CERN and Science Clouds in Europe with TOSCA, OpenStack Heat and the Heat Translator Matt Rutkowski Mathieu Velten Sahdev Zala Ricardo Rocha Brad Topol mrutkows@us.ibm.com mathieu.velten@cern.ch spzala@us.ibm.com Ricardo.Rocha@cern.ch

slide-1
SLIDE 1

CERN and Science Clouds in Europe with TOSCA, OpenStack Heat and the Heat Translator

Ricardo Rocha

Ricardo.Rocha@cern.ch

Brad Topol

btopol@us.ibm.com

Matt Rutkowski

mrutkows@us.ibm.com

Sahdev Zala

spzala@us.ibm.com @sp_zala

Mathieu Velten

mathieu.velten@cern.ch @mrutkowski @bradtopol

slide-2
SLIDE 2

Introduction

  • Indigo DataCloud Project
  • Goal is to provide a sustainable European infrastructure for science, spanning multiple computer centers and existing

public clouds.

  • Challenges
  • Need to effectively exploit heterogeneous cloud infrastructures (OpenStack, OpenNebula, proprietary clouds) as a

single cloud

  • Need a standard orchestration model that works across multiple cloud infrastructures
  • Project Approach
  • Leverage TOSCA as a standard based approach for modeling cloud stacks and applications
  • Support for TOSCA is growing in several cloud communities
  • Leverage OpenStack components as a means of deploying TOSCA cloud stacks
  • OpenStack Heat Project provides robust tools to convert alternative orchestration languages to OpenStack Heat’s

HOT templates

  • Heat-Translator: Provides a framework for translation orchestration models to Hot
  • TOSCA-Parser: Production quality tool for parsing TOSCA templates
  • In this presentation we will cover
  • TOSCA-Parser and Heat-Translator
  • Project Indigo and CERN’s initiative
  • Demo concrete examples of using TOSCA to model a complex infrastructure covering multiplesites
  • Latest on TOSCA specification
slide-3
SLIDE 3

Mitaka: TOSCA-Parser

  • What is the TOSCA-Parser?
  • A parser for TOSCA Simple and Network Functions Virtualization (NFV) YAML based

specifications.

  • Produces in-memory graph of TOSCA nodes and relationship among them
  • Subproject of OpenStack Heat
  • Two point releases – 0.4.0 and 0.3.0
  • 0.4.0
  • Release date: Feb 04, 2016
  • Introduced support for TOSCA Simple Profile for NFV v1.0
  • Support for TOSCA Groups and TOSCA Policies
  • Support for TOSCA namespace, nested properties, bug fixes etc.
  • 0.3.0
  • Release date: Dec 02, 2015
  • Full validation of TOSCA templates
  • Support for nested imports in service template and type definition
  • Shell entry point, bug fixes etc.
  • New features available on master
  • Support for LoadBalancer node type
  • Support for range data type etc.
  • PyPi releases are available at https://pypi.python.org/pypi/tosca-parser

Node Types Relationships Capabilities Interfaces Validation Tests App Server Mongo Server Node App Mongo DB Mongo DBMS Node. js HostedOn HostedOn HostedOn Groups Policies Custom Types

slide-4
SLIDE 4

Mitaka: Heat-Translator

  • What is the Heat-Translator?
  • An OpenStack project to map and translate non-Heat (e.g. TOSCA)

templates to Heat Orchestration Template (HOT)

  • Subproject of OpenStack Heat
  • Two point releases – 0.4.0 and 0.3.0
  • 0.4.0
  • Release date: March 02, 2016
  • Support for TOSCA NFV templates translation
  • Introduced support for Policies translation
  • Completed OpenStack Client plug-in work with new test suites
  • Handle Nova server specific key_name property, bug fixes etc.
  • 0.3.0
  • Release date: Dec 17, 2015
  • Querying Nova flavors to find match to TOSCA constraints
  • New CLI option --validate-only to only validate template without

translation

  • New CLI option --output-fileto save translated output to file etc.
  • New features available on master
  • New CLI option --deploy to automatically deploy translated template
  • Support for Ansible and Puppet scripts in translation etc.
  • PyPi releases are available at, https://pypi.python.org/pypi/heat-translator

TOSCA Heat Orchestration Template (HOT)

slide-5
SLIDE 5

TOSCA OpenStack Integration is Maturing Rapidly

TOSCA-Parser

Heat-Translator

Tacker

TOSCA Plugin TOSCA Integration

apps.openstack.org

OSC Plugin

Translate Deploy

slide-6
SLIDE 6

CERN and the Large Hadron Collider

  • 21 member states
  • Many other involved in other ways
  • Large Hadron Collider (LHC)
  • 27km long
  • 100m underground
  • Particle collisions at specialized detectors
  • ~600 million times / sec
  • Generating ~30PB of data / year
  • CERN Cloud in numbers
  • ~6000 nodes
  • ~150k cores
  • 2000 users
  • 16000 VMs running
slide-7
SLIDE 7

Indigo DataCloud

  • Towards a sustainable European SW infrastructure for science
  • Funded under the European Union Horizon 2020 program
  • Multiple partners, heterogeneous infrastructure (OpenStack, OpenNebula)
  • INFN, CERN, ATOS, UPV, CSIC, DESY, UPV, LIP, T-Systems, CNRS, Reply, …
  • Main strengths
  • Support for multi-disciplinary scientific communities
  • Exploits available, general solutions
  • Low learning curve, rely on popular software tools
  • Hybrid, distributed environment
  • Credits
  • German Molto (UPV), Miguel Caballer (UPV), Marica Antonacci (INFN), Alvaro Lopez Garcia

(CSIC), Giacinto Donvito (INFN)

  • And many others...

https://www.indigo-datacloud.eu

slide-8
SLIDE 8

Why TOSCA?

  • First step was to evaluate available options
  • HEAT, CloudFormation
  • Both tied to specific implementations
  • TOSCA appeared as a viable common denominator
  • Topology definition
  • End user applications
  • Existing codebase (TOSCA parser, HEAT translator)
  • Reusable in other contexts too
  • Growing support in different communities
slide-9
SLIDE 9

Current Use Cases

  • Deploy simple VM with a given image
  • Elastic cluster for batch processing (infrastructure)
  • Supported systems: torque, slurm, condor
  • Deploy a Mesos cluster (infrastructure)
  • Galaxy portal (end user)
  • Data intensive application for biomedical research
  • Indigo specific jobs (infrastructure / end user)
  • Package and deploy applications in docker containers, on

Mesos/Marathon/Chronos

slide-10
SLIDE 10

Basic example: Indigo Compute Node

tosca_definitions_version: tosca_simple_yaml_1_0 imports:

  • indigo_custom_types: custom_types.yaml

description: > TOSCA test for launching compute node with a specified image and getting as an output the IP and SSH credentials to access topology_template: node_templates:

  • utputs:

node_ip: value: { get_attribute: [ simple_node, public_address, 0 ] } simple_node: type: tosca.nodes.indigo.Compute properties: public_ip: yes capabilities: scalable: properties: count: 1 host: properties: num_cpus: 1 mem_size: 1 GB

  • s:

properties: type: linux distribution: ubuntu version: 12.04

slide-11
SLIDE 11

Basic example: Derived Types

tosca.nodes.indigo.Compute: derived_from: tosca.nodes.indigo.MonitoredCompute tosca.nodes.indigo.MonitoredCompute: derived_from: tosca.nodes.Compute properties: zabbix_server: type: string required: no default: 90.147.170.165 zabbix_server_port: type: PortDef required: no default: 32314 zabbix_server_metadata: type: string required: no default: Linux 668c875e-9a39-4dc0-a710-17c41376c1e0 interfaces: Standard: create: implementation: zabbix_agent_install.yml configure: implementation: zabbix_agent_configure.yml inputs: zabbix_server: { get_property: [ SELF, zabbix_server ] } zabbix_server_port: { get_property: [ SELF, zabbix_server_port ] } zabbix_server_metadata: { get_property: [ SELF, zabbix_server_metadata ] } start: implementation: zabbix_agent_start.yml

slide-12
SLIDE 12

Basic example: HOT

heat_template_version: 2013-05-23 description: > TOSCA test for launching compute node with a specified image and getting as an output the IP and SSH credentials to access parameters: {} resources:

  • utputs:

node_ip: value: get_attr:

  • simple_node
  • networks
  • private

simple_node: type: OS::Nova::Server properties: flavor: m1.small image: ubuntu-12.04-software-config-os-init public_ip: true user_data_format: SOFTWARE_CONFIG simple_node_create_config: ... simple_node_create_deploy: ... simple_node_configure_config: type: OS::Heat::SoftwareConfig properties: config: get_file: zabbix_agent_configure.yml group: ansible simple_node_configure_deploy: type: OS::Heat::SoftwareDeployment properties: config: get_resource: simple_node_configure_config input_values: zabbix_server: 90.147.170.165 zabbix_server_metadata: Linux 668c875e-9a39-4d... zabbix_server_port: 32314 server: get_resource: simple_node

slide-13
SLIDE 13

Basic example: Ansible Integration

interfaces: Standard: create: implementation: zabbix_agent_install.yml configure: Implementation: zabbix_agent_configure.yml inputs: zabbix_server: { get_property: [ SELF, zabbix_server ] } zabbix_server_port: { get_property: [ SELF, zabbix_server_port ] } zabbix_server_metadata: { get_property: [ SELF, zabbix_server_metadata ] } start: implementation: zabbix_agent_start.yml

  • hosts: localhost

connection: local tasks: ...

  • name: Apt install

Zabbix agent apt: name=zabbix-agent when: ansible_os_family == "Debian" tasks:

  • lineinfile: |

dest=/etc/zabbix/zabbix_agentd.conf regexp="{{ item.var }}=" line="{{ item.var }}={{ item.value }}" with_items:

  • { var: "ServerActive",

value: "{{zabbix_server}}:{{zabbix_server_port}}"}

slide-14
SLIDE 14

Basic example: Ansible Integration (Galaxy Roles)

interfaces: Standard: configure: implementation: zabbix_agent_configure.yml inputs: zabbix_server: { get_property: [ SELF, zabbix_server ] } zabbix_server_port: { get_property: [ SELF, zabbix_server_port ] } zabbix_server_metadata: { get_property: [ SELF, zabbix_server_metadata ] }

  • hosts: localhost

connection: local roles:

  • role: indigo-dc.zabbix-agent

zabbix_agent_server: "{{ zabbix_server }}" zabbix_agent_server_port: "{{ zabbix_server_port }}" zabbix_agent_metadata: "{{ zabbix_server_metadata }}"

slide-15
SLIDE 15

Multiple deployment & config options

  • Supported in the HEAT Translator
  • .yaml is Ansible
  • .pp is puppet
  • .(anything else) is scripts (python, bash, …)
  • This is reflected on the resulting HOT templates
  • Extending the translator with others should not be hard
  • We did it for Ansible
slide-16
SLIDE 16

Complex example: Batch Cluster

  • A user facing portal manages jobs running on a batch cluster
  • The cluster may spawn multiple sites
  • Sites may be running different cloud flavors
  • Mainly OpenStack and OpenNebula
  • One single frontend for the batch system
  • At least for now
slide-17
SLIDE 17

Complex example: Batch Cluster

node_templates: elastic_cluster_front_end: type: tosca.nodes.indigo.ElasticCluster properties: deployment_id: orchestrator_deployment_id requirements:

  • lrms: torque_front_end
  • wn: wn_node

torque_front_end: type: tosca.nodes.indigo.LRMS.FrontEnd.Torque requirements:

  • host: torque_server

wn_node: type: tosca.nodes.indigo.LRMS.WorkerNode.Torque capabilities: wn: properties: max_instances: 5 min_instances: 0 requirements:

  • host: torque_wn

torque_wn: type: tosca.nodes.indigo.Compute properties: public_ip: no capabilities: scalable: properties: count: 0 host: properties: num_cpus: 1 mem_size: 1 GB

  • s:

properties: type: linux distribution: ubuntu version: 14.04 torque_server: type: tosca.nodes.indigo.Compute properties: public_ip: yes capabilities: host: properties: num_cpus: 1 mem_size: 1 GB

slide-18
SLIDE 18

Demos

  • Basic compute node

https://www.youtube.com/watch?v=TaEXhcjP7x0

  • Batch cluster

https://www.youtube.com/watch?v=IyKp3cXxm4c

slide-19
SLIDE 19

Indigo TOSCA Status

  • First use cases already covered by existing tools
  • Indigo contributions upstream
  • TOSCA Parser: UPV 2nd contributor in number of commits (after IBM :-))
  • Heat Translator: CERN 2nd contributor in number of commits (after IBM :-))
  • Using the heat-translator CLI, the common openstack client, and in some

cases other APIs

  • Coming Next
  • Expand deployment to more sites within the project
  • Experiment with end user applications definitions in TOSCA
  • Continue contributing upstream to both projects
slide-20
SLIDE 20

Newton dev plan: TOSCA-Parser and Heat-Translator

  • Two to three point releases of both projects
  • New features as need arise from work on project Indigo by CERN and other members
  • Enhance Network Functions Virtualization (NFV) support with complex and real life NFV

templates continuing collaboration with OpenStack Tacker project team

  • Enhancement to both projects per OPNFV need
  • Work on completing implementing remaining TOSCA Simple Profile v1.0 specification features
  • TOSCA container parsing and translation support
  • Intrinsic functions, navigation functions
  • Enhanced artifacts support
  • Support for credential data type
  • etc.
  • Grow TOSCA templates eco system
  • Support to provide inputs via a configuration file
  • Horizon plug-in to translate and deploy TOSCA templates from dashboard
slide-21
SLIDE 21

TOSCA Simple Profile v1.1

  • Target: Public Draft release ~June 2016
  • Target “Final” 3Q 2016 -after 30-day public comment/review period

New Features

  • Metadata (completed)
  • now supported in all Types (Node, Relationship, Capability, Data, etc.) (c
  • Group Type (completed)
  • Expanded Group Type to allow management of member resources (i.e., Lifecycle)
  • Has its own Capabilities and Requirements
  • Policy Definition (completed)
  • Event-Condition-Action model (completed)
  • Includes Event Filters and Triggers
  • Cluster Type (75% completed)
  • Add support for Cluster normative type; based upon new Group Type
  • Will support new normative LoadBalancer , Scalable and Router Capability Types
  • Data Clusters (e.g., Cassandra, MongoDB, etc.) – In-Progress
  • Workflow(50% completed)
  • Intermix declarative with Imperative (e.g., Ansible, Ant, Bash)
  • Preserve investment in existing scripts for complex installations / configurations
slide-22
SLIDE 22

TOSCA Policy Definition:

<policy_name>: type: <policy_type_name> description: <policy_description> properties: <property_definitions> # allowed targets for policy association targets: [ <list_of_valid_target_resources> ] triggers: <trigger_symbolic_name_1>:

event: <event_type_name>

target_filter: node: <node_template_name> | <node_type> # (optional) reference to a related node # via a requirement requirement: <requirement_name> # (optional) Capability within node to monitor capability: <capability_name> # Describes an attribute-relative test that # causes the trigger’s action to be invoked.

condition:

<constraint_clause> action: # implementation-specific

  • peration

name <operation_name>: description: <optional description> inputs: <list_of_parameters> implementation: <script> | <service_name>

...

Event

  • Name of a normative TOSCA Event Type
  • That describes an event based upon a

Resource “state” change.

  • Or a change in one or more of the

resources attribute value.

Condition

Identifies:

  • the resource (Node) in the TOSCA

model to monitor.

  • Optionally, identify a Capability of the

identified node.

  • Describe the attribute(state) of the

resource to evaluate (condition)

TOSCA Policy Definition - Event, Condition, Action model

1..N Triggers can be declared Action

Describes:

  • An Operation (name) to invoke when

the condition is met

  • within the declared Implementation
  • Optionally, pass in Input parametersto

the operation along with any well- defined strategy values.

slide-23
SLIDE 23

TOSCA Work Group Activities

  • Interoperability
  • Conformance test suite for v1.0 (Service Templates)
  • Work underway in new GitHub repo., announcement (target ~May 2016)
  • Network Function Virtualization (NFV)
  • Working directly with OpenStack Tacker Project
  • Publishing v1.0 Public Draft 3 – All Normative Types / Models designed with Tacker contribs.
  • Define and Compose: Network Services, VNFs, Links, with Forwarding Graphs & Paths, etc.
  • Expanded scope to include Software-Defined Network (SDN) use cases
  • Container
  • Finish new Cluster capability definitions, Data Cluster use cases. for Simple Profile v1.1
  • Instance Model
  • New Group - will produce new schema for an Instance Model (reuse existing schema)
  • API potentially enabling capture, export and management of deployed application
  • Monitoring
  • Goal: Create normative event types for basic operational events
  • Focus on events types for Health, Scaling & Performance
  • Support basic “Red-Yellow-Green” and Percentage-based monitoring for dashboards
slide-24
SLIDE 24

vBrownBag TechTalk

Deploy TOSCA NFV Workloads into OpenStack Cloud

Tuesday, April 26 at 2:15 PM Austin Convention Center -4th floor - Room 13b Sahdev Zala (IBM) PTL, TOSCA-Parser and Heat-Translator Bob Haddleton (Nokia)Core reviewer, OpenStack Tacker http://openstack.prov12n.com/vbrownbag-techtalk-schedule-tuesday/

slide-25
SLIDE 25

THANK YOU!!
