BMP Design Aids w w w. t r a n s p o r t a t i o n . o h i o . g o v 1 Equations / Programs Rational Method Mannings Equation Outlet Discharge Equations ODOT CDSS SCS Curve Number Hydrograph and Pond Routing Programs USGS StreamStats

slide-1
SLIDE 1

w w w. t r a n s p o r t a t i o n . o h i o . g o v

1

BMP Design Aids

slide-2
SLIDE 2

w w w. t r a n s p o r t a t i o n . o h i o . g o v

2

Rational Method Manning’s Equation Outlet Discharge Equations ODOT CDSS SCS Curve Number Hydrograph and Pond Routing Programs USGS StreamStats

Equations / Programs

slide-3
SLIDE 3

w w w. t r a n s p o r t a t i o n . o h i o . g o v

3

Training Intent

Introduction and overview of various design aids (equations and programs) Not a detailed training on how to use each one

slide-4
SLIDE 4

w w w. t r a n s p o r t a t i o n . o h i o . g o v

4

Rational Method Manning’s Equation Outlet Discharge Equations ODOT CDSS SCS Curve Number Hydrograph and Pond Routing Programs USGS StreamStats

Equations / Programs

slide-5
SLIDE 5

w w w. t r a n s p o r t a t i o n . o h i o . g o v

5

Rational Method

For peak flow rate only Q = CiA Q: flow rate (cfs) C: coefficient of runoff i: rainfall intensity (in/hr)

Based on time of concentration Sheet flow, shallow concentrated flow, and open channel or pipe flow

A: tributary area (ac)

slide-6
SLIDE 6

w w w. t r a n s p o r t a t i o n . o h i o . g o v

6

Rational Method

Q = CiA C:

slide-7
SLIDE 7

w w w. t r a n s p o r t a t i o n . o h i o . g o v

7

Rational Method

slide-8
SLIDE 8

w w w. t r a n s p o r t a t i o n . o h i o . g o v

8

Rational Method Manning’s Equation Outlet Discharge Equations ODOT CDSS SCS Curve Number Hydrograph and Pond Routing Programs USGS StreamStats

Equations / Programs

slide-9
SLIDE 9

w w w. t r a n s p o r t a t i o n . o h i o . g o v

9

Manning’s Equation

(0.15 for Vegetated Biofilter)

slide-10
SLIDE 10

w w w. t r a n s p o r t a t i o n . o h i o . g o v

10

Manning’s Equation

slide-11
SLIDE 11

w w w. t r a n s p o r t a t i o n . o h i o . g o v

11

Manning’s Equation

Program or Spreadsheet Calculation

Use bisection method (trial and error)

Inputs:

Channel geometry and slope Manning’s roughness coefficient Flow rate

Results:

Normal depth Velocity

slide-12
SLIDE 12

w w w. t r a n s p o r t a t i o n . o h i o . g o v

12

Rational Method Manning’s Equation Outlet Discharge Equations ODOT CDSS SCS Curve Number Hydrograph and Pond Routing Programs USGS StreamStats

Equations / Programs

slide-13
SLIDE 13

w w w. t r a n s p o r t a t i o n . o h i o . g o v

13

Discharge Equations

Orifice flow Weir flow

slide-14
SLIDE 14

w w w. t r a n s p o r t a t i o n . o h i o . g o v

14

Orifices

Orifices

slide-15
SLIDE 15

w w w. t r a n s p o r t a t i o n . o h i o . g o v

15

Weir Orifice

slide-16
SLIDE 16

w w w. t r a n s p o r t a t i o n . o h i o . g o v

16

Orifice Flow

slide-17
SLIDE 17

w w w. t r a n s p o r t a t i o n . o h i o . g o v

17

Weir Flow

L&D Vol. 2, 1102.3.4

slide-18
SLIDE 18

w w w. t r a n s p o r t a t i o n . o h i o . g o v

18

Rational Method Manning’s Equation Outlet Discharge Equations ODOT CDSS SCS Curve Number Hydrograph and Pond Routing Programs USGS StreamStats

Equations / Programs

slide-19
SLIDE 19

w w w. t r a n s p o r t a t i o n . o h i o . g o v

19

ODOT CDSS

CDSS is a hydraulic design software developed by ODOT C – Culvert Design D – Ditch Design SS – Storm Sewer Design

slide-20
SLIDE 20

w w w. t r a n s p o r t a t i o n . o h i o . g o v

20

Rational Method Manning’s Equation Outlet Discharge Equations ODOT CDSS SCS Curve Number Hydrograph and Pond Routing Programs USGS StreamStats

Equations / Programs

slide-21
SLIDE 21

w w w. t r a n s p o r t a t i o n . o h i o . g o v

21

SCS Curve Number

Technical Release 55 (TR-55) Technical Release 20 (TR-20) Urban Hydrology for Small Watersheds Determines runoff depth (inches) Combines with unit hydrograph theory Produces runoff hydrographs

Peak flow and total volume

slide-22
SLIDE 22

w w w. t r a n s p o r t a t i o n . o h i o . g o v

22

SCS Curve Number

CN: depth of runoff abstracted Total P – Abstracted P = Runoff Depth Runoff Depth * Area = Runoff Volume NRCS unit hydrograph gives runoff volume a shape (distribution over time) Produces a full runoff hydrograph

Time Runoff Flow Rate

slide-23
SLIDE 23

w w w. t r a n s p o r t a t i o n . o h i o . g o v

23

SCS Curve Number

slide-24
SLIDE 24

w w w. t r a n s p o r t a t i o n . o h i o . g o v

24

SCS Curve Number

slide-25
SLIDE 25

w w w. t r a n s p o r t a t i o n . o h i o . g o v

25

SCS Curve Number

Analyses that require a full hydrograph

Pre vs. post volumes (CSO areas) Routing a design storm through a detention basin, bioretention cell, or infiltration trench

Still gives peak flow rate, but will likely be slightly different from Rational Method

slide-26
SLIDE 26

w w w. t r a n s p o r t a t i o n . o h i o . g o v

26

Rational Method Manning’s Equation Outlet Discharge Equations ODOT CDSS SCS Curve Number Hydrograph and Pond Routing Programs USGS StreamStats

Equations / Programs

slide-27
SLIDE 27

w w w. t r a n s p o r t a t i o n . o h i o . g o v

27

Hydrograph and Pond Routing Programs

Many different programs

Different inputs Different calculations Different limitations

Know your tool before you use it

slide-28
SLIDE 28
  • Basic Pipe or Open

Channel Capacity Calcs.

  • Basin Inlet/Outlet
  • Peak Flow and HGL
  • Steady/Unsteady Flow
  • Open Channels
  • Some Sediment

Transport/Quality

  • Often used in FEMA Floodplains
  • Normal Gravity Sewer, Detention Pond Design
  • Hydrology and Hydraulics Combined
  • Rational/TR-55/SCS Hydrology
  • Manning’s/Orifice/Weir Hydraulic Calcs.
  • Some Quality Calculations Available
  • Complex Drainage Systems that have:
  • tail water, reverse flow, pump stations, surface flooding
  • Horton/Green-Ampt Hydrology
  • Hydrodynamic and Kinematic Wave Hydraulic Calcs.
  • Detailed Quality Calculations Available

Common Hydraulics and Hydrology Software Options

Design Calculations

  • Hydraflow Express
  • Bentley CulvertMaster
  • Bentley FlowMaster
  • Urban Drainage HY22
  • HY-8, ODOT CDSS

HEC

  • HEC-1
  • HEC-HMS
  • HEC-2
  • HEC-RAS
  • GEO-RAS

Simple Stormwater Routing Models

  • HydraFlow Hydrographs
  • HydraFlow Storm Sewers
  • Bentley StormCAD
  • Bentley PondPack
  • HydroCAD

Robust Stormwater Routing Models

  • EPA SWMM
  • Bentley CivilStorm
  • AutoDesk SSA
  • PCSWMM
  • XP SWMM
slide-29
SLIDE 29

w w w. t r a n s p o r t a t i o n . o h i o . g o v

29

PondPack and HydroCAD

Inputs for runoff hydrograph

Area Curve number, land use, or runoff coefficient Time of concentration Design storm frequency

Produces runoff hydrograph Then route that hydrograph into your BMP

slide-30
SLIDE 30

w w w. t r a n s p o r t a t i o n . o h i o . g o v

30

PondPack and HydroCAD

Inputs for BMP

Stage vs storage curve (elevation vs. volume)

Inputs for BMP discharge

Stage vs. depth curve Each outlet

WQ orifices Weirs, catch basin grates Overflow weirs Discharge pipe

Downstream constraints (tailwater)

793 794 795 796 797 798 799 800 0 0.10.20.30.40.50.60.70.80.9 1 1.11.21.3 Elevation (ft) Volume (ac-ft)

Elevation vs. Volume

slide-31
SLIDE 31

w w w. t r a n s p o r t a t i o n . o h i o . g o v

31

PondPack and HydroCAD

Two types of analyses

Hydrograph routing Drawdown analysis

Split event into many short pieces and calculate:

Volume entering Volume leaving Volume and depth in basin

slide-32
SLIDE 32

w w w. t r a n s p o r t a t i o n . o h i o . g o v

32

PondPack and HydroCAD

Make sure you have all of the potential discharge conveyances Make sure the BMP storage information in the model matches the design sheets Make sure the modeled discharge conveyance characteristics match the design sheets and site, including tailwater Make sure the results make sense

slide-33
SLIDE 33

w w w. t r a n s p o r t a t i o n . o h i o . g o v

33

Rational Method Manning’s Equation Outlet Discharge Equations ODOT CDSS SCS Curve Number Hydrograph and Pond Routing Programs USGS StreamStats

Equations / Programs

slide-34
SLIDE 34

w w w. t r a n s p o r t a t i o n . o h i o . g o v

34

slide-35
SLIDE 35

w w w. t r a n s p o r t a t i o n . o h i o . g o v

35

slide-36
SLIDE 36

w w w. t r a n s p o r t a t i o n . o h i o . g o v

36

Rational Method

Peak flow rate only

Manning’s Equation

Flow conditions (velocity and depth) at a given flow rate

Outlet Discharge Equations

Flow rate at a given outlet shape and hydraulic head

ODOT CDSS

Hydraulic design of culverts, ditches, and storm sewers

SCS Curve Number

Full runoff hydrograph (flow rate over time and full storm volume)

Hydrograph and Pond Routing Programs

Full hydrograph, detention, peak flow rate, and draw down analyses

USGS StreamStats

Peak design storm flow rates as well as other stream statistics

Equations / Programs

slide-37
SLIDE 37

w w w. t r a n s p o r t a t i o n . o h i o . g o v

37

Questions ?

Jon Prier, P.E. jonathan.prier@dot.ohio.gov 614-644-1876
