Lights, Camera, Action! Broadband Basics September 17, 2013 Larry Fausett, P .E. Vice President Communications Missouri Division fecinc.com Basic Terminology Upload and Download Whats the difference? Upload is sending newly

slide-1
SLIDE 1

fecinc.com

September 17, 2013 Larry Fausett, P .E. Vice President Communications – Missouri Division

Lights, Camera, Action! Broadband Basics

slide-2
SLIDE 2

fecinc.com

Upload and Download

  • What’s the difference?

– Upload is sending newly created information (files, data, pictures, video, gaming commands) and making it available for use on the internet network.

  • Linked In
  • DropBox
  • Face Book

– Download is pulling stored information or purchased media (music, books, pictures, VIDEO) from sources over the internet for your use.

  • Netflix
  • YouTube
  • iTunes

Basic Terminology

slide-3
SLIDE 3

fecinc.com

Bits and Bytes

  • A terminology for digital information transfer rates (bits)

and storage (Bytes)

– bit = 0 or 1 – Nibble = 4 bits – Byte = 8 bits – KiloByte (KB) = 1024 Bytes – MegaByte (MB) = 1024 KB – GigaByte (GB) = 1024 MB – TeraByte (TB) = 1024 GB – PetaByte (PB) = 1024 TB – ExaByte (EB) = 1024 PB http://lifehacker.com/the-difference-between-bits-and-bytes- and-why-it-matte-510705022

Basic Terminology

slide-4
SLIDE 4

fecinc.com

Average Sizes of some common residential items:

  • A picture taken with my Android Device = 1.4 MB
  • A photo taken with a typical digital camera = 4.0 MB
  • A song download from iTunes = 5.0 MB
  • A CD worth of data = 560 MB
  • A HD movie on Netflix (varies) but today = 3.8 GB

– Future Sony 4K HD Movie = 50 GB (uncompressed)

Perspective on Size

slide-5
SLIDE 5

fecinc.com

Sizes of a large business file:

  • Digital Lidar file flown by a fixed wing aircraft for a 50

mile segment of new transmission line imaging 800’ in width @ 6 data points per square meter:

= 500 GB file

Perspective on Size

slide-6
SLIDE 6

fecinc.com

  • If my vacation picture (1.4 MB) taken on my Android

device was the size of a golf ball… (Surface Area of a Sphere)

  • Dia. = 1.68”

Perspective on Size

slide-7
SLIDE 7

fecinc.com

  • Then a 50MB GIS database has the surface area

equivalent to a men’s basketball.

  • Diameter = 10”

Perspective on Size

slide-8
SLIDE 8

fecinc.com

  • Then the new 4K HD Sony movie = 50 GB would require

2.6 of the largest beach balls I could find. (D = 10’)

  • Diameter = 26.75’

Perspective on Size

slide-9
SLIDE 9

fecinc.com

  • The Finley 500 GB Lidar file would require a football

field

  • Diameter = 84.6’ (28.2 yards)

Perspective on Size

slide-10
SLIDE 10

fecinc.com

  • A 1 TeraByte file…..Surface Area of a sphere near the

diameter of the halo of the space needle. Dia =138’

  • Diameter = 121.16’

Perspective on Size

slide-11
SLIDE 11

fecinc.com

FCC National Broadband Plan Goals

  • Current

– 4 Mbps down / 1 Mbps up actual data rates to all homes

  • 2015

– 50 Mbps down / 20 Mbps up actual data rates to 100 million homes

  • 2020

– 100 Mbps down / 50 Mbps up actual data rates to 100 million homes

How Much Bandwidth is Enough?

slide-12
SLIDE 12

fecinc.com

12

How Much Bandwidth is Enough?

  • The average broadband package today is

approximately 7.0 Mbps

  • “Fast” broadband is typically advertised as being
  • ver 30 Mbps
  • CATV & FTTP companies are rolling out 50 -100 Mbps

services, promising 150 Mbps and 300 Mbps services

  • FTTP can deliver over 1 Gbps services and is

currently rolled out to over 40 cities

slide-13
SLIDE 13

fecinc.com

Future Bandwidth Requirements

  • Many experts envision 100 Mbs to the customer within the

next 5 years:

  • As HDTV becomes the normal TV medium
  • As 20-50 Mbps High Speed Internet becomes the norm to

support:

  • Multimedia Applications (i.e.. Online Gaming)
  • Streaming Video (i.e. YouTube, Netflix, Apple TV)
  • The Cloud increases the need for higher upload speeds
  • Symmetrical bandwidth becomes more important
  • Gigabit Speeds for future applications
slide-14
SLIDE 14

fecinc.com

  • Quad HD Video-2160p-4K UHDTV
  • It has a resolution of 3840 x 2160.
  • Product introduction started in the 2012
  • 55” Sony 4K Ultra HD TV run $ 5,000 at Best Buy
  • It requires 4 times the bandwidth of a HD signal
  • Large screen sizes work against higher

compression levels

  • 8K UHDTV
  • has a resolution of 7680 × 4320
  • It requires 16 times the bandwidth of a HD

signal

What’s Next for Video?

slide-15
SLIDE 15

fecinc.com

Over The Top Video

– A disruptive force in video content distribution – The customer purchases content directly from the Content Provider not from a CATV, Satellite or IPTV Service Provider – Content is downloaded over system to the customer’s device

Service Provider provides a pipe only

– Family TV Family time has been redefined with everyone watching their show on their own device – Multi-Screen Viewing and supplemental content

  • Watching and Tweeting or posting to Facebook
slide-16
SLIDE 16

fecinc.com

Network Recommendations

Below are the internet speed requirements and recommendations for playing movies and TV shows

  • n the Netflix website.
  • 1.5 Mbps- Recommended broadband connection speed
  • 3.0 Mbps- Recommended for DVD quality
  • 5.0 Mbps- Recommended for HD quality
  • 7.0 Mbps- Recommended for Super HD quality
  • 12.0 Mbps- Recommended for 3D quality
slide-17
SLIDE 17

fecinc.com

Today’s Network Performance

http://ispspeedindex.netflix.com/

slide-18
SLIDE 18

fecinc.com

Wireless Broadband

– Benefits

  • Lower startup costs
  • Serve low density areas
  • Use as an “edge out” platform

– Challenges

  • Bandwidth limitations
  • Spectrum

– Licensed 700 MHz (Future 600MHz) – Non Licensed 900 MHz, 2.4 GHz, 5.8 GHz – “Registered” 3.65 GHz

slide-19
SLIDE 19

fecinc.com

  • Data Over Cable Service Interface

Specification

  • Allows for transport of Ethernet over coax

and fiber cable using CMTS (RF modems)

  • DOCSIS 3.0 support 300 Mbps downstream

speeds

  • DOCSIS 3.1

– 10 Gigabit downstream / 1 Gigabit Upstream – Planned Equipment availability in 2015

DOCSIS

slide-20
SLIDE 20

fecinc.com

  • Digital Subscriber Line common

deployment from traditional broadband providers.

  • Many “flavors” of DSL deployed over time
  • Most Common ADSL2+ or now VDSL
  • Bandwidth (down and up) vary with

distance of copper loop.

DSL over twisted pair

slide-21
SLIDE 21

fecinc.com

DSL over twisted pair

45.26 29.41 17.08 11.62 4.59 32.40 27.40 14.90 10.80 4.00 9.00 14.00 19.00 24.00 29.00 34.00 39.00 44.00 49.00 4200 6500 9300 11000 14787

VDSL Down Stream

AD VDSL TU (DN) AD VDSL TP (DN)

FEET

slide-22
SLIDE 22

fecinc.com

  • Active Optical Network

– Dedicated bandwidth to each subscriber.

  • 1 Gigabit downstream
  • 1 Gigabit upstream

– Dedicated fiber facility to each subscriber.

  • Point to Point System.

– Larger fiber sizing required.

Standard Fiber Systems

slide-23
SLIDE 23

fecinc.com

  • Active Optical Network is defined as an optical network where the Active Ethernet

component is directly sent to a single user.

  • No Splitters in the network.
  • OLT: Optical Line Terminal – Active optical to electrical unit at the C.O.
  • ONT: Optical Network Terminal – Active optical to electrical unit at the premise

Premise 2 Premise 1 ONT OLT Voice, Data, Video

Single Fiber (Each Premise)

Voice Data Network Video

Standard Fiber Systems

Central Office

slide-24
SLIDE 24

fecinc.com

  • Gigabit Passive Optical Network (G-PON)

– Shared bandwidth by subscribers connected to the same equipment port.

  • 2.4 Gigabit downstream
  • 1.2 Gigabit upstream
  • Equipment “dynamically divides” bandwidth to each

subscriber.

– Shared fiber to Fiber Distribution Hut (FDH).

  • Optical splitters “divide” light between subscribers.
  • 1x32 (1 input fiber and 32 output fibers)

Standard Fiber Systems

slide-25
SLIDE 25

fecinc.com

  • PON: Passive Optical Network is defined as an optical network where the active

components are split and shared among users.

  • Splitter: Optical device that divides (downstream) and combines (upstream) a single optical

source to multiple destinations. In FTTP networks, this device is passive in that it does not require power.

  • OLT: Optical Line Terminal – Optical to electrical unit at the CO
  • ONT: Optical Network Terminal – Active optical to electrical unit at the premise

Premise 32 Premise 1

Fiber Distribution Hut

ONT OLT Central Office

Single Fiber

Voice Data Network Video Combiner

Standard Fiber Systems

Voice, Data, Video

slide-26
SLIDE 26

fecinc.com

Fiber Pictures

  • Aerial
slide-27
SLIDE 27

fecinc.com

Fiber Pictures

slide-28
SLIDE 28

fecinc.com

  • Understand your market area
  • Develop your business model based on your

data and research

  • Engage your local Community

– Economic Development – Focus Groups

  • Google is using brand power and strength
  • FCC initiative “one in every state”
  • Funding Sources

Are You Ready??

slide-29
SLIDE 29

fecinc.com

Larry Fausett l.fausett @fecinc.com 417-682-5531

Finley Contact Info.
