CHUVA Project: 2010-2011 and Perspectives for 2012-2014

CHUVA Science Team

6

CHUVA Project: 2010-2011 and Perspectives for 2012-2014

CHUVA Science Team

Cloud processes of tHe main precipitation systems in Brazil: A contribUtion to cloud resolVing modeling and to the GPM (GlobAl Precipitation Measurement)

CHUVA Project: Main Goals

• Improve Rainfall Estimation Using Satellites and/or Radar
• Improve the Skill of Cloud Resolving Models
• Compile a Climatology of the Main Precipitation Systems in Brazil

and their physical and microphysical characteristics

• Develop Tools for Nowcasting.

WORKING GROUP–1: CHARACTERISTICS OF THE PRECIPITATING SYSTEMS AS FUNCTION OF THE REGION AND LIFE STAGE (Luiz Machado) WORKING GROUP–2: PRECIPITATION ESTIMATION – DEVELOPMENT AND VALIDATION ALGORITHM (Daniel Vila) WORKING GROUP–3: ELETRIFICATION PROCESS: MOVING FROM CLOUDS TO THUNDERSTORMS (Carlos Morales) WORKING GROUP–4: CHARACTERISTICS OF THE BOUNDARY LAYER FOR DIFFERENT CLOUD PROCESSES AND PRECIPITATION REGIMES (Gilberto Fisch) WORKING GROUP–5: MODEL IMPROVEMENTS AND VALIDATION, WITH FOCUS IN CLOUD MICROPHYSICS AND AEROSOL INTERACTIONS, FOR SATELLITE PRECIPITATION ESTIMATES IN BRAZIL (Maria Assunção Dias)

CHUVA Field Campaign Schedule

CHUVA Field Campaign Schedule

YEAR JAN FEB MAR APR MAY JUN JUL AUG SEP OCT NOV DEC 2010

Alcântara (NE)

2011

Fortaleza (NE) Fortaleza (NE) Belém (N) Belém (N) V.Paraíba (SE) V.Paraíba (SE)

2012

V.Paraíba (SE) V.Paraíba (SE) V.Paraíba (SE) Sta.Maria (SO) Sta.Maria (SO)

2013

Brasília (CE) Brasília (CE)

2014

Manaus (NO) Manaus (NO) Manaus (NO) Manaus (NO) Manaus (NO) Manaus (NO) Manaus (NO) Manaus (NO) Manaus (NO) Manaus (NO) Manaus (NO)

Field Experiments

Mobile Dual-Pol X-band radar Micro-radars Radiometers Weather Stations (T, Td, V) Solar Radiation Parsivel Disdrometers Thies Distdrometers JW Disdrometers Rain gauges GPS humidity Soil humidity Flux Station Air Quality measurements CCN counter Lidar Field-Mills Lightning Location Systems High Speed Video Camera Radiosonde stations Aircraft (microphysics)

Instruments

CHUVA-GLM Vale do Paraíba

• CHUVA contribution for GOES-R GLM

and MTG LI activities (Risk Reduction, Algorithm Working Group, Calibration/Validation)

• First comprehensive Lighting Location

Systems intercomparisons:

• Lightning Mapping Array (NASA/UAH/NOAA)
• LiNET (EUMETSAT/DLR)
• TLS200 (Vaisala)
• ENTLN (EarthNetworks)
• RINDAT (INPE)
• STARNET (USP)
• WWLLN (Univ. Washington)
• GLD360 (Vaisala)
• ATDnet (MetOffice)
• ????
• TRMM-LIS

CHUVA-GLM Vale do Paraíba

CHUVA-GLM Vale do Paraíba

CHUVA-GLM Vale do Paraíba

5 instrumentation sites

CHUVA-GLM Vale do Paraíba

Radiosonde sites

Headquaters and Dual-Pol X-band radar site

CHUVA-GLM Vale do Paraíba

CHUVA-GLM Vale do Paraíba

CHUVA-GLM Vale do Paraíba

CHUVA-GLM Vale do Paraíba

• CHUVA-GLM Vale do Paraíba ends 31 March 2012.
• 5 months of continuous data:
• Local convection due to thermodynamics
• Local convection due to topography
• Cold fronts
• Convection from South Atlantic Convergence Zone (SACZ)
• Squall Lines
• Severe Weather (20+ cases of hail storms, damaging winds, flooding):
• Severe Weather reports are being gathered from Civil Defense, Newspapers, TV

news, Internet sources (blogs, social networking, etc.), Insurance Companies

CHUVA-GLM Vale do Paraíba

• 07 January 2012:
• Pea sized hail at

15:40LST in downtown São Paulo

• Future goals:
• Develop nowcasting
• f severe weather

and lightning

NEXT FIELD EXPERIMENTS

Main Goal: Mesoscale Convective Systems November - December 2012 In the region of two S Band Radar

• verlapping and a mesoNet

Santa Maria, RS – South Brazil

Percentage of surface rain from 2A25 explained by MCSs over La Plata Basin

Courtesy of Paola Salio Courtesy of Daniel Cecil Courtesy of Paola Salio

Santa Maria, RS – South Brazil

NEXT FIELD EXPERIMENTS

Santa Maria, RS – South Brazil

NEXT FIELD EXPERIMENTS

22 March 2012 22 March 2012

Main Goal: Continental convective processes - Savanna March 2013.

Additional Data: S Band Radar

Brasília, DF – Central Brazil

NEXT FIELD EXPERIMENTS

Main Goal: Tropical Forest Continental Convection February- March 2014 (with a possible extension to +9 months)

Additional Data: The ARM Climate Research Facility in the Amazon Basin ( Havard University and several partners) - S Band Radar (SIPAM)

NEXT FIELD EXPERIMENTS

Manaus, AM – North Brazil

NEXT FIELD EXPERIMENTS

Manaus, AM – North Brazil

CHUVA contribution to CWG

• CHUVA is collecting data from a large variety of convective

systems over Brazil:

• Several Golden Cases from tropical convection trough large MCSs
• Brazil is observed both by GOES and MSG:
• Great environment for GOES-R and MTG activities:
• Risk Reduction (nowcasting algorithms)
• Algorithm Working Group (proxy data)
• Calibration/Validation
• We are open to additional measurements:
• You can bring your instruments to the field experiments
• CHUVA data is openly available for the research community:
• Collaborations are greatly welcome!!!

CHUVA WEB- http://chuvaproject.cptec.inpe.br/

Data Access First step – Sign up; Second Step – Sign In Third Step – You must accept a Term of use.

Data Access

• Fourth Step – There are 3 options:

– FTP Access – For a ftp client; – Winscp Software – If you have not a client ftp, you can make a download of it; – Data Access: Direct access by browser.
