Arthur Flury AG Railway Technology Earthing and lightning protection Power distribution technology Presentation contents General company data Products of Arthur Flury AG ALL IN HOUSE Philosophy 21.07.2016 Company presentation Arthur

slide-1
SLIDE 1

Arthur Flury AG

Railway Technology Power distribution technology Earthing and lightning protection

slide-2
SLIDE 2

Presentation contents

General company data Products of Arthur Flury AG «ALL IN HOUSE» Philosophy

21.07.2016 Company presentation Arthur Flury AG 2

slide-3
SLIDE 3

Company details

  • Founded: 1920
  • Employees: 110
  • Turnover: CHF 40 million
  • Export share: > 50 %
  • ISO 9001; ISO 14001

and OHSAS 18001

21.07.2016 Company presentation Arthur Flury AG 3

slide-4
SLIDE 4

21.07.2016

Site map

Company presentation Arthur Flury AG 4

slide-5
SLIDE 5

21.07.2016

Own organisations:

  • Arthur Flury S.R.L., Milano, Italy

100 %

  • Arthur Flury U.K. Ltd, Milton Keynes, United Kingdom 100 %

Representations abroad: > 30

Representations and own organisation abroad

Company presentation Arthur Flury AG 5

slide-6
SLIDE 6

21.07.2016

Arthur Flury EXPORT market

Company presentation Arthur Flury AG 6

slide-7
SLIDE 7

Railway technology with the three domains overhead contact line components, safety- and earthing material, section insulators and phase breaks. Earthing and lightning protection with the domains lightning protection components, earthing components, over voltage protection and equipotential bonding. Power distribution technology with the domains srewed couplers, conical couplers, compression sleeves, cutting and compression tools, voltage detectors, short-circuit

  • indicators. A wide range of products for power lines

and cables.

Product line of Arthur Flury AG

21.07.2016 Company presentation Arthur Flury AG 7

slide-8
SLIDE 8

21.07.2016

Railway technology

Company presentation Arthur Flury AG 8

slide-9
SLIDE 9

21.07.2016

Conical coupling Forked collar socket Eyelet collar socket Crimping sleeve

Conical couplings and collar sockets

Company presentation Arthur Flury AG 9

slide-10
SLIDE 10

21.07.2016

Dropper clamps Cable droppers Strap droppers

Catenary suspension

Company presentation Arthur Flury AG 10

slide-11
SLIDE 11

21.07.2016

Feeder clamps Contact wire splices / Special contact wire splices Guide arm clamps Turnbuckles / Divers

Catenary material Clamps / Turnbuckles

Company presentation Arthur Flury AG 11

slide-12
SLIDE 12

21.07.2016

Earthing bar Voltage detector up to 36 kV AC up to 6.6 kV DC Rail clamps / Accessory Earthing accessory

Catenary material / Earthing material

Company presentation Arthur Flury AG 12

slide-13
SLIDE 13

21.07.2016

Messenger wire isolators

Catenary material / Isolators and accessory

Accessory Contact wire isolators

Company presentation Arthur Flury AG 13

slide-14
SLIDE 14

21.07.2016

Contact wire crossing

FDX 50° - 90° FFDX 50° - 90°

Company presentation Arthur Flury AG 14

slide-15
SLIDE 15

21.07.2016

Section insulators 0.7 kV DC – 25 kV AC

v = 60km/h 80km/h 140km/h 160km/h 200km/h 250km/h DC

1 kV 3 kV

AC

15 kV 25 kV

Company presentation Arthur Flury AG 15

slide-16
SLIDE 16

Neutral sections / Phase breaks DC, DC – AC and AC up to 25 kV AC

DC

1.5 kV

AC

15 kV 25 kV

v = 60km/h 80km/h 200km/h 250km/h

21.07.2016 Company presentation Arthur Flury AG 16

slide-17
SLIDE 17

Speed up to 60 km/h

  • Max. operating voltage

1 kV Contact wire 1 contact wire up to 150 mm²

  • Max. breaking load

80 kN Working load

  • max. 24 kN

Weight 3.6 kg

21.07.2016

Type LT1 1 kV DC Section insulator, Tram

  • ptional

suspension

Company presentation Arthur Flury AG 17

slide-18
SLIDE 18

Speed Up to 60 km/h

  • Max. operating voltage

3 kV DC Contact wire 1 contact wire up to 150 mm²

  • Max. breaking load

60 kN Working load

  • max. 24 kN

Weight 4.1 kg

21.07.2016

Type LT3 3 kV DC Section insulator

  • ptional

suspension

Company presentation Arthur Flury AG 18

slide-19
SLIDE 19

21.07.2016

Type FB1 1.5 kV DC Section insulator, Trolley

Speed Up to 60 km/h

  • Max. operating voltage

1.5 kV DC Contact wire 1 contact wire up to 107 mm²

  • Max. breaking load

80 kN Working load

  • max. 15 kN

Weight 5.5 kg

Company presentation Arthur Flury AG 19

slide-20
SLIDE 20

21.07.2016

Type FT1 1.5 kV DC Section insulator, Tram

Speed Up to 80 km/h

  • Max. operating voltage

1.5 kV DC Contact wire 1 contact wire up to 150 mm²

  • Max. breaking load

80 kN Working load

  • max. 15 kN

Weight 11 kg

Company presentation Arthur Flury AG 20

slide-21
SLIDE 21

21.07.2016

Type FTN 1.5 kV DC Neutral section, Tram

Speed Up to 80 km/h

  • Max. operating voltage

1.5 kV DC Contact wire 1 contact wire up to 150 mm²

  • Max. breaking load

80 kN Working load

  • max. 15 kN

Weight 11 kg

Company presentation Arthur Flury AG 21

slide-22
SLIDE 22

21.07.2016

Type FT/B1 1.5 kV DC Neutral section, Trolley & Tram

Speed Up to 70 km/h

  • Max. operating voltage

1.5 kV DC Contact wire 1 contact wire up to 150 mm²

  • Max. breaking load

80 kN Working load

  • max. 15 kN

Weight 11 kg

Company presentation Arthur Flury AG 22

slide-23
SLIDE 23

21.07.2016

Type FG3 3 kV DC Section insulator

Speed Up to 140 km/h

  • Max. operating voltage

3 kV DC Contact wire 1 or 2 contact wires up to 160 mm²

  • Max. Breaking load

120 kN Working load Max 2x12 kN Weight 22,5 kg

Company presentation Arthur Flury AG 23

slide-24
SLIDE 24

21.07.2016

Type FO3 3 kV DC Section insulator

Speed Up to 100 km/h

  • Max. operating voltage

3 kV DC Contact wire 1 contact wire up to 170 mm²

  • Max. breaking load

80 kN Working load

  • Max. 15 kN

Weight 11.5 kg

Installation «JIG»

Company presentation Arthur Flury AG 24

slide-25
SLIDE 25

21.07.2016

Type ZBLT15 and ZBLT25 15 kV and 25 kV AC Section insulator

Speed Up to 60 km/h

  • Max. operating voltage

ZBL15: 15 kV ZBLT25: 25 kV Contact wire 1 contact wire up to 150 mm²

  • Max. breaking load

50 kN Working load

  • Max. 12 kN

Gewicht 12 kg

Installation «JIG»

Company presentation Arthur Flury AG 25

slide-26
SLIDE 26

21.07.2016

TYP ZS3 / ZS15 3 kV DC and 15 kV AC Section insulator

Speed Up to 160 km/h

  • Max. operating voltage

ZS3: 3 kV DC ZS15: 15 kV AC Contact wire 1 or 2 contact wires up to 150 mm²

  • Max. breaking load

70 kN Working load 1 x 15 kN or 2 x 10 kN Weight 11 - 18 kg

Installation «JIG»

Company presentation Arthur Flury AG 26

slide-27
SLIDE 27

21.07.2016

Type LS25 25 kV AC Section insulator

Speed Up to 120 km/h

  • Max. operating voltage

25 kV AC Contact wire 1 contact wire up to 193 mm²

  • Max. breaking load

80 kN Working load

  • Max. 20 kN

Weight 16 kg

Installation «JIG»

Company presentation Arthur Flury AG 27

slide-28
SLIDE 28

21.07.2016

Type HS3 / HS25 3 kV DC and 25 kV AC Section insulator

Speed Up to 200 km/h

  • Max. operating voltage

HS3: 3 kV DC HS25: 25 kV AC Contact wire 1 or 2 contact wires up to 193 mm²

  • Max. breaking load

120 kN Working load 1 x 22.5 kN or 2 x 22.5 kN Weight 17 - 20 kg

Installation «JIG»

Company presentation Arthur Flury AG 28

slide-29
SLIDE 29

Type HID3 / HI15 / HI25

speed up to 250 km/h

  • max. operating voltage

HID3: 3 kV DC HI15: 15 kV AC HI25: 25 kV AC contact wire 1 (2 with HID3) CW 100 to 120 mm²

  • max. breaking load

120 kN working load

  • max. 25 kN

weight 24 kg

21.07.2016 Company presentation Arthur Flury AG 29

slide-30
SLIDE 30

21.07.2016

Type NS25 25 kV AC Phase break

Speed Up to 200 km/h

  • Max. operating voltage

25 kV AC Contact wire 1 or 2 contact wires up to 193 mm²

  • Max. breaking load

120 kN Working load

  • Max. 2 x 22.5 kN

Weight 38 kg

Installation «JIG»

Company presentation Arthur Flury AG 30

slide-31
SLIDE 31

Single rod phasebreak

Speed > 200 km/h

  • Max. operating voltage

25 kV AC Contact wires 1 contact wire SML 60 kN Working load

  • Max. 25 kN

21.07.2016 Company presentation Arthur Flury AG 31

slide-32
SLIDE 32

21.07.2016

  • This equipment avoids any arc creation

at passing locomotives even in power consuming condition.

Type ASNS25 25 kV AC Automatic switched phase break

  • As safety equipment at sites where different

phase of electric OHL have to be connected.

Company presentation Arthur Flury AG 32

slide-33
SLIDE 33

21.07.2016

Lightning protection outside Earthing Overvoltage protection Equipotential rail

Earthing and lightning protection

Company presentation Arthur Flury AG 33

slide-34
SLIDE 34

21.07.2016

RED CAD Flury

CAD-Lightning protection planning with RED CAD Flury

Company presentation Arthur Flury AG 34

slide-35
SLIDE 35

21.07.2016

Universal clamp Derivation clamp for conductor Connection set Quadro conductor clip Conductor holder for interlocking tiles Ridge conductor holder Gutter folding border clip Snow guard terminal

Lightning protection material

Company presentation Arthur Flury AG 35

slide-36
SLIDE 36

21.07.2016

Earthing and Foundation earthing components

Cross connector Parallel clamp Wedge connector Connection set with round crossing clamp Cross and parallel connector Earth wire connector Earthing strip climp Equipotential box

Company presentation Arthur Flury AG 36

slide-37
SLIDE 37

21.07.2016

Overvoltage protection

Overvoltage protection DS 250 VG combined- Type 1/2/3 Overvoltage protection DS 40 - Type 2 Overvoltage protection DS 240 – Type 3 Adaptor PBCH-HF / CS 1 – Type 3 Coarse and middle protection DS 60 VGPV - Type 1 + 2 Telephone applications MJ 8 2 RN – Type 3 RF Search Protection

Company presentation Arthur Flury AG 37

slide-38
SLIDE 38

Power distribution technology

21.07.2016

Electrical connection

Company presentation Arthur Flury AG 38

slide-39
SLIDE 39

Connection material / Cutting and Compression tools

21.07.2016

Cone connector Branch joint bronze Crimping sleeve Mechanical connector

Company presentation Arthur Flury AG 39

slide-40
SLIDE 40

21.07.2016

Security technology

Earthing and short circuiting devices

Company presentation Arthur Flury AG 40

slide-41
SLIDE 41

Philosophy Arthur Flury AG «ALL IN HOUSE»

Customer expectations

Corporate management Strategic management

Customer satisfaction Internal support processes Sales Production Purchasing Tool manufacture Construction Development

Quality management

21.07.2016 Company presentation Arthur Flury AG 41

slide-42
SLIDE 42

Setting objectives and planning Evaluation

Customer expectations Customer satisfaction

Continual improvement of the management system

Management process Process model for ISO 9001

C U S T O M E R C U S T O M E R

Monitoring

Product realization

Production process Procurement process Development process Marketing and distribution process Management of resources Implementation

Quality management

21.07.2016

Constant inspections, measurements and analyses in all areas provide data for steady improvements to meet requirements of our customers optimally.

  • Document and data monitoring (incl. Change processes)
  • Quality certification monitoring
  • Labeling and traceability of products
  • Variance monitoring (defects)
  • Testing instruments

monitoring

  • Statistical methods
  • Internal audits

Company presentation Arthur Flury AG 42

slide-43
SLIDE 43

21.07.2016

Efficient use of row-material and ressources Prevention of unnecessary noise,

  • dour and electro-smog

No discharge of sewage in waters Prevention of emissions in the air Prevention of contamination of ground Ecological handling of waste Ongoing implementation of improvements following the norm ISO 14000

Ecology

We care about ecology. Ecology aspects are analysed and improved every year by our quality supervisor according the following points:

Company presentation Arthur Flury AG 43

slide-44
SLIDE 44
  • Innovative new development
  • Product adjustment on individual

customer request

  • Steady improvements
  • Own test facility
  • Own high voltage- and

high current laboratory

21.07.2016

Development Engineering Tool manufacture Purchasing Production Sales

Company presentation Arthur Flury AG 44

slide-45
SLIDE 45

21.07.2016

  • Monitoring
  • Training
  • Support

Development Engineering Tool manufacture Purchasing Production Sales

Company presentation Arthur Flury AG 45

slide-46
SLIDE 46
  • Construction
  • Change management
  • Project documentation
  • Engineering
  • Tool development
  • Tool construction

21.07.2016

Development Engineering Tool manufacture Purchasing Production Sales

Company presentation Arthur Flury AG 46

slide-47
SLIDE 47
  • Production of new tools and

mounting devices

  • Safeguarding of tool maintenance
  • Prototype construction
  • Testing constructions
  • Apprenticeship as polytechnician

21.07.2016

Development Engineering Tool manufacture Purchasing Production Sales

Company presentation Arthur Flury AG 47

slide-48
SLIDE 48

Purchasing

  • Securing and efficient warehousing of the goods to be procured
  • Periodical audits and benchmarks guarantee the compliance
  • f the philosophy of the company
  • Clever pooling of qualified, proved and ISO certified suppliers

21.07.2016

Development Engineering Tool manufacture Purchasing Production Sales

Company presentation Arthur Flury AG 48

slide-49
SLIDE 49

21.07.2016

  • Presses from 25 up to 300 tonnes
  • Efficient follow-on cutting tools
  • Modern follow-on composite tools
  • Computer controlled runner manufacture

Development Engineering Tool manufacture Purchasing Production Sales

Company presentation Arthur Flury AG 49

slide-50
SLIDE 50
  • CNC universal lathe
  • Robot technology
  • Assembly

21.07.2016

Development Engineering Tool manufacture Purchasing Production Sales

Company presentation Arthur Flury AG 50

slide-51
SLIDE 51
  • Isolator tensile testing machine
  • High bay storage facility
  • Modern assembly of section

insulators and phase breaks

  • Custom length droppers from

precalculation

  • Testing and final assembly of all

products in house

  • Labelling of

relevant components for tracking

21.07.2016

Development Engineering Tool manufacture Purchasing Production Sales

Company presentation Arthur Flury AG 51

slide-52
SLIDE 52

21.07.2016

  • Consulting
  • Support
  • Partnership

Development Engineering Tool manufacture Purchasing Production Sales

Company presentation Arthur Flury AG 52

slide-53
SLIDE 53

21.07.2016

  • Seminars
  • Training
  • Courses

Development Engineering Tool manufacture Purchasing Production Sales

Company presentation Arthur Flury AG 53

slide-54
SLIDE 54

«ALL IN HOUSE»

  • Innovation by steady further development
  • Flexibilty for custom specific solutions
  • Continuous high product quality through
  • ptimized manufacturing process
  • State of the art production methods

to guarantee sustainable products Our lengthy experience, our modern production techniques and our contemporary quality management system combine to ensure high quality products from Arthur Flury.

21.07.2016 Company presentation Arthur Flury AG 54
