A Global Leader in Air Pollution Control Technology CECO Environmental 1 CECO Environmental CECO is a global leader in Air Pollution Control, Product Recovery & Fluid Handling Technology. Headquarters:

slide-1
SLIDE 1

工业空气净化整合方案

1

CECO Environmental

A Global Leader in Air Pollution Control Technology

slide-2
SLIDE 2

工业空气净化整合方案

CECO Environmental

CECO is a global leader in

Air Pollution Control, Product Recovery & Fluid Handling Technology.

Headquarters: Cincinnati, OH Founded: 1966 Core Facilities: 12 CECO China: Since 2005 China Facilities ： 2 Exchange: NasdaqGM Ticker: CECE Employees: 800 Customer Base: 5,000+

slide-3
SLIDE 3

工业空气净化整合方案

Air Pollution Control Fluid Handling & Filtration

Key Brands Key Brands

Power & Energy

Key Brands

Three Core Strategic Segments

slide-4
SLIDE 4

工业空气净化整合方案

Effox Profile

slide-5
SLIDE 5

工业空气净化整合方案

Effox Profile

Since 1980 Effox has taken pride in designing and manufacturing Dampers & Expansion Joints for use in flue gas and process air handling systems in the following industries:

  • Coal, Oil and Gas Fired Systems
  • Refineries and Petrochemical Applications
  • HRSG
  • Metal Industry
  • Cement Industry
  • Mining Industry
  • Ethanol
  • Pulp and Paper
  • Other Heavy Industries
slide-6
SLIDE 6

工业空气净化整合方案

Effox Profile

  • Design and manufacture Dampers & Expansion Joints for flue gas systems
  • 1980 Founded
  • 2007 Effox acquired by CECO Environmental
  • Market Leader – US $500+ million installed base
  • 2013 CECO Power Sector Sales – US $70 million
  • Employees: 70 Effox / 80 CECO Shanghai
  • Locations:
  • Cincinnati, USA – Headquarters with 9,300 square meters captive shop
  • Shanghai, China – Sales / Manufacturing Facility with 6,000 square meters

captive shop

slide-7
SLIDE 7

工业空气净化整合方案

Manufacturing Capabilities

slide-8
SLIDE 8

工业空气净化整合方案

Effox World Headquarters ‐ USA

Technical & Fabrication center for the Past 30 years

slide-9
SLIDE 9

工业空气净化整合方案

Effox Manufacturing Facility

Dampers being fabricated in the Effox USA Facility for global supply

slide-10
SLIDE 10

工业空气净化整合方案

CECO China Manufacturing Facility

  • China Fabrication Facility since 2005
  • 80 Full‐Time Staff (40 Office & 40

Shop)

  • Close Proximity to Port of Shanghai,

PRC

  • ISO: 9001, 14001 Certified
  • High Technology company status in

PRC

  • ASME U Stamp
  • 6,000 m2

Effox USA technology fabricated in our CECO China Facility

slide-11
SLIDE 11

工业空气净化整合方案

CECO China Manufacturing Facility

Dampers in fabrication for FGD Project to be installed in Thailand

slide-12
SLIDE 12

工业空气净化整合方案

The Effox Difference

slide-13
SLIDE 13

工业空气净化整合方案

The Effox Difference

  • World‐wide installed references
  • Global Fabrication capabilities
  • USA (wholly owned)
  • China (wholly owned)
  • Malaysia (partner)
  • India (partner)
  • Saudi Arabia (partner)
  • Romania (partner)
  • Multi‐Language staff that can speak

8 different languages Global reach with local support

slide-14
SLIDE 14

工业空气净化整合方案

The Effox Difference

Engineered Product

  • All Effox dampers custom engineered for specific system requirements
  • Detailed calculations performed for each project
  • 25+ Engineers / Mechanical Designers on staff in all positions
  • President – Jack Neiser, BSE Civil Engineering w/ 38+ years experience
  • Vice President of Sales – Jeff Korth, BSE Mechanical Engineering w/ 33+ years experience
  • Engineering Manager – Dave Forney, BSE Mechanical Engineering w/ 33+ years experience
  • Proposal Engineer – Doug Varick, BS Manufacturing Engineering w/ 22+ years experience
  • Asia Sales Manager – Dante Zannoni, BSME Mechanical Engineering w/ 3+ years experience

World‐class Engineering Knowledge & Expertise

slide-15
SLIDE 15

工业空气净化整合方案

The Effox Difference

3-D Modeling FEA analysis CFD Analysis Advanced Design Solutions

slide-16
SLIDE 16

工业空气净化整合方案

The Effox Difference

Extensive experience

  • 100+ Coal Fired Boilers Including Super Critical with Effox Dampers
  • 100+ Coal Fired Boiler FGDs with Effox Dampers
  • 75+ Coal Fired Boiler SCRs with Effox Dampers

Diverse Customer Base

  • End Users
  • Engineering & Procurement Contractors (EPCs)
  • Original Equipment Manufactures (OEMs)

Unparalleled industry experience

slide-17
SLIDE 17

工业空气净化整合方案

Our Customers

slide-18
SLIDE 18

工业空气净化整合方案

Effox Product Lines

  • Louver dampers
  • Slide Gate/Guillotine dampers
  • Stack dampers
  • Diverter dampers
  • Butterfly dampers
  • Radial Vane dampers
  • Poppets
  • Non Metallic Expansion Joints
slide-19
SLIDE 19

工业空气净化整合方案

Louver Dampers

slide-20
SLIDE 20

工业空气净化整合方案

Louver Dampers

Showcasing the Effox technology

slide-21
SLIDE 21

工业空气净化整合方案

Louver Design Features

  • Isolation (Open/Close) or Control

(Modulating) Applications

  • 300% Safety Factor in Drive Sizing

(Breakaway & Running Torque Analyzed)

  • Dual skin, bolted airfoil

construction minimizes blade warpage

  • Blade profile/axle designed for

minimal deflection under all

  • perating conditions

Robust design features for optimized reliability

slide-22
SLIDE 22

工业空气净化整合方案

Louver Design Features

  • Primary Seal: Blade‐to‐Blade Overlap
  • Secondary Seal: Bolted on Metallic

Blade Seals in standard 3 meter seal sections for ease of maintenance

  • Jamb seals along each side frame
  • Top and Bottom J‐seals
  • <1% Leakage of flow volume

Extremely tight sealing efficiency

slide-23
SLIDE 23

工业空气净化整合方案

Louver Design Features

  • Independent packing glands with
  • utboard bearing assemblies
  • Replacement of the packing can be

achieved without removing the bearing for ease of maintenance

  • Linkage (fixed/adjustable)
  • Actuation (pneumatic, electric,

hydraulic, manual)

Unique design for ease of maintenance

slide-24
SLIDE 24

工业空气净化整合方案

Double Louver Design Features

  • Two (2) independent banks
  • f blades
  • 200% Safety Factor or Seal

Air Volume at +8 mbar above duct pressure for Zero Leakage

Robust zero leakage design

slide-25
SLIDE 25

工业空气净化整合方案

Tandem Louver Design Features

  • One (1) bank of blades
  • Used where flange‐to‐flange

dimension is limited

  • 200% Safety Factor or Seal Air

Volume at +8 mbar above duct pressure for Zero Leakage

Zero leakage in simple and economical design

slide-26
SLIDE 26

工业空气净化整合方案

Slide Gate Dampers

slide-27
SLIDE 27

工业空气净化整合方案

Slide Gate Design Features

  • Single thickness, solid plate blade

(12mm minimum) designed for minimal deflection under all

  • perating conditions
  • Ensures close contact with seals and

minimizes potential leak path

  • Internal bolted on seals for ease of

maintenance supplied in standard 3 meter seal sections

  • 300% Safety Factor in Drive Sizing
  • 200% Safety Factor on Seal Air

Volume at +8 mbar above Duct Pressure

High technology isolation design

slide-28
SLIDE 28

工业空气净化整合方案

Slide Gate Design Features

  • Chain & Sprocket, Rack & Pinion, &

Pneumatic drive assemblies are available

  • No pins and side plates to corrode or

shear as seen with traditional chain & sprocket drives

  • Open bonnet on chain drive
  • Closed bonnet on rack & pinion drive
  • Standard Electric & Pneumatic

Actuators

Flexible design for wide variety of applications

slide-29
SLIDE 29

工业空气净化整合方案

Slide Gate Design Features

Robust design for harsh environments

slide-30
SLIDE 30

工业空气净化整合方案

Slide Gate Robust Design Operation

Proven design capable of operating in these harsh environments

slide-31
SLIDE 31

工业空气净化整合方案

Summary

  • High technology equipment
  • Robust design for harsh environments
  • Diverse manufacturing capabilities
  • Technological know how
  • Unparalleled industry experience
slide-32
SLIDE 32

工业空气净化整合方案

Questions
