CMP722 ADVANCED COMPUTER VISION Lecture #4 Multimodality Aykut - - PowerPoint PPT Presentation

Lecture #4 – Multimodality

Aykut Erdem // Hacettepe University // Spring 2019

CMP722

ADVANCED COMPUTER VISION

Illustration: Detail from Fritz Kahn’s Der Mensch als Industriepalast

• sequential data
• convolutions in time
• recurrent neural networks (RNNs)
• autoregressive generative models
• attention models
• case study: transformer model

Previously on CMP722

Illustration: DeepMind

Lecture overview

• what is multimodality
• a historical view on multimodal research
• core technical challenges
• joint representations
• coordinated representations
• multimodal fusion
• Disclaimer: Much of the material and slides for this lecture were borrowed from

—Louis-Philippe Morency Tadas Baltrusaitis’s CMU 11-777 class —Qi Wu’s slides for ACL 2018 Tutorial on Connecting Language and Vision to Actions

3

What is Multimodal?

• Multiple modes, i.e.,

distinct “peaks” (local maxima) in the probability density function

4

Multimodal distribution

➢ Multiple modes, i.e., distinct “peaks”

Multimodal distribution

What is Multimodal?

Sensory Modalities

5

What is Multimodal?

Modality: : The way in which something happens or is experienced.

• Modality refers to a certain type of information and/or the

representation format in which information is stored.

• Sensory modality: one of the primary forms of sensation, as vision or

touch; channel of communication. Medium (“middle”): A means or instrumentality for storing or communicating information; system of communication/transmission.

• Medium is the means whereby this information is delivered to the

senses of the interpreter.

6

Examples of Modalities

• Natural language (both spoken or written)
• Visual (from images or videos)
• Auditory (including voice, sounds and music)
• Haptics/touch
• Smell, taste and self-motion
• Physiological signals
• Electrocardiogram (ECG), skin conductance
• Other modalities
• Infrared images, depth images, fMRI

7

Psychology Medical Speech Vision Language Multimedia Robotics Learning

Multiple Communities and Modalities

8

Psychology Medical Speech Vision Language Multimedia Robotics Learning

A Historical View

9

Prior Research on “Multimodal”

Four eras of multimodal research

• The “behavioral” era (1970s until late 1980s)
• The “computational” era (late 1980s until 2000)
• The “interaction” era (2000 - 2010)
• The “deep learning” era (2010s until ...)
• Main focus of this lecture

10

The “Behavioral” Era (1970s until late 1980s)

Multi-sensory integration (in psychology):

• Multimodal signal detection: Independent decisions vs. integration [1980]
• Infants' perception of substance and temporal synchrony in multimodal events

[1983]

• A multimodal assessment of behavioral and cognitive deficits in abused and

neglected preschoolers [1984]

Ø TRIVIA: Geoffrey Hinton received his B.A. in Psychology

11

Multimodal al Behavi avior Therap apy y by Arnold Lazarus [1973] ➢ 7 dimensions of personality (or modalities)

The McGurk Effect (1976)

Hearing lips and seeing voices – Nature

12

The “Computational” Era (Late 1980s until 2000)

1) Audio-Visual Speech Recognition (AVSR)

• Motivated by the McGurk effect
• First AVSR System in 1986

“Automatic lipreading to enhance speech recognition”

• Good survey paper [2002]

“Recent Advances in the Automatic Recognition of Audio-Visual Speech”

Ø TRIVIA: The first multimodal deep learning paper was about audio visual speech recognition [ICML 2011]

13

The “Computational” Era (Late 1980s until 2000)

2) Multimodal/multisensory interfaces

• Multimodal Human-Computer Interaction

(HCI) “Study of how to design and evaluate new computer systems where human interact through multiple modalities, including both input and output modalities.”

14

Glove-talk: A neural network interface between a data-glove and a speech synthesizer By Sidney Fels & Geoffrey Hinton [CHI’95]

The “Computational” Era (Late 1980s until 2000)

2) Multimodal/multisensory interfaces

15

Rosalind Picard Affective Computing is computing that relates to, arises from, or deliberately influences emotion or other affective phenomena.

➢ The “ ” Era (Late 1980s until 2000)

Ro

The “Computational” Era (Late 1980s until 2000)

3) Multimedia Computing

16

“The Informedia Digital Video Library Project automatically combines speech, image and natural language understanding to create a full-content searchable digital video library.”

➢ The “ ” Era (Late 1980s until 2000)

“The digital video library.”

[1994-2010]

The “Computational” Era (Late 1980s until 2000)

3) Multimedia Computing Multimedia content analysis

• Shot-boundary detection (1991 - )
• Parsing a video into continuous camera shots
• Still and dynamic video abstracts (1992 - )
• Making video browsable via representative frames (keyframes)
• Generating short clips carrying the essence of the video content
• High-level parsing (1997 - )
• Parsing a video into semantically meaningful segments
• Automatic annotation (indexing) (1999 - )
• Detecting prespecified events/scenes/objects in video

17

The “Computational” Era (Late 1980s until 2000)

• Hidden Markov Models [1960s]

18

• Factorial Hidden Markov Models [1996]
• Coupled Hidden Markov Models [1997]
• kov Models [1960s]

• Models [1997]

Multimodal Computation Models

• Artificial Neural Networks [1940s]

19

• Backpropagation [1975]
• Convolutional neural networks [1980s]
• ural Networks [1940s]
• tion [1975]

Convolu

• Backpropagation [1

The “Interaction” Era (2000s)

1) Modeling Human Multimodal Interaction Ø TRIVIA: Samy Bengio started at IDIAP working on AMI project

20

➢ The “ ” Era (2000s)

• AMI Project [2001-2006, IDIAP]
• 100+ hours of meeting recordings
• Fully synchronized audio-video
• Transcribed and annotated

CHIL Project [Alex Waibel]

• Computers in the Human Interaction Loop
• Multi-sensor multimodal processing
• Face-to-face interactions

The “Interaction” Era (2000s)

1) Modeling Human Multimodal Interaction

• TRIVIA: LP Morency’s PhD research was partially funded by CALO

21

CALO Project [2003-2008, SRI]

• Cognitive Assistant that Learns and Organizes
• Personalized Assistant that Learns (PAL)
• Siri was a spinoff from this project

SSP Project [2008-2011, IDIAP]

• Social Signal Processing
• First coined by Sandy Pentland in 2007
• Great dataset repository: http://sspnet.eu/

➢ The “ ” Era (2000s)

CA

• SS
• TRIVIA: LP’s PhD research was partially funded by CALO ☺

The “Interaction” Era (2000s)

2) Multimedia Information Retrieval Rese sear arch ch tasks asks an and ch chal allenges: s:

• Shot boundary, story segmentation, search
• “High-level feature extraction”: semantic event detection
• Introduced in 2008: copy detection and surveillance events
• Introduced in 2010: Multimedia event detection (MED)

22

➢ The “ ” Era (2000s)

“Yearly competition to based evaluation”

• “High level feature extraction”: semantic event detection
• “Yearly competition to

promote progress in content-based retrieval from digital video via open, metrics-based evaluation” [Hosted by NIST, 2001-2006]

Multimodal Computational Models

• Dynamic Bayesian Networks
• Kevin Murphy’s PhD thesis and Matlab toolbox
• Asynchronous HMM for multimodal [Samy Bengio, 2007]

Audio-visual speech segmentation

23

▪

▪ Kevin Murphy’s PhD thesis and Matlab toolbox ▪ segmentation

Multimodal Computational Models

• Discriminative sequential models
• Conditional random fields [Lafferty et al., 2001]
• Latent-dynamic CRF [Morency et al., 2007]

24

▪

▪ tional random fields [Lafferty et ▪

▪

▪ ▪ dynamic CRF

The “deep learning” era (2010s until ...)

Representation learning (a.k.a. deep learning)

• Multimodal deep learning [ICML 2011]
• Multimodal Learning with Deep Boltzmann Machines [NIPS 2012]
• Visual attention: Show, Attend and Tell: Neural Image Caption Generation with

Visual Attention [ICML 2015]

Key enablers for multimodal research:

• New large-scale multimodal datasets
• Faster computer and GPUS
• High-level visual features
• “Dimensional” linguistic features

25

The topic of

• ur next lecture

Real World tasks tackled by MMML

• Affect recognition
• Emotion
• Persuasion
• Personality traits
• Media description
• Image captioning
• Video captioning
• Visual Question Answering
• Event recognition
• Action recognition
• Segmentation
• Multimedia information retrieval
• Content based/Cross-media

26

▪

▪ ▪ ▪

▪

▪ ▪ ▪

▪

▪ ▪

▪ retrieval

▪

▪

▪ ▪ ▪

▪

▪ ▪ ▪

▪

▪ ▪

▪ eval

▪

Core Technical Challenges

27

Multimodal Machine Learning

Core Technical Challenges: Representation Translation Alignment Fusion Co-Learning

28

Verbal Vocal Visual

Verbal Vocal Visual

Core Challenge 1: Representation

Definition: : Learning how to represent and summarize multimodal data in away that exploits the complementarity and redundancy.

29

Joint representations: A

Modality 1 Modality 2

Representation

Joint Multimodal Representation

30

“I like it!”

Joyful tone

Tensed voice

“Wow!”

Joint Representation

(Multimodal Space)

Joint Representations (Multimodal Space) "Wow!" "I like it!"

Joyful tone Tensed voice

Joint Multimodal Representation

Audio-visual speech recognition

[Ngiam et al., ICML 2011]

• Bimodal Deep Belief Network

Image captioning

[Srivastava and Salahutdinov, NIPS 2012]

• Multimodal Deep Boltzmann Machine

Audio-visual emotion recognition

[Kim et al., ICASSP 2013]

• Deep Boltzmann Machine

31

DepthVerbal DepthVideo DepthMultimodal

• Verbal

Visual Multimodal Representation

Multimodal Vector Space Arithmetic

32

[Kiros et al., Unifying Visual-Semantic Embeddings with Multimodal Neural Language Models, 2014]

Core Challenge 1: Representation

Definition: : Learning how to represent and summarize multimodal data in away that exploits the complementarity and redundancy.

33

Modality 1 Modality 2

Representation

Joint representations: A Coordinated representations: B

Modality 1 Modality 2

Repres 2

• Repres. 1

Coordinated Representation: Deep CCA

34

𝒁 𝒀 𝑽 𝑾 𝑰𝒚 𝑰𝒛

𝑿𝒚 𝑿𝒛 𝒀 𝒁 𝒗 𝒘 𝒗∗, 𝒘∗ = argmax

𝒗,𝒘

𝑑𝑝𝑠𝑠 𝒗𝑼𝒀, 𝒘𝑼𝒁

𝒁 𝒀 𝑽 𝑾 𝑰𝒚 𝑰𝒛

𝑿𝒚 𝑿𝒛 𝒀 𝒁 𝒗 𝒘 𝒗∗, 𝒘∗ = argmax

𝒗,𝒘

𝑑𝑝𝑠𝑠 𝒗𝑼𝒀, 𝒘𝑼𝒁

Andrew et al., ICML 2013

· · · · · · Text Image 𝒁 𝒀 𝑽 𝑾 · · · · · · 𝑰𝒚 𝑰𝒛

· · · · · · 𝑿𝒚 𝑿𝒛 𝒀 𝒁 𝒗 𝒘 𝒗∗, 𝒘∗ = argmax

𝒗,𝒘

𝑑𝑝𝑠𝑠 𝒗𝑼𝒀, 𝒘𝑼𝒁 ted:

• Learn linear projections that are maximally correlated:

Core Challenge 2: Alignment

Definition: : Identify the direct relations between (sub)elements from two or more different modalities.

35

Explicit Alignment

The goal is to directly find correspondences between elements of different modalities

A Implicit Alignment

Uses internally latent alignment of modalities in order to better solve a different problem

B

t1 t2 t3 tn t4 t5 tn

Fancy algorithm

Modality 1 Modality 2

Implicit Alignment

36

Karpathy et al., Deep Fragment Embeddings for Bidirectional Image Sentence Mapping, https://arxiv.org/pdf/1406.5679.pdf

Attention Models for Image Captioning

37

Distribution

• ver L

locations Expectation

• ver features:

D

𝑏1 𝑡0 𝑡1 𝑨1 𝑧1 𝑏2 𝑒1 𝑡2 𝑨2 𝑧2 𝑏3 𝑒2

First word

Output word

Core Challenge 3: Fusion

38

• Definition:

: To join information from two or more modalities to perform a prediction task.

Model-Agnostic Approaches A 1) Early Fusion 2) Late Fusion

Classifier

Modality 1 Modality 2 Classifier Classifier Modality 1 Modality 2

Core Challenge 3: Fusion

39

• Definition:

: To join information from two or more modalities to perform a prediction task.

Model-Based (Intermediate) Approaches B 1) Deep neural networks 2) Kernel-based methods 3) Graphical models

Multiple kernel learning Multi-View Hidden CRF

Core Challenge 4: Translation

40

Definition: : Process of changing data from one modality to another, where the translation relationship can often be open-ended or subjective.

Example-based A Model-driven B

Core Challenge 4: Translation

41

–

Transcriptions + Audio streams Visual gestures

(both speaker and listener gestures)

Marsella et al., Virtual character performance from speech, SIGGRAPH/Eurographics Symposium on Computer Animation, 2013

Core Challenge 4: Translation

42

–

Transcriptions + Audio streams Visual gestures

(both speaker and listener gestures)

Marsella et al., Virtual character performance from speech, SIGGRAPH/Eurographics Symposium on Computer Animation, 2013

Core Challenge 5: Co-Learning

Definition: : Transfer knowledge between modalities, including their representations and predictive models.

43

Modality 1 Prediction Modality 2

Core Challenge 5: Co-Learning

44

Parallel A Non-Parallel B Hybrid C

Taxonomy of Multimodal Research

Represe sentation

• Joint
• Neural networks
• Graphical models
• Sequential
• Coordinated
• Similarity
• Structured

Translation

• Example-based
• Retrieval
• Combination
• Model-based
• Grammar-based
• Encoder-decoder
• Online prediction

Alignment

• Explicit
• Unsupervised
• Supervised
• Implicit
• Graphical models
• Neural networks

Fusion

• Model agnostic
• Early fusion
• Late fusion
• Hybrid fusion
• Model-based
• Kernel-based
• Graphical models
• Neural networks

Co-learning

• Parallel data
• Co-training
• Transfer learning
• Non-parallel data
• Zero-shot learning
• Concept grounding
• Transfer learning
• Hybrid data
• Bridging

45

Tadas Baltrusaitis, Chaitanya Ahuja, and Louis-Philippe Morency, Multimodal Machine Learning: A Survey and Taxonomy https://arxiv.org/abs/1705.09406

Multimodal Representations

46

Multimodal representations

• Why do we need multimodal representations?
• Can just have unimodal ones and just fuse them

§ What if relationship is complex? § Doesn’t exploit joint information, especially at lower/intermediate levels

47

Multimodal representations

• What do we want from multi-modal

representation

• Similarity in that space implies

similarity in corresponding concepts

• Useful for various discriminative

tasks – retrieval, mapping, fusion etc.

• Possible to obtain in absence of one
• r more modalities
• Fill in missing modalities given others

(map between modalities)

48

• modal
• epts
• –
• ne
• Modality 1

Modality 2 Modality 3

Fancy representation

Modality 1 Modality 2 Modality 3

Fancy representation

Prediction Modality 1 Modality 2

Fancy representation

Multimodal representation types

Ø Simplest version: modality concatenation (early fusion) Ø Can be learned supervised or unsupervised Ø Multimodal factor analysis Ø Similarity-based methods (e.g., cosine distance) Ø Structure constraints (e.g.,

• rthogonality, sparseness)

49

Modality 1 Modality 2

Representation

Modality 1 Modality 2

Repres 2

• Repres. 1

Joint represenations: A Coordinated representations B

Joint representations

50

Shallow multimodal representations

• Want deep multimodal representations
• Shallow representations do not capture complex relationships
• Often shared layer only maps to the shared section directly

51

• Shallow RBM

Shallow Autoencoder

Deep multimodal autoencoders

• A deep representation learning

approach

• A bimodal auto-encoder
• Used for Audio-visual speech

recognition

52

▪ ▪

▪ speech

[Ngiam et al., Multimodal Deep Learning, 2011]

Deep multimodal autoencoders – training

• Individual modalities can be

pre-trained

• RBMs
• Denoising Autoencoders
• To train the model to

reconstruct the other modality

• Use both
• Remove audio

53

▪ ▪

▪ speech

Deep multimodal autoencoders – training

• Individual modalities can be

pre-trained

• RBMs
• Denoising Autoencoders
• To train the model to

reconstruct the other modality

• Use both
• Remove audio
• Remove video

54

▪ ▪

▪ speech

Multimodal Encoder-Decoder

• Visual modality often encoded

using CNN

• Language modality will be

decoded using LSTM

• A simple multilayer

perceptron will be used to translate from visual (CNN) to language (LSTM)

55

· · · · · · · · · · · · Text Image · · · 𝒁 𝒀

▪ ▪ g LSTM

▪

Multimodal Joint Representation

• For supervised learning tasks
• Joining the unimodal

representations:

• Simple concatenation
• Element-wise multiplication or

summation

• Multilayer perceptron
• How to explicitly model both

unimodal and bimodal interactions?

56

e.g. Sentiment

Deep multimodal Boltzmann machines

• Generative model
• Individual modalities trained like a

DBN

• Multimodal representation trained

using Variational approaches

• Used for image tagging and cross-

media retrieval

• Reconstruction of one modality

from another is a bit more “natural” than in autoencoder representation

• Can actually sample text and

images

57

▪ ▪ ▪ ▪ ▪ another is a bit more “natural” than in ▪

· · ·

softmax

[Srivastava and Salakhutdinov, Multimodal Learning with Deep Boltzmann Machines, 2012, 2014]

Deep multimodal Boltzmann machines

58

Srivastava and Salakhutdinov, “Multimodal Learning with Deep Boltzmann Machines”, NIPS 2012

[Srivastava and Salakhutdinov, Multimodal Learning with Deep Boltzmann Machines, 2012, 2014] Srivastava and Salakhutdinov, “Multimodal Learning with Deep Boltzmann Machines”, NIPS 2012

Coordinated Representations

59

Coordinated multimodal embeddings

• Instead of projecting to a joint space enforce the similarity between

unimodal embeddings

60

• Modality 1

Modality 2 Repres 2

• Repres. 1

Coordinated multimodal embeddings

• Learn (unsupervised)

two or more coordinated representations from multiple modalities. A loss function is defined to bring closer these multiple representations.

61

· · · · · · · · · · · · Text Image · · · · · ·

Similarity metric

(e.g., cosine distance)

𝒁 𝒀

Coordinated multimodal embeddings

• Instead of projecting to a joint space enforce the similarity between

unimodal embeddings

• Often referred to as semantic space embeddings

62

[Kiros et al., Unifying Visual-Semantic Embeddings with Multimodal Neural Language Models, 2014] [Frome et al., DeViSE: A Deep Visual-Semantic Embedding Model, 2013]

Coordinated multimodal embeddings

63

[Huang et al., Learning Deep Structured Semantic Models for Web Search using Clickthrough Data, 2013]

Multimodal Vector Space Arithmetic

64

[Kiros et al., Unifying Visual-Semantic Embeddings with Multimodal Neural Language Models, 2014]

Multimodal Vector Space Arithmetic

65

[Kiros et al., Unifying Visual-Semantic Embeddings with Multimodal Neural Language Models, 2014]

Structured coordinated embeddings

• Instead of or in addition to similarity add alternative structure

66

[Vendrov et al., Order-Embeddings of Images and Language, 2016] [Jiang and Li, Deep Cross-Modal Hashing]

Recap: Multimodal representations

• Joint representations
• Project modalities to the same space
• Use when all the modalities are present during test time
• Suitable for multimodal fusion
• Coordinated representations
• Project modalities to their own coordinated space
• Use when only one of the modalities is present during test- time
• Suitable for multimodal translation
• Good for retrieval

67

Multimodal Fusion

68

Concatenate

What s the mustache made of ? CNN LSTM

Element-wise sum

What s the mustache made of ? CNN LSTM

Element-wise product

What s the mustache made of ? CNN LSTM

Bilinear pooling

What s the mustache made of ? CNN LSTM

Outer product

2048 2048 3000 12.5 billion !!!

Multimodal Compact Bilinear Pooling (MCB)

What s the mustache made of ? CNN LSTM

Fukui et al. EMNLP 2016

Next Lecture: Language and Vision

74
