CDM REFRESHER Philip Baker WHERE ARE WE NOW Confusion still abounds Chasing SKE and OC Many have stopped worrying about the regulations and focussed on worker well-being Business as usual Still some resistance!! FATALITIES 160 140 120
SLIDE 2
SLIDE 3
FATALITIES
Range: 154 max, 30 min
Construction Industry
Courtesy of HSE (c) Philip Baker
20 40 60 80 100 120 140 160 FATALITIES PERIOD
SLIDE 4
WORKING DAYS LOST
Ill Health 1.7m Accidents 0.6m UK Construction Industry 2011 – 2012 2.3 million days lost More people are off with MSD than with any other issue
SLIDE 5
Cause Numbers Asbestos 2,773 Solar radiation 841 Silica 701 PAH, coal tars and pitches 471 Painters and decorators 344 Diesel engine exhaust 290
CANCER REGISTRATIONS
UK Construction Industry 2004
RR931
SLIDE 6
Other construction worker ill health issues
COPD Dermatitis HAVS Musculoskeletal disorders
Cost? Want to contribute to the Research?
ILL HEALTH
SLIDE 7
6,100 new Industrial Injuries Disablement Benefit cases in 2014
2/3 (4,080) lung related disease
of which 2,215 were mesothelioma but proportion fell because osteoarthritis of
knee (miners and carpet/floor fitters) was added to IIDB list 130 deafness 70 asthma 30 dermatitis.
IIDB
SLIDE 8
After Reason, Human Error, 1990
SLIDE 9
After Reason, Human Error, 1990
SLIDE 10
SLIDE 11
SLIDE 12
WORKERS
Engage in consultation Care for own H&S & that of ‘others’ Cooperate with
- thers.
Report any concerns
SLIDE 13
CONTRACTORS
Secure site P, M & M their work Prepare and update CPP Provide welfare Provide induction Cooperate & coordinate.
SLIDE 14
PRINCIPAL CONTRACTORS
Secure site P, M & M & Coord H&S in Construction Phase Prepare and update CPP Provide welfare Consult workforce Provide induction Finish & issue HSF. Contractor cooperation & coordination
SLIDE 15
2 Fixings 9 Fixings
SLIDE 16
DESIGNERS
Provide information Eliminate or reduce & control risks Take account of GPP and PCI Relevant info in HSF. Address 5 classes of people Risks in future construction activity
SLIDE 17
THE DESIGN PROCESS?
SLIDE 18
Courtesy of Ingeniería de Riesgos de los Procesos Quimicos
SLIDE 19
L153 PARAGRAPH 83
Health and safety risks need to be considered alongside other factors that influence the design, such as cost, fitness for purpose, aesthetics and environmental impact.
SLIDE 20
MIXING DESK OF DRM
DRM = design risk management
SLIDE 21
QUEEN MOTHER’S GATE
Courtesy of Alamy A5Y41W and GYCMRW
SLIDE 22
MIXING DESK OF DRM
DRM = design risk management
SLIDE 23
SLIDE 24
LSE SAW SWEE HOCK
Bricks
46 varieties of standard-shapes 127 specially designed ones. 175,000 brick in total
Not one of them was cut Every brick was shaped and baked individually - some are straight, others kink to fit the
- ddly shaped corners.
SLIDE 25
Not necessarily those that involve the greatest risks, but those (including health risks) that are:
Not likely to be obvious (to a competent
contractor or designer)
Unusual Likely to be difficult to manage effectively.
SIGNIFICANT RISKS
SLIDE 26
UNUSUAL CONCEPTS
SLIDE 27
HYATT SKYWALK
SLIDE 28
HYATT SKYWALK
2W W W 2W 2W W W
As designed As built
SLIDE 29
SLIDE 30
PRINCIPAL DESIGNERS
P, M & M & Coord H&S in Pre Constn Phase
SLIDE 31
PROJECT PRE CONSTRUCTION PHASE Design or preparatory work CONSTRUCTION PHASE Construction work
Project Inception Project Completion
PHASES
SLIDE 32
PRINCIPAL DESIGNERS
Manage pre construction information P, M & M & Coord H&S in Pre Constn Phase Identify, eliminate or control risk Prepare and issue HSF. Ensure PC has information needed Ensure designer CDM performance
SLIDE 33
PRINCIPAL DESIGNER
“principal designer” means the designer appointed under regulation 5(1)(a) to perform the duties in regulations 11 and 12; 5(1)(a) “… a designer with control over the pre-construction phase …”
CONIAC 19/11/14 “such as an Architect or
- ther competent designer”.
SLIDE 34
DESIGNER
“designer” means any person (including a client, contractor or other person referred to in these Regulations) who in the course or furtherance of a business—
(a) prepares or modifies a design; or (b) arranges for, or instructs, any person
under their control to do so,.
SLIDE 35
Principal Designer must be a Designer, appointed in writing by the Client as PD with control over the H&S elements of the Pre Construction Phase One of the Design Team, perhaps the Lead Designer may be best placed to undertake the role but the PD does not have to be a Designer on the project. NB SKE & OC for the role.
WHO CAN BE THE PD?
APS definition
SLIDE 36
PRINCIPAL DESIGNER OPTIONS
1
Lead Designer Building Surveyor Architect Civil/ Structural Engineer M&E Engineer Quantity Surveyor ‘Principal Contractor’ TW Engineer? M&E Contractor?
SLIDE 37
PRINCIPAL DESIGNER OPTIONS
Lead Designer CDM Consultant Client Project Manager
SLIDE 38
PD MATURITY MODEL
Level 2 Compliance Level 1 Unaware Level 3 Proactive Level 4 Natural
Pre-October 2015 Next 2 years 1-5 years 5+ years Delegate of H&S responsibility. Pre-CDM 2015 inc transition Use of non- Active designers (ex-CDMC’s) for PD role Active designers wanting to take
- n the PD role,
some support Lead designer automatically takes on PD role, with no support
SLIDE 39
For me the Principal Designer role is about asking questions What are some of the questions that could be asked to improve DfS
- utcomes?
QUESTIONS
SLIDE 40
Is it necessary for a worker to work at height? What stops the worker injuring themselves if they fall? What are the health implications of the activity that arises from that design? What maintenance processes does the client already have in place?.
QUESTIONS
SLIDE 41
Is the site big enough to build out this design? Can the fire risk during the build process be managed? Is there adequate information about current risks? Why are we building this structure? Why does it have this form? Why are we using these materials?.
QUESTIONS
SLIDE 42
The designer will say:
I don’t know, you tell me; What should we do then.
RISKS
SLIDE 43
Overturning decisions that have been carefully thought out by the design team Residual risk information and decision making process needs to be consulted Risk is that perceived cost of health and safety is ‘known’ but value is not.
VALUE ENGINEERING
SLIDE 44
CLIENTS
Provide information Management arrangements & welfare Appointees have K, S & E and OC Notification. Appointment & performance of PD & PC
SLIDE 45
SLIDE 46
SLIDE 47
SUMMARY
Co-ordinate contractors Provide information. Eliminate and reduce risks Work safely Safe & healthy working environment Design risk management
