Supported by: water from air anytime, anywere. Atmospheric Water Generators Our Aim: Translating Advanced Technologies for Social Good Team ANKIT NAGAR ARPAN SOREN RAMESH KUMAR PROF. T. PRADEEP Co-Founder and Director Electrical &

SLIDE 1

water from air – anytime, anywere.

Supported by: Our Aim: Translating Advanced Technologies for Social Good

Atmospheric Water Generators

SLIDE 2

Team

PROF. T. PRADEEP

Co-Founder and Director

Prof. at IIT Madras,

24 years R&D/working Experience RAMESH KUMAR Co-Founder and CEO MS (IIT Madras) 6 years R&D/working Experience ANKIT NAGAR Co-Founder and Director PhD Student at IIT Madras, 2 years R&D/working Experience SAGAR PATIL

Refrigeration System Engineer, M.Tech. (Mechanical Engineering) 3 years of working experience

SUDEEP PATEL

Mechanical System Design Engineer B.Tech. (Mechanical Engineering) 3 years of working experience

GUTHI RAJA

Mechanical System Design Engineer B.Tech. (Mechanical Engineering) 1 year of working experience

ARPAN SOREN

Electrical & Electronics System Enginner, B.Tech. (Electrical Engineering) 2 years of working experience

SWATHI CHOUDHARY M.Sc. (Organic Chemistry) 6 years of R&D Experience in Water Technoogies

SLIDE 3

Atmospheric Water Generator Process

Dry Air Water Collection Air Filter Fresh Humid Air Stain-less Steel Water tank 8 – Stage water treatment Mineral water

SLIDE 4

Humid air Water collection Cooling coils Hot air HX Coils

Atmospheric Water Generator Nanotech - Innovation

SLIDE 5

VJ 100 Rated water production capacity in 24 hrs 100 litres Actual size (LxWxH) (cms) 60 x 70 x 130 Net weight (kg) 90 Power rating (kW) 1.4 kW (at 70 %RH and 30 0Celcius) Refrigerant R407c Power supply 230 Vac, 1 phase, 50 Hz Internal storage tank capacity (litres) 60 Noise level (dB) < 65 Air Purification Al mesh supported HDPE fabric Water Purification Customized filtration cartridges and ozonizer Air flow rate (CFM) 400

*Water output and power consumption dependent on ambient conditions

Working Condition: Relative humidity range: 35 - 99 %RH, and temperature range: 20 - 40 0C

Complies with all required World Health Organization (WHO) standards Generates quality drinking water Low

perating

cost Power efficient water generation = 0.3 kWh/litre Enabling affordability through nanotech

VJ-100 Atmospheric Water Generator

SLIDE 6

VJ 400 Rated water production capacity in 24 hrs 400 litres Actual size (LxWxH) (cms) 90 x 100 x 160 Net weight (kg) 360 Power rating (kW) 5 kW (at 70 %RH and 30 0Celcius) Refrigerant R410A Power supply 380 Vac, 3 Phase, 50 Hz Internal storage tank capacity (litres) 100 – 300, as required. Noise level (dB) < 65 Air Purification Al mesh supported HDPE fabric Water Purification Customized filtration cartridges and ozonizer Air flow rate (CFM) 3500

Working Condition: Relative humidity range: 35 - 99 %RH, and temperature range: 20 - 40 0C

*Water output and power consumption dependent on ambient conditions

Complies with all required World Health Organization (WHO) standards Generates quality drinking water Low

perating

cost Power efficient water generation = 0.3 kWh/litre Enabling affordability through nanotech

VJ-400 Atmospheric Water Generator

SLIDE 7

VJ 2000 Rated water production capacity in 24 hrs 2000 litres Actual size (LxWxH) (cms) 2700 x 2350 x 1800 Net weight (kg) 800 – 1000 Power rating (kW) 25 kW (at 70 %RH and 30 0Celcius) Refrigerant R410A Power supply 380 Vac, 3 Phase, 50 Hz Internal storage tank capacity (litres) On demand as required. Noise level (dB) < 75 Air Purification Al mesh supported HDPE fabric Water Purification Customized filtration cartridges and ozonizer Air flow rate (CFM) 5000

Working Condition: Relative humidity range: 35 - 99 %RH, and temperature range: 20 - 40 0C

*Water output and power consumption dependent on ambient conditions

Complies with all required World Health Organization (WHO) standards Generates quality drinking water Low

perating

cost Power efficient water generation = 0.3 kWh/litre Enabling affordability through nanotech

VJ-2000 Atmospheric Water Generator

SLIDE 8

100 LPD AWG at Industrial Center and Consultancy Research, IIT Madras

Deployments

100 LPD AWG at Sify Technologies, Mumbai

SLIDE 9

Deployments

100 LPD AWG at Chennai Primary School, Tambaram

SLIDE 10

100 LPD AWG at IITM 100 LPD AWG at Fib-Sol Life Technologies Pvt. Ltd. 100 LPD AWG at ICCW, IITMRP 100 LPD AWG at Vidhya Mandir School, Chennai 100 LPD AWG at Chennai primary school, Tambaram

Deployments

SLIDE 11

400 LPD AWG at Taramani Guest House (Hotel)

Deployments

SLIDE 12

Conference Visibility

SLIDE 13

Exhibition

SLIDE 14

Government Support

SLIDE 15

Government Support

SLIDE 16

Our Factory in Perungudi, Chennai

105,000 Litres of drinking water provided to more than 600 users

SLIDE 17

VayuJal Technologies Private Limited • CIN: U74999TN2017PTC118695 C/O IIT Madras Research Park,, 01FA, First Floor, Kanagam Road, Taramani, Chennai, Tamil Nadu, India, 600113 Phone: 91-8939017761, 91-9840871968 Email: ramesh@vayujal.in, ankitnr@vayujal.in, • http://www.vayujal.com
