slide-1
SLIDE 1

Asphalt Paving Materials

slide-2
SLIDE 2

Bituminous Materials

Bitumen—also known as asphalt or tar—is a black, oily, viscous form of petroleum, which is a naturally occurring organic byproduct of decomposed plants. Natural bitumen is the thickest form of petroleum there is, and is made up of 83% carbon, 10% hydrogen and lesser amounts of oxygen, nitrogen, sulfur, and other elements.

CIVL 3137 2

slide-3
SLIDE 3

CIVL 3137 3

Bituminous Materials

Bituminous Materials Natural Asphalts Petroleum Asphalts Tar & Pitch

(late 1800s) (early 1900s) (late 1800s)

slide-4
SLIDE 4

CIVL 3137 4

Natural Asphalt

Rock Asphalt Native Asphalt Asphalt Sand

slide-5
SLIDE 5

Rock Asphalt

Asphalt rock is formed when natural layers of petroleum harden in the pores of sedimentary rocks such as limestone or sandstone. Over time, the lighter components evaporate away leaving material that ranges in consistency from a thick liquid to a crumbly sand or stone. Only about 5% to 15% of the composition of asphalt rocks is asphalt.

CIVL 3137 5

slide-6
SLIDE 6

CIVL 3137 6

Rock Asphalt

slide-7
SLIDE 7

Rock Asphalt

CIVL 3137 7

ROCK ASPHALT & OIL SHALE IN KENTUCKY

slide-8
SLIDE 8

Asphalt Sands

Asphalt sands (also called oil or tar sands) are either loose sands or partially consolidated sandstone containing a mixture of sand, clay, water, and bitumen. It is increasingly used as a source for crude oil thanks to technological developments such as steam extraction.

CIVL 3137 8

slide-9
SLIDE 9

CIVL 3137 9

Asphalt Sands

slide-10
SLIDE 10

CIVL 3137 10

Asphalt Sands

slide-11
SLIDE 11

CIVL 3137 11

Asphalt Sands

slide-12
SLIDE 12

Native Asphalt

Native asphalts are seepages of natural asphalt that rise to the surface from deeper oil-bearing rocks and collect in depressions on the ground

  • surface. The lighter components evaporate to

leave behind a viscous or semi-solid deposit. The asphalt is so viscous you can walk on the

  • surface. But if you stand on the surface for too

long, you will slowly sink into it!

CIVL 3137 12

slide-13
SLIDE 13

Native Asphalt

CIVL 3137 13 Source: Geological Society of Trinidad and Tobago (www.gstt.org)

slide-14
SLIDE 14

CIVL 3137 14

Native Asphalt

slide-15
SLIDE 15

La Brea “Tar” Pits

CIVL 3137 15

Wilshire Blvd

slide-16
SLIDE 16

Pitch Lake, Trinidad

CIVL 3137 16

slide-17
SLIDE 17

Pitch Lake, Trinidad

CIVL 3137 17 http://www.flickr.com/photos/striderv/4314238332/lightbox/

slide-18
SLIDE 18

CIVL 3137 18

Pitch Lake, Trinidad

slide-19
SLIDE 19

CIVL 3137 19

Pitch Lake, Trinidad

slide-20
SLIDE 20

CIVL 3137 20

Pitch Lake, Trinidad

slide-21
SLIDE 21

CIVL 3137 21

Pitch Lake, Trinidad

slide-22
SLIDE 22

CIVL 3137 22

Pitch Lake, Trinidad

slide-23
SLIDE 23

CIVL 3137 23

Bituminous Materials

Bituminous Materials Natural Asphalts Petroleum Asphalts Tar & Pitch

(late 1800s) (early 1900s) (late 1800s)

slide-24
SLIDE 24

Tar / Pitch

Tar is a dark brown or black viscous liquid of hydrocarbons and free carbon, obtained from a variety of organic materials such as coal, wood, or peat. The material is heated without

  • xygen (so the source material doesn’t burn)

until the tar liquefies and seeps out.

CIVL 3137 24

slide-25
SLIDE 25

Wood Tar

Wood tar (primarily made from pine wood) has many uses as a disinfectant, a flavoring agent for candies and alcohol, a spice for meat, and a water repellant. It is also used in cosmetics and anti-dandruff shampoos. Turpentine and charcoal are the byproducts of wood tar distillation.

CIVL 3137 25

slide-26
SLIDE 26

Wood Tar Kiln, Sweden

CIVL 3137 26 https://en.wikipedia.org/wiki/Tar

slide-27
SLIDE 27

Coal Tar

Coal tar is produced by heating coal without

  • xygen to produce coke and oil gas. Coal tar

was used to construct the first surfaced roads. This is where we get the term “tarmac” or “tar macadam”. Today it can still be found in some parking lot sealers though it’s being phased

  • ut due to environmental and health concerns.

CIVL 3137 27

slide-28
SLIDE 28

CIVL 3137 28

Dunlap, TN Coking Ovens

slide-29
SLIDE 29

CIVL 3137 29

Chickamauga Coking Ovens

slide-30
SLIDE 30

CIVL 3137 30

Pennsylvania Coking Ovens

slide-31
SLIDE 31

CIVL 3137 31

Bituminous Materials

Bituminous Materials Natural Asphalts Petroleum Asphalts Tar & Pitch

(late 1800s) (early 1900s) (late 1800s)

slide-32
SLIDE 32

Petroleum Asphalt

Petroleum asphalt is produced as a byproduct

  • f crude oil distillation. It is the fraction of the

crude oil with the highest boiling point (greater than 500°C) so it represents the residual left

  • ver after everything else (gasoline, kerosene,

diesel, etc.) has boiled off in the distillation process.

CIVL 3137 32

slide-33
SLIDE 33

CIVL 3137 33

Crude Oil Chemistry

Oils (Hydrocarbons) Resin-coated asphaltenes

slide-34
SLIDE 34

CIVL 3137 34

Crude Oil

Aromatic Hydrocarbons (oils) Saturated Hydrocarbons

Light Crude Heavy Crude

“oils” “oils” “oils” “oils”

slide-35
SLIDE 35

CIVL 3137 35

Atmospheric Distillation

Tube Heater Topped Crude

38-70 Carbons

Crude Distillation Column Diesel Oil - 270°C

15-38 Carbons

Kerosene - 170°C

10-14 Carbons

Naphtha - 120°C

5-10 Carbons

Gasoline - 70°C

1-4 Carbons

Butane & Propane

1-4 Carbons

 400ºC

slide-36
SLIDE 36

CIVL 3137 36

Vacuum Distillation

Heat Bitumen Residuum (Asphalt Cement) Topped Crude

Vacuum

Heavy Gas Oil Medium Gas OIl Light Gas OIl Vaporizes the topped crude without using excessive heat (“cracking”)

slide-37
SLIDE 37

CIVL 3137 37

Crude Oil

33 20 16 30 58 6 7 26 21 14 10 28 27 Bitumen Residuum Gasoline Kerosene

  • Lt. Gas Oil
  • Hv. Gas Oil

Boscan Venezuela Arabian Heavy Nigeria Light

slide-38
SLIDE 38

Petroleum Asphalt

Petroleum asphalt at room temperature is very

  • stiff. In order to mix it with aggregate to make

asphalt concrete, it has to be liquefied.

CIVL 3137 38

slide-39
SLIDE 39

CIVL 3137 39

Liquefying Asphalt Cement

Asphalt Cement (Bitumen Residuum)

Heat it Suspend it in water Thin it with solvents

Hot-Mix Asphalt Emulsified Asphalt Cutback Asphalt

slide-40
SLIDE 40

Temperature-Viscosity

CIVL 3137 40

Peanut Butter Ketchup Chocolate Syrup Honey Tomato Juice Vegetable Oil

AASHTO T-245 MARSHALL MIXING TEMP. RANGE (170 +/- 20 cSt) AASHTO T-245 MARSHALL COMPACTING TEMP. RANGE (280 +/- 30 cSt)

slide-41
SLIDE 41

CIVL 3137 41

Liquefying Asphalt Cement

Asphalt Cement (Bitumen Residuum)

Heat it Suspend it in water Thin it with solvents

Hot-Mix Asphalt Emulsified Asphalt Cutback Asphalt

slide-42
SLIDE 42

Cutback Asphalt

Cutback asphalt is asphalt cement that has been blended with a solvent in order to reduce its viscosity. After a cutback asphalt is applied the solvent evaporates leaving behind asphalt cement residue on the surface to which it was

  • applied. A cutback asphalt is said to “cure” as

the petroleum solvent evaporates away.

CIVL 3137 42

slide-43
SLIDE 43

Cutback Asphalt

Cutback asphalt is classified according to the rate at which it cures (fast, medium, slow) and the viscosity of the liquid. The curing rate is a function of the boiling point of solvent used. The viscosity is based on how much solvent is used.

CIVL 3137 43

slide-44
SLIDE 44

CIVL 3137 45

Cutback Asphalt

30

30-60

70

70-140

250

250-500

800

800-1600

3000

3000-6000

Solvent Asphalt

Grade

Kinematic Viscosity @ 140°F (in centistokes)

slide-45
SLIDE 45

CIVL 3137 46

Cutback Asphalt

Rapid Curing (RC)

Asphalt cement thinned with gasoline or naphtha Used for tack and seal coats (surface applications)

Medium Curing (MC)

Asphalt cement thinned with kerosene Used for prime coats, cold-laid pavement bases

Slow Curing (SC)

Asphalt cement thinned with diesel oil or gas oils Used for cold-laid pavement bases

slide-46
SLIDE 46

CIVL 3137 47

Liquefying Asphalt Cement

Asphalt Cement (Bitumen Residuum)

Heat it Suspend it in water Thin it with solvents

Hot-Mix Asphalt Emulsified Asphalt Cutback Asphalt

slide-47
SLIDE 47

Emulsified Asphalt

Emulsified asphalt is a suspension of very small asphalt cement droplet in water, which is assisted by an emulsifying agent (e.g., soap) that disrupts the surface tension of the water and imparts an electrical charge to the surface

  • f the asphalt cement droplets so that they do

not coalesce into larger droplets and fall out of suspension.

CIVL 3137 48

slide-48
SLIDE 48

CIVL 3137 49

Emulsified Asphalt

hydrophilic group(s) hydrophobic component

Asphalt droplet

slide-49
SLIDE 49

CIVL 3137 50

Emulsified Asphalt

Repulsion between negative surface charges prevents coalescence

Asphalt droplet Asphalt droplet

slide-50
SLIDE 50

CIVL 3137 52

Emulsified Asphalt

slide-51
SLIDE 51

CIVL 3137 53

Emulsified Asphalt

LIMESTONE SILICA Anionic Emulsifier Cationic Emulsifier

slide-52
SLIDE 52

Emulsified Asphalt

Emulsified asphalts appear as a thick brown liquid when first applied. When the asphalt droplets start to adhere to the aggregate the color changes to black and the emulsion is said to “break” (i.e., separate). As the water evaporates, the emulsion behaves more like pure asphalt cement. Once all the water has evaporated, the emulsion is said to have “set”.

CIVL 3137 54

slide-53
SLIDE 53

Emulsified Asphalt

There are three main emulsion grades: rapid set, medium set and slow set. The terms relate to the amount of time it takes for the emulsion to set and the amount of mixing that can be performed before the emulsion breaks. Slow setting emulsions can stand up to more mixing than fast setting emulsions.

CIVL 3137 55

slide-54
SLIDE 54

CIVL 3137 56

Emulsified Asphalt

Rapid Setting (RS or CRS)

Used for surface coats, penetration macadam

Medium Setting (MS or CMS)

Used for open-graded asphalt-treated base

Slow Setting (SS or CSS)

Used for dense-graded asphalt-treated base
