Ceramically reinforced zinc rich epoxy primer Thor Hkon Krane Thvedt - - PowerPoint PPT Presentation

Barrier Smart Pack

Protective Coatings

Ceramically reinforced zinc rich epoxy primer

Thor Håkon Krane Thvedt & Lasse Isaksen

Barrier Smart Pack

Protective Coatings BARRIER SMART PACK

«when you want maintenance with newbuild performance»

Barrier Smart Pack

Protective Coatings

What makes Barrier Smart Pack different?

NORSOK compliant on ST3 prepared steel Designed to achieve typical DFT in one coat by brush and roller

BARRIER SMART PACK

Surface tolerant ceramically reinforced zinc epoxy primer High volume solids (70%) Low VOC 300 g/L 1:1 mixing ratio for reduced mixing errors and waste

Barrier Smart Pack

Protective Coatings BARRIER SMART PACK

Surface tolerance

• Unique combination of binders and hardener
• Worlds first surface tolerant for a zinc rich epoxy with external

documentation (NORSOK)

• Lower molecular weight epoxy and hardner gives better

penetration into the steel substrate

− More mobility of the molecules − Better surface tolerance − Require less roughness

Barrier Smart Pack

Protective Coatings BARRIER SMART PACK

Superior corrosion resistance

Barrier Smart Pack 70 mm Std 80% zink epoxy 40 mm

• Optimized combination of

binders, hardener and additives improves availability of zinc particles to act as cathodic protection

• High zinc dust level of 80%
• Gives the required DFT according

to standards, in one coat and delivers a even film

Brush application 6 months salt spray

Barrier Smart Pack

Protective Coatings BARRIER SMART PACK

Superior corrosion resistance

The worlds first and only zinc rich epoxy primer that complies with NORSOK recuirments on power tool prepared steel surfaces!

Surface Application Result SA2½ Airless spray NORSOK Comp. Grinded («3M disc») Airless spray NORSOK Comp. Grinded («3M disc») Brush NORSOK Comp. Water jetted SA2½ Brush NORSOK Comp. Water jetted SA2½ Roller NORSOK Comp. Bristle blaster Airless spray May 30 Bristle blaster Brush May 30 Bristle blaster Roller May 30 Grinded («3M disc») Roller May 30

Substrate St3 or better

Barrier Smart Pack

Protective Coatings BARRIER SMART PACK

Steel Rust BSP JMSPHB HT ONE Zinc oxide in the scribe

SEM image after 6 months NORSOK testing on UHPWJ substrate applied with roller

Barrier Smart Pack

Protective Coatings BARRIER SMART PACK

Steel Rust JMSPHB HT ONE Zinc oxide in the Barrier coating Yellow and green Zinc Yellow

SEM image after 6 months NORSOK testing on UHPWJ substrate applied with roller

Barrier Smart Pack

Protective Coatings BARRIER SMART PACK

Rust creep

SEM image after 6 months NORSOK testing on UHPWJ substrate applied with roller

NORSOK and ISO 20340 requirement is less than 3mm rust creep

Barrier Smart Pack

Protective Coatings BARRIER SMART PACK

Superior corrosion resistance

• Ceramic spheres adds volume inaccessable to zinc dust
• Compresses zinc dust into a much smaller volume increasing contact point between

the zinc particles and the steel

− More activated zinc / more available zinc to protect

Steel substrate Normal Zinc Epoxy Barrier Smart Pack

Zinc dust Ceramic spheres

Barrier Smart Pack

Protective Coatings BARRIER SMART PACK

Mixing of components

• 1:1 mixing ratio by volume
• Robust against wrong ratios +/- 15%
• Visual indicator for proper mixing

− Easy indication as soon as all the white has disappeared

Barrier Smart Pack

Protective Coatings BARRIER SMART PACK

Mixing of components – visual indicator

1 min 1 min

Barrier Smart Pack

Protective Coatings BARRIER SMART PACK

Diisocyanates – Free!

• Test done at IFKAN – Sweden
• Free of all kinds of isocyanates
• Test report available if needed

No diisocyantes!

Barrier Smart Pack

Protective Coatings BARRIER SMART PACK

Application by brush&roller

• Coating rheology goes «hand-in-hand» with design of

application equipment

• Barrier Smart Pack has an unique thixotropic

− Slow recovery thixotropic agents provides ample anti- settling properties and excellent flow and leveling − Low viscosity while applying gives little resistance for the applicator − In cobination with high body gives the proper film thickness «in one go»

Barrier Smart Pack

Protective Coatings BARRIER SMART PACK

Brush application

• Robust to application equipment
• Designed to give best application when

applied by low cost/low quality brushes with relatively high stiffeness

• Soft synthetic brushes will give

improved finish and more even DFT

• We recommend:

− A long haired soft synthetic or semi- synthetic brush to give the best flow and appearance.

Barrier Smart Pack

Protective Coatings BARRIER SMART PACK

Roller application

• Different rollers – different appearence

and DFT

• Barrier Smart Pack is very robust to

roller type

− All rollers tested gives minimum 60mm DFT

• We recommend:

− Short haired filt roller (picture) of high quality

Barrier Smart Pack

Protective Coatings BARRIER SMART PACK

Spray application

Barrier Smart Pack has excellent sprayability with airless, HVLP and conventional spray

Battery driven airless

Barrier Smart Pack

Protective Coatings BARRIER SMART PACK

Reduced wrong mixing and waste

Easy 1:1 mixing ratio – Reduces wrong mixing or mixing to much for the job Visual instructions on lids - No mix up of components Less mistakes and less paint thrown away

Barrier Smart Pack

Protective Coatings

Summary

NORSOK compliant on ST3 prepared steel Designed to achieve typical DFT in one coat by brush and roller

BARRIER SMART PACK

Surface tolerant ceramically reinforced zinc epoxy primer High volume solids (70%) Low VOC 300 g/L 1:1 mixing ratio for reduced mixing errors and waste
