B-Box HV- Bespoke Storage for Everyone BYD Batteries, May, 2017 - - PowerPoint PPT Presentation

▶

Nov 24, 2023 145 likes •356 views

B-Box HV- Bespoke Storage for Everyone BYD Batteries, May, 2017 GLOBAL STORAGE TREND 2024 We expect 16GWh of behind-the-meter storage, alongside PV, Global cumulative storage deployment: utility-scale versus behind-the- to be

SLIDE 1

B-Box HV- Bespoke Storage for Everyone

BYD Batteries, May, 2017

SLIDE 2

Global cumulative storage deployment: utility-scale versus behind-the-

meter, 2015-24 (GW)

We expect 16GWh of behind-the-meter storage, alongside PV,
to be installed in 2024. Utility-scale renewable energy integration

becomes increasingly important over this period as well.

GLOBAL STORAGE TREND 2024

GWh

1.8 3.5 3.3 5.9 8.5 9.8 12.5 13.8 16.2

4.0 6.0 8.0 10.0 12.0 14.0 16.0 18.0 2016 2017 2018 2019 2020 2021 2022 2023 2024 Other Behind-the-meter: C&I demand charges Behind-the-meter: PV + storaqe Distribution Level Transmission Level Renewable energy integration Peaking capacity Short duration balancing

1.9 2.9 4.6 6.8 9.6 14.3 19.7 27.3 35.3 45.0

10.0

20.0 30.0 40.0 50.0 2015 2016 2017 2018 2019 2020 2021 2022 2023 2024 Utility-scale Behind-the-meter

Source: Bloomberg New Energy Finance
Global cumulative storage deployment: utility-scale versus behind-the-

meter, 2015-24 (%)

84% 84% 84% 73% 66% 57% 47% 42% 37% 34% 16% 16% 16% 27% 34% 43% 53% 58% 63% 66% 2015 2016 2017 2018 2019 2020 2021 2022 2023 2024 Utility-scale Behind-the-meter

SLIDE 3

OFF GRID

Self Consumption
Grid Response

Required Batteries

Small current, Small power,
Flexible
Being Independent
Integration of Various source

( Diesel generator, Wind/PV) Required Batteries

Peak High Charge/ Discharge current
Bigger Battery

VS

ON GRID

SLIDE 4

THREE

PHASE

Standard Load
Small Current
Cost Sensitive ( both Capex and Opex)
Critical Load (A/C, Oven etc)
High Discharge Current

SINGLE PHASE VS

SLIDE 5

Self-consumption driven
Environment friendly
Single System Operation
High peak current
Critical Environment
Multi-Clusters Operation

HOUSEHOLD COMMERCIAL

VS

SLIDE 6

WE NEED A BATTERY FOR EVERY SINGLE UNIQUE APPLICATION

SLIDE 7

SYSTEM DESIGN CONCEPT

Safety Flexibility

Highest Power Output

Easy Installation

SLIDE 8

FLEXIBILITY FOR WIDE VOLTAGE RANGE AND CAPACITY

Flexibilities of extend from H5 to H9 in Whole life time. H5 H9 H6 H7 H8 Maximum 5 BOX-HV in parallel H9 H9 in parallel

SLIDE 9

HIGHEST OUTPUT POWER IN INDUSTRY

BYD B-Box LV BYD B-Box HV Brand A Brand B Battery Capacity (kWh) 10.24 10.08 9.8 13.5 Output Power (kW) 10.24 10.08 5.0 5.0

V.S .

5kW 10kW

SLIDE 10

HOW WE ACHIEVE HIGHEST OUTPUT POWER IN INDUSTRY

LiFePO4 technology
Unique olivine structure
Featuring stable and high

current

Direct battery output
No DC-DC converter
High efficiency
High output power

SLIDE 11

EASY INSTALLATION

DC cable

BCU Battery module Base

SLIDE 12

PARTNERS

SLIDE 13

LV GLOBAL INSTALLATIONS

SLIDE 14

SLIDE 15

About BYD

SLIDE 16

Revenue – Million（USD） Employees

Growth

SLIDE 17

BYD POWER & STORAGE BATTERY PRODUCTION CAPACITY

(GW h)

2015

2016

2017

2018

SLIDE 18

EV sales

100,178 76,243 62,14856,498 46,42037,52337,36332,199 32,179

20,000 40,000 60,000 80,000 100,000 120,000

The World Top 9 Best Selling Manufacturers

SLIDE 19

2016 GLOBAL LITHIUM POWER & STORAGE BATTERY DELIVERED CAPACITY

4% 5%

10%

12%

Lishen Samsung SDI LG Chem AESC Panasonic Others 6%

CATL

10%

48%

BYD

Source: 2016 Bloomberg New Energy Finance

SLIDE 20

Where every you are we power you better
