Water ater di disi sinfe fectant ctant Tablets blets

WATER CONTENTS



Soluble minerals, gases ,organic Matter



Suspended matter



Micro -organism

DANGEROUS CONTENTS and DISEASES

 Virus :

viralhepatitis,polionyelitis

 Bacteria:

cholera,typhoid,paratyphoid, Diarrhoea,dysentry,jaunndice

 Helminths:

roundworm,whipworm, Threadworm,hydrial Diseases

 Leptospiral:

weil’s Disease

 Protozoans:

amoebiosis,giardiasis

Need for water disinfectant:

 Loss of working hours  Financial loss  Manpower loss  Sick family  Sick society & Nation

PREVENTION

 To prevent spread of the causative organisms  Preventing disease  Use of germs free drinking water

SAFE WATER

 Germs free water  Boiling of water  Sterilization of germs  Use of chlorine & its

compounds to destroy the germs

Our Product

EF- CHLOR

(Effervescent Chlorine Tablets)

NADCC TABLETS

(Sodium Dichloro Isocynurate Tablets)

FOR DRINKING WATER DISINFECTION

(Sodium Dichloro Isocynurate Tablets) APPROVED FOR DRINKING WATER DISINFECTION

BY-

 WORLD HEALTH ORGANISATION

new emergency kit 98

 UNITED NATIONS DEVELOPMENT PROGRAMME

(UNCCS CODE 356461)

 INTERNATIONAL RED CROSS SOCIETY

”Standard Specifications For Water And Sanitation”

 OXFAM Specify Use Of Tablets

 The European Standard(en) For Chemicals Use For Warter

Intended For Human Consumption NaDCC TABLETS CODE-EN

12931:2000)

 UNICEF Supply Codes For NaDCC TABLETS S 15350,S 158355

 THE GERMAN DRINKING WATER REGULATIONS

specify the use of NaDCC tablets for drinking water treatment.

 THE U.K SECRETARY OF STATE FOR THE

ENVIRONMENT, TRANSPORT AND REGIONS

have approved NaDCC Tablets in accordance with The Water Supply (Water Quality) Regulations 1989 No.1147, under Regulation 25(1)a, for the disinfection of water and water supply systems.

 THE FRENCH HIGH COUNCIL FOR PUBLIC

HEALTH, MINISTRY OF EMPLOYMENT AND SOLIDARITY, approved NaDCC Tablets for the treatment of

drinking water.

 Many DEFENCE FORCES specify NaDCC for water disinfection.

CHLORINE & COMPOUNDS

available for drinking water disinfection

 Sodium hypochlorite  Bleaching powder  Halazone 4-(dichlorosulphamoyl)

Benzoic acid i.e.Pantocid

 Chloramine t(sodium-n-chlorotoluene-4-

sulphonimidate trihydrate)

 Liquid chlorine

NADCC + H2O = HClO + Na+ + H2C4- HClO = H+ + ClO- HClO = HCl + [O] [O] + MICROORGANISM= HCl +OXIDISED MICRO ORGANISM (DEATH OF GERMS)

Hydrolysis of chlorine compound Formation of hypochlorous acid Stabilization of hypochlorous acid at the pH of water Decomposition of HClO to liberate nascent oxygen Oxidation & destruction of germs by nascent oxygen

Action

Action

 Underchloric acid (HOCl, which is electrically neutral) and hypochlorite

ions (OCl-, electrically negative)

 The cell wall of pathogenic microorganisms is negatively charged by

• nature. As such, it can be penetrated by the neutral underchloric acid,

rather than by the negatively charged hypochlorite ion.

• OCl-

HOCl

penetrates slime layers, cell walls and protective layer

MICRO ORGANISM

Less effective since negatively charged

action

The free available chlorine released by Na DCC (and other chlorine donors, including the chlorinated isocyanurates) in solution will OXIDISE MANY ORGANIC AND INORGANIC COMPOUNDS IN WATER. Of particular significance are:

Ammonia Organic nitrogen compounds (amides, amines etc.) Proteins Total organic carbon Multiple C-C bonds, aromatic rings and carbonyl groups Nitrites Iron Manganese Hydrogen Sulphide Cyanides

OTHER USES OF EF-CHLOR

 Water treatment .  Steralizing equipments of medical through formation of instant

hypochlorous acid.

 Steralizing various products in household usage.eg; baby

bottles,vegetables,etc.

 Swimming pool water treatment.  Poultry farms.  Disinfection of water from various sources in flood affected areas

and in case of emergency .

 For bleaching of clothes.

Chlorine Gas (Cl2 ) Sodium Hypochlorite (NaoCl) Ha Halo lozon

• ne

e (C (C2HCL HCL2NO NO4S) S)

Other disinfecting agents in the market

Bleach aching Powder der (CaoC

• Cl)

l)

DRINKING WATER PURIFICATION COMPOUND – COMPARATIVE CHART Sodium Di Chloro iso Cynurate Chlorine Gas (Cl2 ) Bleaching Powder (CaoCl) Sodium Hypochlorite (NaoCl) Halozone (C2HCL2NO4S ) Category Chloramines Chlorinated Compound Chlorinated Compound Chlorinated Compound Chlorinated donor compound Available Chlorine 60% 100% Active 12.5% (HOCL) 30% 20% 50% Stability in water 48 Hours 2Hours, Low Hydrolysis Constant 2Hours, Low Hydrolysis Con stant 2Hours, Low Hydrolysis Constant 12 Hours Hazards Very Safe Very Hazardous Hazardous Heavy Dusting Liquid, High Volume Safe

Sodium Di Chloro iso Cynurate Chlorine Gas (Cl2 ) Bleaching Pow der (CaoCl) Sodium Hypochlorite (NaoCl) Halozone (C2HCL2NO4 S)

Taste of water No Significant change Chlorine Gas Lime Taste Alkaline No significant change Odour No Significant Chlorine Gas Chlorine Chlorine No significant change Shelf Life 3 Years 1 Year 2 Months 20 - 30 days 2 Years Environment Eco-Friendly Toxic 70% Lime Sludge Eco-Friendly Eco-Friendly Formulation (EFF, TAB) Effervescent Tablets Not Possible Not Possible Not Possible Not Possible Handling Easy Heavy Weight Cylinders Unsafe High Manpower Required High Volume Transportation Easy

In comparision to Calcium Hypochlorite

 Calcium hypochlorite has to be dissolved into the water by vigorous

• stirring. It is not readily soluble. Indeed, it contains calcium carbonate

(chalk) and other insoluble impurities, which deposit into the water making the solution cloudy and deposits cause scale formation in pipework and pumping systems, causing blockages.

 The product had the capacity to kill over 100 times more

microorganisms than calcium hypochlorite, under adverse conditions.

In comparision to Calcium Hypochlorite

In comparision to Calcium Hypochlorite

 Halazone has a short shelf-life of 5 months when

stored at 32°C.

 It loses 75% of its activity when exposed to air for

2 days (13).

 Drinking water standards require the absence of

coliform bacteria. This was not achieved using Halazone Tablets. NaDCC tablets achieved zero count.

In comparision to HALAZONE

In comparision to HALAZONE

In comparision to HALAZONE

EF- CHLOR CHARACTERISTICS

 Easy to use ,handle and store as available in the form of packed

tablet

 High solubility in water  Fast hydrolysis  Fast release of HClO  60% available chlorine  High free residual available chlorine  High concentration of HClO at pH of drinking water i.e. 6.8-7.2

Cont’d…

 Soluble hydrolyzed products  No insoluble products, scales & deposits  Volatile and effervescent  Diffuses faster in water  5 years shelf life of strip packed nadcc  Produces palatable water , no filtration  High and fast microcidal activity  Broad spectrum sanitizer

 First company to INTRODUCE THE

PRODUCT in India

 Our company of international Standards

guarantees QUALITY MATERIAL as against the cheap material imported in the name of pool chemical treatment is being promoted for drinking water.

ABOUT US

 ESTABLISHED IN THE YEAR 1977  FDA GMP CERTIFIED WORLD CLASS

MANUFACTURING FACILITY IN 38000 SQ FT CONSTRUCTED AREA

 IN HOUSE QUALITY CERTIFICATION  PRESENCE IN MORE THAN 12 COUNTRIES

Our valuable Customers

 International relief organizations  Public Health and Family Welfare Department  Public Health Engineering  Chief Medical and Health Officer

Exports

 United kingdom  Iraq  Dubai  Jordan  Kyrgyzstan  Kenya  Bangladesh  Egypt

QUALITY STANDARDS

 F.D.A. G.M.P.  ISO 9001:2000  In House QUALITY CERTIFICATION  Batch wise Quality Certification From MSME GOVT

OF INDIA TESTING LABORATORY

 Certification from FDA APPROVED INDEPENDENT

LABORATORY

REFERENCES

• 1. KUECHLER, T.C. Chemistry of the Chlorinated Isocyanurates. Occidental Chemical Corp., USA. October 6, 1997.

(Personal Communication)

• 2. WHITE, G.C. Handbook of Chlorination. 2nd Edition. Van Nostrand Reinhold Co., New York, 1986
• 3. BLOOMFIELD, S.F. and MILES, G.A. The Antibacterial Properties of Sodium Dichloroisocyanurate and Sodium

Hypochlorite Formulations. J.Appl. Bacteriol., 46, 1979, 65-73, (18).

• 4. PINSKY, M., and HU, H-C. Evaluation of Chloroisocyanurate Hydrolysis Constants. Environ. Sci. Technol. 15, No 4,

1981, 423-431, (377).

• 5. International Dispensary Association, The Netherlands. Sodium Dichloroisocyanurate as a Disinfectant.
• 6. Lynch, C. Stability Studies on A) Available Chlorine in Solution, B) NaDCC Content of Chlorine Release Tablets.

March 1990, (unpublished report).

• 7. Kelly, A.M. and Flood, M. Test Report Med 1. Efficacy Trials. Q-Lab Ltd., Wexford, Ireland. May 1998.
• 8. Baylac, P. Sere, O., Wanegue, C and Luigi, R. Comparison of the Disinfecting Power of Chloramine T and Sodium

Dichloroisocyanurate on River Water. Ministry of Defence. Central Study and Evaluation Service of the Land Army Commissariat, Paris, 1995, (A7).

• 9. Chang, S.L. Waterborne Viral Infections and their Prevention. Bull. Wld. Hlth. Org. 1968, 38, 401-414, (49).

10.Sobsey, M.D. Inactivation of Health-Related Microorganisms in Water by Disinfection Processes. Water Sci. Tech.

1989, 21, 179-195, (270).

• 11. Kahn, F.H. & Visscher, B.R. Water Disinfection in the Wilderness. West J. Med., 1975, 122, 450-453 (230).
• 12. Dychdala, G.R. Chlorine and Chlorine Compounds in Disinfection, Sterilization and Preservation. Ed. Block. S.S., 3rd

Edn., Lea & Febiger, 1983, 174
