OpenStack: The OpenSource Cloud’s Application in High Energy Physics

That Title’s Overstated

OpenStack: The OpenSource Cloud’s Potential Application in Data Intensive Research

That Title’s Overstated

OpenStack: The OpenSource Cloud’s Potential Application in Data Intensive Research

Not as Catchy...

Caveats

» I am not a storage or network engineer » I am not a scientist

I am:

» a Technical Product Manager. » Dashboard Developer » working for piston{cloud}computing » Pragmatic.

Caveats

» I am not a storage or network engineer » I am not a scientist

I am:

» a Technical Product Manager. » Dashboard Developer » working for piston{cloud}computing » Pragmatic.

» despite illusions of grandeur.

What is openstack?

» Founded by NASA and Rackspace » The open source cloud computing platform » Feature-rich and massively scalable » Powers cloud storage, compute, and networking » A world-wide open source collaboration

OpenStack as a Cloud OS

AP

Creates Pools of Resources Automates The Network

USER ADMIN

CLOUD OPERATING SYSTEM

Connects to apps via APIs Self-service Portals for users

Benefits of OpenStack as a Common Platform

» Easy to migrate data and applications across clouds Based on: » security policies » economics » research needs » No vendor lock-in » Common Layer of Data Exchange » Less exposed to security issues than public cloud, but still interoperable.

3 Major OpenStack Components

» OpenStack Compute/Nova: provision and manage large networks of virtual machines » OpenStack Object Store/Swift: Create petabytes of reliable storage using standard servers » OpenStack Image Service/Glance: Catalog and manage large libraries of server images

+

» Other components: Dashboard, Load Balancing, Authentication...

Compute/Nova Key Features

• 2. Horizontally and

massively scalable

• 1. REST-based
• 3. Hardware agnostic: supports

a variety of standard commodity hardware.

• 4. Hypervisor Agnostic: support for Xen,

Citrix XenServer, Microsoft Hyper-V, KVM, UML, LXC and ESX

HOST 1 HOST 2 HOST 3 HOST 4, ETC. VMs Hypervisor: Turns 1 server into many “virtual machines” (instances or VMs) (VMWare ESX, Citrix XEN Server, KVM, Etc.)

» Hypervisors provide abstraction layer between apps and hardware (SERVERS) » OpenStack pools servers, you run operating systems and applications on VMs instead of physical computers

Nova close up

» nova-api daemon

» endpoint for all OpenStack or EC2 API queries

» nova-schedule process

» takes a virtual machine instance request from the queue and determines which compute server host it should run on » a pluggable architecture allowing custom scheduling algorithm

» nova-compute process

» worker daemon that creates and terminates virtual machine instances

We mentioned Commodity. How Commodity?

Commodity Hardware

» Piston Silicon Mechanics

» 2 Intel Xeon processors 5600 Series » 96GB of DDR3 RAM » 24TB of SATA storage » Redundant 1200W power supplies » 2U rackmount chassis

» That’s what our clients get, we’re on:

» 32GB, 16TB, 2 Intel Xeon E5645 processors

Commodity Hardware

» Piston Silicon Mechanics

» 2 Intel Xeon processors 5600 Series » 96GB of DDR3 RAM » 24TB of SATA storage » Redundant 1200W power supplies » 2U rackmount chassis

» That’s what our clients get, we’re on:

» 32GB, 16TB, 2 Intel Xeon E5645 processors DevOp borrowed the rest for other machines

Performance: 500 VM Spin Up

» Assuming:

» 500 copies of one 8GM image » Image warm on the nodes » 50 VMs/Server

» Based on NASA’s experience in regular use, less than 30 seconds

» Worst case:

» Image is still in Glance » VM has to be copied via HTTP

Image Service/Glance

• 2. REST-

based API

• 1. Store &

retrieve VM images

• 3. Compatible with

all common image formats

• 4. Storage agnostic: Store

images locally, or use OpenStack Object Storage, HTTP, or S3

Storage/Swift Key Features

• 4. Scalable

to multiple petabytes, billions of

• bjects
• 1. REST-based API
• 6. Account/Container/Object structure (not file

system, no nesting) plus Replication (N copies of accounts, containers, objects)

• 5. No central

database required

• 2. Data distributed evenly

throughout system.

• 3. Runs on

commodity hardware

The Storage Story: Nova

» Nova/Compute has it’s own storage » Block Storage or Nova-volume

» an iSCSI solution » employs the use of Logical Volume Manager (LVM) for Linux » intended for read/write purposes (databases, log, etc.) » basically is an LVM/iSCSI implementation to mount block devices in VM.

The Storage Story: Swift

» Swift: Object Storage

» Fully Distributed » Commodity Hardware (Linux/x86) » Data Protection in Software » Not a File System » Not SAN/NAS/DAS... or any attached storage » Optimized for Scale - Petabytes

Swift in Production

» Swift has been running in production at Rackspace for over a year with near 100% uptime. » Rackspace’s swift clusters store billions of objects and petabytes of data. » Internap, KT , SDSC, and HP are also running Swift in production

Swift OS

• r

EC2 API

Sharing the Research

Location B Location A

Private Cloud Private Cloud

Common software platform making Federation possible, through a shared API.

To federate Swift across locations, you write a scheduler within OpenStack and drive it through the API.

Swift Components

Proxy ¡Servers Clients Account ¡ Servers Container ¡ Servers Object ¡ Servers Rings

Swift Components

» Proxy Server

» Tie together the Swift architecture » Request routing » Exposes the public API

Swift Components

» The Ring: Maps names to entities (accounts, containers, objects) on disk.

» Stores data based on zones, devices, partitions, and replicas » Weights can be used to balance the distribution of partitions » Used by the Proxy Server for many background processes

Swift Components...

» Object Server:

» Blob storage server » metadata kept in xattrs » data in binary format » Object location based on name & timestamp hash

Swift & Large Object Storage

» default 5GB limit on the size of an uploaded

• bject

» segmentation makes download size of a single

• bject is virtually unlimited

» segments large object are uploaded and a special manifest file is created » when downloaded, all segments are concatenated as a single object. » greater upload speed » possible parallel uploads of segments.

But Wait, Swift...

» Doesn’t load balance for often requested

• bjects.

» throw Varnish Cache or Squid Proxy in front of Swift » Has a “simple” ReSTful API » Wasn't intended for storing unknown data » Isn’t searchable » Is like Amazon’s S3

Potential Solutions for Those Needing to Search Data

» Or wait...

» Swifts Blueprints Include Searchable MetaData » https://blueprints.launchpad.net/swift/ +spec/future-searchable-metadata » Contribute to the greater community

What’s Piston Doing Different?

» Piston Enterprise OS:

» A hardened cloud operating system built on OpenStack

™

» Optimized for secure and easy operation of enterprise private clouds » Fully supports interoperability with other OpenStack

™ powered public and private cloud

solutions.

{pentOS}

TM features

{CloudKey}™ » Two-factor capable physical authentication » Minimizes security risk of administrative logins » Hands-free install in under 5 minutes Null-Tier [Architecture]™ » Storage, compute and networking on every node » Massively scalable » Automated scaling

Top of Rack Switch

{pentOS}

TM Null-Tier [Architecture]™

Server<1>

• Networking
• Storage
• Compute
• Management

Server<N>

• Networking
• Storage
• Compute
• Management

Highly available

{pentOS}

controllers

Highly available Virtual Machines Highly available Virtual Storage

Hands-Free OS Install and Configuration

…

{CloudKey}™ ¡
