays for shrink tunnel Custom design according to the design of the cable terminal

SLIDE 12

ME META TAL L SH SHEET EET PR PROCESSING OCESSING

EKRA Assembly roller Lighting table for stencils Custom design according to the customers specifications

SLIDE 13

OT OTHER ER TO TOOL OLS

NOZZLES AND NOZZLE PLATES FOR SELECTIVE SODERING Custom made nozzles and nozzles plates

SLIDE 14

CON ONTACT TACT

Mr. George Juhasz

Sales Manager Mob: +40 (748) 856 724 E-mail: gj@schaefer-tech.ro Web: www.schaefer-tech.ro Social address: Str. Liszt Ferenc 18, PC.69/5; 410539 Oradea-Romania
