Chagrin Falls Exempted Village Schools Master Plan Presentation

November 22, 2013

Key Drivers

• Board of Education needs data for a strong strategic

plan

• Most buildings are nearing or beyond their useful life.
• Inflexible spaces for 21st century teaching methods
• Significant occupant comfort issues in all buildings
• High maintenance/operational costs
• No “swing space” within the District
• High square footage per student
• Very favorable construction and finance costs

Process

DISCOVERY WORKSHOPS

• Gauge public sentiment toward facilities
• Learn how Chagrin Falls applies its educational

philosophy

• Discuss how building design can support teaching and

learning

• Explore potential of existing buildings
• BUILDING ASSESSMENTS
• CREATE MASTER PLAN and CONCEPTUAL

DESIGN

• FORMULATE BUDGETARY COSTS/

RECOMMENDATIONS

Discover Workshop Summary

• Tradition/History are very important
• Feel Chagrin Falls students are well

prepared for the future

• PAC is a valued asset
• Strong desire for 21st Century learning

environments

• HVAC problems in all buildings
• Safety/Security extremely important
• Strong connection to Intermediate School

as a building, not necessarily as a school

• Libraries are not Media Centers
• Quality athletic facilities are a strong driver

(fields, gym, pool)

What does 21st Century learning look like?

TYPICAL CLASSROOM WING EDUCATIONAL ENVIRONMENT FOR 21ST CENTURY EDUCATION

21ST Century Education

A corridor becomes an extended learning environment

Dining encourages collaborative learning A stairwell becomes a learning tower

Supporting/Supplemental files/Images

Every space within the school is used for educational purposes. Student artwork is celebrated throughout the Academy.

The Neighborhood Academy

Gaming is used as a learning tool to support differentiated instruction for kinesthetic learners

The Neighborhood Academy

The traditional classroom extends into the corridors. Garage doors provide privacy when needed but also allow supervision of extended learning environments.

The Neighborhood Academy

Educational utilization is maximized through extended collaborative learning in the corridors. Circulation through these spaces is minimized by perimeter classroom locations, providing a single loaded corridor effect.

The Neighborhood Academy

Rocky River High School

ROCKY RIVER HIGH SCHOOL

Rocky River High School

Rocky River High School

Beachwood High School

Play is incorporated into the literacy curriculum via the alphabet walk and carefully selected play equipment.

Springfield Literacy Center

The Library takes the place of a lobby and is the first interior space experienced by students and visitors.

Springfield Literacy Center

The classroom extends into the single-loaded circulation system to maximize educational utilization. The separation is transparent to allow the teacher to monitor activity. Small group instruction areas are located between classrooms for literacy intervention. They are separated by sliding barn doors.

Springfield Literacy Center Springfield Literacy Center

Springfield Literacy Center

Building Assessments

Gurney Elementary School

• Currently grades PK-3
• 67,283 square feet
• Enrollment of 542
• 20 acres
• Newer gym and classroom

addition (1997)

• Several playfields with strong

usage by community Rec programs

Gurney Elementary School

• Over capacity
• Significant roof issues
• Safety/Security systems need

improvement

• Not ADA compliant
• Well water issues
• Parking/Circulation issues
• Significant issues with HVAC No

fire suppression/alarm system

• OSFC estimate for renovation

$10,203,000

Intermediate School

• Currently grades 4-6
• 89,364 square feet
• 3.4 acres
• Built between 1914 and 1940
• Current Enrollment is 480
• Building has significant historic

value

• Auditorium is a valued asset

Intermediate School

• Significant roof issues
• Safety/Security systems need

improvement

• Classrooms undersized
• Not ADA compliant
• Significant Parking/Circulation

issues

• HVAC/Electrical/ Plumbing

systems need to be replaced

• No fire suppression/alarm

system

• OSFC estimate for renovation

$13,760,000

High School/Middle School

• Currently grades 7-12
• 250,000 square feet
• 31.2acres
• Current Enrollment 916
• Middle School and PAC newer

construction (‘97-’06)

• PAC is a valued and highly

utilized asset

High School/Middle School

• Roof issues on high school
• Science labs and technology need

updating

• Safety/Security systems need

improvement

• Not ADA compliant
• Single Ingress/Egress for vehicular

traffic

• Significant issues with HVAC

systems

• No fire suppression/alarm system
• OSFC estimate for renovation

$17,268,600

Concept Options

High School/Middle School

7-12 Renovation/Expansion

• Improve security with passive

entry and relocated Admin. area

• Create student commons
• Redesign Media Center
• Build new Science Wing
• Reconfigure classrooms for 21st

Century Learning

• Upgrade Building Systems
• Improve ADA accessibility

High School – First Floor

High School – First Floor

High School – Second floor

High School – Lower Level

Middle School

Middle School – First Floor

Middle School – First Floor

Improvements to 7-12 facility

Base Building Renovations 250,000 square feet @ $69/square foot $17,270,000 Re-purposing/Reconfiguration 130,000 square feet @ $50/square foot $6,500,000 Entry/Admin Addition 8,750 square feet @ $250/square foot $2,187,500 Science Addition 19,900 square feet @ $300/square foot $5,970,000 TOTAL COST $31,927,500

Intermediate School

Renovation Pros and Cons

PRO

• Tradition/History
• Community attachment to building
• Building has been very well maintained

CON

• Lack of temporary classroom space
• ADA accessibility
• All major building systems beyond useful life
• Energy inefficient (higher operating costs)
• Still have site circulation/parking issue
• Still have 70-100 year old building

Historic Tax Credit Opportunities

1. Keep original 1914 building, demolish 1940 addition and rebuild intermediate school at existing site. 2. Reuse existing facility as an intermediate school 3. Re-purpose building for the district administration and maintain the gym and auditorium as auxiliary school and community space 4. Sell the building for commercial residential redevelopment.

Historic Redevelopment

• Retains Tradition/History
• Community attachment to building
• Very attractive to developers as residential

development

• Provides Revenue for District
• Sale of Property
• Puts property back on the tax rolls

Option 3 – Sell Intermediate school, construct new

building on other site and lease space for board offices

Gurney Elementary School

Gurney Options

1. Renovate Gurney retain as PK-3 2. Build new K-3 on site & Renovate Gurney as 4-6 3. Build New PK-6 on Gurney siteDemolish existing building 4. Renovate/Expand Gurney into PK-6

• a. Re-use entire Gurney building
• b. Retain gym and 1997 Classroom addition

Renovate Gurney

PROS

• Resolves current building problems
• Lower first cost
• Resolves site circulation problems
• Maintains athletic fields

CONS

• Building is currently at capacity
• No swing space during construction
• Student/Construction Interface
• Needs City Water

Option 1 – Renovate Gurney

Renovate Gurney as PK-3

62,850 square feet Estimated Cost - $195/square foot $12,256,000

Option 1 – Renovate Gurney

Option 2 – Build new K-3 on Gurney site

New PK-3 school single story building Keep bus garage Renovate Gurney into 4-6

Build New PK-3 & Renovate Gurney to 4-6

PROS

• Relieves over crowding at Gurney
• Increased operational efficiencies
• No swing space issues
• Resolves site circulation problems

CONS

• Need to replace playfields
• Student/Construction Interface
• Needs City Water

Option 2 – Build new K-3 on Gurney site

Build New PK-3 & Renovate Gurney to 4-6

Renovate Gurney to 4-6 62,850 square feet Estimated Cost - $195/square foot $12,256,000 New PK-3 64,500 square feet Estimated Cost - $241.50/square foot $15,576,750 TOTAL COST $27,832,750

*does not include field relocation

Option 2 – Build new K-3 on Gurney site

Option 3.a – Build new PK-6 on Gurney site

New PK-6 school building Keep bus garage Demolish existing Gurney and create play fields

Option 3.b – Build new PK-6 on Gurney site

New PK-6 school building Demolish existing bus garage Build new bus garage Maintain athletic fields

All New PK-6 at Gurney Campus

PROS

• All new elementary facilities
• Increased operational efficiencies
• No swing space issues

CONS

• Higher initial cost
• Need to replace playfields

All New PK-6 at Gurney Campus

PK-6 Building 121,778 square feet @ $232/square foot $28,252,500 Demolish Gurney 67.983 square feet @ $3.75/square foot $255,000 New Bus Facility $1,100,000 TOTAL COST $29,607,500

Option 4A – Renovate Gurney into PK-6

Keep existing gym

Keep existing two- story classroom as classroom spaces Demolish existing building and rebuild new

First Floor

Option 4A – Renovate Gurney into PK-6

Keep existing two- story classroom as classroom spaces Demolish existing building and rebuild new

Second Floor

Option 4B – New PK-6 w/ Adaptive Re-use

Demolish existing bus garage Build new bus garage Maintain athletic fields Convert 1997 Wing into BOE offices

Option 4B – New PK-6 w/ Adaptive Re-use

Keep existing gym

Keep existing two- story classroom Building-re-purpose for Board offices Demolish existing building

First Floor

Option 4B – New PK-6 w/ Adaptive Re-use Second Floor

Keep existing 1997 two- story classroom Building Demolish existing building

New second floor academic spaces

Consolidated K-6 facility

• Shared Common Facilities
• Cafeteria
• Media Center
• Gyms
• Increased Operational Efficiency
• More teacher collaboration
• All new spaces

Option 4B – New PK-6 w/ Adaptive Re-use

New PK-6 at Gurney Campus

PK-6 Building 112,278 square feet @ $232/square foot $26,048,496 Selective Demolition of Gurney 48,000 square feet @ $5.25/square foot $252,000 Renovate 1997 Classroom Wing for BOE office 21,250 square feet @ $175/square foot $3,718,750 New Bus Facility $1,100,000

TOTAL COST $31,119,246

Option 4B – New PK-6 w/ Adaptive Re-use

SUMMARY

Recommended Option

– Offer Intermediate School for Historic Tax credit re-development – Renovate/Expand High School

• New Science Wing
• New Secure Entrances
• Create Student Commons
• Renovate/Reconfigure Media Center
• Update Building Systems

– Build new PK-6 at Gurney Site

• Utilize existing 1997 gymnasium

– Relocate BOE offices to Gurney

• Re-purpose 1997 Classroom wing

– Relocate Bus Facility on Gurney site

Estimated Cost for Recommended Option

New PK -6 @Gurney

$31,119,246

Renovate/Expand HS/MS

$31,936,000

TOTAL $63,055,246*

*based on 2013 OSFC Design Manual program and budget

Estimated cost to renovate all buildings

Gurney $15,729,000 Intermediate $15,824,000 High School/Middle School $20,721,000

TOTAL $52,274,000*

*based on 2013 OSFC Design Manual program and budget

Estimated cost to replace existing square footage

Gurney $11,223,000 Intermediate $15,136,000 High School/Middle School $60,000,000

TOTAL $86,359,000*

*based on 2013 OSFC Design Manual program and budget exclusive of land acquisition costs
