SLIDE 1
BLUE PLANET RESEARCH
Pu’u Wa’awa’a / Kona
Big Island of Hawaii
BLUE PLANET RESEARCH Puu Waawaa / Kona Big Island of Hawaii HAWAII - - PowerPoint PPT Presentation
BLUE PLANET RESEARCH Puu Waawaa / Kona Big Island of Hawaii HAWAII - - PowerPoint PPT Presentation
BLUE PLANET RESEARCH Puu Waawaa / Kona Big Island of Hawaii HAWAII HAWAII ISLAND (BIG ISLAND) Area of 4,000 sq. miles Population of 190,000 90% of food imported 100% of fuel is imported Has over 7.5 gigawatt hours
SLIDE 2
SLIDE 3
- Area of 4,000 sq. miles
- Population of 190,000
- 90% of food imported
- 100% of fuel is imported
- Has over 7.5 gigawatt hours
- f renewable energy
potential
HAWAII ISLAND
(BIG ISLAND)
SLIDE 4
HAWAII ISLAND
(BIG ISLAND)
- Area of 4,000 sq. miles
- Population of 190,000
- 90% of food imported
- 100% of fuel is imported
- Has over 7.5 gigawatt hours
- f renewable energy
potential Most Isolated Land Mass on our Blue Planet
SLIDE 5
PU’U WA’AWA’A RANCH
(Big Island)
- Largest Cinder Cone in Hawaii
- Kona side at Pu’u Wa’awa’a
- Elevation of 2,700’ msl
- 2,500’ Deep Well with water
- Founded in 1884 - off-grid
- 128 years later, off-grid again
SLIDE 6
BPR ENERGY LAB
(Pu’u Wa’awa’a Ranch)
SLIDE 7
ENERGY LAB FACILITIES
SLIDE 8
Alkaline Electrolyzer
TRUE NORTH 35 kW HIGH VOLTAGE TRANSFORMER 10 kW LOW VOLTAGE TRANSFORMER 15 kW LOW VOLTAGE TRANSFORMER LOW VOLTAGE CABLE HIGH VOLTAGE CABLE 7,200 vac 240/120 vac
1 2 3 4 5 6 7 8
(1) Energy Lab: Machine Shop, Laundry, Bathroom/Shower, 8 Work Bays, 3 One Bedroom Apts. w/1 1/2 baths & Full Kitchens (2) Residence: 2 bedrooms, 1 Bath, Kitchen (3) Wood Shop: Full Wood Working Shop, Mechanic Shop, 100 sf. Walk-In Cooler for Seed Bank (4) Large A-Frame Guest Unit: Two Large Suites, Full Kitchen (5) Small A-Frame Guest Unit: Two Bedrooms, One Full Bath, Kitchen (6) 3 Guest Suites: Full Baths, Wet Bars (7) Main Residence: 4 Bedroom Suites, Large Kitchen, 2 Guest Baths, Wine Cellar, Main Laundry (8) Future Residence: 5 Bedroom Suites, Full Kitchen, Pool, Laundry, Large Office
85 kW PV H2 Storage Tanks Sony ESS H2 Fueling Station
PU’U WA’AWA’A RANCH
Micro-Grid Design
SLIDE 9
DC STORAGE
(Primary Storage)
50 kW / 108 kWh
runs microgrid 18 hrs/day
2,400 adc buss
for testing dc equip
Sony Olivine LFP
safest L-ion chemistry
SLIDE 10
EASY ON THE EYES
SLIDE 11
H2 GENERATION & STORAGE
(Secondary)
SLIDE 12
ALKALINE ELECTROLYZER
(12 kg / Day - 99.999 purity)
millenium reign energy
SLIDE 13
H2 STATIONARY FUEL CELLS
SLIDE 14
H2 COOKING
(Wok Burner Conversion)
SLIDE 15
I.C.E. H2-CONVERSION
(Ryobi Leaf Blower)
SLIDE 16
HABITAT 3D MODEL
(Wired Magazine)
SLIDE 17
NASA / HI-SEAS / PISCES UH and Cornell
MARS HABITAT
(Mauna Loa)
SLIDE 18
UILA CONSOLE
SLIDE 19
SLIDE 20
SLIDE 21
RESIDENTIAL OFF-GRID
(Honolulu- 20 kW PV, 60 kWh Blue Ion)
SLIDE 22
RESIDENTIAL OFF-GRID
(Kona- 20 kW PV, 60 kWh Blue Ion)
SLIDE 23 N
50' 100' 200'
Waimea Nui Agricultural Park
Equestrian Center & Arena Greenhouses Sports Complex Central Park & Amphitheater Kanu School Wellnes Center & Clinic University Retail Retail Stadium Community Center Planetarium Cultural Museum Golf Golf Energy Systems Cultural Arts Energy Systems Agricultural Facilities Kapuna Housing Sports Medical RehabN S E W
Cultural Cemetery Soccer Auditorium Other Other- Located in Waimea on the Big Island
- Multi-use Community Hub
- Powered 100% by Renewables
- Carbon Harvesting Technologies
- H2 Production Facility
- EVs and FCEVs for on-site duty
WAIMEA NUI
Waimea-165 acre Micro-Grid Concept
SLIDE 24
BIG ISLAND HYDROGEN
(Hydrogen Highway)
SLIDE 25
FUELED BY EVERYTHING
Biomass Geothermal Solar Wind Hydro
SLIDE 26
HOLISTIC APPROACH
- Renewable & Sustainable Energy
- Replace Transportation Fuels with Hydrogen and Electric Mobility
- Make Agriculture Sustainable on a regional level
- Carbon Neutral & Carbon Negative Technologies
- Use Carbon Harvesting Technologies to sequester carbon into durable goods
- Carbon Fiber, Carbon Foam, Carbon Nanotubes, Graphene
SLIDE 27
Civilization didn’t emerge from the STONE AGE because we ran out of STONES
(fossil fuels)
SLIDE 28
