CBCN4103

 Provides all the features and benefits of

traditional LAN technologies such as Ethernet without the limitations of wires or cables

 A WLAN, just like a LAN, requires a physical

medium through which transmission signals

• pass. Instead of using twisted-pair or fiber-
• ptic cable, WLANs use infrared light (IR) or

radio frequencies (RFs).

 High availability;  Scalability;  Manageability; and  Open architecture.

 Modern WLANs offer many benefits to

networking:

• Mobility
• Scalability
• Flexibility
• Short and long term cost savings
• Installation advantages
• Reliability in harsh environments
• Reduced installation time

 IT professionals or business executives who want

mobility within the enterprise, perhaps in addition to a traditional wired network.

 Business owners or IT directors who need

flexibility for frequent LAN wiring changes, either throughout the site or in selected areas.

 Any company whose site is not conductive to LAN

wiring because of building or budget limitations, such as older buildings, leased space, or temporary sites.

 Any company that needs the flexibility and cost

savings offered by a line-of-sight, building-to- building bridge, that avoids expensive trenches, leased lines, and right-of-way issues

 IEEE is the prime issuer of standards for

wireless networks.

 The standards have been created within the

framework of the regulations created by the Federal Communications Commission (FCC)

802.11a 802.11b 802.11g 802.11n Frequency band 5GHz 2.4GHz 2.4GHz 2.4, 5GHz

• Max. data rate

54Mpbs 11Mbps 54Mpbs 248Mbps

1.

Management,

2.

Control and

3.

Data

 Only the data frame type is similar to 802.3

frames.

 The payload of wireless and 802.3 frames is

1500 bytes; however, an Ethernet frame may not exceed 1518 bytes whereas a wireless frame could be as large as 2346 bytes. Usually the WLAN frame size will be limited to 1518 bytes as it is most commonly connected to a wired Ethernet network.

 Since radio frequency (RF) is a shared

medium, collisions can occur just as they do

• n wired shared medium. The major

difference is that there is no method by which the source node is able to detect that a collision occurred. For that reason WLANs use Carrier Sense Multiple Access/Collision Avoidance (CSMA/CA). This is somewhat like Ethernet CSMA/CD.

 CSMA/Collision Detection

• In CSMA/Collision Detection (CSMA/CD), the device

monitors the media for the presence of a data signal. If a data signal is absent, indicating that the media is free, the device transmits the data. If signals are then detected that show another device was transmitting at the same time, all devices stop sending and try again

• later. Traditional forms of Ethernet use this method.

 CSMA/Collision Avoidance

• In CSMA/Collision Avoidance (CSMA/CA), the device

examines the media for the presence of a data signal. If the media is free, the device sends a notification across the media of its intent to use it. The device then sends the data. This method is used by 802.11 wireless networking technologies.

 Only Star and Mesh topologies make sense in a

wireless environment

Star Topology Mesh Topology

 Wireless LANs usually have two types of realization:

• Infrastructured
• ad-hoc

Ad-hoc Network

 In the ad-hoc network, computers are brought

together to form a network "on the fly."

 There is no structure to the network, there are no

fixed points and usually every node is able to communicate with every other node

Infrastructure Network

 Uses fixed network access points with which

mobile nodes can communicate.

 Higher-speed wired (or wireless) backbone.  Network traffic divided into two directions:

• uplink (into the backbone) and
• downlink (from the backbone)

 The contact points to the backbone are called

Access Points (AP)

 WLAN authentication occurs at Layer 2. It is the

process of authenticating the device not the user.

 Authentication may be a null process, as in the case

• f a new AP and NIC with default configurations in
• place. The client will send an authentication request

frame to the AP and the frame will be accepted or rejected by the AP. The client is notified of the response via an authentication response frame. The AP may also be configured to hand off the authentication task to an authentication server, which would perform a more thorough credentialing process.

 As

Associ

• ciation

ation, performed after authentication, is the state that permits a client to use the services of the AP to transfer data.

 Unauthenticated and Unassociated

• The node is disconnected from the network and not

associated to an access point.

 Authenticated and Unassociated

• The node has been authenticated on the network

but has not yet associated with the access point.

 Authenticated and Associated

• The node is connected to the network and able to

transmit and receive data through the access point.

 1. First one is an open connectivity standard

in which only the SSID must match. This may be used in a secure or non-secure environment even though the ability of low level networks sniffers to discover the SSID of the WLAN is high. SSID shorts for Service Set Identifier, a 32-character unique identifier attached to the header of packets sent over a WLAN that acts as a password when a mobile device tries to connect to the Wireless Access Point (WAP).

 2. The second process is the shared key. This

process requires the use of Wired Equivalent Privacy (WEP) encryption. WEP is a fairly simple algorithm using 64,128 and 256 bit

• keys. The AP is configured with an encrypted

key and nodes attempting to access the network through the AP must have a matching key.

 Computers send data signals electronically. Radio

transmitters convert these electrical signals to radio waves. Changing electric currents in the antenna of a transmitter generates the radio waves.

 Radio waves attenuate as they move out from the

transmitting antenna. In a WLAN, a radio signal measured at a distance of just 10 meters (30 feet) from the transmitting antenna would be

• nly 1/100th of its original strength. Like light,

radio waves can be absorbed by some materials and reflected by others.

 Wireless signals are electromagnetic

waves which can travel through space.

802.11g Radio Frequency Channels Channel Center Frequency Frequency Spread 1 2412 MHz 2399.5 MHz - 2424.5 MHz 2 2417 MHz 2404.5 MHz - 2429.5 MHz 3 2422 MHz 2409.5 MHz - 2434.5 MHz 4 2427 MHz 2414.5 MHz - 2439.5 MHz 5 2432 MHz 2419.5 MHz - 2444.5 MHz 6 2437 MHz 2424.5 MHz - 2449.5 MHz 7 2442 MHz 2429.5 MHz - 2454.5 MHz 8 2447 MHz 2434.5 MHz - 2459.5 MHz 9 2452 MHz 2439.5 MHz - 2464.5 MHz 10 2457 MHz 2444.5 MHz - 2469.5 MHz 11 2462 MHz 2449.5 MHz - 2474.5 MHz 12 2467 MHz 2454.5 MHz - 2479.5 MHz 13 2472 MHz 2459.5 MHz - 2484.5 MHz

 No license necessary  Many devices use the same RF  Examples: Cordless phones, Bluetooth

devices, other WLANs and microwave ovens.

 Degrade user connectivity in terms of

throughput, connection quality and range

 Causes 802.11 stations to wait indefinite

periods of time before attempting to access medium

 What happens when an interfering signal

starts while an 802.11 station is transmitting?

 Analyze the potential for RF interference  Prevent the interfering sources from

• perating

 Provide adequate WLAN coverage  Set configuration parameters properly  Deploy 5GHz wireless LANs

 When using RF technology many kinds of

interference must be taken into consideration.

 Narrowband does not affect the entire frequency

spectrum of the wireless signal. One solution to a narrowband interference problem could be simply changing the channel that the AP is using.

 All band interference affects the entire spectrum

• range. Bluetooth™ technologies hops across the

entire 2.4 GHz many times per second and can cause significant interference on an 802.11b

• network. It is not uncommon to see signs in

facilities that use wireless networks requesting that all Bluetooth™ devices be shut down before entering.

 In homes and offices, a device that is often

• verlooked as causing interference is the

standard microwave oven. Leakage from a microwave of as little as one watt into the RF spectrum can cause major network disruption. Wireless phones operating in the 2.4GHZ spectrum can also cause network disorder.

 Generally, the RF signal will not be affected by

even the most extreme weather conditions. However, fog or very high moisture conditions can and do affect wireless networks. Lightning can also charge the atmosphere and alter the path of a transmitted signal.

 A number of new security solutions and

protocols, such as Virtual Private Networking (VPN) and Extensible Authentication Protocol (EAP) are emerging. With EAP, the access point does not provide authentication to the client, but passes the duties to a more sophisticated device, possibly a dedicated server, designed for that purpose.

 EAP-MD5 Challenge

• Extensible Authentication Protocol is the earliest

authentication type, which is very similar to CHAP password protection on a wired network.

 LEAP (Cisco)

• Lightweight Extensible Authentication Protocol is the

type primarily used on Cisco WLAN access points. LEAP provides security during credential exchange, encrypts using dynamic WEP keys, and supports mutual authentication.

 User authentication

• Allows only authorised users to connect, send and

receive data over the wireless network.

 Encryption

• Provides encryption services further protecting the data

from intruders.

 Data authentication

• Ensures the integrity of the data, authenticating source

and destination devices.
